Life Span PRIME User manual

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au
Product may vary slightly from the item pictured due to model upgrades
Read all instructions carefully before using this product. Retain this owner’s manual for
future reference.
PRIME OWNER’S MANUAL

2
PRIME
TABLE OF CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS 3
2. IMPORTANT ELECTRICAL INFORMATION 4
3. IMPORTANT OPERATING INSTRUCTIONS 5
4. ASSEMBLY INSTRUCTIONS 6
5. OPERATION GUIDE 10
6. EXERCISE GUIDE 21
7. MAINTENANCE INSTRUCTIONS 23
8. EXPLODED DIAGRAM 28
9. PARTS LIST 29
10. TROUBLE SHOOTING GUIDE 31
11. WARRANTY 32

3
PRIME
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING - Read all instructions before using this treadmill.
It is important your treadmill receives regular maintenance to prolong its useful life. Failing to
regularly maintain your treadmill may void your warranty.
Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to
cleaning and/or service work.
DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY
USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.
Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.
Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and
treadmill may result.
Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of
the treadmill and any fixed object.
Place your unit on a solid, level surface when in use
When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should
you fall or move too far back on the treadmill.
Keep hands away from all moving parts.
Never operate the treadmill if it has a damaged power cord or plug. When damaged, these must be
replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Keep the cord away from heated surfaces.
Do not operate where aerosol spray products are being used or where oxygen is being administered.
Sparks from the motor may ignite a highly gaseous environment.
Never drop or insert any object into any openings.
The treadmill is intended for in-home use only and not suitable for long term running.

4
PRIME
To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug
from the outlet.
The pulse sensors are not medical devices. Various factors, including the user’s movement, may
affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in
determining heart rate trends in general.
Use the handrails provided; they are for your safety.
Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your
treadmill. Quality athletic shoes are recommended to avoid leg fatigue.
Before undertaking any type of exercise program, it is recommended that you consult a doctor.
Injuries to health may result from incorrect or excessive training.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
WARNING heat rate monitoring systems may be inaccurate. If you feel faint stop exercising
immediately.
Children should not be allowed on or around the equipment, even when not in use.
Children should be supervised to ensure that they do not play with this machine
Loose-fitting clothing or jewellery that could become an entanglement hazard should not be worn.
Training shoes should be worn when using the equipment.
Equipment must be used on a level and stable surface.
All fixings should be checked before the equipment is used.
All literature relating to the use of the equipment should be retained for future reference.
Allowed operating temperature: 5-40°C
Remove the safety key after use to prevent unauthorized treadmill operation.

5
PRIME
2. IMPORTANT ELECTRICAL INFORMATION
WARNING!
Route the power cord away from any moving part of the treadmill including the elevation mechanism
and transport wheels.
NEVER remove any cover without first disconnecting AC power.
NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,
near a pool, or in any other high humidity environment.
This is a high-power item; please do not share the same outlet with other high power machines such
as, fridges, air conditioning etc. Please choose an outlet exclusively for the machine and make sure
the fuse is 10A.
3. IMPORTANT OPERATING INSTRUCTIONS
Understand that changes in speed and incline do not occur immediately. Set your desired speed on
the computer console and release the adjustment key. The computer will obey the command
gradually.
Use caution while participating in other activities while walking on your treadmill, such as watching
television, reading, etc. These distractions may cause you to lose balance or stray from walking in
the centre of the belt; which may result in serious injury.
In order to prevent losing balance and suffering unexpected injury, never mount or dismount the
treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the
belt during slow acceleration is proper after you have learned to operate this machine.
Always hold on to handrail while making control changes.
A safety key is provided with this machine. Remove the safety key will stop the walking belt
immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.
Do not use excessive pressure on console control keys. They are precision set to function properly
with little finger pressure.
Replace any defective components immediately. The machine must be kept out of use until repaired.

