Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
Solera®Slide Topper
Access Kit
Installation and
Owner’s Manual
(For Aftermarket Applications)
Solera Slide Topper Access KitSolera Slide Topper Access Kit
Part #Part # Description
795354 Access Kit, Black
795355 Access Kit, White
NOTE: If the unit came with a pre-installed Solera® Slide
Topper Access Plate (Fig.1A or 2A),shown, it will require the
Solera Slide Topper Access Bracket (Fig.3A) provided in
this kit.
If the Solera Slide Topper Access Kit was purchased
then utilize these instructions for the Solera Slide Topper
installation process.
To reference components of the Solera Slide Topper,
please visit www.lci1.com under “Awnings.”
A
A
Table of Contents
Introduction ........................................... 2
Safety Information .................................... 2
Resources Required .................................. 2
Parts List ............................................... 3
Solera Slide Topper Access Kit ....................... 3
Prior to Installation .................................... 3
Installation ............................................. 3
Installing the Awning Rail ............................. 3
Assemble the Extension Rod and Cap ............... 4
Installation of the Access Plate if NOT Already installed
on the Unit ............................................ 4
Installing the Solera Slide Topper Access Bracket ... 5
Securing the Fabric ................................... 7
Troubleshooting ....................................... 7
Maintenance ........................................... 8
Fabric Care .......................................... 8
Notes ................................................... 8
NOTE: If the unit came with a pre-installed Solera® Slide
Topper Access Plate shown below (Fig.1A or 2A), the access
plates, part number 768004 or 768005 and screws part
number 793617 will not be needed for this installation.
Fig.1 Fig.2
Fig.3
A

2
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
Introduction
The Solera Slide Topper Access Plates are being utilized
by specific OEMs for prepping the unit to make installing
the Solera Slide Topper quicker and easier.
The Solera®Slide Topper is a high-quality, cost-effective
way to help keep slide-outs free of dirt, leaves and debris.
The Solera®Slide Topper is permanently attached to the
slide-out and retracts/extends with the room. The easy-
to-install kits are designed to fit rooms from 66” to 192” in
length.
The Solera®Slide Topper Access Kit comes complete with
mounting hardware.
Additional information about this product can be obtained
from lci1.com/support or by using the myLCI app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the myLCI app.
The myLCI app is available for free on iTunes®for iPhone®
and iPad®and also on Google Play™for Android™users.
iTunes ®, iPhone®, and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety Information
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
This manual provides general installation procedures.
Many variables can change the circumstances of the
procedure, i.e., the degree of difficulty involved in the
service operation and the ability level of the individual
performing the operation.
This manual cannot begin to plot out procedures for every
possibility, but will provide the general instructions for
effectively installing the system. In the event the skill level
required is too advanced or the procedure too difficult,
a certified technician should be consulted before
performing the necessary installation. Failure to correctly
install the system may result in voiding the warranty,
inflicting injury or even death.
FAILURE TO FOLLOW THE INSTRUCTIONS
PROVIDED IN THIS MANUAL MAY RESULT IN DEATH,
SERIOUS INJURY, UNIT DAMAGE OR VOIDING OF
THE COMPONENT WARRANTY.
ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING SERVICE OR MAINTENANCE TO THE
UNIT. OTHER SAFETY EQUIPMENT TO CONSIDER
WOULD BE HEARING PROTECTION, GLOVES AND
POSSIBLY A FULL FACE SHIELD, DEPENDING ON
THE NATURE OF THE SERVICE.
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.
Resources Required
• 1-2 people, depending on task
• Cordless or electric drill or screw gun
• Appropriate drive bits
• Screwdriver
• (2) #6 x ½” hex head screws
• 1/8” Hex key wrench
• Tape measure
• Silicone sealant or butyl tape
• Silicone lubricant

