Lippert Cosmo 2 Euro User manual

Cosmo 2 Euro
Collapsible table leg
OEM INSTALLATION MANUAL

Rev: 08.31.23 Page 2 CCD-0007174
TABLE OF CONTENTS
Introduction 2
Safety 3
Resources Required 3
Installation 4
Post-installation Check 11
Introduction
Lippert's COSMO 2 Euro Collapsible Table Leg (Fig. 1) has telescoping cylinders powered by gas struts for
easy height adjustment and the table can slide as needed to fully optimize interior space.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/lci-interiors.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
Fig. 1

Rev: 08.31.23 Page 3 CCD-0007174
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause
death or serious personal injury if not performed safely and within the parameters set forth in this
manual.
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
Moving parts can pinch, crush or cut. Keep clear and use caution.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
in this manual.
Safety
Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as
necessary, for effectively interfacing with the device, product or system. Failure to correctly install, remove
or service the system may result in voiding the warranty, inflicting injury or even death.
Resources Required
• 1-2 persons, depending on task
• Fastening hardware, OEM-supplied
• Tabletop material
• Cordless or electric drill
• Appropriate drill bits
• Appropriate drive bits
• Appropriate-sized open-end wrench
• Appropriate-sized hex wrench
• Screwdriver
• Tape measure
• Pencil
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
shield, depending on the nature of the task.

Rev: 08.31.23 Page 4 CCD-0007174
Installation
1. Find a location for the COSMO 2 Euro Collapsible Table Leg (Fig. 2), making sure there is enough
clearance for the pedestal with a table top installed to fully extend.
2. Pull the height adjustment handle (Fig. 2A) and lift the leg's slide support mounting plate (Fig. 3A) to
fully extend the leg.
3. Move the height adjustment handle back into its locked position.
4. The slide support has four mounting holes located across its two pedestal mounting flanges (Fig.4A).
Place the slide support on top of the pedestal's top mounting plate such that the support's four
mounting holes align with the four mounting slots located on the pedestal's top plate.
5. Orient the slide support with the table slide handle on the same side as the height adjustment
handle(Fig. 4).
A
A
Fig. 2 Fig. 3

Rev: 08.31.23 Page 5 CCD-0007174
6. Install a flat washer (Fig. 5A) onto a hex socket head button screw (Fig. 5B). Repeat to assemble
fourscrews.
7. Insert each assembled screw into a mounting hole on the slide support (Fig. 5C).
8. Secure the slide support to the pedestal's top plate by installing a hex nylon lock nut (Fig. 5D) onto
each screw (four places) and securely tighten with a wrench.
A
C
B
D
A
A
Height Adjustment Handle
Table Slide Handle
Slide Support
Fig. 4
Fig. 5

Rev: 08.31.23 Page 6 CCD-0007174
9. Pull the table slide handle outward (Fig. 6A) to release tension on the cable (Fig. 6B).
10. Use a wrench to turn the cable tensioner (Fig. 6C) counterclockwise to loosen the cable.
11. Route the cable so that it goes between the slide table bracket (Fig. 7A) and the threaded stud (Fig. 7B)
for the stopper nut.
NOTE: Pedestal not shown for clarity.
A
CB
A
B
Fig. 6
Fig. 7

Rev: 08.31.23 Page 7 CCD-0007174
12. Hold or clamp the cable against the slide table bracket (Fig. 8A) while installing the stopper nut
(Fig.8B) onto the threaded stud. Use a hex wrench to tighten the stopper nut in-place.
NOTE: Pedestal not shown for clarity.
13. Release the cable. The cable should now rest between the slide table bracket and the stopper
nut(Fig.9A).
NOTE: Pedestal not shown for clarity.
14. Push the table slide handle (Fig. 9B) inward. The cable should rest against the cable tension lock
(Fig.9C) on the handle.
A
B
A
B
C
Fig. 8
Fig. 9

Rev: 08.31.23 Page 8 CCD-0007174
15. If necessary, adjust the table slide until it is centered with the pedestal.
16. Use a wrench to turn the cable tensioner (Fig. 10A) clockwise to restore full tension on the cable.
17. The table is now in its default, locked position.
18. Retrieve the OEM-supplied table top and place it squarely on the slide support.
19. Use a tape measure to make sure that the table top is centered on the slide support side rails (Fig. 11).
Dimensions A and B should be equal and dimensions C and D should be equal for each side (Fig. 11).
C
AB
D
A
Fig. 10
Fig. 11

Rev: 08.31.23 Page 9 CCD-0007174
20. Secure the table top to the slide support's outside rails with OEM-supplied hardware (Fig. 12A)
appropriate for the material and thickness of the table top.
21. Place the pedestal on the floor where it will be mounted.
22. Raise and secure the lower leg covering in-place (Fig. 13).
23. Depending on the type of OEM-supplied fasteners, attach the pedestal to the floor.
A
Fig. 12
Fig. 13
Lower Leg Covering
Base Plate
Floor

Rev: 08.31.23 Page 10 CCD-0007174
A
IV. Using the appropriate-sized drill bit for the OEM-supplied fasteners, drill through the flooring
at the previously marked (step II) six locations.
V. Retrieve the leg and place the pedestal on the floor, aligning the pedestal mounting plate
holes with the drilled holes in the flooring.
VI. Install the OEM-supplied fasteners through the pedestal mounting plate and flooringholes to
secure the collapsible table leg in-place. Tighten mounting hardware wrench-tight.
B. For flathead wood screws:
I. With the pedestal placed on the floor where it will be mounted, use the appropriate-sized drill
bit for the OEM-supplied fasteners.
II. Secure the collapsible table leg in-place with the OEM-supplied fasteners into theflooring.
Fig. 14
Do NOT drill through service lines; hydraulic, electric, fuel, gas. Drilling through service lines can
cause damage to the unit and/or personal injury. Use caution when drilling.
Floor
A. For flathead machine screws with washers and hex nylon lock nuts:
I. Make sure designated drilling area is clear of service lines.
II. Use a pencil to mark the locations of the six mounting holes (Fig. 14A) in the base plate.
III. Set the table leg aside.

Rev: 08.31.23 Page 11 CCD-0007174
Post-installation Check
1. Pull the height adjustment handle (Fig. 16A) and lift to extend the table (Fig. 17).
2. Move the height adjustment handle back into its locked position.
3. Press downward on the table to make sure the collapsible leg is locked in-place and the table does
NOT travel downward.
A
Fig. 15
Fig. 16 Fig. 17
24. Release the leg covering (Fig. 15A) so it extends down to the base.
A
Floor

Rev: 08.31.23 Page 12 CCD-0007174
4. Pull the table slide handle outward (Fig. 18A) to release the table.
A
5. Slide the table right (Fig. 19), left (Fig. 20), backward (Fig. 21) then forward (Fig. 22); locking it in-place
at each direction by pushing the table slide handle(Fig. 23A) inward.
Right Left
Backward
Forward
Fig. 18
Fig. 19 Fig. 20
Fig. 21 Fig. 22

Rev: 08.31.23 Page 13 CCD-0007174
6. Using the table slide handle (Fig. 23A), center the table then pull the height adjustment handle
(Fig.24A) and lower thetable.
7. Move the height adjustment handle back into its locked position.
A
A
Fig. 23
Fig. 24