6
PRIME
4. ASSEMBLY INSTRUCTIONS
PARTS LIST
NO.
DES.
Specification
Nos.
NO.
DES.
Specification
Nos.
1
Main Frame
1
52
Bolt
M8*15
5
6
Left Upright Tube
1
66
Arc Washer
8
4
7
Right Upright Tube
1
4
Left handle bar
1
45
Bolt
M10*15
18
5
Right handle bar
1
64
Lock washer
10
18
82
5# Allen Wrench
5mm
1
41
Left Upright Tube Cover
1
83
6# Allen Wrench
6mm
1
42
Right Upright Tube Cover
1
17
Left handle bar cover
1
87
Console
1
18
Right handle bar cover
1
58
Bolt
ST4.2*12
2
38
Wrench s/screw Driver
S=13、14、15
1
65
Bolt
M5*12
6
102
Fasten bar
1
103
Bolt
M8*50
1
62
Lock washer
8
1
ASSEMBLY TOOLS:
5# Allen Wrench 5mm 1pc
6# Allen Wrench 6mm 1pc
Wrench s/screw Driver S=13, 14, 15 1pc

7
PRIME
Do not connect power until assembly is complete
STEP 1:
STEP 2:
STEP 3:
1. Open the carton
2. Extract the parts listed above
3. Place the Main Frame onto level
ground
1. Use the 6# Allen Wrench(83), fasten
the Left Upright Tube (6) and right
upright tube(7) onto the Main Frame(1)
with Bolt (45) M10*15 and Lock Washer
(64 ).
1. Attach the left and right upright tubes (6,
7) to the main frame.
Please connect the middle signal wire and the
lower signal wire at the same time.

8
PRIME
STEP 4:
STEP 5:
1. Use the Wrench w/screw Driver(38) to
loosen the screw ST4.2*12(58) and
bolt M5*12(65). [Seen in step 5]
2. These will be used to fasten the left
handle bar (41) and right handle
bar(42). [Seen in step 5]
3. Use the 6# Allen Wrench(83) to attach
the console(87) to the upright tubes
with the Bolt (45) and Lock Washer
(64).
1. Use the Wrench w/screw Driver(38) to
attach the left handle bar(41) and right
handle bar(42) onto the left and right
upright tubes with screw ST4.2*12(58)
and bolt M5*12(65).

9
PRIME
STEP 6:
STEP 7:
1. Using the 5# Allen Wrench(82), attach
the left handle bar(4) and right handle
bar(5) onto the console by using bolt
M8*15(52) and arc washer(66).
Attention: Before attaching the left and right
handle bar onto the console, please connect the
speed pulse signal wire and incline signal wire
with the wires from the console.
1. Use Wrench w/screw Driver(38) to attach
the left upright tube cover(17) and right
upright tube cover(18 ) onto the upright
tubes using bolt M5*12(65).

10
PRIME
STEP 8:
1. Use the 5# Allen Wrench (82) to attach
the left end of the fasten bar (102) to the
left upright tube using bolt M8*50(103)
and lock washer(62)
2. Attach the right end of fasten bar(102) to
the right upright tube by using bolt
M8*15(52) and lock washer(62).

11
PRIME
5. OPERATION GUIDE
WINDOW DISPLAY:
1. “Speed” window: Shows speed. The speed range is 0.5-22 km/h.
2. “Incline” window: Shows incline. The incline range is 0-20 section.
3. “Pulse” window: shows an estimation of your pulse. Hold the pulse sensors for 2 seconds and your
pulse will be displayed on the treadmill. The pulse data range is 50-200 beats/min (this data is for
reference only and cannot be used as medical data.)
4. “Time” window: shows the total workout time. The range is from 0:00 to 99:59 (minutes:seconds). After
reaching 99:59, the machine will stop smoothly and show ‘End’. The display will then enter startup
mode after 5 seconds. During a preset countdown, when the countdown timer reaches 0:00, the
machine will stop smoothly and show ‘End’. It will then enter the startup mode.
5. “Distance” window: Shows the running distance. It counts up from 0.00 to 99.9. Upon reaching 99.9, it
will begin counting up from 0. During a preset countdown, the machine will slowly stop and show ‘End’
once distance reaches 0. It will then enter startup mode after 5 seconds.

