Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Parts List ................................................ 3
Equa-Flex Triple Axle 3-6K Aftermarket Kit ........... 3
Equa-Flex Triple Axle 5-8K Aftermarket Kit ........... 3
Parts Available for Purchase .......................... 4
Resources Required ................................... 4
Prior to Installation ..................................... 5
Installation .............................................. 6
Rear Axles ............................................. 6
Front Axles ............................................ 7
Notes .................................................... 9
Equa-Flex Triple Axle Aftermarket KitsEqua-Flex Triple Axle Aftermarket Kits
Part #Part # DescriptionDescription
281314 Equa-Flex® Triple Axle, 3-6K
279689 Equa-Flex® Triple Axle, 5-8K
Equa-Flex®
Triple Axle
Installation and
Owner’s Manual
(For Aftermarket Applications)
Kit# 279689
One side - Equa-Flex
Triple Axle 5-8K
Kit# 281314
One side - Equa-Flex
Triple Axle 3-6K

2
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Introduction
The Equa-Flex Triple Axle 3-6K kits are used for triple-axle
trailers with double-eye leaf springs and weight capacity
from 3,000 to 6,000 lbs. The Equa-Flex Triple Axle 5-8K
heavy-duty kit is for triple-axle trailers with double-eye leaf
springs and a weight capacity from 5,000 to 8,000 lbs.
Quick Facts
• Comes with two Equa-Flex sub units and two Equa-Flex
sub units with upper shock weldmounts.
• Each sub unit comes with pre-installed bronze bushings.
• Center hanger and other mounting hardware
sold separately.
NOTE: Images used in this document are for reference
only when assembling, installing and/or operating this
product. Actual appearance of provided and/or purchased
parts and assemblies may differ.
Additional information about this product can be
obtained from lci1.com/support or by using the myLCI app.
Replacement kits can be ordered from https://store.lci1.com/
or by using the myLCI app.
The myLCI app is available for free on iTunes®for iPhone®
and iPad®and also on Google Play™for Android™users.
iTunes®, iPhone®, and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc
Information regarding the assembly and
components of this product can be obtained from
https://support.lci1.com/equa-flex.
Safety
Read and fully understand all instructions before installing
or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e.,
the degree of difficulty, operation and ability of the
individual performing the instructions. This manual
cannot begin to plot out instructions for every possibility,
but provides the general instructions, as necessary,
for effectively interfacing with the device, product
or system.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR
PROPERTY DAMAGE IF NOT SAFELY ADHERED TO
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL
MOVING PARTS CAN PINCH, CRUSH, OR CUT. KEEP
CLEAR AT ALL TIMES.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
DEATH, SERIOUS PERSONAL INJURY AND/OR
SEVERE PRODUCT OR PROPERTY DAMAGE IF
NOT SAFELY ADHERED TO AND WITHIN THE
PARAMETERS SET FORTH IN THIS MANUAL.
FAILURE TO FOLLOW INSTRUCTIONS PROVIDED
IN THIS MANUAL MAY RESULT IN DEATH, SERIOUS
PERSONAL INJURY AND/OR SEVERE PRODUCT
AND PROPERTY DAMAGE, INCLUDING VOIDING OF
THE COMPONENT WARRANTY.
THE TRAILER MUST BE SUPPORTED PER
MANUFACTURER’S RECOMMENDATIONS BEFORE
WORKING UNDERNEATH. FAILURE TO DO SO MAY
RESULT IN DEATH OR SERIOUS INJURY.
Failure to correctly follow the provided instructions may
result in death, serious personal injury, severe product and/
or property damage, including voiding of the LCI limited
warranty.

3
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Equa-Flex Triple Axle 3-6K Aftermarket Kit #Equa-Flex Triple Axle 3-6K Aftermarket Kit # 281314
LetterLetter PNPN DescriptionDescription QtyQty
A 167407 Equa-Flex 3K - 6K Triple Axle Set 1
B122102 Bolt, 7/16” - 20 X 2 7/8”; GR5
(.563 Body Dia.), Black Phos & Oil 2
C122103 Nut, 7/16” - 20 REVLKN ZN GR2 ST 2
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
Equa-Flex Triple Axle 3-6K Aftermarket Kit Equa-Flex Triple Axle 5-8K Aftermarket Kit
Equa-Flex Triple Axle 5-8K Aftermarket Kit #Equa-Flex Triple Axle 5-8K Aftermarket Kit # 279689
LetterLetter PNPN DescriptionDescription QtyQty
A 145549 Equa-Flex 5K - 8K Triple Axle Set 1
B271254 Bolt, 7/16” - 20 X 3.375”; GR5
(.563 Body Dia.), Black Phos & Oil 2
C122103 Nut, 7/16” - 20 REVLKN ZN GR2 ST 2
A
B C
A
B C
NOTE: The 279689 kit can only be used when the hanger
spacing is 30.5”/35”/30.5”. 30.5” spacing from front to
center hanger, 35” from center to center hanger and 30.5”
from center to rear hanger.
NOTE: The 281314 kit should only be used with a hanger
spacing of 29.5”/33”/29.5”. 29.5” spacing from front to
center hanger, 33” from center to center hanger and
29.5” from center to rear hanger. The *front spring eye
of the middle axle should go into the hole closest to
the Equa-Flex body.
*front spring eye
location

