Lippert Thomas Payne series User manual

1
lci1.com 5 74 - 5 37- 8 9 0 0 Rev:0 2.13 .18
Thomas Payne®Euro
Recliner
Installation and Owner’s Manual
(For Aftermarket Applications)
Table of Contents
Introduction ............................................ 1
Parts List ................................................ 1
Safety ................................................... 1
Installation .............................................. 2
Additional information .................................. 3
Notes .................................................... 4
Thomas Payne®
Euro Recliner
Installation and
Owner’s Manual
(For Aftermarket Applications)
Introduction
Thomas Payne®furniture is shipped partially assembled.
Parts List
Part # Description
671210 Euro Clip
Safety
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.

2
lci1.com 5 74 - 5 37- 8 9 0 0 Rev:0 2.13 .18
Thomas Payne®Euro
Recliner
Installation and Owner’s Manual
(For Aftermarket Applications)
Installation
1. The seating comes with the back laying on top of the
seat cushion (Fig.1).
Fig.1
Fig.2
2. Lift the seat back and position the single brackets at the
lower seat back in between the double brackets on the
seat bottom, aligning all three holes (Fig.2).

3
lci1.com 5 74 - 5 37- 8 9 0 0 Rev:0 2.13 .18
Thomas Payne®Euro
Recliner
Installation and Owner’s Manual
(For Aftermarket Applications)
3. Once the holes are properly aligned, slide the provided
pin (Fig.3A) through all three holes.
NOTE: If pin is lost or damaged, see Parts List table for
replacement part number.
Fig.3
4. Slide the provided clasp (Fig.4A) down over the end
of the pin. Make sure the head of the pin is inside of the
clasp. The clasp will lock into place.
NOTE: If clasp is lost or damaged, see Parts List table for
replacement part number.
Fig.4
Additional information
Additional information about this product can be obtained
from lci1.com/support or by downloading the free MyLCI
app. The app is available on iTunes®for iPhone®and iPad®
and also on Google Play™for Android™users.
iTunes®, iPhone®and iPad®are registered trademarks of
Apple Inc. Google Play™and Android™are trademarks of
Google Inc.
A
A

4
lci1.com 5 74 - 5 37- 8 9 0 0 Rev:0 2.13 .18
Thomas Payne®Euro
Recliner
Installation and Owner’s Manual
(For Aftermarket Applications)
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lci1.com. Manual information is considered
factual until made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
Notes
