Life Span Control User manual

CONTROL
USER’S
MANUAL
This is HIGH-POWER item; please DO NOT USE THE SAME OUTLET WITH OTHER
HIGH-POWER HOUSEHOLD APPLIANCE like air-conditioning etc.
Please choose an outlet exclusively for the machine and make sure the fuse is 10A.
Special tips:
1. Before installation and operation, please read this operation manual carefully.
2. Please save this manual for future reference.
3. Product may vary slightly from the item pictured due to model upgrades
http://www.lifespanfitness.com.au/

Table of Contents
1Brief Description………………………………………………………………………………2
2Main Technical Features…………………………………………………………………………2
3Tips for safety…………………………………………………………………………………3-4
4Installation………………………………………………………………………………………4
5Use and Operation…………………………………………………………………………… 4-6
6Maintenance………………………………………………………………………………… 7-11
7Guides for malfunction…………………………………………………………………11-12
8Warranty……………………………………………………………………………………12
9Error and self-inspection………………………………………………………………12-13
10 Installation Sketch…………………………………………………………… 13-16
- 1 -

1. Brief Description
Treadmill CONTROL (diagram 1) can help complete your goal of keeping fit
together with unique and elegant appearance. Easily read panel parameter.
Easily operated folding system realizes space-saving. Auto speed range
1-20km/h and auto incline range1-20. Evaluating bodyfat and MP3 are available .
All makes it a hot home use fitness equipment.
Heart rate senso
r
Meter accessories Handle
Power switch Pillar accessories
Running belt
Footplate
Running belt adjustor
Safety key
Diagram 1: Treadmill CONTROL
2. Main Technical Features
Main use: Body and beauty building
This treadmill is for home use
Panel displays speed, time, distance, incline, calories, pulse, etc.
Display Mode：LED
Input voltage: 240V±15%
Frequency: 50 Hz or 60 Hz
Input current: ≤8A
Temperature for working: 0∽40℃
Speed range: 1∽20km/h
Auto incline: 0-20%
Time display range: 00:00 - 99:59(minute: second)
Distance display range: 0.000 - 9.999 KM
Machine size (L*W*H):：1854x845x1400（mm）
N/W: 93 KG; GW: 110 KG
- 2 -

3. Tips for Safety
3.1Insert the power plug into the socket directly. Current load should not be
less than 10A.
3.2The constant running time is less than 2 hours, max weight is less than
250kgs.
3.3Place your treadmill on the clean floor，not on the thick carpet, otherwise
it will not convenient for ventilation. Also please don’t put the treadmill in
the moist place or outdoors; If there is something wrong with the electrical
wire, please replace it with the electrical wire provided by our company.
For the replacement, please contact with the local distributor.
3.4The treadmill should be placed in the convenient position for electric
socket.
3.5The freshman should grip the handrails when jogging and running until
familiarly. Please don’t stand on the running belt, after the machine is
power on (the safe key is at the appointed position).Please stand on the
footplates besides the treadmill, press the “start” button, it runs at the
lowest speed, at this time you can run on the belt.
3.6While running, you should dress properly. Don’t dress too loosely in case
your clothes are entangled by the machine .And please wear sport shoes
with soft sole.
3.7Before taking down the protecting cover of the treadmill, please keep the
machine is power off.
3.8Don’t let children and non-sporters get close to the running treadmill to
avoid unnecessary injury.
3.9Please make sure one end of the safe key has been placed in the appointed
position and the other one has been nipped to your clothes when you are
running on the machine. In this way, you can pull the safe key for the
machine’s sudden stop under the dangerous condition. Then you will not
be injured.
3.10 If you are enjoying other entertainment while running such as watching TV,
reading. Please be particularly careful. These activities will distract your
attention, which may make you lose your balance and get hurt.
3.11 Please pull the plug off from socket and keep the safe key, when the
treadmill is unused.
3.12 Please don’t put anything under treadmill and don’t let your children play
near it after folding.
3.13 Please consult your doctor at first before running, if you have one of the
following diseases.
a) Cardiopathy, hypertension, sugar diabetes, respiratory disease,
smoking, and other chronic diseases, complication disease.
b) If you are over 35 years old and heavier than common weight.
c) Women in pregnant or in breasting period.
- 3 -