12
PRIME
6. “Calories” window: Shows calories burnt. When your hand is on the pulse sensors, it will show the
current pulse data. When showing calories, the window will count from 0 to 999 calories. Upon reaching
999, the window will restart from 0. During countdown, the window will count down from the preset
amount to 0. Upon reaching 0, the machine will stop smoothly and show ‘End’. It will then enter startup
mode after 5 seconds.
7. Centre LCD display window: In setting state, it will show P1-P24, U1-U3, HP1-HP2, FAT. When the
machine is operating, the window will display a 400 meter running track. It will also show the lap
progress and number of laps. Upon completed of a lap, the display will “beep”.
BUTTON FUNCTION:
1. “Program” button: During startup mode, press this button to choose a program. Programs are ‘P1-P24,
U1-U3, FAT” Manual mode is the default program. The default speed is 0.5 KM/H. (“0:00” is manual
program, P1-P24 is inner install program, U1-U3 is self-define program, FAT is the body fat test
function)
2. “HRC” button: During startup mode, press this button to choose heart rate control from HP1 to HP2.
3. “MODE” button: During startup mode, press this button to choose between “0:00”, “15:00”, “ 1.0 ”, “50”
( “0:00” is manual mode, “15:00” is time countdown mode, “ 1.0 ” is distance countdown mode, “50” is
calories counting down mode). When setting each mode, you can press speed +/- and incline +/- to set
the data, press “START” to start the machine.
4. “START” button: When the machine is connected to power and safety key attached, press this button at
any time to start the machine. If starting from manual mode, the machine will operate at the lowest
speed: 0.5 km/h, incline 0.
5. “STOP/PAUSE” button: Press this button to stop the motor running.
Pressing the STOP button once during your workout will pause the workout and the workout data on the
LCD will remain. Press the START button to resume your workout. Instead of pressing START, you may
clear the workout data by pressing the STOP button a second time.
6. “SPEED +”, “SPEED –” buttons: During startup mode, set speed data with this button. When the
machine is running, press theses buttons to adjust speed. Speed will be adjusted at 0.1 KM at each
press, when holding the button for over 0.5 seconds, the speed will change up or down continuously.

13
PRIME
7. “INCLINE+”, “INCLINE-” buttons: During startup mode, set incline data with this button. When the
machine is running, press theses buttons to adjust incline. Incline will be adjusted at 1 level per press,
when holding the button for over 0.5 seconds, the speed will change up or down continuously.
8. “INCLINE: 5, 8, 12, 18” – quick shortcut buttons to set incline.
9. “SPEED: 5, 8, 12, 18” – quick speed shortcut buttons to set speed.
10. “MUTE” button: Stop or Start the music from playing out of the speakers.
11. Emergency button: Press this button to stop the machine immediately.
QUICK START UP (MANUAL)
1. Switch the machine on at the power switch and twist the emergency button in a clockwise direction. The
machine will then enter startup mode.
2. Press the START/STOP button. The machine will enter a 3 second count down. The buzzer will then
make a sound and the time display window count down from 3 to 0. The speed will begin at 0.5km/hour
after the countdown.
3. After start-up, you can use the SPEED buttons to adjust speed and INCLINE buttons to adjust incline.
THE OPERATION OF EXERCISE PROCESS:
1. Pressing speed-down will reduce the running speed.
2. Pressing speed-up will increase the running speed.
3. Pressing incline down will reduce the incline level.
4. Pressing incline up will increase the incline level.
5. Pressing the speed shortcut button will adjust the running speed.
6. Pressing incline shortcut button will adjust the incline level.
7. Pressing the stop button will stop the machine.
8. Holding the handle pulse with two hands approximately 5 seconds will show pulse data.

