Lippert Components Vela User manual

Vela Pop Up
Roof System
Class B (EU)
OWNER'S MANUAL

Rev: 05.10.2021 Page 2 CCD-0004280
TABLE OF CONTENTS
Introduction 2
Safety 3
Preparation 3
Operation 4
Opening the Pop Up Roof System 4
Windows 5
Utilizing the Bed 6
Closing the Pop Up Roof System 6
Optional Features Available 8
Lighting 8
Electrical Ports 8
Troubleshooting 9
Maintenance 10
Care and Maintenance 10
Cleaning External Pop Up Roof Surfaces 10
Cleaning Internal Pop Up Roof Surfaces 10
Notes 11
Introduction
The Vela Pop Up Roof is a manually operated, van roof-mounted sleeper. The Pop Up Roof has a solid roof
with a canvas body that includes:
• A double bed
• Screened windows
• Hot or cold air circulation
• Special storage shelving molded into the thermoformed lower section
• Two flexible lamps with USB ports (optional)
• Ceiling courtesy lights (optional)
• Power socket and/or USB module (optional)
• The capability to top-mount a porthole or solar panel (optional)
For information on the assembly or individual components of this product, please visit:
lippertcomponents.eu
Note: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.

Rev: 05.10.2021 Page 3 CCD-0004280
The “WARNING” symbol above is a sign that a procedure has a safety risk involved and may cause
death or serious personal injury and/or severe product or property damage if not performed safely
and within the parameters set forth in this manual.
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
shield, depending on the nature of the task.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
in this manual.
Make sure camper van is fully supported and secured per manufacturer's recommendations before
working on or underneath the camper van or death, serious personal injury and/or severe product
and property damage, including voiding of the component warranty, may occur.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Safety
Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage,
including voiding of the LCI limited warranty.
Preparation
1. Make sure camper van is level.
2. Make sure camper van is properly supported and secured.
A. Engage brakes.
B. Chock all tires.
Do NOT exceed the product's maximum speed limit.
Do NOT drive with the pop up roof system opened or product damage may occur.
Do NOT drive with people or pets inside the pop up roof system's sleeping area or personal injury
may occur.

Rev: 05.10.2021 Page 4 CCD-0004280
Fig. 1
ABC
Fig. 2
Ladder
Hooks
Fig. 3
A
Fig. 4
A
B
Operation
Opening the Pop Up Roof System
1. From inside the camper van, release the clips on the two safety belts (Fig. 1A) by pressing on both sides
of the clip (Fig. 1B). The upper portion of the pop up will move freely (Fig. 1C).
2. Attach the ladder supplied to the specific hooks (Fig. 2).
3. Climb the ladder to reach the release button (Fig. 3A).
4. Grab the handle with one hand (Fig. 4A), then at the same time press the release button (Fig.4B) and
push the handle upwards.
5. After unlocking the roof, grab both handles (Fig. 4A) and push the roof upwards.

Rev: 05.10.2021 Page 5 CCD-0004280
Fig. 5 Fig. 6
Fig. 7 Fig. 8
Fig. 9
A
Windows
Opening the Windows:
The windows with mosquito netting positioned along the perimeter of the pop up roof (Fig. 5A) can be
opened (Fig. 6A) to further ventilate the sleeping area. Opening all pop up windows improves ventilation
against heat build-up and helps to refresh the sleeping area.
A
B
1. Open the zipper (Fig. 7).
2. Roll down the window covering towards the base of the window (Fig. 8A).
3. Fasten the window covering in-place with the straps located at the base (Fig. 8B).
Closing the Windows:
The windows can be closed (Fig. 9A) to protect against cold and rain.
1. Unfasten the straps holding the window covering in place at the base.
2. Unroll the window covering toward the top of the window.
3. Close the zipper.
A
A

Rev: 05.10.2021 Page 6 CCD-0004280
Fig. 10
Fig. 11
Ladder
Hooks
Utilizing the Bed
The Vela Pop Up Roof System comes equipped with a 1300 mm x 2000 mm double bed (Fig. 10).
1. Attach the supplied ladder to the two hooks (Fig. 11).
2. Climb the ladder to the bed, sit on the surface of the sleeping area, then rotate your torso.
Closing the Pop Up Roof System
1. Attach the supplied ladder on the hooks (Fig. 11).
2. Climb the ladder to inspect the pop up roof to make sure the windows are properly closed. If
necessary, zip the windows closed.
3. After making sure all windows are closed, grip both roof handles (Fig. 12) and pull down as evenly as
possible. Do NOT completely close the pop up roof at this point.
4. Make sure that the canvas is folded correctly inside to prevent jamming of the built-in mechanism or
the locking latch.
5. Walk around the vehicle and visually inspect the pop up roof for any canvas material sticking out of the
frame. If necessary, carefully tuck in any protruding material.
6. From inside the vehicle, continue to lower the roof until it is completely closed.
Note: A clicking sound should be heard, signifying the locking system has engaged.
7. To make sure the pop up's locking system has been engaged:
A. Grab the handles on the roof with both hands and push upward.
B. If the upward pressure on the roof does not change its position significantly on both sides, then
the locking system is properly engaged.
Fig. 12
Handles

Rev: 05.10.2021 Page 7 CCD-0004280
Fig. 13
Closed
Safety Belt
Safety
Belt
Closed Pop Up Roof
Fig. 14
C. If the roof changes position, the locking system is not properly engaged. Repeat steps 4-6, then
check the locking system again for proper engagement.
8. Clip the safety belts (Fig. 13) closed to secure the roof.
9. Inspect the outside of the Pop Up Roof System to make sure it has completely closed (Fig. 14).
10. After the Pop Up Roof System has been fully closed, the camper van may be driven.
A. If wheel chocks have been used, make sure they have been removed before driving.
B. If brakes are engaged, release brakes before driving.
Do NOT exceed the product's maximum speed limit.
Do NOT drive with the pop up roof system opened or product damage may occur.
Do NOT drive with people or pets inside the pop up roof system's sleeping area or personal injury
may occur.