3
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
Prior to Installation
The unit will be equipped with a removable, cosmetic
access plate cover (Fig.4A) on the access plate (Fig.4B).
This cover snaps on and off and must be removed prior to
installation of the access bracket.
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
Solera Slide Topper Access Kit
For units with the Solera Slide Topper Access Plate
already attached.
Solera Slide Topper Access Kit - WhiteSolera Slide Topper Access Kit - White
LetterLetter PNPN DescriptionDescription QtyQty
A 768008 Access Bracket 2
B 768005 *Access Plate 2
C 786718 Set Screw, 1/4” - 20 x 1/2” 4
D 793617 *Screw, #10 - 13 x 1 1/4” 10
C
A
Solera Slide Topper Access Kit - BlackSolera Slide Topper Access Kit - Black
LetterLetter PNPN DescriptionDescription QtyQty
A 768007 Access Bracket 2
B 768004 *Access Plate 2
C 786718 Set Screw, 1/4” - 20 x 1/2” 4
D 793616 *Screw, #10 - 13 x 1 1/4” 10
B
D
Fig.4
Installation
All screws supporting the awning assembly MUST have a
backer within the structure of the wall of the unit. Refer to
unit manufacturer for proper location.
Installing the Awning Rail
Awning rail included.
1. Position the awning rail along the line where the roof and
wall meet or a minimum of 3” above the upper edge of the
slide room the Solera®Slide Topper will cover. The awning
rail must be level and parallel with the top of slide room box
of the unit.
NOTE: If mounting the Solera Slide Topper access plate
on the T-molding, see (Fig.2), the awning rail must be a
minimum of 4 ½” above the upper edge of the slide room
the awning will cover.
2. After determining the awning rail’s proper location, mark
its position with a non-permanent method of marking.
3. Apply sealant along the horizontal length of the back
(Fig.5A) of the awning rail.
4. Align the awning rail on the wall and secure with
#8 - 18 x 1” screws, using all fastener holes.
* If the Access Plate is already installed on the unit these
parts will not be needed for this installation.
A
Fig.5
B
A

4
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
Fig.6
Fig.7
A
B
C
Assemble the Extension Rod and Cap
1. Slide the extension rod (Fig.6A) into the spring head
assembly torsion arm (Fig.6B), aligning the fastener
locations (Fig.6).
2. Slide the spring head assembly torsion arm end cap
(Fig.6C) into the extension rod (Fig.6A), aligning all three
fastener locations (Fig.6). Fasten using the provided
 screw (Fig.7).
3. Repeat steps 1 and 2 for the opposite end.
fastener locations
Fig.8
Installation of the Access Plate if NOT Already
installed on the Unit
1. If The access plate (Fig.8) has NOT already been
(Fig.8A) at
the top or bottom, depending on which option allows for a
more square installation on the unit.
A
2. Install the access plate below the T-molding (Fig.9) or on
the T-molding (Fig.10).
A
Fig.9 Fig.10
A
A. If installing below the T-molding, start on one side of
the front of the slide-out by placing one of the two access
brackets (Fig.11A) against the bottom of the T-molding at
the top corner of the slide-out (Fig.11B) as close to the
corner as possible. Keep the mounting bracket parallel
with the bottom edge of the T-molding.
Fig.11
A
B
C

5
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
1. Slide an access bracket onto an access plate at the
appropriate position (Fig.14 or Fig.15) at both ends of the
slide room.
NOTE: There might be a slight gap between the T-molding
side and the side of the mounting bracket (Fig.11C) if the
corner does not have a 90 degree angle.
B. If installing on the T-molding, start on one side of
the front of the slide-out by placing one of the two
access brackets (Fig.12A) at the very bottom corner of
the T-molding, (Fig.12B) as close to the outside of the
T-molding as possible without going over the corner mold
(Fig.12C).
NOTE: Make sure the screws do not go over the roof line.
A
B
C
Fig.14
Fig.12
3. Fasten the mounting bracket to the slide-out exterior
¼” recessed
square head screws (Fig.13).
Fig.13
FALLING SLIDE TOPPER ACCESS BRACKETS
CAN CAUSE PERSONAL INJURY, PRODUCT AND/
OR PROPERTY DAMAGE. SLIDE TOPPER ACCESS
BRACKETS ARE INSTALLED LOOSE ON THE ACCESS
PLATE UNTIL FINAL INSTALLATION. MAKE SURE
ACCESS BRACKETS ARE SECURE ENOUGH TO
PREVENT FALLING FROM THE ACCESS PLATE.
Installing the Solera Slide Topper Access Bracket
NOTE: The Solera Slide Topper Access Bracket can be
installed in two different positions. The lower position
(Fig.14A), first extrusion from the top of the access bracket,
is used for regular clearance. The higher position (Fig.15A),
second extrusion from the top of the access bracket, is
used if the slide topper requires extra clearance.
NOTE: If installing the slide topper access plate on the
T-molding, see (Fig.2), use the first extrusion from the top of the
access bracket method (Fig.14A).
A
A
access
plate
access
plate
Fig.15