3.14 Please stop exercising immediately and consult your doctor if you’re feel
giddy, surfeit, thorax ache or other symptoms.
3.15 Please drink adequate water after taking exercises on our treadmill for
more than 20 minutes.
4. Installation: See “Installation sketch”
5. Use and Operation
5.1 Panel Keys and Function
（9）incline-down
（11）safety key
（1）on
（3）MODE
（8）set
（6）speed-down
（7）select
(10)incline-up
（13）speed shortcut key
（14）incline shortcut key
（12）speed window
（15）incline window
（5）speed-up
（4）stop
（16）time ,distance, calorie ,hear rate windows
（2）clear/set
（1）“on”
Under ready condition, press this key, it runs at the lowest speed. All windows
display in a dynamic model.
（2）“clear/set”
Under ready condition, press this key once, all windows will be in the original
conditions.
（3）“profile”
Press this key to enter own programs mode, you have 3 own programs, C1~C3,
P1-P99 are fixed programs.
- 4 -

（4）“off”
Press this key to make machine stop working.
（5）“speed up”
Under running condition, press this key, speed can be speeded up to the one
you need.
（6）“speed down”
Under running condition, press this key, speed can be speeded down to the one
you need.
（7）“select”
Press this key, time, distance and calorie will be displayed.
（8）“set”
Under original mode, press this key, you can set a countdown time, a
countdown distance, a countdown calorie.
（9）“incline up”
Press this key, you can choose the incline you need, except for the alarm
condition.
（10）“incline down”
Press this key, you can choose the incline you need, except for the alarm
condition.
（11）“safety key”
Under urgent condition, pull this key, machine stops immediately.
（12）Speed Window
Press “fast’ or “slow” , the window shows the results.
(13）“speed short cut key”
Under running condition, press this key, speed can be set to the value directly.
（14）“incline short cut key”
Press this key, the incline goes directly to the chosen height.
(15) Incline window
Press “incline-up”, “incline-down” , this window shows the results .
(16) Time, distance, calorie and heart rate window
This window automatically .shows time, distance, calorie and hear rate
5.2 Unload operating
1) Insert power plug into the socket with earth wire, turn the switch to “1”
position which is on the frame.
2) Put the safe key in the right position, then circuit is on, press “on/off”, keep
it run in unload condition. Do not let anyone run on the belt at this time .Test
the condition of running belt (testing from low speed to high ones), after
testing, press “on/off”.
3) If everything is ok, then start to run.
5.3 Meter operating instruction
5.3.1
1) Insert power plug into the socket with earth wire, turn the switch to “1”
- 5 -

position which is on the frame. Place the safe key to the appointed position.
After a few seconds, panel will show that the machine is ready.
2) Nip another end of safe key to your clothes, and stand on the footplate on
both sides.
3) Press “on/off” key, running belt moves at the lowest speed (1.0km/h). Speed
windows will display your running speed.
4) Start to run.
5) Press speed key or incline key to adjust speed and incline, speed window and
incline window will display your speed and incline.
6) To end your exercise in a safe way, please first press “on/off” key to close the
treadmill. Please leave the running belt until it stops slowly. Turn off the
power.
5.3.2 Heart Rate Testing
Our treadmill can test your heart rate via the heart rate sensor. The data is only
for reference.
5.4 Folding and Opening Treadmill
5.4.1 Folding
Firstly lift and fold the back part of the frame board by hand till you hear a light
sound, which means the folding system has been locked. At this time running
board can’t be turned to the opposite direction
5.4.2 Opening
Put the folded treadmill in a capacious position when you want to run. Then pull
the adjusting parts by hand to keep it is unlocked. Press the back part by your
hands down to about 10%, release it, then it will open automatically.
- 6 -

6. Maintenance
Reasonable cleaning/lubricating should be made to extend the life time of this
unit. Performance is maximized when the belt and mat are kept as clean as
possible.
WARNING: THE MAT/DECK FRICTION MAY PLAY A MAJOR ROLE IN THE
FUNCTION AND LIFE OF YOUR TREADMILL AND THAT IS WHY WE
RECOMMEND YOU CONSTANTLY LUBRICATE THIS FRICTION POINT TO
PROLONG THE USEFUL LIFE OF YOUR TREADMILL. FAILING TO DO THIS
MAY VOID YOUR WARRANTY.
WARNING: UNPLUG POWER CORD BEFORE MAINTENANCE.
WARNING: STOP TREADMILL BEFORE FOLDING.
6.1 Maintenance and servicing
AFTER EACH USE (DAILY)
Clean and inspect, following these steps:
• Turn off the treadmill with the on/off switch, then unplug the power cord at the
wall outlet.
• Wipe down the running belt, deck, motor cover, and console casing with a
damp cloth. Never use solvents, as they can cause damage to the treadmill.
• Inspect the power cord. If the power cord is damaged, contact Lifespan Fitness.
• Make sure the power cord is not underneath the treadmill or in any other area
where it can become pinched or cut.
• Check the tension and alignment of the running belt. Make sure that the
treadmill belt will not damage any other components on the treadmill by being
misaligned.
EVERY WEEK
Clean underneath the treadmill, following these steps:
• Turn off the treadmill with the on/off switch, then unplugs the power cord at the
wall outlet.
• Fold the treadmill into the upright position, making sure that the lock latch is
secure.
• Move the treadmill to a remote location.
• Wipe or vacuum any dust particles or other objects that may have accumulated
underneath the treadmill.
• Return the treadmill to its previous position.
- 7 -

