Life Fitness Multi-Jungle MJACO User manual

Multi-Jungle
MJACO, MJADC, MJAP, MJAP41, MJAXO, MJBLNKSHRD, MJCORE,
MJDPH, MJDPL, MJFCO, MJFXO, MJHAR, MJHL, MJLP, MJLPD, MJRW,
MJRWD, MJTP
Assembly Manual
1007875-0001 REV AA

Table of Contents
Safety
Safety Information..................................................................................................................................................................... 2
Access Control...........................................................................................................................................................................2
Installation.................................................................................................................................................................................. 2
Proper Usage............................................................................................................................................................................. 2
Inspection................................................................................................................................................................................... 2
Operating Warnings................................................................................................................................................................. 2
Selectorized Weight Stack Systems........................................................................................................................................ 3
Warnings and Cautions............................................................................................................................................................ 3
Product Labels........................................................................................................................................................................... 4
Assembly
Install Weight Stacks................................................................................................................................................................. 5
Install Top Mount.......................................................................................................................................................................7
Install Top Mount.....................................................................................................................................................................11
Install Lower Mount.................................................................................................................................................................13
Install Lower Mount.................................................................................................................................................................13
Install Lower Mount.................................................................................................................................................................13
Install Lower Mount.................................................................................................................................................................16
Install Handle Accessory Rack............................................................................................................................................... 19
Install Blank Shroud................................................................................................................................................................ 20
Install Front Shroud.................................................................................................................................................................21
Cable Routing..........................................................................................................................................................................24
Cable Handling Guide
Cable Connections, Seating, and Installation......................................................................................................................34
Cabling Procedure..................................................................................................................................................................35
Tensioning Cable.................................................................................................................................................................... 36
Strength Cable Wear Guide.................................................................................................................................................. 36
Bolt to Floor Guide
Introduction............................................................................................................................................................................. 38
Delivery and Installation Tips.................................................................................................................................................39
Anchor Types...........................................................................................................................................................................39
Pullout Force............................................................................................................................................................................39
Tools Required........................................................................................................................................................................ 40
Anchor Procedure...................................................................................................................................................................41
Foot Dimensions..................................................................................................................................................................... 43
Life Fitness®is a registered trademark.
Gym Wipes®is a registered trademark of the 2XL Corporation. PureGreen 24 is a trademark of Pure Green.
© Copyright 2017, Life Fitness, LLC. All Rights Reserved. Life Fitness, Hammer Strength, Cybex, ICG and SCIFIT are registered trademarks of
Life Fitness, LLC and its affiliated companies and subsidiaries. Disclaimer: Images and specifications are current as of the date of publication
and are subject to change.
10601 W Belmont Ave, Franklin Park, IL 60131 • 847-288-3300 •
www.lifefitness.com • 1007875-0001 AA • 2017
Page 1 of 43

