Lifeloc FC20BT
Operations Manual
Unlock the Power
of Alcohol Testing

2
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Table of Contents
Introduction
Congratulations ................................................................................................................................. 5
Front View ...........................................................................................................................................6
Features................................................................................................................................................ 7
Preparation
Installing Batteries............................................................................................................................ 8
Turning the FC On and Off............................................................................................................ 8
Observing the Subject.................................................................................................................... 9
Attaching a Mouthpiece................................................................................................................. 9
Breath Testing Modes
Testing Modes Explained ............................................................................................................. 10
End of Breath & Precise Volume Explained.......................................................................... 10
Auto Air Blank Explained............................................................................................................. 10
Conducting an Automatic Test....................................................................................................11
Manual Override During an Automatic Test ...........................................................................11
Conducting a Manual Test ............................................................................................................12
Conducting a Passive Test............................................................................................................12
Operation
Breath Flow........................................................................................................................................13
Alcohol Curve....................................................................................................................................13
Test Results ........................................................................................................................................13
Viewing Previous Test Results ....................................................................................................13
Removing the Mouthpiece ...........................................................................................................13
User Settings
Printing Test Results ...................................................................................................................... 14
Changing the Time ......................................................................................................................... 14
Changing the Date ..........................................................................................................................15
Setting the Automatic Air Blank................................................................................................15
Setting the Automatic Shutoff Time ........................................................................................15
Data Entry Explained .....................................................................................................................16
Using Data Field 2 ...........................................................................................................................16
Entering a Subject I.D.............................................................................................................16 - 17
Entering a Subject I.D. and Data Field 2. ................................................................................17
Disabling Subject I.D. and Data Field 2. ..................................................................................18
Using a Keyboard.............................................................................................................................18
Setting the Trigger Mode..............................................................................................................18
Security Settings Explained.........................................................................................................19
Setting Up Security Password ....................................................................................................19
Using Security Password ..............................................................................................................19

3
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Table of Contents
Removing Security Password ................................................................................................... 20
Print Settings Explained.............................................................................................................. 20
Number of Copies Printed.......................................................................................................... 20
Print Format.......................................................................................................................................21
Printer Selection...............................................................................................................................21
Adjusting LCD Contrast.................................................................................................................21
Setting the Default Test Order...................................................................................................22
Results Format Explained............................................................................................................22
Setting Results Format.................................................................................................................23
Setting the Pass/Warn/Fail Levels...........................................................................................23
Bluetooth Settings
View Current Device ......................................................................................................................23
Changing the Selected Printer Device....................................................................................24
Changing the Selected Keyboard Device..............................................................................24
Calibration Settings
Calibration Explained ....................................................................................................................25
Selecting the Calibration Standard.................................................................................25 - 26
Calibration/Cal Check Explained..............................................................................................26
Selecting the Standard Type ......................................................................................................27
Calibration/Cal Check Lock-out Explained...........................................................................27
Setting the Calibration Lock-out Type ..........................................................................27 - 28
Setting the Cal Check Lock-out Type.....................................................................................28
Wet Bath Calibration
Wet Bath Simulator Set-Up ........................................................................................................28
Wet Calibration................................................................................................................................29
Wet Calibration Check................................................................................................................. 30
Dry Gas Calibration
Dry Gas Tank Set-Up.......................................................................................................................31
Dry Gas Calibration ................................................................................................................31 - 32
Dry Gas Calibration Check..................................................................................................32 - 33
Maintenance
How to Check Status.....................................................................................................................33
Fuel Cells............................................................................................................................................33
Cleaning..............................................................................................................................................33
Batteries ............................................................................................................................................ 34
Printers
Lifeloc Bluetooth Printer............................................................................................................. 34

4
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Computer Connection
AlcoMark® Explained .....................................................................................................................35
AlcoMark® Setup .............................................................................................................................35
On-Screen Messages
Messages Explained.......................................................................................................................36
Service
Lifeloc Factory Warranty....................................................................................................37 - 39
Fuel Cell Warranty.........................................................................................................................40
Extended Service Plans.................................................................................................................41
Service..................................................................................................................................................41
General Usage
Notice ...................................................................................................................................................41
Specifications ...................................................................................................................................42
FC20BT Supplies
Accessories and Supplies ............................................................................................................42
Factory Options
Available Upgrades ........................................................................................................................42
Sample Printouts
Sample Printouts (Long, Short, Cal/Cal Ck)........................................................................ 43
Menu Charts
User Settings Chart....................................................................................................................... 44
Calibration Display Chart............................................................................................................ 45
Bluetooth Settings Chart............................................................................................................ 46

