LG LS121HSV2 Installation and user guide

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
Tag#:
(Company) (ProjectManager)
HighEfficiencySingleZoneInverter
LS121HSV2
Performance:
Capacity(Btu/h) 11,200
SEER 20.0
EER 12.5
Cooling:
Heating:
Capacity(Btu/h) 13,300
HSPF 11.0
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB Indoor: 70°FDB/60°FWB
Outdoor: 95°FDB/75°FWB Outdoor: 47°FDB/43°FWB
Electrical:
MCA(A) 10.0
MOP(A) 15
Compressor(A) 7.6
FanMotor(A) 0.25
OutdoorUnit:
CoolingRatedAmps(A) 7.3
HeatingRatedAmps(A) 8.1
IndoorUnit:
CoolingPowerInput(kW) 0.90
HeatingPowerInput(kW) 1.0
Piping:
LiquidLine(in,OD) 1/4
AdditionalRefrigerant(oz/ft) 0.22
MaxElevation(ft) 32
PipingLength(noadd'lrefrigerant,ft) 41
ControlsFeatures:
•24-Houron/offmer
•4-Wayautoswing
•Autochangeover
•Autorestart
•Built-inlowambientstandard,
downto14°F(coolingmode)
•Chaoswind
•CondensateSensorConnecon
•Energysaving
•Inverter(variablespeed
compressor)
•Jetcool/Jetheat
•Plasmaairpurifyingsystem
•Self-cleaningindoorcoil
•Sleepmode
•Ultraquietoperaon
Page1of2DFS-SB-AA-022-US012F26
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
PowerSupply(V/Hz/Ø) 208-230/60/1
PowerSupply(V/Hz/Ø) 208-230/60/1
VaporLine(in,OD) 3/8
MaxPipeLength(ft)¹ 65
OperatingRange:
OutdoorUnit:
Cooling(°FDB) 14-118
Heating(°FWB) 5-75
Cooling(°FDB) 64-86
Heating(°FDB) 60-86
IndoorUnit:
UnitData:
RefrigerantType R410A
RefrigerantCharge(lbs) 2.21
Fan:
StandardFeatures:
•LimitedFiveYearCompressorWarranty
•LimitedTwoYearFunconalPartsWarranty
Notes:
1.Pipinglengthsareequivalent.
2.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
3.Allcommunicaoncabletobeminimum18AWG,2-conductor,stranded,shieldedand
mustcomplywithapplicablelocalandnationalcode.
4.SeeEngineeringManualforsensibleandlatentcapacies.
5.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
6.Theindoorunitcomeswithadryheliumcharge.
7.Thisdataisrated0abovesealevel,with24.6ofrefrigerantlineanda0level
differencebetweenoutdoorandindoorunits.
8.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
ODUType Propeller
IDUType CrossFlow
Motor/Drive BrushlessDigitallyControlled/Direct
Dehumidification(pts/hr) 3.0
RefrigerantControl EEV
HeatExchangerCoating GoldFin™
IDUSoundPressure(±3dB(A))² 39/33/24
ODUSoundPressure(±3dB(A))² 45
ODUNetUnitWeight(lbs) 77.2
ODUShippingWeight(lbs) 81.6
IDUNetUnitWeight 22.1
IDUShippingWeight(lbs) 26.5
FanSpeeds(Fan/Cooling/Heating) 6/Auto/Chaos
Quantity(ODU+IDU) 1+1
IDUMaxAirFlowH/M/L(CFM) 350/280/210
ODUMaxAirFlowRate(CFM) 1,165
CommunicationCable(NoxAWG)³ 4x18
IDU-LSN121HSV2ODU-LSU121HSV2
O
p
tionalAccessories
(
soldse
p
aratel
y)
7-DayProgrammableController(Black)-PQRCVSL0
7-DayProgrammableController(White)-PQRCVSL0QW
LowAmbientWindBaffle(Coolingoperationto0°F)-ZLABGP01A
SEER-SeasonalEnergyEfficiencyRatio EER-EnergyEfficiencyRatio
HSPF-HeatingSeasonalPerformanceFactor
MOP-MaximumOvercurrentProtection MCA-MinimumCircuitAmpacity

JobName/Location:
Tag#:
Date:
PONo.:
HighEfficiencySingleZoneInverter
Page2of2DFS-SB-AA-022-US012F26
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
ODU-LSU121HSV2

JobName/Location:
Tag#:
Date:
PONo.:
HighEfficiencySingleZoneInverter
Page3of3DFS‐SB‐AA‐022‐US012F26
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lghvac.com
IDU‐LSN121HSV2
