Calculite®Incandescent Surface Cylinder 7026AO
Page 1 of 2 9” Aperture BR40 / R40 / PAR38
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Features
1. Reflector: 16 ga. Specular clear Alzak®aluminum. 50° visual cut-off to lamp
and lamp image .
2. Housing: One piece spun 16 ga. aluminum with returned bottom edge to
seat reflector, no visable hardware.Matte white baked enamel finish.
3. Retaining Springs: Coil steel springs secure reflector to housing.
4. Heat Insulltor: Fiberglass bulk insulation.
5. Socket: Medium base porcelain, nickel plated screw shell.
Options & Accessories
Stem Kit: 7249 Matte white
Permits surface units to be stem mounted. Supplied with 1/2" dia.
and 5 1/2" dia. canopy. 37 5/8" O.A. Length. Stem can be cut to
length at the job site. Self aligning swivel provides up to 41° verti-
cal adjustment.
Other reflector and housing finishes consult factory.
Electrical
Requires 75°C Supply wires. No.18 SF-1 leads to porcelain socket.
Labels
UL Listed for damp locations, I.B.E.W.
Catalog Number Lamp
7026AO Matte white housing with specular clear reflector PAR38,150W (cool beam)
PAR38, 250W (T.H.)
R40, 300W
BR40, 300W
Alzak®is a registered trademark of ALCOA.

Conversion Factors:
Use quick calculator chart to determine spacing of luminaires for desired level of illumination.
75W & 65W IR PAR38 FL, F.C. X 0.3
90W PAR38 FL, F.C. X 0.4
120W PAR38 FL, F.C. X 0.5
100W PAR38 FL IR, F.C. X 0.6
(6' x 6' x 8.5' room)
(12' x 12' x 8.5' room)
(60' x 60' x 8.5' room)
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
3600 Lumens Per Lamp
RCR = 10
RCR = 5
RCR = 1
Clear Alzak with 250W PAR38 FL, T.H.
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
151413121110987654
225200175150125100755025
100
90
80
70
60
50
40
30
20
10
(6' x 6' x 8.5' room)
(12' x 12' x 8.5' room)
(60' x 60' x 8.5' room)
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
3600 Lumens Per Lamp
RCR = 10
RCR = 5
RCR = 1
Clear Alzak with 250W PAR38 FL, T.H.
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
151413121110987654
225200175150125100755025
100
90
80
70
60
50
40
30
20
10
COEFFICIENTS OF UTILIZATION
%
EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
0
.88
.87
.86
.84
.83
.82
.81
.79
.78
.77
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10
1 1.02 1.01 .99 1.00 .99 .98 .96 .96 .95 .93 .93 .92 .90 .90 .89
2 .98 .96 .94 .97 .92 .93 .94 .93 .91 .92 .91 .90 .89 .89 .88
3 .95 .93 .91 .94 .92 .91 .93 .91 .89 .91 .89 .88 .89 .88 .87
4 .93 .91 .89 .92 .90 .88 .91 .89 .87 .89 .87 .86 .88 .86 .85
5 .91 .88 .86 .90 .87 .86 .89 .87 .85 .88 .86 .84 .86 .85 .84
6 .89 .86 .85 .89 .86 .84 .88 .85 .84 .87 .85 .83 .86 .84 .83
7 .87 .85 .83 .87 .84 .82 .86 .84 .82 .82 .83 .81 .84 .83 .81
8 .86 .83 .81 .82. .83 .81 .84 .82 .81 .84 .82 .81 .84 .82 .80
9 .84 .82 .80 .84 .81. 80 .83 .81 .79 .83 .80 .79 .82 .80 .79
10 .82 .80 .78 .82 .80 .78 .82 .79 .78 .81 .79 .78 .81 .79 .77
% WALL REFLECTANCE
COEFFICIENTS OF UTILIZATION
%EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
0
.81
.79
.76
.74
.72
.70
.67
.65
.63
.61
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
Conversion Factor:
65W to 120W BR40FL, C.U. x 1.0; 300W R40FL, C.U. x .95
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10
1 .94 .93 .91 .93 .91 .90 .89 .88 .87 .86 .85 .85 .83 .83 .82
2 .90 .88 .86 .89 .87 .85 .86 .85 .83 .84 .83 .81 .82 .81 .80
3 .87 .84 .82 .86 .83 .81 .84 .82 .80 .82 .80 .79 .80 .79 .78
4 .84 .81 .78 .83 .80 .78 .81 .79 .77 .80 .76 .76 .78 .77 .75
5 .80 .77 .75 .80 .77 .74 .78 .76 .74 .77 .75 .73 .76 .74 .73
6 .78 .75 .72 .77 .74 .72 .76 .74 .72 .75 .73 .71 .74 .72 .71
7 .75 .72 .69 .75 .72 .69 .74 .71 .69 .73 .70 .68 .72 .70 .68
8 .73 .69 .67 .72 .69 .67 .71 .69 .67 .71 .68 .66 .70 .68 .66
9 .70 .67 64 .70 .67 .64 .69 .66 .64 .69 .66 .64 .68 .65 .64
10 .68 .65 .62 .68 .65 .62 .67 .64 .62 .67 .64 .62 .66 .64 .62
% WALL REFLECTANCE
ANGLE MEAN CP LUMENS
0 12498
5 11063 1009
10 7681
15 4689 1319
20 2148
25 677 416
30 88
35 18 21
40 9
45 0 2
50 0
55 0 0
60 0
65 0 0
70 0
75 0 0
80 0
85 0 0
90 0
CERTIFIED TEST REPORT NO. 0870FR
COMPUTED BY LSI PROGRAM **TEST-LITE**
SURFACE CYLINDER OPEN DOWNLIGHT
8” DIA. APERTURE, SPECULAR CLEAR FINISH REFLECTOR
250W PAR38 FL (KRYPTON) PHILIPS LAMP. LUMEN RATING = 3100 LMS.
