OPERATING MANUAL
Handheld3016IAQ
PARTICLE COUNTER

00

Lighthouse Worldwide Solutions
HANDHELD 3016 IAQ Particle Counter
Gen E
Operating Manual

Copyright © 2011-2014 by Lighthouse Worldwide Solutions. All rights reserved. No part of this
document may be reproduced by any means except as permitted in writing by Lighthouse
Worldwide Solutions.
The information contained herein constitutes valuable trade secrets of Lighthouse Worldwide
Solutions. You are not permitted to disclose or allow to be disclosed such information except as
permitted in writing by Lighthouse Worldwide Solutions.
The information contained herein is subject to change without notice. Lighthouse Worldwide
Solutions is not responsible for any damages arising out of your use of the LMS program.
HANDHELD 3016 IAQ™, LMS™, ECS™, ACU™, SIU™, AIU™ and MIU™ are trademarks
of Lighthouse Worldwide Solutions.
Microsoft®, Microsoft Windows© and Excel© are trademarks of Microsoft Corporation.
LWS Part Number: 5HY

EU DECLARATION OF CONFORMITY
Manufacturer’s Name Lighthouse Worldwide Solutions, Inc.
Manufacturer’s Address: Lighthouse Worldwide Solutions, Inc.
1221 Disk Drive
Medford, OR 97501
Declares that the product:
Product Name: Handheld Airborne Particle Counter
Model Number(s): Handheld 3016IAQ
Conforms to the following Product Specifications:
SAFETY EN61010-1:2001 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use Part I:
General Requirements IEC 61010-1:2000
CAN/CSA C22.2 Safety Requirements for Electrical
No. 1010.1-1992 Equipment for Measurement, Control, and Laboratory
Use, Part1: General Requirements
LASER SAFETY IEC 60825-1 Am. 2 Guidance on Laser Products: Conforms to
IEC 60601-2-22 FDA 21 CFR Chapter 1 Subchapter J
(Laser Notice 50)
EMC EN61326 Electrical Equipment for Measurement, Control and
Laboratory Use EMC Requirements Part 1: General
Requirements Includes Amendment A1:1998;IEC
61326:1997 + A1:1998
UL 61010A-1 – UL Standard for Safety Electrical Equipment for Laboratory Use; Part 1: General Requirements.
Replaces UL 3101-1
Supplementary information: The product herewith complies with the requirements of the Low Voltage
Directive 73/23/EEC amended by Directive 93/68/EEC and the EMC Directive 89/336/EEC amended by Directive
93/68/EEC, and carries the CE marking accordingly.
Fremont, CA, May 15, 2007 William L. Shade – V.P. Engineering

00
5HY t-i
Table of Contents
About this Manual
Chapter 1 General Safety
General Safety ............................................................................................................... 1-1
Laser Safety Information ............................................................................................... 1-1
Chapter 2 Introduction
Overview ........................................................................................................................ 2-1
Description ..................................................................................................................... 2-1
HANDHELD Specifications .......................................................................................... 2-2
Chapter 3 Unpacking, Inspecting and Installation
Unpacking and Initial Inspection ................................................................................... 3-1
Accessories .................................................................................................................... 3-1
Prepare Instrument for Use ........................................................................................... 3-2
Power Requirements ......................................................................................... 3-2
Install the Battery ............................................................................................... 3-3
Connect Power ................................................................................................... 3-6
Battery Removal ............................................................................................... 3-7
Optional Printer Accessory ................................................................................ 3-9
Connecting to an External Computer or Facility Management System .......... 3-10
Chapter 4 Operation - Particle Mode
Using the Instrument ...................................................................................................... 4-1
Touch Screen Overview ................................................................................................. 4-2
Operation Mode ................................................................................................. 4-2
Menu Map Particle Mode .................................................................................. 4-3
MAIN Screen ................................................................................................................. 4-4
LOCATION Selection ....................................................................................... 4-8
Changing Locations ............................................................................... 4-8
Locations in AUTO Mode ..................................................................... 4-8
Zoomed Data View ................................................................................ 4-9

