Lighthouse RLPC 0.1m User manual

00

Lighthouse Worldwide Solutions
REMOTE Liquid Particle Counter (MODBUS Output)
Operating Manual

Copyright © 2005 - 2015 by Lighthouse Worldwide Solutions. All rights reserved. No part of
this document may be reproduced by any means except as permitted in writing by Lighthouse
Worldwide Solutions.
The information contained herein constitutes valuable trade secrets of Lighthouse Worldwide
Solutions. You are not permitted to disclose or allow to be disclosed such information except as
permitted in writing by Lighthouse Worldwide Solutions.
The information contained herein is subject to change without notice. Lighthouse Worldwide
Solutions is not responsible for any damages arising out of your use of the LMS program.
REMOTE LPC™ and LMS™ are trademarks of Lighthouse Worldwide Solutions.
Microsoft®, Microsoft Windows™, and Excel™ are trademarks of Microsoft Corporation.
Manufactured by:
Lighthouse Worldwide Solutions
1221 Disk Drive
Medford, Oregon 97501
LWS Part Number: 248083227-1 Rev 8

EU DECLARATION OF CONFORMITY
Manufacturer’s Name: Lighthouse Worldwide Solutions, Inc.
Manufacturer’s Address: Lighthouse Worldwide Solutions, Inc.
1221 Disk Drive
Medford, OR 97501 USA
Declares that the product:
Product Name: Remote Liquid Particle Counter
Model Number(s): RLPC 0.1, RLPC 0.2, RLPC 0.3, RLPC 0.5MODBUS
Conforms to the following Product Specifications:
SAFETY EN61010-1:2001 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use Part 1:
General Requirements IEC 61010-1:2000
Safety Requirements for Electrical Equipment for
Measurement, Control and Laboratory Use, Part 1:
General Requirements
LASER SAFETY Guidance on Laser Products: Conforms to FDA 21 CFR
Chapter 1 Subchapter 1
EMC EN61326 Electrical Equipment for Measurement, Control and
Laboratory Use EMC Requirements Part 1: General
Requirements Includes Amendment A1:1998; IEC
61326:1997 + A1:1998
UL 61010A-1 - UL Standard for Safety Electrical Equipment for Laboratory Use; Part 1: General Requirements
Replaces UL 3101-1
Supplementary information
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC amended by
Directive 93/68/EEC and the EMC Directive 89/336/EEC amended by Directive 93/68/EEC and carries the
CE marking accordingly.
William Shade - V.P. Engineering
Fremont, CA. March 7, 2008
CAN/CSA C22.2
No. 1010.1-1992
IEC 60825-1 Am. 2
IEC 60601-2-22
(Laser Notice 50)

00
248083227-1 Rev 8 t-i
Table of Contents
List of Figures
About this Manual
Text Conventions ................................................................................................................ i
Additional Help ................................................................................................................... i
Chapter 1 General Safety
LASER Safety Information ........................................................................................... 1-1
Electrostatic Safety Information .................................................................................... 1-2
Chapter 2 Introduction
Overview ........................................................................................................................ 2-1
Description ..................................................................................................................... 2-1
Accessories .................................................................................................................... 2-2
RLPC 0.1m Specifications .......................................................................................... 2-3
RLPC 0.2m Specifications .......................................................................................... 2-4
RLPC 0.3m Specifications .......................................................................................... 2-5
RLPC 0.5m Specifications .......................................................................................... 2-6
RLPC Chemical Compatibility ...................................................................................... 2-7
Chapter 3 Get Started
Initial Inspection ............................................................................................................ 3-1
Annual Calibration ......................................................................................................... 3-1
Shipping Instructions ..................................................................................................... 3-1
LEDs .............................................................................................................................. 3-2
Understanding the LEDs .................................................................................... 3-2
Instrument Overview ..................................................................................................... 3-3
Outlet Nozzle ..................................................................................................... 3-3
Communication Ports ........................................................................................ 3-4
RS485 Adapter Cable ........................................................................................ 3-4
DIP Switches ...................................................................................................... 3-5
Power ................................................................................................................. 3-5

