Lippert Thomas Payne Tri-Fold Sofa Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Table of Contents
Introduction ............................................ 2
Preparation ............................................. 2
Tools Required ......................................... 2
Safety ................................................... 2
Sofa Part Numbers ..................................... 3
Installation .............................................. 4
Foot Assembly Instructions ........................... 4
Back Assembly ........................................ 4
Operation Instructions ................................. 5
Care and Cleaning ...................................... 6
Maintenance ............................................ 6
Notes ................................................. 6-8
Thomas Payne®
Tri-Fold Sofa
Installation and
Owner’s Manual
(For Aftermarket Applications)

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Introduction
Our steel frame Tri-Fold Sofa requires no spare mattress to
store, however requires some assembly. In just four simple
steps, it transforms into a comfortable bed. Traditional
hide-a-beds have uncomfortable mattresses with support
bars that can make sleeping uncomfortable. Air mattress
hide-a-beds eliminate the support bar issue, but can be
damaged more easily and become unusable. The Tri-Fold
Sofa coverts from sofa to a very supportive, high-density
foam sleep surface in four simple steps. Now campers can
actually look forward to sleeping on the couch!
Additional information about this product can be obtained
from lci1.com/support or by downloading the free
LippertNOW app in Apple App Store®for iPhone®and
iPad®and also on Google Play™for Android™users. App
Store®and iPad®are registered trademarks of Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
For information on the assembly or individual components
of this product, please visit: https://support.lci1.com/
thomas-payne-collection
Images used in this document are for reference only when
assembling, installing and/or operating this product. Actual
appearance of provided and/or purchased parts and
assemblies may differ.
Safety
Read and fully understand all instructions before installing
or operating this product. Adhere to all safety labels.
FAILURE TO FOLLOW THE INSTRUCTIONS
PROVIDED IN THIS MANUAL MAY RESULT IN DEATH,
SERIOUS INJURY, UNIT DAMAGE, OR VOIDING OF
THE COMPONENT WARRANTY.
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.
Preparation
Tools Required
• Cordless or electric drill or screw gun
• ½” Socket (import tri-fold sofas may use a 8 mm socket)
• Appropriate screw drivers
• Appropriate drive bits

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Sofa Part Numbers
Destination Tri-Fold Sofa - AltoonaDestination Tri-Fold Sofa - Altoona
Description/ColorDescription/Color Part Number
62” Tri-Fold Sofa - Altoona 2020134887
68” Tri-Fold Sofa - Altoona 2020134966
72” Tri-Fold Sofa - Altoona 2020134969
Millbrae
Gummund
Altoona
Norlina
Destination Tri-Fold Sofa - GummundDestination Tri-Fold Sofa - Gummund
Description/ColorDescription/Color Part Number
62” Tri-Fold Sofa - Grummund 2020126718
68” Tri-Fold Sofa - Grummund 2020128147
72” Tri-Fold Sofa - Grummund 2020128895
Destination Tri-Fold Sofa - NorlinaDestination Tri-Fold Sofa - Norlina
Description/ColorDescription/Color Part Number
62” Tri-Fold Sofa - Norlina 2020126719
68” Tri-Fold Sofa - Norlina 2020128771
72” Tri-Fold Sofa - Norlina 2020128896
Destination Tri-Fold Sofa - MillbraeDestination Tri-Fold Sofa - Millbrae
Description/ColorDescription/Color Part Number
62” Tri-Fold Sofa - Millbrae 2020126716
68” Tri-Fold Sofa - Millbrae 2020127590
72” Tri-Fold Sofa - Millbrae 2020128894

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Installation
Foot Assembly Instructions
1. Remove sofa from shipping box.
2. Organize parts.
3. Place sofa on its back (Fig.1) and attach all four feet by
inserting two screws into each foot and into the bottom
of the sofa (Fig.2).
Back Assembly
1. Unfold the front seat and middle seat to expose
mounting bolts and nuts (Fig.3).
Fig.1
Fig.2
foot
screw
Fig.3
front seat
middle seat
bolts and nuts
2. Set back assembly in place with holes in the mounting
brackets aligned with holes in the V2 frame (Fig.4).
Fig.4
3. Insert bolts through mounting bracket and V2 frame.
4. Secure bolts with nuts located on the underside (Fig. 5).
bolts and nuts
Fig.5
V2 frame
bracket
5. Fold front seat and middle into stored position.
6. Attach back cushions using the hook and loop fabric.

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Operation Instructions
back cushions
arm rest
arm insert
foot
couch seat
middle seat
stationary back middle seat
V2 frame
front kick rail
couch seat legs
couch seat
stationary back
Fig.6
NOTE: Refer to (Fig.6) for steps 1-5.
1. Remove back cushions from the hook and loop fabric
strips and set aside.
2. Fold out the couch seat to expose the middle seat.
3. Fold out the couch seat legs and set upright.
4. Fold down the stationary back.
5. Use back cushions as headrest or pillows.

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Care and Cleaning
Thomas Payne Furniture Cleaner is safe for vinyl, leather,
and carpet surface. Cleans the furniture without damaging
the fabric. Spray on, wipe-off application.
Available online at the Lippert store; Thomas Payne
Furniture Cleaner - 32 oz. bottle - 2021017626
Lippert does not recommend the use of any other chemical
products to clean the sofas.
Maintenance
It is recommended that the bolts and nuts of the legs
of the fold out portion of the Tri-Fold Sofa be tightened
on a monthly basis. Over time the bolts and nuts can
loosen, which could cause damage to the middle
cushion.
Notes

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Notes

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 02.08.22
Thomas Payne®
Tri-Fold Sofa
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004522
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
Notes
