Nautilus Hyosung MS400A Assembly instructions

Hardware Installation Manual
MS400A
V01.00.03 (2014.10.20)
© 2014 Nautilus Hyosung Inc. All Rights Reserved.

© 2014 Nautilus Hyosung Inc. All Rights Reserved. ii
Revision History
Hardware Installation Manual – MS400A System
No.
Version
Date
Description of Change
Chapter
1
V01.00.00
2013/06/03
New Publication
All
2
V01.00.01
2014/07/10
Added Anchor Bolts Location Sheet
Chapter4
3
V01.00.02
2014/10/15
Modified Dimension and Recommended Installation
Chapter3
And Service Clearance sections
4
V01.00.03
2014/10/20
Edited document throughout
All
© 2014 Nautilus Hyosung All Rights Reserved.
The content of this specification is protected by copyright laws.
2014.10. 20. 4th Release

© 2014 Nautilus Hyosung Inc. All Rights Reserved. iii
Contents
Chapter 1 Introduction...................................................................................................................1-1
Purpose ........................................................................................................................................................1-1
Audience.......................................................................................................................................................1-1
Support Information......................................................................................................................................1-1
What is in This Manual.................................................................................................................................1-1
Terminology ..................................................................................................................................................1-2
Abbreviations................................................................................................................................................ 1-2
Safety Precautions .......................................................................................................................................1-4
Related Documents...................................................................................................................................... 1-6
Chapter 2 Installation Information................................................................................................2-1
Installation Environment and Spacing.......................................................................................................... 2-1
Dimensions...................................................................................................................................................2-2
Recommended Installation and Service Clearances ...................................................................................2-4
Chapter 2 System Installation.......................................................................................................3-1
Unpacking the MS400A................................................................................................................................3-1
Bolting Down the MS400A ...........................................................................................................................3-2
Chapter 3 Notes .............................................................................................................................4-1

Installation Manual Chapter 1 Introduction
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 1-1
Chapter 1 Introduction
Purpose
This manual explains how to install the Nautilus Hyosung America’s (NHA) MoniSafe™
400A (MS400A) Teller Cash Recycler hardware.
Audience
This manual has been written for anyone responsible for installing the MS400ATeller Cash
Recycler (TCR) in bank branches or similar locations.
Support Information
For question or if error occurs while installing the MS400A while following this manual,
contact the NHA maintenance staff or help desk. For contact information, see your support
email addresses and telephone numbers that are provided separately.
What is in This Manual
This manual provides detailed installation guidelines and important warnings that should
be followed while installing the MS400A.
All measurements in this manual are in metric with inches provided in braces [ ].
All information described in this manual refers to licensed products of Nautilus Hyosung
Inc. It is the policy of Nautilus Hyosung Inc. to improve products as new technology,
components, software, and firmware become available. Therefore Nautilus Hyosung
America Inc. reserves the right to change specifications without notice.

Installation Manual Chapter 1 Introduction
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 1-2
Terminology
The following terminology is used in this document.
Customer and consumer refer to any person who transacts business through the
MS400A.
Device and unit refer to the standard and optional equipment.
Fascia refers to the entire front portion of the unit, including the portion where the
customer transacts business.
Module refers to a plug-in device that can be serviced or replaced.
Note(s) and bill(s) refer to the individual documents loaded into and dispensed from
the dispenser.
Servicing and maintenance refer to the supervisor, operator and technician’s tasks
performed to keep the operational.
Screen refers to the text appearing on the customer display.
Abbreviations The following abbreviations are used in this document.
#
Abbreviations
Description
1
AD board
Analog Digital Board
2
ADA
American Disabilities Act
3
AP
Application Program
4
Assy
Assembly
5
BRM
Bill Recycle Machine
5-1
BC
Bill Checker
5-2
BMD
Body Module-Down (Lower Body of the Module)
5-3
BMU
Body Module-Up (Upper Body of the Module)
5-4
BRM
Bill Recycle Machine
5-5
CSM
Customer Service Module
5-6
DPC
Deposit Cassette
5-7
RC
Recycle Cassette
5-8
RJC
Reject Cassette
5-9
TE
Tape Escrow
5-10
UTC
Utility Cassette
6
BATT S/W
Battery Switch
7
CAM
Camera Unit
8
CE
Control Electronics
9
EP
Elementary Program
10
H/W
Hardware
11
I/F
Interface

Installation Manual Chapter 1 Introduction
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 1-3
#
Abbreviations
Description
12
LCD
Liquid Crystal Display
13
OPL
Operation Panel
14
OSD board
On Screen Display Board
15
P/S
Power Supply
16
PNC
Panel Control Board
17
S/W
Switch
18
SIU
Sensor and Indications Unit
19
SP
Service Provider
20
TTU
Text Terminal Unit (OPL or SPL)

Installation Manual Chapter 1 Introduction
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 1-4
Safety Precautions
Common Safety Precautions
The Safety Precautions outlined this manual provide information on safe and proper
handling of the product. Non-compliance with these safety precautions may result in
personal injury or damage to the product.
This caution symbol will be accompanied by warning terminology that points out safety
warnings during equipment handling.
Please read the following instructions before operating the equipment.
Operate equipment as outlined in this manual.
Follow the cautions indicated in this manual, as well as on the equipment itself.
Failure to properly address these precautions may lead to personal injury or
damage to the product.
Avoid operations not addressed in this manual.
If you cannot remedy a system problem using the methods outlined in this manual,
contact your NHA support personnel.
Any change or modifications to the construction of this device which is not
expressly approved of by the party responsible for compliance could void the user’s
warranty.
<Note!>
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his expense.
CAUTION
1. To reduce the risk of fire, use only No. 26 AWG OR LARGER Telecommunication
cord
2. There is a risk of explosion if the battery is replaced with an incorrect type.
Dispose of used batteries according to the instructions.
3. For pluggable equipment, the socket-outlet shall be installed near the equipment
and shall be easily accessible.
4. The equipment is to be secured to the building structure before operation.
5. A security container shall be permitted to optionally be provided with a secondary
lock, but improper use of the secondary lock feature will reduce the security level
of the MS400A.

