APS Auto Parts Specialist IA04SJJ2B User manual

For 2002-2008 Dodge Ram 1500 Quad Cab/2003-2009 Dodge Ram 2500/3500 Quad Cab
REV: 20190401
Installation Instructions for IA04SJJ2B
by APS Auto Parts Specialist Inc.
Application: For 2002-2008 Dodge Ram 1500 Quad Cab/2003-2009 Dodge Ram 2500/3500
Quad Cab
Estimated Time: 1 to 2 hours
The instruction here is for your
reference only. We strongly
recommend the professional
installer for best result. We are
not responsible for any damage
caused by the installation.
Thank you for choosing our
product!

For 2002-2008 Dodge Ram 1500 Quad Cab/2003-2009 Dodge Ram 2500/3500 Quad Cab
REV: 20190401
Page 1 of 3
PARTS LIST:
Item
QTY
Description
Item
QTY
Description
#1
2
Driver/ Passenger Side Bar
#10
24
M10 Hex Nuts
#2
1
Driver Front Mounting Bracket (DFM)
#11
8
2-Hole Support Bracket
#3
1
Passenger Front Mounting Bracket (PFM)
#12
8
Plastic Washer
#4
4
Driver/ Passenger Center Mounting Bracket(DCM)
#13
16
M10X1.5-75 Carriage Bolts
#5
1
Driver Rear Mounting Bracket (DRM)
#14
8
ST6x22 Self Tapping Screw
#6
1
Passenger Rear Mounting Bracket (PRM)
#15
8
M6x1-25 Hex Bolts
#7
8
M10x35 Bolt Plate
#16
16
M6 Flat Washers
#8
24
M10 Flat Washer
#17
8
M6 Lock Washers
#9
24
M10 Lock Washer
#18
8
M6 Hex Nuts
PROCEDURE:
1. Verify all parts are present. Read and understand instruction before beginning.
2. Remove tape from locations as shown. Install bolt plates as shown.(See FIG 1 & 2).
3. Attach brackets. Mark holes. Remove brackets. Drill holes as shown. (See FIG 3).
NOTE: Be sure to use the correct drill bit size for each hole.
4. Attach mounting brackets as shown. Hand tighten. (See FIG 4-front brackets, FIG 5-center bracket
and FIG 6-rear brackets)
5. Select the Driver Side Bar. Slip (2) M10X1.5-75 Carriage Bolts into each 2-Hole Support
Brackets ,and insert the 2-Hole support bracket into the Driver Side Bar.(Fig 7). Carefully
position the Bar onto the (4) Mounting Brackets. IMPORTANT: Do not slide the Bar on the
Brackets or damage to the finish may result. Attach the Driver Side Bar to the Mounting
Brackets with (2) M10 Hex Nuts,(2)10mm lock washers and (2)10mm flat washers, (Fig 8). Do
not tighten hardware.
6. Level and adjust the Bar properly and tighten all hardware. NOTE: Torque all M10 X1.5-75
Carriage Bolts to 22~25 Ib-ft. Don't over tighten,or the aluminum square bars will be
damaged by the brackets.
7. Repeat Step 2-6 for the other side installation. Installation completed!!! (See Fig 9)
8. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
Products have a high quality finish that must be cared for like any other exposed finish on the vehicle. Protect
the finish with a non-abrasive automotive wax, (e.g.Pure Carnauba ) on a regular basis. The use of any soap,
polish or wax that contains an abrasive is detrimental, as the compounds scratch the finish and open it to
corrosion.
2-Hole Support Bracket
DCM
PRM
DFM
PFM
DRM

For 2002-2008 Dodge Ram 1500 Quad Cab/2003-2009 Dodge Ram 2500/3500 Quad Cab
REV: 20190401
Page 2 of 3
Driver/Passenger Side Installation Pictured
*Pictures are for reference only, actual Brackets may be a little different.
FIGURE3

For 2002-2008 Dodge Ram 1500 Quad Cab/2003-2009 Dodge Ram 2500/3500 Quad Cab
REV: 20190401
Page 3 of 3
Complete Installation
Fig 8
Fig 7
Fig 9