5
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Attention FC20BT Operator:
Congratulations on your purchase of a Lifeloc FC20BT (Bluetooth).
For over 25 years, Lifeloc Technologies has been providing advanced alcohol testing
equipment & training to Law Enforcement and Corrections Professionals. We are the
leader in product innovation, precision instruments, ease of use & Five Star Customer Care.
The FC20BT breath alcohol tester is manufactured in Wheat Ridge, Colorado, by Lifeloc
Technologies, Inc. Lifeloc offers premium quality products combined with exceptional
service and technical support.
The FC20BT incorporates unique cutting edge technologies:
• Secure wireless printing for unsurpassed testing capability.
• Easy data entry using our wireless keyboard.
• Results on a positive test register within 10 seconds.
• You can take another test within 30 seconds after a positive. Repeatability is not
compromised.
• Your FC20BT will automatically take the test when it senses a deep lung sample is
delivered.
• Your FC20BT will provide an accurate test, or else explain to you why it cannot, and
even provide suggestions on how to proceed to complete an accurate test on your
subject.
• AA Alkaline or NiMH batteries last for about 50 “on” hours or up to 1900 tests.
Your FC20BT includes many other features such as: Calibration/Calibration Check,
Lock-Out Periods, 4000 test memory, numerous printout options, multiple test modes and
optional Password Protection.
The following pages will explain in detail the operation of your FC20BT portable breath
tester.
Unlock the Power of Alcohol Testing
Introduction

6
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Mouthpiece
+/- Buttons set
calibration standard
Battery Icon indicates
battery level
Function Button
scrolls through menus
and saves changes
Execute Button
enables you to perform
the function
Mouthpiece Removal Tab
Large Graphic LCD Screen
displays functions and results
Power Button
turns unit on and off;
also returns you to
main testing mode
Wrist Strap
Attachment Loop
Front View (with Mouthpiece)
Introduction
Bluetooth Status
Indicator

7
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
• Bluetooth Connectivity: Provides users with truly mobile testing.
• Large Graphic LCD Display: Capable of showing numbers, letters, icons and plain
English text messages.
• Simplified Calibration: Automatic with EASYCAL®. Software controlled guiding you
step by step manually.
• Auto Test Mode: The easiest way to take a test. Unit automatically takes a deep
lung sample when the subject is at end of breath.
• Manual Test Mode: Enables the operator to control exact point of breath sample.
• Passive Test Mode: Checks for the presence of alcohol in the breath or in an open
container, without using a mouthpiece.
• On Board Memory: Stores the last 4000 tests.
• Real Time Clock: Stores time and date information with test results as well as
calibration and cal check results.
• Wireless
Printer Ready: Print out any or all results using Lifeloc Bluetooth printer
with up to 33' range.
• Two Printout Options: Long or short.
• Data Entry: Capable of storing two separate data fields, one for subject and one
for additional uses, operator, precinct, etc.
• User-Selectable Test Order: Allows choice of either Auto Test or Passive Test
default mode.
• Calibration Reminder with Lockout: Prevents you from using an FC20BT when it is
due for calibration.
• Adjustable Auto Shut-Off: Preserves battery life.
• Fast, Simple Operation: While the FC20BT contains a host of features, it is still easy
to use.
• Automatic Backlight: Easy viewing of test results either day or night.
• Exceptional Battery Life: Up to 50 hours of operation or up to 1900 tests using four
AA Alkaline or NiMH rechargeable batteries.
Features
Introduction

8
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Installing Batteries
Turning the FC On and Off
Press in and down on the battery door located on the back of the FC20BT.
Install the four AA Alkaline batteries in the direction of the symbols in the battery case.
Close the case by pushing up on the battery door until it locks shut.
See page 34 for directions on using rechargeable batteries.
Press and hold the Power button on the bottom
of the front of the unit until it beeps. The FC20BT
performs an automatic internal diagnostics check
when turned on.
To turn the unit off, press and hold the Power
button until it beeps twice. The unit will shut
down.
Note: Momentarily pressing the Power button
when the unit is on will return you to the main
menu.
Preparation

