Lightolier Lytespan 23F70T6 User manual

Lytespan®Track Lighting System 23F70T6
Page 1 of 2 Alcyon HID 70W CMH T6 G12 Rectangular Flood
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0308
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier is a Philips group brand
2 3/8"
[60 mm]
6 7/16 "
[163 mm]
1 1/16"
[27 mm]
8 1/16"
[204 mm]
1 7/16"
[37 mm]
4 1/2"
[114 mm]
1/4"
[6 mm]
7 5/16"
[186 mm]
4 7/8 "
[124 mm]
8 5/8 "
[219 mm]
3 9/16 "
[90 mm]
3"
[77 mm]
Ordering Information
Catalog No. Finish Mounting Lamps
23F70T6AL Aluminum For use with Lytespan Radius, Basic and Advent 70W T6 G12 Base Ceramic Metal Halide
23F70T6BK Black Track. Not compatible with extension wands
23F70T6WH White or slope ceiling adapters. For monopoint
applications refer to spec sheet 6173.
Features
1. Track Attachment Fitting: Locking lever for mechanical/
electrical connection.
2. Brass Contact: Extends for connection to second circuit (Advent track only).
3. Horizontal Pivot: Wireless stem profile with 365˚ horizontal rotation.
Position may be locked using an allen key.
4. Vertical Pivot: 0-180˚ vertical adjustment with aiming indicator.
Position may be locked using an allen key.
5. Fixture Housing: Die cast aluminum
6. Ballast Housing: Die cast aluminum
7. Lamp Cartridge: Allows easy side relamping without removal of
glass shield.
8. Safety Lens: Tempered 1/8" glass. Meets or exceeds UL safety requirement
for metal halide lamps.
9. On/Off Switch: Rocker switch to disconnect power to the ballast.
10. Safety Locking Lever: Locks ballast housing to track.
Finish
All Painted finishes are baked enamel.
Accessories
None
Electrical
Electronic Ballast
Input Voltage: 120V
Power Factor: High
Input Power: 77W
Max. Input Current: 0.64A
ANSI Code: M139, M143, M98
Do not use on dimming circuit.
Labels
UL, cUL
1
3
4
5
7
8
6
10
9
2

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • C0308
Lightolier is a Philips group brand
Lytespan®Track Lighting System 23F70T6
Page 2 of 2 Alcyon HID 70W CMH T6 G12 Rectangular Flood
Distance From Ceiling
Lamp Information:
70W CDM T6 Single Ended Metal Halide.
Initial Lumens: 6600
CRI: 82
Rated Avg. life: 9,000 - 15,000 hrs.
For 39W Multiply by 0.5.
Lighting Data
1' 153 129 70 30 13 6
2' 127 111 73 38 16 6
3' 85 76 56 34 17 7
4' 57 51 40 28 16 9
5' 39 35 20 21 13 8
6' 26 25 20 16 11 7
7' 17 16 14 11 9 6
8' 12 11 10 8 7 5
9' 8 8 7 6 5 4
104 150 184
159 149 159
120 118 120
93 90 93
67 65 67
53 52 53
39 38 39
29 29 29
23 23 23
Footcandles on Wall
Track 3 Feet From Wall Single Unit Multiple Units
4'
163 63 163
132 76 132
90 69 91
67 59 68
47 42 47
37 35 37
27 26 27
20 20 20
16 16 16
6'
3'
50°
EXAMPLE: With track located 4' from wall and multiple units spaced
8' on center and aimed 50˚ from horizontal, the illumination on wall 4'
from ceiling will be 50.c. beneath units and 37 f.c. between units.
1' 72 67 46 24 9 3
2' 84 76 56 36 19 9
3' 65 61 48 34 21 11
4' 48 45 38 29 19 12
5' 35 33 28 23 17 11
6' 26 25 21 18 14 10
7' 20 19 17 14 11 8
8' 15 14 13 11 9 7
9' 11 11 10 9 7 6
77 57 77
91 72 91
74 69 74
60 57 60
47 45 47
38 36 38
31 28 31
24 22 24
19 18 19
15 14 15
12 11 12
10 9 10
76 23 76
87 37 87
67 41 67
50 37 50
38 32 38
31 26 31
24 21 24
19 17 19
15 14 15
12 11 12
10 9 10
8 7 8
75 7 75
86 15 86
66 21 66
49 22 49
36 21 36
28 19 28
21 16 21
16 13 16
13 11 13
10 9 10
8 7 8
6 6 6
Track 4 Feet From Wall Single Unit Multiple Units
6' * 8' * 10' *
4'
Distance From Ceiling
Footcandles are average and rounded off and data for multiple units are based on a minimum of five units.
Footcandles on wall:
4'
50ϒ
6'
4'
50 f.c.
37 f.c.
50 f.c.
0' 1' 2' 3' 4' 5'
0' 1' 2' 3' 4' 5'
Beam Center
Beam Center
169 98 169
139 109 139
99 91 99
76 73 76
54 52 54
43 41 43
31 31 31
23 23 23
19 19 19
5'
50°
For 39W: Multiply values by 0.5 Rated Lamp Life 9,000 - 12,000 Hrs.
