Lincat Lynx 400 Operating instructions

IS317 ECN3016
User and Installation Instructions
Lynx 400 Pasta Boiler
LPB

IS317 ECN3016 2
Dear Customer,
Thank you for purchasing this Lincat Product.
This is just one of over 450 different items of catering equipment available from our range which is constantly being
extended and improved. Details are available from your local distributor or direct from us.
Used for the purposes for which it is intended, and with careful maintenance as outlined in this user Guide, your
Lincat product will give years of trouble free use.
IMPORTANT INFORMATION
Please read all of the safety and operating instructions carefully before using this product. Please pay
particular attention to all sections of this User Guide that carry warning symbols and notices.
WARNING!
This is a Warning symbol. This symbol is used throughout the user guide whenever there is a risk
of personal injury. Ensure that these warnings are read and understood at all times.
CAUTION!
This is a Caution symbol. This symbol is used throughout the User Guide whenever there is a risk
damaging your Lincat product. Ensure that these warnings are read and understood at all times.

IS317 ECN3016 3
SAFETY INSTRUCTIONS
TECHNICAL SPECIFICATION
WARNING!
Basic safety precautions, including the following, should be followed to reduce the risk of personal injury.
Make sure you have read all of these instructions before switching on the unit. Keep this User Guide in
a safe place for future reference for you and your staff.
GENERAL
Do not clean the unit with a water jet.
Do not try to modify this product.
Remove all plastic coatings and clean units before use.
Ensure that the electrical supply cable is not damaged. If the supply cable is damaged it should be replaced by Lincat
Ltd or other suitably qualified persons, in order to avoid a hazard.
Do not try to move this unit when the tank contains hot water
Disconnect the unit from the electric supply before servicing.
This unit must be earthed.
Maximum cooking quantities per basket:
Product BA157 Large Basket BA158 Small Basket
(Optional accessory)
Fusilli – Fresh 600g 200g
Spaghetti - Fresh 600g 200g
Penne - Fresh 600g 200g
Tagliatelle - Fresh 500g 200g
Potato Gnocchi - Fresh 500g 250g
Macaroni - Fresh 500g 200g
Pasta Shells - Fresh 400g 200g
Penne - Dried 600g 200g
Spaghetti - Dried 400g 150g
Tagliatelle - Dried 300g 125g
Model LPB
Width mm 270
Depth mm 400
Hob Height mm 205
Maximum Height mm 315
Power Rating watts 3000
Weight (net) kg 7.7
Water Capacity (max) litres 4.5

IS317 ECN3016 4
I
NSTALLATION
PACK CONTENTS
Electric pasta boiler (with cable and 13 Amp plug) Basket
4 x Rubber feet Basket Handle
User Guide 2 x Stainless Steel Screws
Guarantee Card Allen Key
Base Plate
Dust Cover Lid
Optional accessory: 2 x Small basket BA158.
Push rubber feet into base holes provided and ensure the unit is installed on a sound, level work surface,
which is heat resistant e.g. stainless steel or formica. Inform your personnel that external surfaces and base
will become hot.
For safety regulations, the plug must always be accessible .
To fix the basket handle to the basket use screws and allen key. Ensure the screws are inserted from
the inside of the basket.
CONNECTING TO THE ELECTRICITY SUPPLY
Ensure that the voltage of your electricity supply corresponds to the serial plate details. The product is supplied
with a 13 Amp plug. To replace the plug, follow these instructions:
•green and yellow wire to 'E' or (Earth)
•blue wire to 'N' (Neutral)
•brown wire to 'L' (Live)

IS317 ECN3016 5
OPERATING INSTRUCTIONS
4
36
2
7
1
5
Fig 1 – Model LPB
1 Base plate
2 Water markers (Max/min)
3 Green neon
4 Amber neon
5 Control head
6 Control knob
7 Basket support
Before first use:
•Disconnect the unit from the power supply. Remove the base plate, lift the control head out of the rear
channel (Fig 2) and clean the tank with a little hot water and mild detergent.
Note: The control head is fitted with a safety switch to cut off the power supply when it is lifted up.
•Replace tank. To replace the control head, lower it carefully into the rear channel. Replace the base plate.
•Fill the tank with water to a level between the markers (Fig 1) on the base plate. Do not exceed the
maximum amount (See Technical Specifications). Ensure water is above the minimum marker, using
boiling water when required. Note: One kilo of pasta will use approximately 1.5 litres of water.
Operating the unit:
•Connect the unit to the power supply. The green neon will light up. Turn the control knob to 6. The amber
neon will also light up. When the water has heated up to the set temperature, the amber neon will
extinguish. Fill the basket with food and lower carefully into the boiling water. Turn the control knob to
between 4 and 5.
The water level will rise considerably.
After cooking
•Place the basket with the cooked food into the slots in the basket support (Fig.1) to allow the water to drain.
Safety (High Limit) Thermostat
Lincat electric pasta boilers are fitted with a high limit thermostat. This prevents the unit from excessive damage
under a fault condition.
Ensure that this thermostat is not damaged during use and cleaning.

IS317 ECN3016 6
CLEANING AND MAINTENANCE
If the green neon lights up, but the element does not heat up, the safety thermostat may need to be reset.
To re-set the safety thermostat:
•The re-set button is located below the control head (See Fig 2) inside the access hole. Push
button upwards to re-set.
•If the thermostat needs re-setting repeatedly this indicates a fault with the pasta boiler and it
should be checked by a competent engineer.
3
2
1
Fig 2
1 Channel
2 Support Bar
3 Access Hole (Re-set Button)
CLEANING
Disconnect the unit from the electricity supply and ensure it is cool to touch before starting any maintenance or
cleaning. Use a mild detergent in hot water and a soft cloth. Do not use abrasive creams or scourers.
Remove basket and base plate, and slide control head up and lift off. Remove tank and pour away water.
Wipe the control head clean with a damp cloth – do not allow water to penetrate control head.
MAINTENANCE
Regular cleaning of the unit is recommended.
No regular maintenance is required.

IS317 ECN3016 7
SERVICE INFORMATION
GUARANTEE
For help with the installation, maintenance and use of your Lincat equipment, please contact our service department:
01522 875520
All service work, other than routine cleaning should be carried out by one of our authorised service agents. We
cannot accept responsibility for work carried out by other persons.
To ensure your service enquiry is handled as efficiently as possible, you need to have the following details available:
•Brief details of problem
•Product code, type number and serial number of unit (both on serial plate)
Lincat reserve the right to carry out any work under warranty during normal working hours, ie Monday to Friday,
08:30 a.m. – 17:00 p.m.
This unit carries a comprehensive UK twelve-month warranty. The guarantee is in addition to, and does not
diminish your statutory or legal rights.
The guarantee does not cover:
•Accidental damage, misuse (or use not in accordance with the instructions in this User Guide), or
consumable items.
•Damage due to incorrect installation, modification or unauthorised service work.
•The manufacturer disclaims any liability for incidental, or consequential damages.