1. Safety
Safety Information
It is the sole responsibility of the purchaser of LIFE FITNESS products to read the owner’s manual and warning
labels and instruct all individuals, whether they are the end user or supervising personnel, on proper usage of the
equipment.
UNDERSTANDING EACH AND EVERY WARNING TO THE FULLEST IS IMPORTANT. IF ANY OF THESE WARNINGS ARE
UNCLEAR, CONTACT LIFE FITNESS CUSTOMER SERVICE IMMEDIATELY AT 1-800-351-3737.
This equipment is categorized as class S per EN ISO 20957-1. As such this equipment is only intended for commercial,
institutional and/or studio facilities. It is not intended for home use. Contact LIFE FITNESS with any questions regarding
this classification.
It is recommended that all users of LIFE FITNESS exercise equipment be informed of the following information prior to
use.
Access Control
LIFE FITNESS recommends that all commercial fitness equipment be used in a supervised area. It is recommended that
the equipment be located in an access controlled area. Control is the responsibility of the facility owner.
Installation
SECURING EQUIPMENT - LIFE FITNESS requires that all equipment be secured to a solid, level surface to stabilize it
and eliminate rocking or tipping over. This must be performed by a licensed contractor. See Bolt to Floor Guidelines
for installation procedure.
Proper Usage
• Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that
LIFE FITNESS equipment is used properly to avoid injury.
• Injuries may result if exercising improperly or excessively. It is recommended that all individuals consult a physician
prior to commencing an exercise program. If at any time during exercise you feel faint, dizzy or experience pain,
STOP EXERCISING and consult your physician.
• Keep body parts (hands, feet, hair, etc.), clothing and jewelry away from moving parts to avoid injury.
• When adjusting any seat, knee hold down pad, range of motion limiter, foothold pad, pulley or any other type of
adjuster, make certain that the adjusting pin is fully engaged in the hole to avoid injury.
Inspection
• DO NOT use or permit use of any equipment that is damaged and/or has worn or broken parts. For all LIFE
FITNESS equipment use only replacement parts supplied by LIFE FITNESS.
• Cables and belts pose an extreme liability if used when frayed. Always replace any cable at first sign of wear
(consult LIFE FITNESS if uncertain).
• Routinely inspect all accessory clips that join attachments to the cables and replace them at the first sign of wear.
• MAINTAIN LABELS AND NAME PLATES - Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact LIFE FITNESS for a replacement.
• EQUIPMENT MAINTENANCE - Preventative maintenance is the key to smooth operating equipment as well as to
keep your liability to a minimum. Equipment needs to be inspected at regular intervals.
• Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do
so. LIFE FITNESS will provide service and maintenance training at our corporate facility upon request or in the field
if proper arrangements are made.
• Before any use, examine all accessories approved for use with the LIFE FITNESS equipment for damage or wear.
• DO NOT ATTEMPT TO USE OR REPAIR ANY ACCESSORY APPROVED FOR USE WITH THE LIFE FITNESS
EQUIPMENT WHICH APPEARS TO BE DAMAGED OR WORN.
Operating Warnings
WARNING: This product can expose you to chemicals including Methyl Isobutyl Ketone, which is known to the
State of California to cause cancer and birth defects or other reproductive harm. For more information go to
http://www.P65Warnings.ca.gov
• It is the purchaser’s sole responsibility to properly instruct its end users and supervising personnel as to the proper
operating procedures of all equipment.
Page 2 of 43

• Keep children away from strength equipment. Parents or others supervising children must provide close
supervision of children if the equipment is used in the presence of children.
• Do not allow users to wear loose fitting clothing or jewelry while using equipment. It is also recommended to have
users secure long hair back and up to avoid contact with moving parts.
• All bystanders must stay clear of all users, moving parts and attached accessories and components while machine is
in operation.
Selectorized Weight Stack Systems
• Use only weight selector pins supplied by LIFE FITNESS on weight stacks. Substitutes are forbidden.
• Fully insert weight selector pins. Partial insertion can cause weights to fall unexpectedly.
• Never pin the weight stack in an elevated position.
• Never remove selector pin if any weights are suspended.
• Never attempt to release jammed weights or parts.
• Never use dumbbells or other means to incrementally increase the weight resistance. Use only those means
provided by LIFE FITNESS.
Warnings and Cautions
Warning labels indicate a potentially hazardous situation that could result in serious injury or death if the precautions
are not observed.
Caution labels indicate a potentially hazardous situation that could result in serious injury or damage to machine if the
precautions are not observed.
Contact Customer Support Services to replace any worn or damaged labels.
Page 3 of 43

Product Labels
General Warning Label Suspension Training Label
Carriage Label
Serial Number Label
Weight At Handle Label
Pinch Hazard Label
Description Location
General Warning Label Tower Frame
Suspension Training Label Tower Frame
Carriage Label Carriage
Serial Number Label Tower Frame and Top or Lower Mount of Stations
Weight At Handle Label Top of Weight Stack
Pinch Hazard Label Pinch Points
Page 4 of 43

2. Assembly
Install Weight Stacks
Tools Required:
• 5 mm Allen wrench
• Retaining ring pliers
• Torque wrench
NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
Description Qty
1 Screw, M10 x 1.5 HXS, 50 mm 2
2 Guide rod retainer 2
3 Retaining ring 2
4 Guide rod 2
2.
Description Qty
1 Guide rod retainer 2
2 Guide rod 2
Page 5 of 43

