Section - F22 - 7D Form 404123MAR - 2012
MODEL 3866
PRESETABLE METERING CONTROL VALVE
Series “A”
SPECIFICATIONS:
Dial Capacity 1 to 16 Quarts/1 to 12 Liters
Totalizer Quarts
Flow Max. 4 Gallons per min. (15 liters per min.)
Flow Min. 0.4 Gallons per min. (1.5 Liters per min.)
Operating Pressure Max. 1000 PSI (70 Bar)
Operating Temp. Max. 110°F (45° C)
Accuracy +/- 0.65%
Weight 3.3 Lbs. (1.5 Kg.)
Meter Inlet & Outlet Thds. 1/2 NPTF (1/2 BSPP)
Graduation 1/2 Quart/1 Liter
© Indicates change
©
70457
BASIC METER
INDICATOR
KNOB
90464
SWIVEL
93548 NOZZLE
(NON-DRIP)
34210 O-RING
(Included with 93548 Nozzle.
May be purchased separately.)
1/2” NPTF (F)
Before meter can be placed in service “After Repair”, meter must
be tested and approved in accordance with U.S. Government’s
Weights and Measures Standards.
New metering systems must be purged prior to installation of
metering control valve to free system of contaminates.
OPERATION
The Meter can handle petroleum products such as automatic trans-
mission uid, S.A.E. 5 to 50 Wt. motor oil, S.A.E. 80 to 240 wt. gear
oil and antifreeze uid (ethylene glycol).
The preset meter is set by turning the knob counterclockwise to the
desired amount amount of material to be dispensed. The trigger is
then depressed and locked in the “on” position. The pointer knob
rotates clockwise towards zero where it strikes a pin in the meter face
above the “0” zero, which releases the lock bar automatically stopping
the ow.
IMPORTANT NOTE:
The automatic nozzle requires 60 PSI to open and function prop-
erly. A pump exceeding 60 PSI is required for adequate ow and
proper operation. A pump ratio of at least 3:1 is recommended.
IMPORTANT NOTE:
THIS UNIT IS NOT FOR RESALE OF PRODUCT AND IS NOT
SUBJECT TO RESALE TOLERANCES.
The meter can be stopped prior to dispensing the preset amount by ro-
tating the pointer manually clockwise until it strikes the pin above the
“0” zero, or by pushing the pin counterclockwise by hand thus leaving
the knob indicating the remaining amount to be dispensed.
Systems which will be dispensing uids under pressure may need to
be protected by using a thermal relief kit, which will safely limit the
pressures caused by thermal expansion. Please contact your local
Lincoln distributor and refer to Service Page Section K5, Page 31 for
more details. Failure to include thermal relief protection may cause
damage not covered under Lincoln’s warranty policy.
To order call 1-800-548-1191 or visit www.partdeal.com - [email protected]

Page Number - 2 Form 404123
If meter is mishandled, the lock bar
(item 16) can become bent and screw
may fail to contact lock pawl (Item 17) .
If this happens, the meter will not shut
off at preset amount, frequent inspec-
tion is recommended.
* May be purchased separately
** See valve assembly item 37
SERVICE PARTS
Item Part No. Qty. Description Item Part No. Qty. Description
1 242911 1 Shroud Protector 20 236400 1 Pin Lock Pawl
2 68410-12 1 Shroud 21 68410-2 2 Screw
3 66871 -5 4 Shroud Screw 22
4 242913 1 Knob Assembly 23 68410-4 2 Quad Ring
5 70457-1 1 Dial Assembly 24 69304-2 1 Cam
6 66871-3 2 Clutch Spring 25 69304-4 1 Trigger Assembly
7 66871-4 2 Clutch Roller 26 69304-24 1 Hand Guard
8 70457-3 1 Compound Gear Assembly 27 1 ** Valve Sleeve Assembly
9 70457-4 1 Preset Knob Drive Cam 28 1 ** Valve Seat Assembly
10 66871-54 1 Worm Assembly 29 69304-3 1 Spring
11 50541 1 Set Screw 30 68410-27 1 Screen
12 69304-23 1 Washer 31 243176 1 O-Ring
13 70457-7 4 Screw 32 243175 1 Adapter
14 69795-3 1 Register Assembly 33 66871-111 1 Upper Driving Pawl Gear Assembly
15 69304-14 1 E-Ring 34 68410-15 1 Chamber and Piston Assembly
16 69304-5 1 Lockbar 35 66871-12 1 O-Ring
17 69304-13 1 Lock Pawl 36 68410-14 1 Cap
18 69304-12 1 Lock Pawl Spring 37 271700 1 Valve Assembly
19 237388 1 Packing Kit
DO NOT TURN POINTER IN A
COLCKWISE DIRECTION AS THIS
WILL DAMAGE METER.