14
PRIME
MANUAL MODE
1. If you do not make any settings and press the START button directly, the treadmill will start to run from
the speed 0.5km/h, incline 0. The other windows will start to count up. Press “SPEED+”, “SPEED-”
change the speed, press “INCLINE+”、“INCLINE -”to change the incline;
2. To set up the Time countdown mode, press “MODE”. The TIME window will then display “15:00” and
flashes. Press “SPEED+”, “SPEED-” or “INCLINE+”, “INCLINE –“ to set the desired time interval. The
setting range is from 5:00-99:00minutes.
3. To set up distance countdown, press “MODE” until the DISTANCE window displays “1.0” and flashes.
Press “SPEED+”, “SPEED-” or “INCLINE+”, “INCLINE –“ to set the desired distance what you need.
The setting range is 0.5—99.9km.
4. To set up calorie countdown, press “MODE” until the CAL window will displays “50” and flashes. Press
“SPEED+”, “SPEED-” or “INCLINE+”, “INCLINE –“ to set the desired distance. The setting range is from
10-999 calories.
After completing this step, press the “START” button to start the treadmill. The treadmill will start after 3
seconds. Use the “SPEED+”, “SPEED-” and “INCLINE+”, “INCLINE –“ buttons to adjust speed and incline;
Press the “STOP” button to stop your workout.
PRESET PROGRAMS
Press the “PROGRAM” button and the centre LCD window will display programs ranging from P1 to P24. To
set the program duration, use the “SPEED+”, “SPEED-”, “INCLINE+” and “INCLINE –“ buttons. The default
duration is 10 minutes. Press the “START” button begin preset program. Each preset program is divided into
10 sections. Each section is 1/10th of the total duration. When the treadmill enters into the next section, it will
beep 3 times and speed/incline will change according to the set program. Use the “SPEED+”, “SPEED-”,
“INCLINE+” and “INCLINE –“ buttons to change the SPEED and INCLINE during a section. When a new
section begins, these settings will revert to the preset settings of the next section. After finish a program, the
treadmill will beep 3 times and stop after 5 seconds. It will then enter standby mode.

15
PRIME
PROGRAM EXERCISE CHART
Each program is divided into 10 sections for the exercise time and each time section has a separate speed
and incline setting.
Time Program
TIME INTERVAL= 1/10th of total workout duration
1
2
3
4
5
6
7
8
9
10
P1
SPEED
2
4
3
4
3
5
4
2
5
3
INCLINE
1
2
3
3
1
2
2
3
2
2
P2
SPEED
2
5
4
6
4
6
4
2
4
2
INCLINE
1
2
3
3
2
2
3
4
2
2
P3
SPEED
2
5
4
5
4
5
4
2
3
2
INCLINE
1
2
2
3
1
2
2
2
2
1
P4
SPEED
3
6
7
5
8
5
9
6
4
3
INCLINE
2
2
3
3
2
2
4
6
2
2
P5
SPEED
3
6
7
5
8
6
7
6
4
3
INCLINE
1
2
4
3
2
2
4
5
2
1
P6
SPEED
2
8
6
4
5
9
7
5
4
3
INCLINE
2
2
6
2
3
4
2
2
2
1
P7
SPEED
2
6
7
4
4
7
4
2
4
2
INCLINE
4
5
6
6
9
9
10
12
6
3
P8
SPEED
2
4
6
8
7
8
6
2
3
2
INCLINE
3
5
4
4
3
4
4
3
3
2
P9
SPEED
2
4
5
5
6
5
6
3
3
2
INCLINE
3
5
3
4
2
3
4
2
3
2
P10
SPEED
2
3
5
3
3
5
3
6
3
3
INCLINE
4
4
3
6
7
8
8
6
3
3
P11
SPEED
2
5
8
10
6
9
5
3
2
2
INCLINE
1
3
5
8
10
7
6
3
2
3