3.
Description Qty
1 Guide rod 2
2 Weight stack See Weight Stack Table
4.
Description Qty
1 Guide rod retainer 2
2 Guide rod 2
5.
Description Qty
1 Set screw, M10 x 1.5 HXS, 50 mm 2
2 Guide rod retainer 2
3 Retaining ring 2
4 Guide rod 2
Weight Stack Table
Product Weight Stack Weight Plates
Attached Cable Crossover (MJACO) 2 x 190 lb./95 kg. stack 10 lb./4.5 kg. plate (x12)
15 lb./6.8 kg. plate (x16)
Page 6 of 43

Product Weight Stack Weight Plates
Assist Dip Chin (MJADC) 295 lb./147.5 kg. stack 20 lb./9 kg. plate (x19)
Adjustable Cable Column (MJAP) 190 lb./91 kg. stack 10 lb./4.5 kg. plate (x6)
15 lb./6.8 kg. plate (x8)
Adjustable Pulley 4:1 (MJAP41) 390 lb./195 kg. stack 15 lb./6.8 kg. plate (x19)
Embedded Cable Crossover
(MJAXO)
2 x 190 lb./91 kg. stack 10 lb./4.5 kg. plate (x12)
15 lb./6.8 kg. plate (x16)
Dual Pulley High (MJDPH) 290 lb./145 kg. stack 20 lb./9 kg. plate (x14)
Dual Pulley Low (MJDPL) 290 lb./145 kg. stack 20 lb./9 kg. plate (x14)
Attached High Low Crossover
(MJFCO)
2 x 190 lb./95 kg. stack 10 lb./4.5 kg. plate (x12)
15 lb./6.8 kg. plate (x16)
Embedded High Low Crossover
(MJFXO)
2 x 190 lb./91 kg. stack 10 lb./4.5 kg. plate (x12)
15 lb./6.8 kg. plate (x16)
High Low (MJHL) 190 lb./91 kg. stack 10 lb./4.5 kg. plate (x6)
15 lb./6.8 kg. plate (x8)
Lat Pull (MJLP) 260 lb./127 kg. stack 15 lb./6.8 kg. plate (x6)
20 lb./9 kg. plate (x8)
Dual Lat Pull (MJLPD) 260 lb./127 kg. stack 15 lb./6.8 kg. plate (x6)
20 lb./9 kg. plate (x8)
Row (MJRW) 260 lb./127 kg. stack 15 lb./6.8 kg. plate (x6)
20 lb./9 kg. plate (x8)
Dual Row (MJRWD) 260 lb./127 kg. stack 15 lb./6.8 kg. plate (x6)
20 lb./9 kg. plate (x8)
Triceps Pushdown (MJTP) 190 lb./95 kg. stack 10 lb./4.5 kg. plate (x6)
15 lb./6.8 kg. plate (x8)
Install Top Mount
The following procedure shows how to install the top mounts to the MJCORE for the following products: MJDPH and
MJDPL.
Tools Required:
• 5 mm Allen wrench
• 7 mm Allen wrench
• 17 mm open end wrench
• Retaining ring pliers
• Torque wrench
Page 7 of 43

NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
Description Qty
1 Screw, M10 x 1.5, 25 mm 3
2 Washer 3
3 Nut, hex nylock 3
4 Top mount 1
5 Core 1
2.
Description Qty
1 Screw, M10 x 1.5 HXS, 50 mm 2
2 Guide rod retainer 2
3 Retaining ring 2
4 Guide rod 2
3.
Description Qty
1 Guide rod retainer 2
2 Guide rod 2
Page 8 of 43

4.
Description Qty
1 Pulley weldment 1
2 Guide rod 2
5.
Description Qty
1 Guide rod retainer 2
2 Guide rod 2
6.
Description Qty
1 Screw, M10 x 1.5 HXS, 50 mm 2
2 Guide rod retainer 2
3 Retaining ring 2
4 Guide rod 2
Page 9 of 43

7.
Description Qty
1 Screw, M10 x 1.5, 65 mm 2
2 Washer 2
3 Nut, hex nylock 2
4 Pulley weldment 1
5 Top mount 1
8.
Description Qty
1 Bottom cap cover 1
Page 10 of 43