6
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
4. Remove packaging from the roll tube and unroll a small
portion of fabric, no more than one turn.
Fig.17
NOTE: The original extension rod brackets in the Solera
Slide Topper Kit will not be needed
Installing the Solera Slide Topper Assembly
1. To prepare for fabric installation, use a screwdriver to
spread open either end of the awning rail on the installation
end (Fig.16A).
2. To protect the fabric from damage during installation,

B
A
3. Spray the inside of the awning rail channel with silicone
lubricant (Fig.16B).
Fig.16
B
A
UNROLLING THE FABRIC MORE THAN ONE TURN
WILL CAUSE THE SLIDE TOPPER TO LOSE TENSION
AND CREATE SLACK WHEN CLOSING THE SLIDE
ROOM. MAKE SURE TO LEAVE THE SLIDE ROOM
CLOSED OR NOT TO EXTEND MORE THAN 6”.
fabric
A
B
5. Using at least two people, feed the polycord (Fig.17A) on
the fabric through the awning rail channel (Fig.17B).
6. Feed one of the extension rods (Fig.18A) into an access
bracket (Fig.18B). By pulling the extension rod all the way
into the access bracket, the opposite end extension rod
can now slide into the access bracket at the opposite end.
Fig.18
NOTE: If needed, the access brackets can slide left or right
to assist in getting both extension rods into the access
brackets.
7. Position the extension rod so that the roll tube will not
be touching the slide room.
8. Install the two provided ¼” - 20 x ½” set screws in the
top two holes of the access bracket (Fig.19) if using the
lower position (Fig.7). Install two set screws in the lower
two holes of the access bracket (Fig.20) if using the higher
position (Fig.8).
Fig.19

7
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
9. Center the Solera®Slide Topper over the slide room
using a tape measure.
Troubleshooting
What’s Happening? What Should Be Done?
Rub marks appear on the fabric. Check that there is no debris in the track where fabric goes into the case.
Fabric sags or is loose. Check tension on springs.
Make sure the end caps are properly secured.
Fabric will not roll up. Check tension on springs.
Make sure there are no debris or foreign objects in the fabric opening or case.
Fabric will not unroll. Make sure the spring clip that lock the tension for install have been removed
from both ends of the end caps.
Fabric appears to roll up
at an angle.
Make sure the rail that is mounted to the unit is square with the main housing
of the slide topper.
Make sure fabric is cut square.
Securing the Fabric
1. Extend and retract the room several times to ensure
that the fabric is square on the roll tube.
2. Secure the fabric (Fig.22A) in the awning rail (Fig.15B) no
more than 1” inside the edge of the fabric on both ends
using a #6 x ½” hex head screw (Fig.22C). Install the screw
(Fig.15C) down through the awning rail (Fig.22B) into the
fabric (Fig.15A) and the polycord (Fig.15D).
1"
B
D
C
A
outer edge
of fabric
Fig.22
ROLL TUBE SPRINGS ARE UNDER TENSION.
IMPROPERLY SECURED ROLL TUBE SPRINGS CAN
CAUSEPERSONALINJURYAND/OR PRODUCTDAMAGE.
SLOWLY RELEASE SPRING TENSION TO AVOID
PERSONAL INJURY AND/OR PRODUCT DAMAGE.
B
A
Fig.20
Fig.21
10. Fasten the extension rods (Fig.21A) to the access
brackets (Fig.21B) by installing two of the provided
#10 - 16 x ¾” self-drilling hex washer head screws (Fig.21).
11. Firmly hold the roll tube when removing the spring clip
to relieve spring tension.

8
lci1.com 574-537-8900 Rev: 09.17.20
Solera®Slide Topper
Access Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002640
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lci1.com. Manual information is considered
factual until made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
NotesMaintenance
Fabric Care
If the Slide Topper is retracted while wet, extend the
Slide Topper and let it dry as soon as conditions allow
before retracting. This will help prevent the formation of
mildew and add greatly to the life of the awning. Mildew
does not form on the fabric itself, but on the accumulated
dust, dirt and grime.
Periodically clean vinyl or woven acrylic fabric using a
mixture of ¼cup of dish soap and five gallons of warm
water. Liberally apply the mixture on the top of the fabric
and retract the Slide Topper for five minutes. This will
apply the mixture to the bottom of the fabric as well.
Extend the Slide Topper and hose off with fresh water.
Repeat if necessary. Allow fabric to dry before retracting.
