Lippert Components 2021130659 Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert™Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Parts List ................................................ 2
Resources Required ................................... 2
Installation .............................................. 3
Install OneControl Application ......................... 3
Operation ............................................... 3
Pairing OneControl app with Temperature Sensor .... 3
Usage Set-up .......................................... 5
Setting Negative Temperature for Android Devices ... 6
Physical Installation of Sensor in Refrigerator ......... 7
Understanding Intelligent Alerts and Notications ..... 8
Battery Information .................................... 9
Resources Required ................................... 9
Troubleshooting ...................................... 11
Maintenance .......................................... 11
Changing Temperature (Fahrenheit to Celsius) ...... 11
Know Bluetooth Range .............................. 11
Unpairing Sensor .................................... 11
Notes .................................................. 12
Lippert
Temperature
Sensor
Installation and
Owner’s Manual
(For Aftermarket Applications)
Lippert Temperature Sensor KitLippert Temperature Sensor Kit
Kit #Kit # DescriptionDescription
2021130659 Lippert Temperature Sensor

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Introduction
Keep an eye on the RV’s fridge and freezer with real-time
updates using the Lippert Temperature Sensor. Using
OneControl®technology, wireless sensors monitor the
RV’s fridge and freezer while traveling and camping.
Monitor up to four sensors simultaneously on a
smart device.
Designed with a unique, out-of-the-way mounting feature,
simply place the sensor on the inside wall of a refrigerator.
This saves space inside the fridge and keeps the sensor
stable in one place.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
FOLLOW BATTERY WARNING INFORMATION OR
SEVERE PERSONAL INJURY MAY OCCUR.
Lippert™ Temperature Sensor Kit - 2021130659Lippert™ Temperature Sensor Kit - 2021130659
LetterLetter PNPN DescriptionDescription QtyQty
A2021126939 Lippert Temperature Sensor 1
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
A
Resources Required
• OneControl App
• Cloth to wipe refrigerator
or cooler
KEEP BATTERIES AWAY FROM CHILDREN.

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Operation
Pairing OneControl app with Temperature Sensor
1. Turn on the sensor: press and hold the large button on
the back until the green LED light turns on. When the light
turns o󰀨, the sensor is now on and ready for pairing.
2. Open the app and look for the “+” on the top of the
screen (Fig.2A).
3. Tap the “+” and navigate to Add and Manage page.
4. At the Add and Manage page, tap sensor (Fig.3A) and
follow the directions queued in the app.
Fig.1
Installation
Install OneControl Application
The sensor requires the OneControl app from Lippert.
• For iOS users, visit the Apple App Store (link).
• For Android users, visit the Google Play store (link).
NOTE: Make sure the smart device is connected to the
Internet and Bluetooth is ON.
1. Search for “OneControl” (Fig.1) in the app store
supported by the smart device.
2. Download the OneControl app to the smart device and
follow the prompts for setting up a new account or logging
in to an existing account.
NOTE: The sensor requires OneControl V5.0 or higher.
Sensors will also work with Compass Connect, Lippert
Connect or OCBT apps provided the versions are V5.0
or higher. To use it on an Apple phone, you will need
an iPhone 8 or higher running iOS Version 13 or higher.
If you have an Android phone, it will need software version
8 or higher.”
Fig.3
A
Fig.2
A

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
6. Press and hold the large button on the back of the
sensor (Fig.5A) until the green LED begins ashing. The
sensor is now in pairing mode. When the OneControl
app makes contact with the sensor, it will be paired
automatically.
A
Fig.4
7. When paring is complete, you will see a conrmation
message (Fig.6).
Fig.5
NOTE: The pairing window times out at 60 seconds. If the
pairing process times out, repeat the process. To ensure
success, make sure the smart device is on, its Bluetooth
is on and its location or location permissions are on. In the
app, make sure permission have been granted and the
sensor and phone are next to one another.
NOTE: Keep the smart device near the sensor during
pairing procedure. The sensor communicates via
Bluetooth. Bluetooth range varies and can be limited
by obstructions, like an RV’s walls or being inside a
refrigerator or freezer.
5. Accept any permission requests that appear on your
smart device screen (Fig.4).
Fig.6

