Lightolier QVS2GPFOS2FT User manual

Mounting Methods / Features Dimensions
Microperforated mesh
lamp shields
Also available with solid opaque swing-
down lamp shield
Ceiling compatibility
Suited to standard exposed
T-grid ceilings
Swing down optical system for
easy relamping and maintenance
Suited to standard exposed
Slot T-grid ceilings
ALTER SOFT LIGHTS QVS2GPFOS2FT 2X40W
Page 1 of 2 2’ X 2’ RECESSED DIRECT/INDIRECT FLUORESCENT 2 LAMP, TT5 BI-TUBE,
5 1/2” DEEP MICROPERFORATED MESH LAMP SHIELD, STATIC
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L10-25
Features
•Efficiency 58.5%.
•Dual swing down microperforated lamp shields
separated by luminous strip for easy relamping and
maintenance.
•Alter soft white film on inside of mesh conceals lamp
image providing balance between reflected and direct
light.
•Fully recessed luminaire and with two separate lamp
compartments.
•95% Reflective Alter soft white paint finish.
•Specular interior reflector.
•One piece body for easy installation.
•Exclusive socket locks lamp into place.
•Easy access to ballast through lamp compartment.
•Fits standard T-Grid ceilings.
•Optional acrylic drop-down visual element.

Ordering Information Explanation of Catalog Number Example: QVS2GPFOS2FT120BE
QUALITY
VISUAL
STATIC
Recessed direct
indirect soft
light
optical system
FIXTURE
WIDTH:
2’
CEILING TYPE:
Standard
exposed
T-grid ceilings
LAMP SHIELD:
PF = Microperforated
SD = Solid
LAMP QUANTITY
LAMP/FIXTURE
LENGTH:
(Nominal 24”)
FT = TT5
Bi-Tube
VOLTAGE:
120V
277V
347V
Specifications
MATERIALS: One piece chassis constructed from die formed 20 gauge cold
rolled steel. Reflectors - 95% reflectance baked white acrylic matte paint finish.
Specular aluminum interior reflector. Soft white acrylic film on inside of lamp
shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic matte
paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast (Bi-tube
type). If K.Os are within 3” of ballast use wire suitable for at least 90C.
LABELS: Listed by
QVS 2 G 2 FT
BALLAST:
BE = 50W Electronic TT5 RS
BR =40W Electronic TT5 RS
BX =40W Magnetic TT5 RS
PB = 40W TT5 PowerSpec Dimming*
PC = 50/55W TT5 PowerSpec Dimming*
SB = 40W Generic Electronic TT5
*Not available in 347V.
OPTIONS:
R= Radio Interference Filter
O= Emergency Lighting System
(for Canada)
N= Emergency Lighting System
(for U.S.)
CLEAR POLISHED ACRYLIC DROP
DOWN VISUAL ELEMENT:
OS = Open slot (no acrylic)
OP = One Piece (no center slot)
GC = Clear acrylic
GG = Clear acrylic / Green pro
jected color face
GB = Clear acrylic / Blue pro-
jected color face
GR = Clear acrylic / Red pro-
jected color face
ALTER SOFT LIGHTS QVS2GPFOS2FT 2X40W
Page 2 of 2 2’ X 2’ RECESSED DIRECT/INDIRECT FLUORESCENT 2 LAMP, TT5 BI-TUBE,
5 1/2” DEEP MICROPERFORATED MESH LAMP SHIELD, STATIC
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L10-25
Job Information Type:
Photometry