Installation Manual Chapter 1 Introduction
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 1-5
Caution Symbols
#
Symbol
Description
1
Electrical Shock Warning
▪Do not remove cover. Only a maintenance engineer is
allowed to open the cover.
▪Do not touch. You may receive electric shock.
▪Make sure to turn off the power when servicing the
equipment.
2
High Temperature Warning
▪Do not touch the equipment when it is running.
▪The equipment can get extremely hot and may cause a
burn.
▪Make sure to close the cover before running the
equipment.
3
Use Precaution when Moving
▪The equipment is heavy. Make sure at least 2 people lift or
move the equipment.
▪Do not attempt to move the equipment alone. You may be
injured from dropping the heavy equipment.
4
Fire Hazard
▪Place the equipment in an area away from any
combustible materials.
▪The equipment may catch on fire from overheating or
short circuit of the power supply unit.
5
Disassembly Warnings
▪Do not disassemble or modify the equipment unless you
are a certified engineer.
▪Contact the service center for maintenance, adjustments
and repairs.
▪Improper disassembly may cause fire or electrical shock.
6
Collapse Precautions
▪Do not place the equipment where the floor cannot sustain
the weight of the equipment, or on slanted or unstable
surface.
▪Equipment may fall and cause injury or damage.
7
Unplug the Equipment
▪Stop using the equipment immediately if it smokes, emits
an unusual smell, makes abnormal sounds, or if liquids or
other foreign materials enter the equipment.
▪If the above-mentioned abnormalities occur, immediately
turn off the power, unplug the equipment and contact the
service center.
▪If you ignore these symptoms, the equipment may catch
on fire or cause electric shock.

Installation Manual Chapter 1 Introduction
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 1-6
Related Documents
The following documents complement this one.
MS400A Hardware Operator Guide
MoniPlus VDM Manual
MS400A Error Code Manual
Contact your NHArepresentative to obtain copies of these documents.

Installation Manual Chapter 2 Installation Information
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 2-1
Chapter 2 Installation Information
Installation Environment and Spacing
When you select the permanent location for your MS400A, ensure that the physical
environment meets the recommended temperature and humidity specifications
supplied with the unit.
The following conditions should be met before installing the equipment.
1. Avoid locations where intense, direct light is reflected off the LCD screen.
2. Avoid locations where strong static electricity can occur.
3. The floor must allow easy wheelchair access from the front or the side when
necessary.
4. Space required for servicing the machine should be considered before installation.

Installation Manual Chapter 2 Installation Information
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 2-2
Dimensions
The figure below shows the dimensions of the MS400A viewed from the front.

Installation Manual Chapter 2 Installation Information
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 2-3
The figure below shows the dimensions of the MS400A viewed from the side.

Installation Manual Chapter 2 Installation Information
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 2-4
Recommended Installation and Service Clearances
The following diagrams show the recommended installation and servicing areas for the
MS400A.
Recommended Installation and Service Clearance Area – Areal View

Installation Manual Chapter 2 Installation Information
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 2-5
Recommended Installation and Service Clearance Area – Side Views

Installation Manual Chapter 3 System Installation
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 3-1
Chapter 3 System Installation
Unpacking the MS400A
Use the following instructions to unpack the MS400A with it on the palette.
1. Cut the straps that are fastened around the box with a knife. (Be careful when cutting the
straps. Refer to figure below.)
2. Use an appropriate tool to remove the nails from the palette. (Refer to figure below.)
3. Remove the lid, and then remove the box from the top. Do not discard the packaging materials
until you have verified any shipping damage claim. Contact your distributor immediately if you
see any shipping damage. Store the box in a safe place to re-use or discard of appropriately.
4. Verify the contents carefully against the packing list to be sure all items listed are included.
Notify your distributor of any shortages.
5. If only the palette needs to be removed, lift the whole machine from the bottom and set it aside.
(See instructions and Caution below.)
To remove the MS400A from the palette:
1. Remove the bolts from the locking bracket.
2. Remove the adjustor with a spanner.
3. Lift the MS400A using an adequate lifting device.
4. Move the MS400Ato the installation site.
CAUTION:
The MS400A is very heavy and can cause injuries if not handled carefully. Read the following
carefully.
▪Firmly close the vault door and lock the door by turning the knob completely.
▪Use only experienced movers to move the MS400A.
▪Do not tilt the MS400A when moving it.

Installation Manual Chapter 3 System Installation
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 3-2
Bolting Down the MS400A
To bolt down the MS400A using the Anchor Bolt Location Sheet (template), perform
the following steps:
1. Ensure that the surface where the MS400Ais to be placed is level so that the unit
will not tip over when opening the upper/lower modules or the door.
2. Place the anchor bolt location sheet where the MS400A is to be installed.
3. Drill the correct diameter and depth holes at the locations marked on the sheet.
4. With the groove of the anchor bolt facing up, drive the anchors into the holes
drilled in step 3. (4 places)
5. Place the MS400Aon the bolt location sheet, matching the mounting holes of the
unit with the anchors.
6. Firmly tighten the mounting bolts in the anchors.

Installation Manual Chapter 3 System Installation
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 3-3
Anchor bolts location sheet sample

Installation Manual Chapter 4 Notes
© 2014 Nautilus Hyosung Inc. All Rights Reserved. 4-1
Chapter 4 Notes