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
The sensor operates between -20°F and 140°F.
If threshold selection exceeds the high temperature range,
the user will receive the following alert (Fig.8)
Fig.7
Usage Set-up
Once OneControl and the senor are paired and
communicating via Bluetooth, the sensor can be set up
within the app.
1. Choose a name for the sensor from the name list (Fig.7A)
to help distinguish what sensor is being measured.
Fig.8
2. Select your temperature threshold (Fig.7B). You may
adjust the temperature to suit other applications, like
freezers or rooms. Alerts are sent if temperature exceeds
thresholds and when it returns to normal.
3. After set up selections have been made, tap CONTINUE
(Fig.7C) to save selections.
NOTE: Sensors may not send alerts if they sense a rapid
and brief rise in temperature, like when loading or removing
food from a fridge.
A
C
B B

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Setting Negative Temperature for Android
Devices
When the number pad is present on the smart device
screen, double tap the “.-” button (Fig.10A). Tapping once
will enter a ‘.’ but tapping twice will enter the ‘-’ for negative
temperatures.
If threshold selection exceeds the low temperature range,
the user will receive the following alert (Fig.9).
Fig.9
Fig.10
A

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
To save your selections, press Apply (Fig.11B). You will be
taken to the OneControl homepage. Scroll down to see
your sensor (Fig.12).
Fig.13
Some smart devices may, by default, have notifications
turned off. OneControl will let you know if they need to be
turned on (Fig.11A).
Physical Installation of Sensor in Refrigerator
The sensor can now be mounted.
1. Locate a spot on the refrigerator or freezer wall near the
door (Fig.13A).
Fig.11
Fig.12
A
NOTE: Confirm the door will close without interference
from the sensor.
A
B

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Understanding Intelligent Alerts and Notifications
Now that the sensor has been paired, customized and
installed, OneControl will begin to send push notifications
to the smart devices when temperature thresholds have
been breached or if the battery is low.
Notifications are sent via Bluetooth. From most RV
refrigerators, the range is about 40 feet. To determine the
range, walk away from the sensor and open the app at
various distances (Fig.16). The app may take up to a minute
to sync with the sensor.
By monitoring the rate and time of temperature changes,
the sensor’s intelligent monitoring system avoids
unnecessary alerts during normal use.
Thresholds can be adjusted anytime in the OneControl app
and when in Bluetooth range of the sensor.
The sensor’s alert thresholds are preset for typical RV
refrigerators (30°F to 46°F). Alerts are sent if temperature
exceeds thresholds and when it returns to normal.
To pair another Sensor, return to the OneControl home
page, press the “+” and repeat the process.
Fig.15
4. Attach to the clean surface (Fig.15).
5. Close the door. You will receive a notication when the
refrigerator or freezer reaches your desired temperature
threshold.
NOTE: By removing the post, you may hang the sensor
anywhere you want; such as rooms, cargo areas and
more.
Fig.16
NOTE: Adhesive is intended for durable plastic and metal
surfaces. It is not recommended for fabric, wallpaper or
painted surfaces.
A
2. Clean the desired location where the sensor will be
mounted. Remove any debris or moisture.
3. Remove the seal from the adhesive pad (Fig.14A),
Fig.14