16
PRIME
P12
SPEED
2
5
5
4
4
6
4
2
3
4
INCLINE
3
5
6
7
12
9
11
11
6
3
P13
SPEED
2
7
4
7
8
9
4
5
3
2
INCLINE
5
6
6
4
6
5
8
9
4
2
P14
SPEED
2
6
5
4
8
6
5
2
3
3
INCLINE
5
6
5
8
4
5
5
10
6
3
P15
SPEED
2
6
5
4
8
7
5
3
3
2
INCLINE
3
4
5
6
3
5
5
6
4
3
P16
SPEED
2
5
7
5
8
6
5
2
4
2
INCLINE
1
5
6
8
12
9
10
9
5
3
P17
SPEED
2
5
6
7
8
9
10
5
3
4
INCLINE
3
5
6
8
6
5
8
7
5
3
P18
SPEED
2
3
5
6
8
6
9
6
5
2
INCLINE
5
7
5
8
6
5
9
10
6
2
P19
SPEED
3
7
6
5
9
7
6
3
5
2
INCLINE
3
5
6
8
5
6
5
12
8
3
P20
SPEED
3
7
9
10
11
12
10
8
5
2
INCLINE
2
5
6
7
6
5
8
6
3
2
P21
SPEED
3
6
8
7
9
10
5
8
3
2
INCLINE
3
6
8
9
9
6
8
10
6
3
P22
SPEED
3
5
8
6
9
10
8
12
6
3
INCLINE
2
6
8
10
12
10
12
8
5
2
P23
SPEED
3
5
9
11
12
8
6
5
3
2
INCLINE
2
6
8
10
9
7
8
10
6
3
P24
SPEED
3
8
10
11
12
10
10
8
5
3
INCLINE
3
6
8
9
10
12
9
6
3
2

17
PRIME
USER DEFINED PROGRAMS
Apart from the 24 preset programs, there are 3 user self-defined programs: U1, U2, U3
1. User self-define program setting: during startup mode, press “program” continuously until the programs
U1, U2, U3, appear, the “time” window flashes and shows the time 15:00. Use the “incline+”, “incline-”,
“speed+”, “speed-” buttons to set the program duration. Press “mode” to set program data, to set data
of the first section, use the “speed+” and “speed-” buttons or the speed shortcut buttons to set speed.
Use the “incline+”, “incline-” or the incline shortcut buttons to set incline. Then press the “mode” button
to finalise the first section data and enter into the second section data. Repeat this process until all 10
sections are completed. The data will be stored until it is overwritten. This data will not be lost if power
is disconnect.
2. User defined program startup: when the machine is in startup mode, press the “program” button
continuously until U1, U2, U3 appears. Set the program duration, then press “start” to start the machine.
3. User self-defined program quick instructions: each program will be divided into 10 time sections, set the
speed and incline in each time section, then press “start” to run the machine.
HEART RATE CONTROL PROGRAM: (THIS FUNCTION IS OPTIONAL)
1. Press the “HRC” button whilst in standby mode. You can choose heart rate control from HP1 to HP2.
HP1: Max speed: 8.0km/h, default heart rate: 120beats/min.
HP2: Max speed: 9.0km/h, default heart rate: 130beats/min.
2. Press the “MODE” button to enter age setting. The time window will begin by showing the default age of
30. Use the “INCLINE+”, “INCLINE -”, “SPEED+” and “SPEED -” buttons to set the correct age. The age
range is between 15 to 80 years old.
3. After age is selected, press “MODE”. The system will recommend a suitable target hear rate, which will
be displayed on screen for reference. Use the “INCLINE+”, “INCLINE -”, “SPEED+” and “SPEED -”
buttons to choose expected target heart rate. The available option range is from 84 to195beats/min.
4. After setting age and target heart rate, press “MODE” to enter time setting. The “TIME” window will
show the preset time of 10:00min. Use the “INCLINE+”, “INCLINE -”, “SPEED+” and “SPEED -” buttons
to adjust time. The available range is from 10:00 to 99:00min.