TESTED ACCORDING TO IES PROCEDURES.
TEST DISTANCE EXCEEDS FIVE TIMES THE
GREATEST LUMINOUS OPENING OF
LUMINAIRE.
ZONE LUMENS % LAMP % LUMINAIRE
0–30 2743 88.50 99.17
0–40 2764 89.18 99.93
0–60 2766 89.24 100.00
0–90 2766 89.24 100.00
40–90 1 .06 .07
60–90 0 .00 .00
90–180 0 .00 .00
0–180 2766 89.24 100.00
** EFFICIENCY = 89.2% **
ZONAL LUMENS AND PERCENTAGES
CANDLEPOWER SUMMARY
ANGLE MEAN CP LUMENS
0 3418
5 2993 280
10 2325
15 1771 508
20 1295
25 791 381
30 413
35 134 150
40 72
45 0 14
50 0
55 0 0
60 0
65 0 0
70 0
75 0 0
80 0
85 0 0
90 0
CERTIFIED TEST REPORT NO.0869FR
COMPUTED BY LSI PROGRAM **TEST-LITE**
SURFACE CYLINDER DOWNLIGHT
8” DIA. APERTURE, SPECULAR CLEAR FINISH REFLECTOR
120W BR40 FL GE LAMP. LUMEN RATING = 1600 LMS
TESTED ACCORDING TO IES PROCEDURES.
TEST DISTANCE EXCEEDS FIVE TIMES THE
GREATEST LUMINOUS OPENING OF
LUMINAIRE.
ZONE LUMENS % LAMP % LUMINAIRE
0–30 1167 73.00 87.70
0–40 1317 82.35 98.95
0–60 1331 83.23 100.00
0–90 1331 83.23 100.00
40–90 14 .88 1.05
60–90 0 .00 .00
90–180 0 .00 .00
0–180 1331 83.23 100.00
** EFFICIENCY = 83.28% **
ZONAL LUMENS AND PERCENTAGES
CANDLEPOWER SUMMARY
Conversion Factors:
Use quick calculator chart to determine spacing of luminaires for desired 
level of illumination. 
75W BR40 FL, F.C. X 0.5
90W BR40 FL, F.C. X 0.7
300W R40 FL, F.C. X 2.2
(6' x 6' x 8.5' room)
(12' x 12' x 8.5' room)
(60' x 60' x 8.5' room)
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
1600 Lumens Per Lamp
RCR = 10
RCR = 5
RCR = 1
Clear Alzak with 120W BR40 FL
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
11109876543
12010080604020
80
70
60
50
40
30
20
10
(6' x 6' x 8.5' room)
(12' x 12' x 8.5' room)
(60' x 60' x 8.5' room)
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
1600 Lumens Per Lamp
RCR = 10
RCR = 5
RCR = 1
Clear Alzak with 120W BR40 FL
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
11109876543
12010080604020
80
70
60
50
40
30
20
10
SPACING RATIO = 0.5
SPACING RATIO = 0.4
Conversion Factor: 45W to 250W PAR38 FL, C.U. x 1.0
DATE: JUL 30, 1999
PREPARED FOR:
LIGHOLIER, FALL RIVER, MA
DATE: JUL 30, 1999
PREPARED FOR:
LIGHOLIER, FALL RIVER, MA
Calculite®Incandescent Surface Cylinder 7026AO
Page 2 of 2 9” Aperture BR40 / R40 / PAR38