9
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Battery Information
Follow battery warning information and the warnings in
this manual. The sensor comes with a BR-2450 coin cell
battery. This battery is rated for refrigerators and freezers.
NOTE: If only used in a refrigerator or to measure
temperature in a room, a CR-2450 battery can be used.
Only use new batteries and of identical type. Do NOT:
• Throw batteries into water.
• Throw batteries into fire
• Short-circuit batteries.
• Open or disassemble batteries.
WHEN HEATED ABOVE 100 °C (212 °F) THE RISK OF
RUPTURE OCCURS. A RUPTURED BATTERY CAN
EXPOSE ITS CAUSTIC CONTENTS TO EYES, LUNGS
AND SKIN CAUSING SEVERE PERSONAL INJURY.
IF EXPOSED TO BATTERY CONTENTS, SEEK
IMMEDIATE MEDICAL ATTENTION.
Resources Required
• BR-2450 or CR-2450
battery (depending)
• Small, at-head
screwdriver
NOTE: Complete removal of the sensor should not be
necessary. The best practice is to NOT remove where the
sensor is adhered and keep adhesive attached.
1. Pull the senor out of the mounting rubber band (Fig.17).
2. Locate the slot on the bottom corner of the Temperature
Sensor (Fig.18A) Insert a small, at-head screwdriver and
twist to open.
Fig.17
Fig.18
A
NOTE: Instead of a screwdriver, a slim coin can be used.
3. The sensor will pop open like a clamshell (Fig.19).
Fig.19
USE CARE WHEN REMOVING OR INSERTING
THE BATTERY. DO NOT USE SHARP OBJECTS
TO REMOVE, INSERT OR HANDLE THE BATTERY.
SHARP OBJECTS CAN CAUSE DAMAGE TO THE
BATTERY THAT MAY RESULT IN ITS RUPTURING. A
RUPTURED BATTERY CAN EXPOSE ITS CAUSTIC
CONTENTS TO EYES, LUNGS AND SKIN CAUSING
SEVERE PERSONAL INJURY. IF EXPOSED TO
BATTERY CONTENTS, SEEK IMMEDIATE MEDICAL
ATTENTION.

10
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
4. Lift out the sensor platform and slide out the old
battery (Fig.20).
5. Install the new battery (Fig.21).
NOTE: Make sure the positive side of the battery faces up.
6. Put the platform into the transparent tray (Fig.22).
Fig.21
Fig.22
Fig.23
Fig.24
7. Snap the top of the sensor body back into place (Fig.23).
NOTE: If the sensor was On/Sleep mode before battery
was replaced, the sensor will return to that mode when
the new battery is installed. If the sensor was Off before
replacing the battery, then it will be necessary to turn on
the sensor and complete the install/set-up process.
Fig.20 8. Open the app and wait until the app and the sensor sync.
NOTE: Lithium button cell batteries are classified by the
U.S. federal government as non-hazardous waste and
are safe for disposal in normal municipal waste systems.
Lithium button cell batteries are classified differently in
other countries wherein battery disposal must follow in
accordance with their respective local laws.
9. Return the sensor back to the rubber band (Fig. 24).

11
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Troubleshooting
What is happening?What is happening? Why?Why? What should be done?What should be done?
Sensor won’t pair with phone. Mobile device and sensor can’t find each
other.
• Make sure Bluetooth connection is good
and ensure device has been synced
following the procedure.
• Make sure smart device’s Settings is
allowing Location to be shared.
OneControl app is incorrectly
reporting temperature.
There is interference between sensor and smart
device.
• Make sure the smart device’s Bluetooth
setting is on, and the app is setup within
the smart device’s Settings.
• Try pairing sensor outside of freezer
or refrigerator to make sure working
properly.
• Try placing on different walls of freezer
or refrigerator.
Sensor improperly placed in freezer or
refrigerator.
Be sure sensor is properly installed (see
Installation section).
Maintenance
Unpairing Sensor
If the sensor is lost or damaged beyond repair, open the
OneControl app and look for the “Unpair” button on the
sensor’s homepage. Unpair the device and dispose safely
like other electronic equipment.
NOTE: If lost and recovered, the sensor can be paired
again with the smart device.
Changing Temperature (Fahrenheit to Celsius)
To change from Fahrenheit to Celsius, go to the Settings
within the app on the smart device being used
for OneControl.
Know Bluetooth Range
Alerts will be received by the smart device when sensor
is in Bluetooth range. The range varies depending on
obstructions. With no obstructions, Bluetooth range may
extend as far as 300 feet.
When installed, refrigerator or freezer walls can limit range
to 30 or 40 feet.
Look for the Bluetooth icon on the OneControl homepage
to determine if you are in range.

12
lippert.com 432-LIPPERT (432-547-7378) Rev: 06.01.22
Lippert Temperature
Sensor
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004546
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
Notes