4
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Parts Available for Purchase
The parts listed are NOT part of the Equa-Flex Triple
Axle Kit but can be purchased separately. It is always
recommended to inspect and replace any worn or
damaged shackles and bolts.
Resources Required
• 1 to 2 People, depending on task
• Pneumatic impact wrench
• Torque wrench (ft-lb)
• Cordless or electric drill or screw gun
• Appropriate drive bits
• ⁄” Deep well socket
• ¾” Deep well socket
• ⁄” Deep well socket
• Steel tube to install bolts with grease fittings
• Multi-purpose grease marked with a NLGI code of GC-LB
• Appropriately-sized and rated bolts and fasteners
• Floor jacks
• Floor jack stands
• Hammer
• Grease gun
Parts Available for PurchaseParts Available for Purchase
Shackle Links and AssembliesShackle Links and Assemblies
LetterLetter PNPN DescriptionDescription QtyQty
A133485 Shackle Assembly, Standard Long, 3.13” 1
B133207 Shackle Link, Standard Long, 3.13” 1
C125675 Shackle Assembly, Standard Short, 2.25” 1
D122487 Shackle Link, Standard Short, 2.25” 1
E156766 Shackle Assembly, Heavy Duty Long, 3.13” 1
F1567651 Shackle Link, Heavy Duty Long, 3.13” 1
G126205 Shackle Assembly, Heavy Duty Short, 2.25” 1
H126172 Shackle Link, Heavy Duty Short, 2.25” 1
I126238 Wet Bolt, 9/16” x 2.325” Body with
7/16” - 20 Threaded End 1
J126197 Wet Bolt, 9/16” x 2.825” Body with
7/16” - 20 Threaded End 1
K122102 Bolt, 9/16” x 2.325” Body with
7/16” - 20 Threaded End 1
L271254 Bolt, 9/16” x 2.825” Body with
7/16” - 20 Threaded End 1
M122103 Nut, 7/16” - 20 REVLKN ZN GR2 ST 1
A B
C D
EF
GH
I J K L
M

5
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Prior to Installation
MAKE SURE ANY POINTS OF CONTACT FOR JACK
STANDS DO NOT RESULT IN DAMAGE TO ANY
PANELS OR LINES UNDER THE TRAILER. IMPROPER
RAISING OR LOWERING OF THE TRAILER COULD
RESULT IN DEATH, SERIOUS INJURY OR SEVERE
PRODUCT OR PROPERTY DAMAGE.
3. Remove the tires and wheels from the trailer.
The suspension should be free from any loads, except
its own weight at this point.
4. Place another set of jack stands under the axles,
close to the U-bolt plates. This will provide support to
the axles and ensure that they do not swing down during
disassembly of the shackle components.
NOTE: Allowing the axles to drop could result in damage
to the wiring for the electric brakes.
5. Remove the two shackle nuts (Fig.2A) on the shackle at
the rear of the front spring.
1. Using the properly-rated oor jacks, lift the trailer
according to the manufacturer’s recommendation until the
wheels are no longer in contact with the ground (Fig.1).
2. Support framework in accordance with the
manufacturer’s recommendations.
Fig.1
NOTE: The bolts are pressed into the shackle plate and
should not turn. However, use a properly-sized box end
wrench to make sure the bolts do not turn during the
removal of the nuts.
6. After the nuts and the shackle plate are removed,
remove the shackle plate with the bolts from the other side.
7. After removing the front spring’s shackles at the
equalizer, repeat the process for the shackles (Fig.2C) that
mate the rear spring to the equalizer.
8. Remove the nut on the cross bolt for the equalizer
(Fig.2B). Again, the bolt may be pressed into the frame
hanger and should not be allowed to rotate.
9. Remove the old equalizer.
NOTE: LCI recommends using new shackle links with
shackle bolts and nuts for installation of the Equa-Flex.
Shackle Link kits not included.
Fig.2
A
B
C