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
t-ii 248083227-1 Rev 8
External Alarm Output ....................................................................................... 3-5
Inlet Nozzle ........................................................................................................ 3-6
Attaching Sensor ............................................................................................................ 3-6
Chapter 4 Communications
DIP Switches .................................................................................................................. 4-1
DIP SWITCH GENERAL DEFINITIONS ....................................................... 4-2
Communication Modes .......................................................................... 4-2
DIP Switch Addressing ...................................................................................... 4-3
Communicating with the Instrument ............................................................................. 4-4
RS232/485 IN Port ............................................................................................. 4-5
RS485 OUT Port ................................................................................................ 4-6
RS232 Communications .................................................................................... 4-6
RS485 Communications .................................................................................... 4-7
Connecting to a PC ............................................................................................ 4-7
Chapter 5 Configuring with LWS ASCII Service Protocol
General Info ................................................................................................................... 5-1
Configuring with ASCIl ................................................................................................. 5-1
ASCII Command Structure ................................................................................ 5-2
Handshake .......................................................................................................... 5-2
Getting Started ................................................................................................... 5-2
Summary of Configuration Commands ............................................................. 5-5
Example: Setting Date and Time ....................................................................... 5-7
Example: Setting Sample Time <ta#> ............................................................... 5-9
Example: Setting Hold Time <tb#> ................................................................. 5-10
Example: Setting Location <pa#> ................................................................... 5-11
Example: Enable Alarm Channel <aa#> ......................................................... 5-11
Example: Disabling Channel Alarm ................................................................ 5-12
Example: Setting Alarm Threshold <axy> ...................................................... 5-13
Example: Setting Alarm Suppression <ae#> ................................................... 5-14
Verify Configuration Changes ..................................................................................... 5-14
Chapter 6 Programming with MR Protocol
DIP Switches .................................................................................................................. 6-1
Protocol Settings ............................................................................................................ 6-1
Power On ....................................................................................................................... 6-1
Connecting the Instrument to a Terminal ...................................................................... 6-2
.Device Select ................................................................................................................ 6-3
Sending a Location/Address .............................................................................. 6-3
Universal Device Select (U) .............................................................................. 6-5
Configuration Commands .............................................................................................. 6-6

Table of Contents
248083227-1 Rev 8 t-iii
General ............................................................................................................... 6-6
Set Alarm Limit (WA) ....................................................................................... 6-6
Set Location(WL) .............................................................................................. 6-7
Set Date & Time(WD) ....................................................................................... 6-8
Counter Setup and Data Record Commands ................................................................ 6-8
Counter Set Up Commands ............................................................................... 6-8
Set Hold Interval (Hhhmmss) ................................................................ 6-8
Set Sample Interval (Lhhmmss) ............................................................ 6-9
Action Commands ....................................................................................................... 6-10
General ............................................................................................................. 6-10
Universal Actions Commands ..................................................................................... 6-12
General ............................................................................................................. 6-12
Data Record Commands .............................................................................................. 6-13
Send Buffered Record(A) ................................................................................ 6-13
Send Current Record(B) .................................................................................. 6-13
Clear Buffer(C) ................................................................................................ 6-13
Number of Records(D) .................................................................................... 6-14
Retransmit Record(R) ...................................................................................... 6-14
Miscellaneous Commands ............................................................................... 6-15
EEPROM Version(E) .......................................................................... 6-15
Operating Mode(M) ............................................................................. 6-15
MODEL (T) ......................................................................................... 6-15
Data Record Format ..................................................................................................... 6-16
GENERAL ....................................................................................................... 6-16
Data Fields ....................................................................................................... 6-17
Chapter 7 Programming with MODBUS Protocol
DIP Switches .................................................................................................................. 7-1
Protocol Settings ............................................................................................................ 7-1
Power On/Auto Start ...................................................................................................... 7-1
Running the Instrument Using MODBUS ..................................................................... 7-2
AUTOMATIC Counting Mode ......................................................................... 7-2
MANUAL Counting Mode ................................................................................ 7-3
Configuring with the MODBUS Protocol ..................................................................... 7-3
Setting the Real Time Clock .............................................................................. 7-3
Changing the Default Instrument Parameters .................................................... 7-4
Using Sensor Setting Registers .............................................................. 7-5
Location (Register 40026) ..................................................................... 7-5
Hold Time (Registers 40031, 40032) .................................................... 7-5
Sample Time (Registers 40033, 40034) ................................................ 7-5
Alarm Enable Registers ..................................................................................... 7-6
Enable Alarming for a Channel ............................................................. 7-7
Threshold Setup Registers ................................................................................. 7-7
Setting the Alarm Threshold Value ....................................................... 7-8