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
t-ii 5HY
CONFIGURATION Screen ......................................................................................... 4-11
DATA SETUP ............................................................................................................. 4-11
Analog Channels .............................................................................................. 4-12
SAMPLE .......................................................................................................... 4-14
SETTINGS ....................................................................................................... 4-17
COUNT MODE ................................................................................... 4-17
Geiger Counter Mode .......................................................................... 4-18
PARTICLE Display ............................................................................. 4-19
ALARM ........................................................................................................... 4-19
Alarm Threshold .................................................................................. 4-20
Alarm Acknowledge ............................................................................ 4-22
Clear Buffer ..................................................................................................... 4-22
DEVICE SETUP .......................................................................................................... 4-23
CLOCK ............................................................................................................ 4-23
OPTIONS ......................................................................................................... 4-26
CONTRAST ADJUST ........................................................................ 4-26
AUDIBLE BEEP ADJUST ................................................................. 4-26
ALIGN TOUCH SCREEN .................................................................. 4-26
Autostart Mode .................................................................................... 4-29
Pump Startup ........................................................................................ 4-29
LANGUAGE ....................................................................................... 4-30
COMM ADDRESS .......................................................................................... 4-31
OUTPUT SETUP ............................................................................................ 4-32
SECURITY ...................................................................................................... 4-33
POWER ON PASSWORD .................................................................. 4-34
CONFIGURATION PASSWORD ...................................................... 4-34
SERVICE ......................................................................................................... 4-35
STATUS ...................................................................................................................... 4-35
RECIPE ........................................................................................................................ 4-36
LOCATION ................................................................................................................. 4-39
DATA VIEW ............................................................................................................... 4-42
ANALOG DATA ............................................................................................ 4-45
PRINT RECORD ............................................................................................. 4-45
PRINT RANGE (BUFFER REPORT) ............................................................ 4-46
Printing Buffer Report ......................................................................... 4-47
Power Shutdown Levels .............................................................................................. 4-49
Chapter 5 Operation - Mass Concentration Mode
Introduction .................................................................................................................... 5-1
Using the Instrument .................................................................................................... 5-2
Touch Screen Overview ................................................................................................. 5-3
Operation Mode ................................................................................................. 5-3
Menu Map Mass Concentration Mode .............................................................. 5-4
MAIN Screen ................................................................................................................. 5-5
MASS / PARTICLE Button .............................................................................. 5-8

Table of Contents
5HY t-iii
LOCATION Selection ....................................................................................... 5-9
Changing Locations ............................................................................... 5-9
Locations in AUTO Mode ..................................................................... 5-9
CONFIGURATION Screen ......................................................................................... 5-10
DATA SETUP ............................................................................................................. 5-10
Analog Channels .............................................................................................. 5-11
SAMPLE .......................................................................................................... 5-13
SETTINGS ....................................................................................................... 5-16
COUNT MODE ................................................................................... 5-16
PARTICLE Display. ............................................................................ 5-16
ALARM ........................................................................................................... 5-17
Alarm Threshold .................................................................................. 5-17
Alarm Acknowledge ............................................................................ 5-19
Clear Buffer ..................................................................................................... 5-20
DEVICE SETUP .......................................................................................................... 5-20
CLOCK ............................................................................................................ 5-21
OPTIONS ......................................................................................................... 5-23
CONTRAST ADJUST ........................................................................ 5-23
AUDIBLE BEEP ADJUST ................................................................. 5-23
ALIGN TOUCH SCREEN .................................................................. 5-23
Autostart Mode .................................................................................... 5-26
Pump Startup ........................................................................................ 5-26
LANGUAGE ....................................................................................... 5-27
COMM ADDRESS .......................................................................................... 5-28
OUTPUT SETUP ............................................................................................ 5-29
SECURITY ...................................................................................................... 5-30
POWER ON PASSWORD .................................................................. 5-31
CONFIGURATION PASSWORD ...................................................... 5-31
SERVICE ......................................................................................................... 5-32
STATUS ...................................................................................................................... 5-32
RECIPE ........................................................................................................................ 5-33
LOCATION ................................................................................................................. 5-36
DATA VIEW ............................................................................................................... 5-39
Analog Data ......................................................................................... 5-41
PRINT RECORD ............................................................................................. 5-41
PRINT RANGE (BUFFER REPORT) ............................................................ 5-43
Printing Buffer Report ......................................................................... 5-43
Power Shutdown Levels .............................................................................................. 5-46
Chapter 6 Maintenance Procedures
Safety ............................................................................................................................. 6-1
Calibration ..................................................................................................................... 6-1
Cleaning ......................................................................................................................... 6-1
Purge Test ...................................................................................................................... 6-1

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
t-iv 5HY
Appendix A Limited Warranty
Limitation Of Warranties: ............................................................................................. A-1
Warranty Of Repairs After Initial Two (2) Year Warranty: ......................................... A-1
Appendix B Default Settings
HANDHELD Default Settings ...................................................................................... B-1
Index