Install Top Mount
The following procedure shows how to install the top mounts to the MJCORE for the following products: MJAP,
MJAP41, MJAXO, MJACO, MJADC, MJFCO, MJFXO, MJHL, MJLP, MJLPD, MJRWD, MJRW, and MJTP.
Tools Required:
• 7 mm Allen wrench
• 17 mm open end wrench
• Torque wrench
NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
Description Qty
1 Screw, M10 x 1.5, 25 mm 3
2 Washer 3
3 Nut, hex nylock 3
4 Top mount 1
5 Core 1
2.
Description Qty
1 Screw, M10 x 1.5, 25 mm 2
2 Washer 2
3 Nut, hex nylock 2
4 Hole plug 2
5 Top mount 1
Page 11 of 43

3.
Description Qty
1 Bottom cap cover 1
Page 12 of 43

Install Lower Mount
The following procedure shows how to install the lower mounts to the MJCORE for the following products: MJDPH,
MJDPL, MJRWD and MJRW.
Tools Required:
• 7 mm Allen wrench (x2)
• Torque wrench
NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
Description Qty
1 Screw, M10 x 1.5, 130 mm 4
2 Washer 4
3 Nut, M10 x 1.5 socket head 4
Install Lower Mount
The following procedure shows how to install the lower mounts to the MJCORE for the following products: MJHL,
MJFCO and MJFXO.
Tools Required:
• 7 mm Allen wrench (x2)
• Torque wrench
NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
Description Qty
1 Nut, M10 x 1.5 socket head 2
2 Spacer 2
3 Washer 2
4 Screw, M10 x 1.5, 130 mm 2
5 Lower mount 1
Install Lower Mount
The following procedure shows how to install the lower mounts to the MJCORE for the following products: MJAP,
MJAP41, MJAXO and MJACO.
Tools Required:
• 7 mm Allen wrench (x2)
Page 13 of 43

• Torque wrench
NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
Description Qty
1 Lower mount 1
2 Screw, M10 x 1.5, 130 mm 2
3 Washer 2
4 Nut, M10 x 1.5 socket head 2
2.
Description Qty
1 Adjustment tube 1
2 Nut, M10 x 1.5 socket head 2
3 Washer 2
4 Screw, M10 x 1.5, 90 mm 1
5 Screw, M10 x 1.5, 45 mm 1
3.
Description Qty
1 Adjustment tube 1
2 Carriage 1
Page 14 of 43

4.
Description Qty
1 Nut, M10 x 1.5 socket head 2
2 Washer 2
3 Screw, M10 x 1.5, 90 mm 1
4 Screw, M10 x 1.5, 45 mm 1
5.
Description Qty
1 Screw, M10 x 1.5, 130 mm 2
2 Screw, M10 x 1.5, 60 mm 1
3 Washer 3
4 Nut, M10 x 1.5 socket head 3
5 Adjustment tube bracket 2
Page 15 of 43

Install Lower Mount
The following procedure shows how to install the lower mounts to the MJCORE for the following products: MJADC.
Tools Required:
• Retaining ring pliers
• 5 mm Allen wrench
• 7 mm Allen wrench (x2)
• Torque wrench
NOTE: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
Description Qty
1 Screw, M10 x 1.5 HXS, 50 mm 2
2 Guide rod retainer 2
3 Retaining ring 2
4 Guide rod 2
2.
Description Qty
1 Guide rod retainer 2
2 Guide rod 2
Page 16 of 43

3.
Description Qty
1 Guide rod 2
2 Weight stack cushion 2
4.
Description Qty
1 Screw, M10 x 1.5, 130 mm 6
2 Washer 6
3 Nut, M10 x 1.5 socket head 6
5.
Description Qty
1 Short guide rod 2
2 Weight stack cushion 2
Page 17 of 43

6.
Description Qty
1 Short guide rod 2
2 Weight stack See Weight Stack Table
7.
Description Qty
1 Guide rod retainer 2
2 Short guide rod 2
8.
Description Qty
1 Set screw, M10 x 1.5 HXS, 50mm 2
2 Guide rod retainer 2
3 Retaining ring 2
4 Short guide rod 2
Page 18 of 43