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
t-iv 248083227-1 Rev 8
Appendix A MR Protocol Commands
COMM Settings ............................................................................................................ A-1
Device Select ................................................................................................................ A-1
Universal Device Select .................................................................................... A-3
Configuration Commands ............................................................................................. A-3
Data Record Format .................................................................................................... A-10
GENERAL ...................................................................................................... A-10
Data Fields ...................................................................................................... A-11
Appendix B RLPC MODBUS Register Map v1.44
COMM Settings ............................................................................................................. B-1
Supported MODBUS Commands .................................................................................. B-1
Sensor Settings Registers ................................................................................... B-2
Device Status ..................................................................................................... B-5
Data Registers ................................................................................................................ B-6
Data Status Byte (30007 - 30008) ...................................................................... B-8
Alarm Flags in Channels (30076) ...................................................................... B-9
Data Type Registers ........................................................................................... B-9
Data Units Registers ........................................................................................ B-11
Data and Alarm Registers ............................................................................................ B-12
Data and Alarm Enable Registers .................................................................... B-12
Enable Alarming for a Channel ....................................................................... B-13
Threshold Setup Registers ............................................................................... B-14
Setting the Alarm Threshold Value ..................................................... B-16
Appendix C Maintenance
Flow Cell Cleaning ........................................................................................................ C-1
Cleaning Procedure ............................................................................................ C-1
Appendix D Limited Warranty
Limitation Of Warranties: ............................................................................................. D-1
Warranty Of Repairs After Initial Two (2) Year Warranty: ......................................... D-1
Index

00
248083227-1 Rev 8 LOF-1
List of Figures
The REMOTE Liquid Particle Counter ...................................................................................... 2-1
Detail of Front Panel LEDs ........................................................................................................ 3-2
RLPC Top Connections .............................................................................................................. 3-3
RLPC Bottom Connections ........................................................................................................3-3
RS485 Adapter Cable ................................................................................................................. 3-4
Example of an RLPC Installation ............................................................................................... 3-6
DIP Switch Cover ....................................................................................................................... 4-1
Communication Port Pin Numbers ............................................................................................. 4-4
RS485 Adapter Cable ................................................................................................................. 4-7
Hyperterminal Communication Settings .................................................................................... 5-1
COM Port and ASCII Properties ................................................................................................ 6-2
Data Record Serial Format ....................................................................................................... 6-16
Data Record Serial Format ......................................................................................................A-10
Flow Cell Cleaning with Brush ................................................................................................ C-1

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
LOF-2 248083227-1 Rev 8

00
248083227-1 Rev 8 i
About this Manual
This manual describes the operation and use of the Lighthouse
REMOTE Liquid Particle Counter (RLPC) with MODBUS output.
Text
Conventions
The following typefaces have the following meanings:
Note: A note appears in
the sidebar to give extra
information regarding a
feature or suggestion
italics Represents information not to be typed
or interpreted literally. For example, file
represents a file name. Manual titles are
also displayed in italics.
WARNING: A
warning appears in a
paragraph like this and
warns that doing
something incorrectly
could result in personal
injury, damage to the
instrument or loss and/or
improper storage of data.
boldface Introduces or emphasizes a term.
Courier font Indicates command syntax or text
displayed by the diagnostic terminal.
Bold Courier Indicates commands and information that
the user types.
Helvetica Italics Indicates a comment on a command or
text output.
Hexadecimal numbers are shown with the word "hex"or with a small
"h" following the digits. For example:
hex 0D
0Dh
Additional
Help
For more information about Lighthouse RLPC 0.1m, RLPC 0.2μm,
RLPC 0.3m or RLPC 0.5m Particle Counters, contact Lighthouse
Worldwide Solutions.
Service and Support:
Tel: [phone] (Toll Free USA)
Tel: [phone] (Outside of USA)
[email protected]

