DL18 IC/DL19 IC system
User manual

Page 2 of 24
Contents
Preface........................................................................................................................................... 3
Valid for ........................................................................................................................................ 4
Important information ............................................................................................................... 5
Safety instructions....................................................................................................................... 4
Safety issues............................................................................................................................. 5
Before installation, reinstallation or troubleshooting .................................................................. 6
Before start-up ......................................................................................................................... 6
During operation....................................................................................................................... 6
Misc ........................................................................................................................................ 6
Only for EU markets..................................................................................................................... 7
Only for Non-EU markets ............................................................................................................ 7
Misuse ........................................................................................................................................... 7
Repairs........................................................................................................................................... 8
Declaration of incorporation of partly completed machinery .............................................. 8
Declaration of Conformity .......................................................................................................... 9
Misc. on the DESKLINE®DL18 IC / DL19 IC system ............................................................... 12
Warranty ................................................................................................................................ 12
Maintenance .......................................................................................................................... 12
ETL-marking .................................................................................................................................13
Description of the DESKLINE®DL18 IC / DL19 IC system ...................................................... 15
Mounting guidelines for the DESKLINE®DL18 IC / DL19 IC system .....................................15
Mount the motor housing ....................................................................................................... 15
Mounting the feet ................................................................................................................... 16
Mounting crossbar................................................................................................................... 17
Mounting the tabletop............................................................................................................. 17
Placing the monitor.................................................................................................................. 17
Connection.............................................................................................................................. 19
Accessories and repair ............................................................................................................... 20
Disposal of LINAK products ...................................................................................................... 21
Labels............................................................................................................................................ 22
Drawing appendix .......................................................................................................................23
LINAK application policy ........................................................................................................... 30
Addresses .................................................................................................................................... 31

Page 3 of 24
Preface
Dear User,
We are delighted that you have chosen a product from LINAK®.
LINAK systems are high-tech products based on many years of experience in the manufacture and development
of actuators, electric control boxes, controls and chargers.
This User Manual does not address the end-user. It is intended as a source of information for the manufacturer
of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It
is the responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety
information from this manual is passed on to the end-user.
We are sure that your LINAK product/system will give you many years of problem-free operation.
Before our products leave the factory, they undergo full function and quality testing. Should you nevertheless
experience problems with your LINAK product/system, you are always welcome to contact your local contact.
LINAK subsidiaries and some distributors situated all over the world have authorised service centres, which are
always ready to help you.
LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance
with the specifications, maintenance being done correctly and any repairs being carried out at a service centre,
which is authorised to repair LINAK products.
Changes in installation and use of LINAK products/systems can affect the operation and durability of the
products/systems. The products are not to be opened by unauthorised personnel.
The User Manual has been written based on our present technical knowledge. We are constantly working on
updating the information and we therefore reserve the right to carry out technical modifications.
LINAK A/S

Page 4 of 24
Valid for:
This User Manual is valid for the following products:
(See the first 3 - 5 characters on the label)
Columns: 2 lifting columns DL18 IC / DL19 IC
Power supply: SMPS001, SMPS002 or SMPS006
Controls: DPA / DPB / DPH / DP1K / DPF1K / DPG1K

Page 5 of 24
Important information
Important information on LINAK®products can be found under the following
headings:
Warning!
Failure to comply with these instructions may result in accidents involving
serious personal injury.
Failing to follow these instructions can result in the product being damaged
or being destroyed.
Safety instruction
General
Safe use of the system is possible only when the operating instructions are read
completely and the instructions contained are strictly observed.
Failure to comply with instructions marked with the ”NOTE” symbol may result in
serious damage to the system or one of its components.
It is important for everyone who is to connect, install, or use the systems to
have the necessary information and access to this User Manual. Follow the
instructions for mounting - there is a risk of injury if these instructions are not
followed.
The appliance is not intended for use by young children or infirm persons
without supervision.
If there is visible damage to the product, do not install it.
Please note that during construction of applications in which the actuator
is to be fitted, there must be no possibility of personal injury, for example
squeezing of fingers or arms.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system.
The power supply shall not be covered while operating to allow sufficient
cooling of this appliance.
...to be continued

Page 6 of 24
Furthermore take care about the connecting wires from the power supply to the
DL19 IC system, don’t damage this by overrun.
Assure free space for movement of the application in both directions to avoid
blockades.
The appliance is only to be used with the power supply unit provided with
the appliance.
Safety issues
The builder of the equipment shall ensure that the use of the component
complies with relevant standards – like the Machine Directive. Care must be
taken to avoid squeezing of cables as it can cause movement of the system!
The SMPS001 / SMPS002 / SMPS006 must not be packed in heat insulating
material, but must be placed so that it can emit waste heat to the surroundings.
There are no ventilation holes to consider, the SMPS emits heat through its
surface.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system.