6
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Reference figure 3 rear Equa-Flex axle for component
clarification during installation.
Rear Axles
NOTE: When installing the Equa-Flex Equalizer into the
center frame hanger, the Equa-Flex Equalizer label should
be facing out.
1. Install the equalizer bolt through the frame hanger
outside plate, the top most bronze equalizer bushing, and
through the frame hanger inside plate.
2. Use a hammer or a piece of steel tube (for bolts with
a grease tting) and drive the bolt into the frame hanger
outside plate, until the bolt head is seated against the
hanger surface.
Installation
THE TRAILER MUST BE SUPPORTED PER
MANUFACTURER’S RECOMMENDATIONS BEFORE
WORKING UNDERNEATH. FAILURE TO DO SO MAY
RESULT IN DEATH OR SERIOUS INJURY.
Fig.3
frame rail frame hanger
equalizer bolt
leaf spring
shackle link
pivot arm
shackle bolts
leaf spring
3. Both the shackle bolts and equalizer bolt must be
installed from the outside-in towards the center of the
trailer chassis. This ensures that the bolt threads do not
interfere with any other assemblies. This applies to bolts
with or without grease ttings.
4. Thread a nut onto the exposed equalizer bolt thread until
the nut seats against the hanger. Torque the nut until it
bottoms out on the bolt shoulder at 30-50 ft-lbs.
5. Place the axles into the normal operating position.
6. Attach the new shackle links with shackle bolts and
mounting nuts.
7. Torque the nuts until they bottom out on the bolt
shoulder at 30-50 ft-lbs.
8. Repeat steps 1-7 for the opposite side of the trailer.
NOTE: If using the triple axle greaseable bolts with grease
fittings, use any multi-purpose grease marked with the
NLGI code of GC-LB.

7
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Front Axles
1. Install the triple axle equalizer on the roadside frame
hanger with the xed arm (Fig.4) facing the rear of the trailer
and the Equa-Flex logo facing outward.
2. Install the equalizer bolt through the rst bracket
of the frame hanger, then through the topmost bushing
of the Equa-Flex equalizer and, nally, through the second
bracket of the frame hanger.
3. Use a hammer or a piece of steel tube (for bolts with
grease ttings) and drive the equalizer bolt into the frame
hanger. This will seat the serrations of the bolt against
the hanger surface and provide resistance to rotation
when tightening.
Fig.4
NOTE: The equalizer bolt must be installed from the outside
in toward the center of the trailer chassis. This ensures the
bolt threads do not interfere with any other assemblies. This
applies to bolts with or without grease fittings.
4. Install the nut onto the equalizer bolt until the nut seats
against the shoulder bolt. Torque nut to 30-50 ft-lbs.
NOTE: When installing the equalizer bolt nuts, use a
wrench to hold the bolt heads.
5. Repeat steps 1-4 for the opposite side of the trailer,
making sure the xed arm faces towards the rear.
Reference gure 5, which illustrates a roadside installation,
and gure 6, which illustrates a curbside installation, for the
following procedural steps:
frame rail frame hanger equalizer bolt
leaf spring
shackle link
pivot arm
shackle bolts
leaf spring
fixed arm
rear of trailerfront of trailer

8
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Fig.5
Fig.6
6. For Axle #1 and Axle #3, attach the leaf springs to the
hangers with shoulder bolts and nuts (Figs.5 and 6).
7. For Axle #2, attach the leaf spring to the xed arm of
triple axle Equa-Flex equalizer conguration with shackle
bolt and nut (Figs.5 and 6), included within kit.
NOTE: For Axle #2, using kit #281314, when attaching
the leaf spring to the fixed arm, use the front spring eye
location, see the Parts List section for location.
NOTE: A longer shoulder bolt MUST be used to attach the
leaf spring to the Equa-Flex fixed arm.
8. For Axle #1, Axle #2 and Axle #3, attach all shackle
links to the Equa-Flex pivot arm bushings and the leaf
springs with shackle bolts and nuts (Figs.5 and 6).
9. Torque all nuts until they bottom out on the shoulder bolt
at 30-50 ft-lbs.
10. If using the triple axle greaseable bolts with grease
ttings, use any multi-purpose grease marked with the
NLGI code of GC-LB.
11. The installation of the LCI Equa-Flex Equalizer on a
triple axle trailer is now complete (Figs.5 and 6).
12. Lower the trailer evenly to the ground. Use care to
avoid jarring movement. The trailer must NOT be dropped
to the ground. Make sure the shackle links are upright
and located approximately in the 10 o’clock and 2 o’clock
position (Figs.5 and 6).
axle #1 axle #2 axle #3
axle #3 axle #2 axle #1
front of trailer
rear of trailer
rear of trailer
front of trailer
ROADSIDE VIEW OF TRAILER
CURBSIDE VIEW OF TRAILER
axles and wheels removed for clarity
axles and wheels removed for clarity

9
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Notes

10
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474

11
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474

12
lci1.com 574-537-8900 Rev: 09.21.20
Equa-Flex®Triple Axle
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0003474
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lci1.com. Manual information is considered
factual until made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