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
ii 248083227-1 Rev 8

00
248083227-1 Rev 8 1-1
1General Safety
Safety
Considerations
Warnings and cautions are used throughout this manual. It is the
responsibilty of the the user to familiarize themselves with the meaning
of a warning before operating the particle sensor. Warnings may
appear in the left margin of the page next to the subject or step to which
it applies or within the step itself. Take extreme care when performing
any procedures preceded by or containing a warning.
There are several classifications of Warnings defined as follows:
WARNING: There are
no user-serviceable
components inside the
particle counter.
• LASER - pertaining to exposure to visible or invisible LASER
radiation.
• Electrostatic - pertaining to electrostatic discharge
• Network Connect - pertaining to communication ports and
instrument damage
LASER Safety
Information
This product is considered to be a Class 1 LASER product (as defined
by FDA 21 CFR, §1040.10) when used under normal operation and
maintenance. Service procedures on the sensor can result in exposure
to invisible radiation. Service should be performed only by factory-
authorized personnel.
The particle counter has been evaluated and tested in accordance with
EN 61010-1:2012, “Safety Requirements For Electrical Equipment for
Measurement, Control and Laboratory Use” and IEC 60825-1:2007,
“Safety of LASER Products”.
WARNING: The use
of controls, adjustments
or procedures other than
those specified within
this manual may result in
personal injury and/or
damage to this
instrument.
For further technical assistance, contact our Technical Support Team at
1-800-945-5905 (Toll Free USA) or 1-541-770-5905 (Outside of
USA).

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
1-2 248083227-1 Rev 8
Electrostatic
Safety
Information
The following information is provided to prevent damage to
Lighthouse instruments or harm to humans.
WARNING: Using a
wrist-strap without an
isolation resistor will
increase the severity of
an electrical shock. Use
of controls or
adjustments or
performing procedures
other than those
specified herein may
result in hazardous
radiation exposure.
Electrostatic discharge (ESD) can damage or destroy electronic
components. Therefore, all service or maintenance work should be
done at a static-safe work station. A static-safe work station can be
created by doing the following:
• Use a grounded conductive table mat and resistor-isolated wrist-
strap combination
• Earth-ground all test instruments to prevent a buildup of static
charge

00
248083227-1 Rev 8 2-1
2Introduction
Overview This operating manual introduces the Lighthouse Liquid Particle
Counter REMOTE models RLPC 0.1m, RLPC 0.2μm, RLPC 0.3m
and RLPC 0.5μm. Included in this manual are instructions for
operation, communications and maintenance.
Description The RLPC 0.1m, RLPC 0.2μm, RLPC 0.3mand RLPC 0.5μmhave a
range of 0.1 - 0.5m, 0.2 - 2.0 m, 0.3 - 3.0 m and 0.5 - 5.0 m at a
sensitivity of 0.1 micron, 0.2 micron, 0.3 micron and 0.5 micron,
respectively, and the capability of real time continuous data collection
using the RS485 MODBUS protocol.
With a user-controlled flow rate of 100 ml/min., + 5%, the RLPC
sensors are designed to accurately measure up to 4 channels of
simultaneous particle counts in various liquids including solvents, acids
and bases (see Table 2-5 and Table 2-6 for chemical compatibilities).
.
Figure 2-1 The REMOTE Liquid Particle Counter
The instrument uses a laser diode light source and laser beam shaping
optics to illuminate a cross section of the liquid flow path. As particles
move through the flow cell, they enter the laser beam and scatter light.
The light scattered is collected by the optical system and imaged onto a