00
5HY i
About this Manual
This manual describes the detailed operation and use of the Lighthouse
HANDHELD 3016 IAQ Airborne Particle Counter.
Text
Conventions
The following typefaces have the following meanings:
Note: A note appears in
the sidebar to give extra
information regarding a
feature or suggestion.
italics Represents information not to be typed
or interpreted literally. For example, file
represents a file name. Manual titles are
also displayed in italics.
WARNING: A
warning appears in a
paragraph like this and
warns that doing
something incorrectly
could result in personal
injury, damage to the
instrument or loss and/or
improper storage of data.
boldface Introduces or emphasizes a term.
Courier font Indicates command syntax or text
displayed by the diagnostic terminal.
Bold Courier Indicates commands and information that
you type. You can use uppercase or
lowercase letters; in this manual,
commands are shown in uppercase.
Helvetica Italics Indicates a comment on a command or
text output.
Hexadecimal numbers are shown with the word “hex” or with a small
“h” following the digits. For example:
hex 0D
0Dh
Additional
Help
For more information about the Lighthouse HANDHELD 3016 IAQ
Airborne Particle Counter, contact Lighthouse Worldwide Solutions:
Service and Support
Tel: [phone] (USA Toll Free)
Tel: [phone] (Outside of USA)
[email protected]

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
ii 5HY

00
5HY 1-1
1General Safety
General
Safety Warnings and cautions are used throughout this manual. Familiarize
yourself with the meaning of a warning before operating the particle
counter. All warnings will appear in the left margin of the page next to
the subject or step to which it applies. Pay close attention to each
warning message. Take extreme care when performing any procedure
preceded by or containing a warning.
There are several classifications of Warnings directed as follows:
• Laser - pertaining to exposure to visible or invisible laser radiation
• Electrostatic - pertaining to electrostatic discharge
Laser Safety
Information
This product contains a laser-based sensor that is a Class 1 product (as
defined by 21 CFR, Subchapter J of the Health and Safety Act of 1968)
when used under normal operation and maintenance. Service
procedures on the sensor can result in exposure to invisible radiation.
Service should be performed only by factory-authorized personnel.
The particle counter has been evaluated and tested in accordance with
EN 610109-1:1993, “Safety Requirements For Electrical Equipment
for Measurement, Control, and Laboratory Use” and IEC 825-1:1993,
“Safety of Laser Products”. See Figure 1-1.
WARNING: The use
of controls, adjustments,
or performance of
procedures other than
those specified within
this manual may result in
exposure to invisible
(infrared) radiation that
can quickly cause
blindness. As a general
precaution, avoid any
possible exposure to
laser radiation by
honoring manufacturer
seals and warranty
stickers .
Figure 1-1 Example of Laser Warning Label
For further technical assistance, contact Lighthouse at 800-945-5905
(USA Toll Free) or 541-770-5905 (Outside of USA).

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
1-2 5HY

00
5HY 2-1
2Introduction
Overview This operating guide describes how to use the Lighthouse
HANDHELD 3016 IAQ Airborne Particle Counter.
The HANDHELD 3016 IAQ has up to six particle-size channels
starting at 0.3m with a flow of 0.1 CFM and a touch screen interface.
A microprocessor controls all instrument functions. Count data is
displayed as cumulative or differential count in Particle Mode. In Mass
Concentration Mode, particles are displayed in micrograms per cubic
meter.
The model number signifies the minimum particle size measured by the
instrument. The number “3016” indicates a 0.3m minimum channel
size at 0.1 CFM with up to 6 channels.
The instrument uses a laser-diode light source and collection optics for
particle detection. Particles scatter light from the laser diode. The
collection optics collect and focus the light onto a photo diode that
converts the bursts of light into electrical pulses. The pulse height is a
measure of particle size. Pulses are counted and their amplitude is
measured for particle sizing. Results are displayed as particle counts in
the specified size channel.
Description Ergonomically designed and lightweight, the Lighthouse HANDHELD
3016 IAQ particle counter is the newest and most advanced handheld
particle counters on the market.
The HANDHELD 3016 IAQ displays cumulative or differential
particle count data, Mass Concentration data and Temperature/Relative
Humidity data on its easy to read 3.8" (9.25cm) touch screen. A
rechargeable battery maximizes the HANDHELD’s uptime. Data is
easily downloaded using LMS XChange software.
The HANDHELD allows you to:
• Set the Sample Time
• Configure the number of samples taken in a given Location