EVERY MONTH -IMPORTANT!
• Inspect all assembly bolts of the machine for proper tightness.
• Turn off the treadmill with the on/off switch, then unplug the power cord and
wait 60 seconds.
• Remove the motor cover. Wait until ALL LED lights turn off.
• Clean the motor and lower board area to eliminate any lint or dust particles
that may have accumulated.
Failure to do so may result in premature failure of key electrical components.
EVERY 6 MONTHS
It may be necessary to lubricate your treadmill running deck at least once every
six months to maintain optimal performance of your treadmill (refer to section
4.4 for information). Only use lubricant provided by Lifespan Fitness! Please
contact Lifespan Fitness with questions about applying lubricant to your
treadmill.
• Turn off the treadmill with the on/off switch, then unplug the power cord at the
wall outlet.
• Loosen both the rear roller bolts. (For best results, place two removable marks
on both sides of the frame and note roller position).Once the belt is loosened,
take the bottle of lubricant and apply it to the entire top surface of the running
deck. Tighten both rear roller bolts (matching up the marks for proper position)
to original position. After you have applied lubricant, plug in the power cord, key,
start the treadmill and walk on the belt for two minutes to spread the lubricant.
• Lubricate the air shocks with Teflon based spray.
EVERY 2 YEARS
It is necessary that you change your treadmill motor brushes once every 2 years
to avoid damaging your motor. If you fail to change the brushes this may cause
the motor to burn out, voiding any warranty.
SERVICING: IF YOU FAIL TO COMPLY WITH LIFESPAN’S MAINTENANCE
AND SERVICING STEPS ABOVE, YOU MAY VOID YOUR WARRANTY. IF
YOU REQUIRE A SKILLED LIFESPAN REPRESENTATIVE TO UNDERTAKE
ONE OF THE STEPS ABOVE, PLEASE EMAIL US AT
[email protected].
6.2 General Cleaning
Use a soft, damp cloth to wipe the edge of the belt and the area between
the belt edge and frame. A mild soap and water solution along with a nylon
scrub brush will clean the top of the textured belt. This task should be done
once a month. Allow to dry before using.
- 8 -

On a monthly basis, vacuum underneath your treadmill to prevent dust
build up. Once a year, you should remove the black motor shield and
vacuum out dirt that may accumulate.
6.3 General Care
Check parts for wear before use.
Pay particular attention to the fixing knobs and make sure they are tight.
Always replace the mat if worn and any other defective parts.
If in doubt, do not use the treadmill and contact our helpline.
TAKE CARE TO PROTECT CARPETS AND FLOOR in case of leakages. This product
is a machine that contains moving parts which have been greased / lubricated
and could leak.
6.4 Belt/Deck/Roller Lubrication
The mat/deck friction may play a major role in the function and life of your
treadmill and that is why we recommend you constantly lubricate this friction
point to prolong the useful life of your treadmill.
Lubrication is provided with this unit. You should apply the enclosed lubrication
after approximately the first 50 hours of operation. We recommend lubrication of
the deck according to the following timetable:
Light use (less that 3 hours per week) every 6 months
Medium use (3-5 hours a week) every 3 months
Heavy use (more than 5 hours per week) every 6-8 weeks.
See below procedures for lubricating:
1) Use a soft, dry cloth to wipe the area between the belt and deck.
2) Spread lubricant onto the inside surface of belt and deck evenly (make sure
the machine is turned off and power is disconnected).
3) Periodically lubricate the front and rear rollers to keep them at there peak
performance.
If the treadmill belt/deck/roller is kept reasonably clean, it is possible to expect
over 1200 hours before additional re-lubing is necessary.
6.5 How to check the running mat for proper lubrication
1) Disconnect the main power supply.
2) Fold the treadmill up into the storage position.
- 9 -