9
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Observing the Subject
Attaching a Mouthpiece
The FC20BT provides a highly accurate reading of breath alcohol acquired by sampling
deep lung air. Readings will also detect residual mouth alcohol.
To prevent mouth alcohol from affecting a test, make certain that the subject is not
allowed to put anything in their mouth for 15 minutes prior to taking a test.
If the subject just took a drink, a 15 minute observation period in which they are not
permitted to put anything in their mouth should be observed before testing. This will
ensure all residual alcohol from any source has completely dissipated and test results will
be valid.
Remove the mouthpiece from its wrapper,
making sure not to touch the end which
the subject will be blowing into.
Attach the mouthpiece to the port on the
back of the FC20BT.
Line up the mouthpiece port over the
holes in the back of the mouthpiece. Press
in place.
Ensure it is securely attached.
Preparation

10
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Breath Testing Modes Explained
The FC20BT is capable of conducting Automatic, Manual, and Passive tests.
•Automatic Test is the easiest way to achieve a deep lung sample. The FC monitors the
subject’s breath and automatically takes the sample near the end of the breath flow.
• Manual Test is normally used only when the subject is unable to provide a sufficient
breath sample for the automatic test.
• Passive Test is a quick screen to detect alcohol but is not designed to quantify the
results. Passive results are reported as “POS” if alcohol is detected, “NEG” if alcohol is
not detected. In this mode, no mouthpiece is use.
End of Breath and Precise Volume Explained
In Auto Test mode, the unit can be set to take a sample either:
•
When the subject nears the end of the exhalation (End of Breath)
— or —
•
When it detects 1.5L of breath (Precise Volume)
Both will give accurate results. Precise Volume may work better with uncooperative
subjects.
(To select “END OF BREATH” or “PRECISE VOLUME” mode, see Trigger Mode
instructions on p.18)
Breath Testing Modes
Auto Air Blank Explained (Optional)
If installed, this option inserts an automatic air blank function in front of Auto, Manual, and
Passive tests.
An automatic air blank is a test of the ambient air. It checks to ensure that no alcohol is
present, which could affect the test result.
If Auto Air Blank is enabled, the FC20BT will prompt you to take a sample before testing
the subject.
Auto Air Blank is normally utilized to satisfy the requirements of a specific testing
protocol.

11
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Breath Testing Modes
Manual Override during an Automatic Test
Note: This feature allows the completion of a test in the occasional instance when the
subject may have diminished lung capacity and cannot activate the Auto Test.
Turn the FC20BT on.
Attach a mouthpiece to the back of the unit and verify the display reads “AUTO TEST”.
Instruct the subject to blow into the mouthpiece firmly and steadily for as long as they
can.
When they are near the end of their breath, press the Execute button.
Read the result.
Conducting an Automatic Test
Turn the FC20BT on.
Verify the display reads “AUTO TEST”.
Attach the mouthpiece to the back of the
unit.
Instruct the subject to blow into the
mouthpiece firmly and steadily for as long
as they can. (But not necessarily as hard as
they can.) The unit calculates volume and
will give an error message if the subject
cannot reach 1.3 liters of breath.
Read the result.
After taking a test, the FC20BT will display
the results in large numbers on the display.
The result is stored in memory and available
for viewing and printing at a later date.
Momentarily press the Power button to return to the test mode.

12
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Turn the FC20BT on.
Press the Function button, if necessary, until
the display reads “PASSIVE TEST.”
Hold the FC20BT sample port (orange-
colored opening labeled “Port” on the back
of the FC20BT) about 4 inches from the
subject’s mouth.
Have the subject blow toward the port.
Press the Execute button while the subject is
blowing.
Read the result. The unit will only display “POS” or “NEG”. It will not display the actual
numerical result.
Note: A passive test can also be done over an open container to detect the presence of
alcohol.
Breath Testing Modes
Conducting a Passive Test (No Mouthpiece)
Conducting a Manual Test
Turn the FC20BT on.
Attach the mouthpiece to the back of the
unit.
Press the Function button until the display
reads “MANUAL TEST”.
Instruct subject to blow into the mouthpiece
firmly and steadily for as long as they can.
When they are near the end of their breath,
press the Execute button.
Read the result.
Please note, manual test mode is pressure
activated. If the subject does not blow air
into the mouthpiece, the test cannot be conducted.