Page 7 of 24
Before installation, re-installation, or troubleshooting:
• Stop the DL.
• Switch off the power supply and pull out the mains plug.
• Relieve the DL of any loads, which may be released during the work.
Before start-up:
• Make sure that the system has been installed as instructed in this User Manual.
• Make sure that the voltage of the control box is correct before the system is
connected to the mains.
• System connection. The individual parts must be connected before connecting the
control box to the mains. See the User Manual for LINAK actuators, if necessary.
During operation
• If the column makes unusual noise or smells, switch off the mains voltage
immediately.
• Take care that the cables are not damaged.
• Unplug the mains cable on mobile equipment before moving it.
• The products must only be used in an environment that corresponds to their IP
protection.
Misc.
The actuator system has a sound level below 55 dB (A) in typical applications.
Updated manuals and declarations can always be found here:
www.linak.com/deskline

Page 8 of 24
Only for EU markets
This appliance can be used by children aged from aged 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Only for Non-EU markets
Persons who do not have the necessary experience or knowledge of the
product/products must not use the product/products. Besides, persons with
reduced physical, sensory or mental abilities must not use the product/products,
unless they are under surveillance or they have been thoroughly instructed in
the use of the apparatus by a person who is responsible for the safety of these
persons.
Moreover, children must be under surveillance to ensure that they do not play
with the product.
It is the operator’s responsibility to ensure that there is free space for the
application to move without risk for the operator or bystanders before
operating the application.
Misuse
Do not overload the actuators – this can cause danger of personal injury and
damage to the system.
Do not use the actuator system for lifting persons. Do not sit or stand on a
table while operating – risk of personal injury.
Do not use the system in environments other than the intended indoor use

Page 9 of 24
Repairs
In order to avoid the risk of malfunction, all DESKLINE®repairs must only be carried out by authorised LINAK workshops or
repairers, as special tools must be used and special gaskets must be fitted. Lifting units under warranty must also be returned
to authorised LINAK workshops.
Warning!
If any of the DESKLINE®products are opened, there will be a risk of subsequent malfunction.
Warning!
The DESKLINE®systems do not withstand cutting oil.
DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY
LINAK A/S
Smedevænget 8
DK -6430 Nordborg
Herewith declares that LINAK DESKLINE®products as characterized by the following models and types:
Control Boxes CBD6S
Linear ActuatorsDB5, DB6, DB7, DB9, DB12, DB14, DB16, LA23, LA31
Lifting ColumnsDL1A, DL2, DL4S, DL5, DL6, DL7, DL8, DL9, DL10, DL11, DL12, DL14, DL15,
DL16,DL17, DL19, BASE1
Desk PanelsDPA, DPB, DPH, DPF, DPG1K, DPG1M, DPG1B, DPG1C, DPT, DP1, DP1CS,
DP1K, DP1V, DP1U
RF ControlsHB10RF,HB20RF, RFT, RFRL
Accessories BA001, SLS, Kick & Click
comply with the following parts of the Machinery Directive 2006/42/EC,ANNEX I,Essential health and
safety requirements relating to the design and construction of machinery:
1.5.1 Electricity supply
The relevant technical documentation is compiled in accordance with part B of Annex VII and that this
documentation or part hereof will be transmitted by post or electronically to a reasoned request by the
national authorities.
This partly completed machinery must not be put into service until the final machinery into
which it is to be incorporated has been declared in conformity with the provisions of the
Machinery Directive 2006/42/EC where appropriate.
Nordborg, 2017-12-08
LINAK A/S
John Kling, B.Sc.E.E.
Certification and Regulatory Affairs
Authorized to compile the relevant technical documentation
Original Declaration

Page 10 of 24
DECLARATION OF CONFORMITY
LINAK A/S
Smedevænget 8
DK - 6430 Nordborg
hereby declares that LINAK Actuator System composed of:
Lifting Column with integrated control, DLIC Master: DLXXXXXXMXXXXXX or
DLXXXXXXMXXXXXX
And
Passive Actuators, DLIC Slave DLXXXXXXSXXXXXX or
DLXXXXXXSXXXXXX
And
Control panel DP1C, DP1K, DPT, DPB, DPF, DP1L, DP1V, DPA, DPH, DP1U,
WDPL1
complies with EMC Directive: 2014/30/EU according to following standards:
EN 61000-6-1:2007, EN 61000-6-3:2007, EN 55022:2010 Class B
complies with Low Voltage Directive 2006/95/EC according to the standards:
EN 60335-1:2012
complies with RoHS2 Directive 2011/65/EU according to the standard:
EN 50581:2012
And
RF Control: RFRL00x, HB1xRF3000, HB2xRFx000; RFT000
complies with the Radio Equipment Directive 2014/53/EU:
EN 300220-2:2006, EN 61000-6-1:2007, EN 61000-6-3:2007,
EN 60335-1:2012, EN 62311:2008
complies with RoHS2 Directive 2011/65/EU according to the standard:
EN 50581:2012
Nordborg, 2017-08-25
LINAK A/S
John Kling, B.Sc.E.E.
Certification and Regulatory Affairs
Authorized to compile the relevant technical documentation
Original Declaration