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
2-2 248083227-1 Rev 8
photodiode. The photodiode converts the light into current which is
converted to voltage and amplified by the electronics.
The result is a voltage pulse each time a particle crosses the laser beam.
The width of the pulse is proportional to the time it takes the particle to
cross the laser beam and the pulse’s amplitude is proportional to the
size of the particle.
The voltage pulses created by the particles are processed by additional
electronics to quantify the pulses by the size of each particle. The
quantities of the various sized particles are processed and stored in the
sensor’s buffers or transferred via MODBUS.
The RLPC counters were created for continuous, 24 hours per day, 7
days per week operation. The instrument provides versatile mounting
options allowing installation where space is at a premium. The RLPC
integrates seamlessly with many large facility monitoring or
management systems and transfers up to 4 channels of simultaneous
particle count data using the RS485 MODBUS or RS485 MR Protocol
output.
Accessories Several accessories can be ordered to tailor the instrument to specific
needs. Contact a distributor for additional information and datasheets.

Introduction
248083227-1 Rev 8 2-3
RLPC 0.1m
Specifications
Table 2-1 RLPC 0.1m Specifications
Size Range 0.1 - 0.5 μm
Channel Thresholds Standard: 0.1, 0.2, 0.3, 0.5 m
Flow Rate 100 ml/min, + 5%, User-controlled
Laser Source Laser Diode
Calibration NIST Traceable
Data Storage Rotating buffer, 2000 Records
Communication Modes RS232/RS485 via RJ45 to PC, RS485/
Modbus, ASCII, Modbus or MR Protocol
LED Indicators Power, Service, Sampling
Supporting Software Lighthouse Monitoring System, LMS Net
XChange, LMS Express and LMS Express RT
Concentration Limit 64,000 counts/ml @ 5% Coincidence Error
Power Input
Requirements
24VDC@ 100mA
External Alarm Output Normally Open Dry Contact Rated 0-60 V
AC/DC 1 Amp
Enclosure Stainless Steel
Sample Inlet/Outlet
Connection
1/4" FlaretekTM
Sample Temperature 32 - 302oF (0 - 150oC)
Sample Pressure 150 PSI
Wetted Surface Material Quartz, PTFE, PFA
Dimensions 5.7"(L) x 5.2"(W) x 3"(H) [14.47 x 13.2 x 7.6
cm]
Weight 3.5 lbs. (1.58 kg)
Operating Temp/RH 50° F to 104° F (10° C to 40° C) / 20% to 95%
non-condensing
Storage Temp/RH 14° F to 122° F (-10° C to 50° C) / Up to 98%
non-condensing

Lighthouse REMOTE Liquid Particle Counter (MODBUS Output) Operating Manual
2-4 248083227-1 Rev 8
RLPC 0.2m
Specifications
Table 2-2 RLPC 0.2m Specifications
Size Range 0.2 - 2.0 μm
Channel Thresholds Standard: 0.2, 0.3, 0.5, 0.7 m
Standard: 0.2, 0.5, 1.0, 2.0 m
Flow Rate 100 ml/min, + 5%, User-controlled
Laser Source Laser Diode
Calibration NIST Traceable
Data Storage Rotating buffer, 2000 Records
Communication Modes RS232/RS485 via RJ45 to PC, RS485/
Modbus, ASCII, Modbus or MR Protocol
LED Indicators Power, Service, Sampling
Supporting Software Lighthouse Monitoring System, LMS Net
XChange, LMS Express and LMS Express RT
Concentration Limit 4,000 counts/ml @ 5% Coincidence Error
Power Input
Requirements
24VDC@ 100mA
External Alarm Output Normally Open Dry Contact Rated 0-60 V
AC/DC 1 Amp
Enclosure Stainless Steel
Sample Inlet/Outlet
Connection
1/4" FlaretekTM
Sample Temperature 32 - 302oF (0 - 150oC)
Sample Pressure 150 PSI
Wetted Surface Material Quartz, PTFE, PFA
Dimensions 5.7"(L) x 5.2"(W) x 3"(H) [14.47 x 13.2 x 7.6
cm]
Weight 3.5 lbs. (1.58 kg)
Operating Temp/RH 50° F to 104° F (10° C to 40° C) / 20% to 95%
non-condensing
Storage Temp/RH 14° F to 122° F (-10° C to 50° C) / Up to 98%
non-condensing