Rev: 05.10.2021 Page 8 CCD-0004280
Optional Features Available
Lighting
Flexible lamps:
Brightness inside the sleeping area can be adjusted by means of two flexible lamps (Fig. 15) located on the
lower part of the pop up. Flexible lamp features include:
A. The flexible lamps are controlled by pressing an integrated on/off switch (Fig. 16A) providing two
intensity levels.
B. Each flexible lamp contains a 5V DC, 2A USB port (Fig. 17A).
Fig. 15 Fig. 16
Fig. 19
A
Fig. 17
Fig. 18
A
A
B
LED Lamps:
There are two LED lamps on the inside of the upper shell (Fig. 18A). The entire sleeping area will be fully
illuminated when these lights are fitted.
A. The lights are switched on/off by pressing a switch inside the opening of the sleeping area
(Fig. 19A).
Electrical Ports
220V Socket Module:
There is one 220V socket module(Fig. 19B) located at the interior of the entrance frame.
Note: Various types of electronic devices can be recharged and used if they meet the provided current
limits and voltages.
A

Rev: 05.10.2021 Page 9 CCD-0004280
Fig. 20
What is Happening Why? What Should Be Done?
Pop up latching
clamps won't release.
Latch release track blocked.
Check latching release track for dirt, debris and
obstructions. Clean track of any dirt and debris.
Clear any obstructions.
Latch release track
damaged.
Do not attempt to repair damaged components
at the risk of voiding the LCI limited warranty.
Contact the Lippert Care Center EU.
Pop up latching
clamps won't clamp
shut.
Latch clamping mechanism
blocked.
Check latching clamp mechanism for dirt, debris
and obstructions. Clean mechanism of any dirt
and debris. Clear any obstructions.
Latch clamping mechanism
damaged.
Do not attempt to repair damaged components
at the risk of voiding the LCI limited warranty.
Contact the Lippert Care Center EU.
Pop Up doesn't fully
extend.
Support arm track blocked.
Check support arm track for dirt, debris and
obstructions. Clean track of any dirt and debris.
Clear any obstructions.
Support arm track
damaged.
Do not attempt to repair damaged components
at the risk of voiding the LCI limited warranty.
Contact the Lippert Care Center EU.
Pop Up doesn't fully
retract.
Support arm track blocked.
Check support arm track for dirt, debris and
obstructions. Clean track of any dirt and debris.
Clear any obstructions.
Support arm track
damaged.
Do not attempt to repair damaged components
at the risk of voiding the LCI limited warranty.
Contact the Lippert Care Center EU.
Troubleshooting
The following troubleshooting chart only covers basic operational concerns. If other concerns exist other
than what is listed in the troubleshooting chart, contact the Lippert Care Center EU at ([phone].
5V DC USB Ports:
There is at least one module with two 5V DC USB ports(Fig. 20) located at the interior of the entrance frame.
Note: Various types of electronic devices can be recharged and used if they meet the provided current
limits and voltages.

Rev: 05.10.2021 Page 10 CCD-0004280
Maintenance
Periodically clean the canvas to prevent dirt and grime build-up. Dirt and grime build-up may penetrate the
fabric. Use a soft bristled brush, sponge or clean cloths to remove dirt from the fabric before washing.
Care and Maintenance
To preserve the integrity of the canvas and extend its lifespan, use the following guidelines when caring for
thecanvas:
• Inspect and treat the canvas every 12-14 months.
• Treat clean seams with high quality seam seal.
• Allow seam seal to completely dry before closing top.
• If needed, apply Kiwi®Camp Dry water repellent, or equivalent quality, spray to thecanvas.
Do NOT close or store a wet canvas. Closing or storing a wet or damp canvas can cause damage
to the material and void the warranty. Make sure the canvas is completely dry before closing
or storing.
Do NOT use harsh soaps and detergents. Harsh soaps and detergents can cause damage to the
water repellent treatment of the canvas. Use a small amount of mild soap or detergent to prevent
damaging the water repellent treatment of the canvas.
Note: Use care when cleaning the Pop Up Roof System. Using harsh detergents and hard bristled brushes
can damage the roof's canvas material.
• Only use clean water.
• Gently clean the canvas by hand.
• Test all cleaning products prior to use. Apply a small amount of the cleaning product to an
inconspicuous area.
Note: Canvas MUST be completely dry before closing/storing pop up roof.
Cleaning External Pop Up Roof Surfaces
• Use a small amount of mild, Eco-friendly detergent to prevent damaging the pop up's material and to
protect the environment.
• When using a hose or power sprayer, make sure to use a weak jet stream of clean water.
• Use a clean, soft sponge. Rinse sponge often.
• Rinse washed surfaces clean with plenty of clean water.
• Allow the roof to completely dry before closing the pop up roof.
Cleaning Internal Pop Up Roof Surfaces
• Use a clean, soft cloth and mild, eco-friendly detergents.
• Allow internal surfaces to completely dry before using the sleeping area or closing the pop up roof.
• Immediately treat any stains on the fabric covering the roof.
– Absorb stains without rubbing.
– Do not use harsh detergents.

Rev: 05.10.2021 Page 11 CCD-0004280
Notes

The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from lippertcomponents.eu.
Please recycle all obsolete materials.
For all concerns or questions, please contact
Lippert Components, Inc.
Ph:([phone]  | Web: lippertcomponents.eu | Email: [email protected]