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
2-2 5HY
• Sample many different locations
• Save your data for historical data review
• Print data tables using the data transfer software included with your
instrument.
HANDHELD
Specifications Table 2-1 Specifications
Size Range 0.3 - 10.0m
HANDHELD 3016
Channel Thresholds
0.3, 0.5, 1.0, 2.5, 5.0, 10.0 m
Flow Rate 0.1 CFM (2.83 LPM)
Counting Efficiency 50% (per ISO 21501-4)
Laser Source Laser diode
Zero Count Level <1 count / 5 minutes (per ISO 21501-4)
Calibration NIST Traceable
Count Modes (Particle
Mode)
Concentration, manual/automatic, beep,
cumulative/differential,
Count Modes (MASS
Mode)
Mass Concentration, PM
Data Storage Up to 3000 sample records, includes particle
& environmental data, plus location and time
Communication Modes RS232 via RJ-45 to PC or printer
Supporting Software LMS XChange Data Transfer Software
Environmental Sensors
Temperature, Relative
Humidity
0-150°F (-17.8 to 65.6°C) ±1.8°F @ 77°F, 0-
100% ± 5% @ 33%
Touch Screen Display 3.8" (9.25 cm), 320x240
Printer External thermal printer (optional)
Key Software Features Historical data review, password protection
Enclosure High impact injection molded plastic
Sample Output Internally filtered to HEPA standards
(>99.97% @ 0.3μm)
Vacuum Source Internal pump, flow controlled

Introduction
5HY 2-3
The manufacturer recommends that your Lighthouse instrument be
calibrated annually by a Certified Lighthouse Service Provider in order
to ensure that your unit continues to perform within specification.
Power Unit: +12VDC; AC/DC Adapter: 100-240V,
50-60Hz
Battery Li-Ion, removable and rechargeable
Dimensions 8.75"(L) x 5.0"(W) x 2.5"(H) [22.23 x 12.7 x
6.35 cm]
Weight 2.2 lb (1kg)
Operating Temp/RH 50°F to 104°F (10°C to 40°C) / 20% to 95%
non-condensing
Storage Temp/RH 14°F to 122°F (-10°C to 50°C) / Up to 98%
non-condensing
Table 2-1 Specifications

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
2-4 5HY

00
5HY 3-1
3Unpacking, Inspecting
and Installation
Unpacking
and Initial
Inspection
Your instrument is thoroughly inspected and tested at the factory and is
ready for use upon receipt. When received, inspect the shipping carton
for damage. If the carton is damaged, notify the shipper immediately.
If the carton appears to be undamaged, carefully inspect the instrument
for broken parts, scratches, dents, or other damage before using.
Verify the contents of the package against the Packing List.
If anything is missing from the above list, please contact your sales
representative at Lighthouse Worldwide Solutions immediately at 1-
[phone] or [email protected].
WARNING: Do not
ship the instrument with
the battery installed.
Keep the carton and all packing material for reshipment of the
HANDHELD for its annual calibration.
Accessories You may order several optional accessories to tailor the unit to your
needs.
•External Battery Charger with AC and car adapters
•Spare Li-Ion Battery (removable and rechargeable)
•Carrying Case
•Isokinetic Sample Probe
•6 ft. Tubing (for extending Isokinetic sampling input)
•Thermal Printer with cable (AC or battery operated)
•Validation Documentation

Lighthouse HANDHELD 3016 IAQ Gen E Operating Manual
3-2 5HY
•LMS Express software (standard), an analysis tool that allows the
user to:
1. Manually download data from the instrument
2. Save data for historical review
3. Have advanced reporting with standard reports and much more.
•LMS Express RT software (optional), an analysis tool that allows
the user to perform the following:
1. Download data from the instrument
2. Collect data real time
3. Save data for historical review
4. Have advanced reporting with standard reports
...and much more.
Please contact Lighthouse Worldwide Solutions at 800-945-5905 (USA
Toll Free) or 541-770-5905 (Outside of USA) for details.
Prepare
Instrument
for Use
Power Requirements
The power adapter input requirement is 100-240VAC, 50-60Hz, 1.25
Amps. Its output is +12VDC, 3A. A power cord and power adapter are
included with your HANDHELD 3016 IAQ.
To protect the instrument from voltage spikes, Lighthouse recommends
using protected power. Using an uninterruptible power supply (UPS)
when the HANDHELD is kept in a stationary location will help prevent
damage to the instrument or loss of data in the event of a power outage.