18
PRIME
5. Press “START” button to start the workout.
6. Under HRC mode, if you do not set any value and press “START” directly, the system will adjust speed
and incline automatically as per the default target heart rate value.
7. During a HRC program, “INCLINE+”, “INCLINE -”, “SPEED+” and “SPEED -” buttons will be available to
adjust speed and incline. The system will also adjust speed and incline automatically to achieve the
user’s target heart rate value.
8. The first minute of any HRC program is the warm-up stage where the system will not adjust speed and
incline automatically. Only manual adjustment is available in the first minute. After 1 min, the system will
add speed under the frequency of 0.5km per adjustment. If the value reaches the max speed but still
does not achieve the target heart rate value, the system will add incline with frequency of 1 level per
adjustment in order to reach owner’s target heart rate value. The machine will stop automatically when
setting time is complete.
9. Note: Heart rate control programs can only be used with a wireless chest strap. This must be attached
closely to bare skin.

19
PRIME
SELF-LUBRICATION SYSTEM: (THIS FUNCTION IS OPTIONAL)
For proper maintenance, this treadmill is designed to self-lubricate.
1. Manual lubrication: Remove the motor cover. Press the button on the oil adding driver board. The
oil output will be around 2-3mL. When complete the system will beep 3 times.
2. Automatic lubrication: The system will lubricate the treadmill with 2-3mL of oil automatically after
every 20 kilometres of operation.
3. The total storage volume for the oil tank is approximately 200ml. A the total running distance
reaches approximately 1200 to 1500 kilometres, please add silicone oil into the storage tank.
Remove the motor cover, remove the storage tank plug and add oil into the tank.
4. After every 1000 kilometres of usage, the system will “beep”15 times to remind the user check the oil
level of the storage tank. Do this by removing the motor cover and examining the oil level. If the oil
level is low, fill the storage tank with silicone oil. It is important that this is done to prevent damage to
the belt.
5. To check the inbuilt odometer, hold the “SPEED+”and “SPEED –“ buttons down together during
startup mode for 3 seconds. The LCD window will then display the total running mileage. Press
“STOP”button to quit.
PROGRAM PARAMETERS
Initial
Initial Data
Set Range
Display Range
TIME(MIN:SECOND)
0:00
15:00
5:00-99:00
0:00－99:59
INCLINE(SECTION)
0
0
0-20
0-20
SPEED(K/h)
0.5
0.5
0.5-20
0.5-20
DISTANCE(KM)
0
1.0
0.5-99.9
0.00－99.9
PULSE(hypo/min)
P
N/A
N/A
50-200
CALORIE(THERM)
0
50
10-999
0－999

20
PRIME
BODY FAT TESTER:
During startup mode, press “PROGRAM” continuously to select FAT.
1. Press “MODE” to enter data values for F-1, F-2, F-3, F-4, F-5 (F-1 SEX, F-2 AGE, F-3 HEIGHT,
F-4 WEIGHT, F-5 BODY FAT).
2. Use the “SPEED+”, “SPEED -” buttons to set F-1 –F4 values (refer to the chart below).
3. Press “MODE” to set the F-5 value.
4. Hold the hand pulse sensors. The window will now display your body mass index after 3
seconds. The body mass index tests the relation between height and weight.
This index is suitable for both males and females. The ideal BMI reading is between 20 and 25.
Readings under 19 suggests that the subject is underweight. Readings between 25 and 29
suggest that the subject is overweight. Readings over 30 suggest that the subject is obese.
(The data is for reference only and must not be used for medical purposes).
F-1
Sex
01 male
02 female
F-2
Age
10------99
F-3
Height
100----200
F-4
Weight
20-----150
F-5
FAT
≤19
Underweight
FAT
=(20---25)
Normal
FAT
=(26---29)
Overweight
FAT
≥30
Obesity