13
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Breath Flow
As the subject blows into the mouthpiece,
the FC20BT will show a graph of the
breath flow on the display, as well as
showing the amount of liters. Liters are
shown in the upper left corner.
Alcohol Curve
If the FC detects alcohol, the alcohol level
is graphed and will be displayed before the
result.
Breath Testing Modes
Removing the Mouthpiece
Test Results
After the alcohol is graphed, the test result
is displayed.
The result will remain on the screen until
the Function or Power button is pressed
or until shut-off time is reached.
The last 4000 test results are retained in
memory.
Viewing Previous Test Results
Press the Function button until the printer
icon is displayed. The results of the last
test will be displayed along with its test
number at the lower left of the display.
Press the + or - button to scroll between
test results.
Momentarily press the Power button to
return to the testing mode.
Remove the mouthpiece by pushing
straight down on the tab at the right of the
display screen. DO NOT BEND the tab.
Press to remove
mouthpiece

14
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Printing Test Results
Printing the Current Test
Take a test. (See pages 11-13)
Ensure the printer is on.
Press the Execute button under the printer icon to print the result.
Printing a Specific Test From Memory
Press the Function button until the printer icon is displayed.
Press the + or – button to select the test number you wish to print.
Press the Execute button under the printer icon to print the result.
Printing All Tests Stored in Memory
Press the Function button until the printer icon is displayed.
Press the + or – button to select “ALL”.
Press the Execute button under the printer icon to print all of the test results.
Printing Calibration/Calibration Check Data
Press the Function button until the printer icon is displayed.
Press the + or – button to select “CAL/CAL CHK”.
Press the Execute button under the printer icon to print the data.
See sample printout on page 43.
Operation
Changing the Time
Press the Function button until the display reads “Settings”.
Press the Execute button.
Display reads “TIME” with the hour digits flashing.
Press the + or – button to change the hour.
Press the Execute button to move to minutes.
Press the + or – button to change the minutes.
Press the Function button to save your changes.
Momentarily press Power to return to the testing mode.

15
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
User Settings
Changing the Date
Press the Function button until the display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until the display reads “DATE”
with the month digits flashing.
Press the + or – button to change the month.
Press the Execute button to move to the day.
Press the + or – button to change the day.
Press the Execute button to move to the year.
Press the + or – button to change the year.
Press the Function button to save your changes.
Momentarily press Power to return to the testing mode.
02/24/2008
Setting the Automatic Air Blank (Optional Feature)
Press the Function button until the display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until the display reads “AUTO AIR BLANK”.
Press the Execute button to turn the air blank “ON” or “OFF.”
Press the Function button to save your changes.
Momentarily press Power to return to the testing mode.
Setting the Auto Shutoff Time
Press the Function button until the display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until the display reads “SHUTOFF TIME”.
Press the + or - button to adjust the shutoff time between
1-15 minutes. Disable auto shutoff by selecting “OFF”.
Press the Function button to save your changes.
Momentarily press Power to return to the testing mode.

16
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
User Settings
Using Data Field 2
Press the Function button until display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until display reads “I.D. SETTINGS”.
Press the Execute button until display reads “DATA FIELD 2”. Press the Function button
once. The display will read “DATA FIELD 2”.
Press the + or - buttons to enter numbers or letters.
(Hold down to scroll quickly)
Press the Execute button to move to the next digit. Up to 24 characters may be entered.
Press the Function button to save the Data Field 2. The Data Field 2 is recorded with
every test until changed or disabled.
Momentarily press Power to return to testing mode.
Entering a Subject I.D.
Press the Function button until display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until display reads “I.D. SETTINGS”.
Press the Execute button until display reads “SUBJECT”.
Press the Function button to save your changes.
Momentarily press the Power button. Display reads “SUBJECT I.D.”
Data Entry Explained
The FC20BT allows you to enter I.D. numbers and/or names that will be printed with
every test result.
• Subject I.D. - Can identify a unique test subject. You will be prompted to enter name
or number each time you administer a test.
• Data Field 2 - Can identify a test administrator or event. Entered once and recorded
with every test until changed or disabled.
• Subject I.D. + Data Field 2 - Identifies unique test subject along with administrator
or event. Data Field 2 is recorded with every test until changed or disabled. You will
be prompted to enter subject name or number each time you administer a test.
Both data entry fields allow for 24 characters.

17
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Entering a Subject I.D. + Data Fields
Press the Function button until display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until display reads “I.D. SETTINGS”.
Press the Execute button until display reads “SUBJECT + DATA”.
Press the Function button once. Display reads “DATA FIELD 2”.
Press the + or - buttons to enter the Subject I.D. numbers or letters. (Hold down to scroll
quickly)
Press the Execute button to move to the next digit. Up to 24 characters may be entered.
Press the Function button to save the Subject I.D. The Subject I.D. is recorded with every
test until changed or disabled.
Momentarily press the Power button. Display reads “SUBJECT I.D.”
Press the + or - buttons to enter the I.D. numbers or letters.
(Hold down to scroll quickly)
Press the Execute button to move to the next digit. Up to 24 characters may be entered.
Press the Function button to save the unique Subject I.D. with the next test.
The FC20BT will now prompt you to enter a unique Subject I.D. before every test.
To bypass entering a Subject I.D., simply press the Function button.
You are now ready to conduct a test.
User Settings
Press the + or - buttons to enter the I.D. numbers or letters.
(Hold down to scroll quickly)
Press the Execute button to move to the next digit. Up to 24 characters may be entered.
Press the Function button to save the unique Subject I.D. with the next test.
The FC20BT will now prompt you to enter a unique Subject I.D. before every test.
To bypass entering a Subject I.D., simply press the Function button and take a test.
You are now ready to conduct a test.