The pointer can only be returned to the
zero stop in a counterclockwise direc-
tion after delivery.
DIAL TOTALS 16 QUARTS/12 LITERS
GRADUATION 1/2 QUART/1 LITER
To order call 1-800-548-1191 or visit www.partdeal.com - [email protected]

Page Number - 3
Form 404123
Americas:
One Lincoln Way
St. Louis, MO 63120-1578
USA
Phone [phone]
Fax [phone]
Europe/Africa:
Heinrich-Hertz-Str 2-8
D-69183 Walldorf
Germany
Phone [phone]
Fax [phone]
© Copyright 2012
Printed in USA
Web site:
www.lincolnindustrial.com
Lincoln Industrial Standard Warranty
LIMITED WARRANTY
Lincoln warrants the equipment manufactured and supplied by Lincoln to be free from defects in material and workmanship for a period of one (1)
year following the date of purchase, excluding therefrom any special, extended, or limited warranty published by Lincoln. If equipment is determined
to be defective during this warranty period, it will be repaired or replaced, within Lincoln’s sole discretion, without charge.
This warranty is conditioned upon the determination of a Lincoln authorized representative that the equipment is defective. To obtain repair or
replacement, you must ship the equipment, transportation charges prepaid, with proof of purchase to a Lincoln Authorized Warranty and Service
Center within the warranty period.
This warranty is extended to the original retail purchaser only. This warranty does not apply to equipment damaged from accident, overload, abuse,
misuse, negligence, faulty installation or abrasive or corrosive material, equipment that has been altered, or equipment repaired by anyone not
authorized by Lincoln. This warranty applies only to equipment installed, operated and maintained in strict accordance with the written specica-
tions and recommendations provided by Lincoln or its authorized eld personnel.
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE WARRANTY OF MERCHANTIBILITY OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
In no event shall Lincoln be liable for incidental or consequential damages. Lincoln’s liability for any claim for loss or damages arising out of the
sale, resale or use of any Lincoln equipment shall in no event exceed the purchase price. Some jurisdictions do not allow the exclusion or limitation
of incidental or consequential damages, therefore the above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights. You may also have other rights that vary by jurisdiction.
Customers not located in the Western Hemisphere or East Asia: Please contact Lincoln GmbH & Co. KG, Walldorf, Germany, for your warranty
rights.
Lincoln Industrial Special Limited Warranties
SPECIAL LIMITED 2 YEAR WARRANTY-
SL-V Series, Single Injectors-85772, 85782, and Replacement Injectors-85771, 85781
Lincoln warrants the SL-V Injector series to be free from defects in material and workmanship for two (2) years following the date of purchase. If an
injector model (single or replacement) is determined to be defective by Lincoln, in its sole discretion, during this warranty period, it will be repaired
or replaced, at Lincoln’s discretion, without charge.
SPECIAL LIMITED 5 YEAR WARRANTY-
Series 20, 25, 40 Bare Pumps, PMV Bare Pumps, Heavy Duty and 94000 Series Bare Reels
Lincoln warrants series 20, 25, 40 bare pumps, PMV bare pumps, Heavy Duty (82206), Mini Bench (81133, 81323), and 94000 LFR series (94100,
94300, 94500) bare reels to be free from defects in material and workmanship for ve (5) years following the date of purchase. If equipment is
determined by Lincoln, in its sole discretion, to be defective during the rst year of the warranty period, it will be repaired or replaced at Lincoln’s
discretion, without charge. In years two (2) and three (3), the warranty on this equipment is limited to repair with Lincoln paying parts and labor
only. In years four (4) and ve (5), the warranty on this equipment is limited to repair with Lincoln paying for parts only.
SPECIAL LIMITED 5 YEAR WARRANTY-
LFM Series Oil Meters (Lincoln Fluid Meter), LFV (Lincoln Fluid Valves), AOD (Air-Operated Diaphragm Pumps)-
Lincoln warrants the LFM meter series (908/912 series), the Lincoln Fluid valve (708/712 series), our Universal Inline Digital Meters (812/813
series), and our AOD Pump offering to be free from defects in material and workmanship for ve (5) years following the date of purchase. If either
is determined to be defective by Lincoln, in its sole discretion, during the warranty period, they will be repaired or replaced, at Lincoln’s discretion,
without charge.
