Lightolier SC4WC232 User manual

Features
• UL-Listed for wet locations.
• Silicone sealed body.
• For industrial or commercial applications.
• Crisp modular design.
• Available in 4' one piece body.
• Continuous closed-cell gasketing at all seal points.
• Smooth one-piece water-clear acrylic lens.
• Lock-tight cam-action latches.
• Water-tight hubs for electrical feed.
• Construction meets NYC Code requirements.
Mounting Methods Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2002 Lightolier Section 7/Folio Q30-22 Rev. B
SC Cleanlite Enclosed Industrial Fluorescent SC4WC232
Page 1 of 2 Wet Locations, 1 or 2 Lamp T8
heavy-duty cam-action latches
fully enclosed and gasketed
crisp modular profile water-tight hubs

SC Cleanlite Enclosed Industrial Fluorescent SC4WC232
Page 2 of 2 Wet Locations, 1 or 2 Lamp T8
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2002 Lightolier Section7/Folio Q30-22 REV. B
Job Information Type:
Ordering Information
Explanation of Catalog Number. Example: SC4WC232120SOTP†
Options/Accessories
Tamperproof Latches: Suffix: TP
Optional Lenses: Lexan lenses or DR acrylic lens. Consult factory.
Water Tight Kits: All fixtures are furnished with one watertight hub kit for top
or end conduit entry. Additional water tight kits required for every entry. Catalog
Number: GWHB CSP. For coupling kits required for continuous row mounting.
Catalog Number: KWCP CSP
Specifications
Materials: Chassis shall be 20 gauge steel.
Wireway Cover: Full length retained by fasteners for quick removal and
convenient servicing.
Lens: One-piece flanged lens enclosure molded from .125" thick smooth water-
clear virgin acrylic. Lens enclosure shall be heavy-duty vapor tight enclosed and
gasketed with closed-cell foam gasketing (permanently attached to fixture
housing).
Latches: Lock-tight cam action.
Finish: Chassis shall be phosphate primed and finished in baked white acrylic
enamel for not less than 86% reflectivity.
Electrical: Thermally protected class “P” ballast C.B.M. approved, non PCB. If
K.O. is within 3" of ballast, use wire suitable for at least 90°.
Labels: I.B.E.W./UL and ULc Listed.
Photometry Model No. SC4WC232120SO
REPORT NUMBER: G92060 DATE: 7/2/02
CATALOG NUMBER: SCC232120SO
LAMP(S): 2 F32T8, EACH RATED 28 0 LUMENS.
LUMINAIRE: 4 FT ENCLOSED INDUSTRIAL
TRIAD B432I120RH-A
CANDELA DISTRIBUTION
0.0 22. 4 .0 67. 90.0
0 1032 1032 1032 1032 1032
1022 1027 1034 1042 1047
1 .0 979 1000 1020 1043 10 7
2 .0 899 934 992 1046 1068
3 .0 78 839 940 1028 10 8
4 .0 642 72 870 101 1070
.0 473 86 818 94 983
6 .0 290 462 667 773 806
7 .0 124 312 493 616 6 3
8 .0 27 162 311 421 4 8
90.0 12 10 231 333 367
ZONAL LUMEN SUMMARY
ZONE LUMENS % LAMP % FIXT
0-30 846 1 19
0-40 1431 2 32
0-60 2792 49 62
0-90 4170 73 92
90-180 3 0 6 8
0-180 4 20 79 100
TOTAL LUMINAIRE EFFICIENCY = 79.0%
CIE TYPE – DIRECT
PLANE: 0-DEG 90-DEG
SPACING CRITERIA; 1.21 1. 6
SHIELDING ANGLES: 90 90
PLANE: 0-DEG 90-DEG
LUMINOUS LENGTH: 46.000 8.1 6
LUMINANCE DATA IN CANDELA/SQ M
ANGLE AVERAGE AVERAGE AVERAGE
IN DEG 0-DEG 4 -DEG 90-DEG
4 42 6 4473 1 6
3770 4644 139
6 3020 4376 4769
7 1939 3978 4608
8 903 3389 41 9
90°
7 °
60°
4 °
30°
1 °
0°
0
268
3
803
1070
LEGEND;
0-deg
4 -deg
90-deg
G92060 7/2/02
SC4WC232120SO
2 F32T8, EACH RATED 28 0 LUMENS
4 FT ENCLOSED INDUSTRIAL
TRIAD B2321120RH-A
THIS REPORT IS BASED ON PUBLISHED INDUSTRY PROCEDURES • FIELD PERFORMANCE MAY VARY FROM LABORATORY PERFORMANCE.
coefficients of utilization — zonal cavity method
RF 20 20 20
RC 80 50 30
RW 70 50 30 50 30 10 50 30 10
1807571 716865 676462
2716458 605651 575349
3645649 524742 494440
4584942 464035 433834
5534336 413430 393329
6493931 373026 352925
7453528 332722 312622
8423225 302420 292319
9392922 282218 262117
10 37 27 20 25 20 16 24 19 16
room cavity ratio
SC
Cleanlite:
Industrial
Fluorescent for
Wet Locations
Number of
Lamps in
Width:
1 or 2 Lamps
32
Lamp/Watts
(By others)
32 = 32w T8
(Nominal 48")
Voltage:
120 or 277 Options:
Add appropriate
suffix to catalog
no, ie: (TP)
Ballast:
<20THD <10THD
1 & 2 Lamp Elec. (T8) SO* HI*
*Instant Start Standard
4
Fixture
Length
4 = 4' Length
W
Location:
W =Wet Locations
C
Lens:
C = Clear Lens
†No Product Change. New Catalog Number Designation.
WATER TIGHT HUB KIT Cat. No. GWHB CSP
Universal waterproof
fitting for conduit
entrance or stem mounting
Rubber
gasket
Knockout Weatherproof
fitting
Housing end
or top
COUPLING KIT Cat. No. KWCP CSP
Housing End
Housing
End
Knockout
Knockout
Threaded
coupling
Rubber Gasket
Lock
nut
Lock
nut