18
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Setting Trigger Mode
Press the Function button until the display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until the display reads “TRIGGER MODE”.
Press the Execute button to select between “END OF BREATH” and “PRECISE VOLUME”.
Press the Function button to save your changes.
Momentarily press Power to return to the testing mode.
User Settings
Using the Bluetooth Keyboard (Optional Feature)
The FC20BT allows for data input using an optional bluetooth keyboard. If you purchase
the keyboard option, you can easily input text or numbers in Subject or Data Fields or
have full command of the FC20BT menu.
Navigation Instructions
Space or Tab = Function Button
Enter = Execute Button
Right Arrow = +Button
Left Arrow = -Button
Escape = Power Button
Please note: The keyboard must be turned on prior to powering on your FC20BT.
To learn more about Lifeloc’s data management solutions, please contact
[e-mail] or 1.800.722.4872.
Disabling Subject I.D. and Data Field
Press the Function button until display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until display reads “I.D. SETTINGS”.
Press the Execute button until display reads “OFF.”
Press the Function button to save your changes.
Now the FC20BT will not prompt you to enter a Subject I.D. (Data Field 2 and Subject I.D.
will be blank until they are enabled.)
Press the Power button to return to the testing mode.

19
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Security Settings Explained
Password can be set to protect access to calibration, calibration check, calibration
settings and user settings.
Without a password, users are still able to conduct Automatic, Manual and Passive tests;
print test results; and check battery status and temperature.
Setting Up Security Password
Press the Function button until the display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until the display reads “SECURITY SETTINGS”.
Press the Execute button. The unit is now ready to accept a password. Use the + or -
buttons to enter a number or letter.
Use the Execute button to move to the next digit. Password is limited to 8 characters.
Press the Function button to save your password. Momentarily press Power to return to
the testing mode.
Note: Record and store your password in a safe place. Lifeloc does not have access to
your password. If password is lost, the only way to reset the unit is to call Lifeloc Tech
Support at 720.317.2190.
Using Security Password
For access to Calibration, Calibration Check, Calibration Settings or User Settings.
Press the Function button until the display reads “CALIBRATION” or “SETTINGS”. Select
the one you would like to access.
Press the Execute button. Display reads “SECURITY CODE”.
Enter your password using the + or - buttons. Use the Execute button to move to the next
digit.
Press the Function button to gain access. You now have access to all menus and settings.
User Settings

20
Lifeloc FC20BT
www.Lifeloc.com |303-431-9500
Number of Copies Printed
Press the Function button until display reads “SETTINGS”.
Press the Execute button. Display reads “TIME”.
Press the Function button until the display reads “PRINT SETTINGS”.
Press the Execute button. Display reads “NUMBER OF COPIES”.
Press the + or - button to change the number of copies.
Press the Function button to save your changes.
Momentarily press Power to return to the testing mode.
User Settings
Print Settings Explained
The FC20BT settings allow you to customize your printout to your particular needs. You
can choose between the following:
Number of Copies - Choose to print 1, 2 or 3 copies of a test.
Print Format - Choose to include (long format) or not to include (short format) the
calibration and calibration check information with every printout. (See sample printouts
on p. 43)
Printer - Select “THERMAL”, “IMPACT”, or “WIRELESS” to print results to your
corresponding printer. Select “ALCOMARK” to download or print results to your computer.
Removing Security Password
Press the Function button until the display reads “SETTINGS”.
Press the Execute button. Display reads “SECURITY CODE”.
Enter your password using the + or - buttons.
Press the Function button until the display reads “SECURITY SETTING”.
Press the Execute button. Display reads “SECURITY SETTING” and shows your password
in the lower left corner.
Clear your password using the + or - buttons to change the letters or numbers to blank
spaces. Use the Execute button to move to the next digit.
Press the Function button to clear the password.
Momentarily press Power to return to the testing mode.
