Livall MTL User manual

Quick Start Guide
www.livall.com
MTL

2
I.Introduction
Thank you for choosing the LIVALL Smart Helmet. This Guide will instruct you on how to use this product. LIVALL
follows the strategy of sustainable development. This Manual will be updated from time to time. If you need more
detailed instructions, please see the "Important Information and Warranty Card" annex. You can also learn more
about the helmet on LIVALL's ocial website.
Note: The picture is for reference only. If the actual product appears dierent from the picture, the real product shall prevail.
(A few models are not equipped with remote controller due to dierent congurations of the products.)
" > "Button
Microphone
"□"Button
" < "Button
Charging port
Speaker
Speaker
Tail light
Front
Main control
Front chinstrap Rear chinstrap
Adjustment knobBuckle
Back
II. Packing List
Helmet x 1 Quick Start Guide x 1 Bling remote controller x 1
Magnet USB charging cable x 1 Important Information and Warranty Card x 1
Adjust the length of
the chinstrap

3
III. Wearing Instructions
IncorrectIncorrect Correct
Adjust the length of
the chinstrap Leave a gap as thick as one nger Correctly position the helmet Check whether the buckle is properly
fastened

4
IV. Operating Instructions(Please charge the battery before use.Some models of helmets are not equipped with
Bluetooth speakers. The helmets without Bluetooth speakers could not take & make calls, listen to music and hear voice prompts.)
Start-Up
POWER ON"□" function button
" < " button " < " button " > " button
Press the " □" button for
3-to-5 seconds
First hold the "<" button Then press the ">" button to
switch between languages.
You will hear a voice saying
"POWER ON".
The orange tail light will blink
twice indicating Start-Up was
successful.
Change the language of the voice
prompt
(the default language is English)
To switch the language of the voice
prompt, follow the procedure
below when in normal standby
mode and disconnected from a
phone(currently only English and
Chinese are supported).
Orange light

5
IV. Operating Instructions(Please charge the battery before use.Some models of helmets are not equipped with
Bluetooth speakers. The helmets without Bluetooth speakers could not take & make calls, listen to music and hear voice prompts.)
Two "beeps"
"□" function button
Turn on the device, which should
be within 5 meters of the helmet.
It will automatically connect the
helmet.
Place a device that is already ON
near the helmet's main control.
After the connection is established, it
will be conrmed with two "beeps".
(The helmets without Bluetooth
speakers could not hear such voice
prompts. Please check the taillight to see
if the helmet is connected successfully.)
When the warming light flashes
and the helmet speakers emit two
"beeps", it indicates that there is a
device nearby requiring connection
to the helmet.(The helmets without
Bluetooth speakers could not hear
such voice prompts.)
Connecting for the rst time or switching devices(Please refer to specic functions of the helmet when using the
remote controller keys.)
≤5m
1. Connecting for the rst time
One helmet can be connected to up to three LIVALL-authorized devices at the same time. After the handlebar
remote control is connected, press the "left" or "right" button to control the helmet’s corresponding indicator light.
2. Replacing device
Press the " □" button on the helmet
within 10 seconds after you hear
the beeps and conrm connection
to the device.When pressing the
arrow left or right key on the bling
jet remote, the right or left turning
signal appears.
Two "beeps"

6
Connect to the phone (Tip: Once connected, it can control the music player as well as make and receive calls. To ensure
the stability of the connection, please try to position your mobile phone in front of you.)
Helmet Headset
"Click to
connect"
"Pairing..."
"□" function
button
When the device is o, press and
hold the " □" button until you hear
the "Pairing..." sound.
After the connection is completed, you can play music as well as make and answer calls as follows
To Play/Pause Music: Press the " □" button on the helmet or the handlebar remote control to play/pause music.
Adjust Volume: When calls are made or music is played, press the "</>" buttons on the helmet to adjust the
speaker volume.
Previous Song/Next Song: Press the "up/down" buttons on the handlebar remote control or press and hold "</>" buttons on
the helmet to cycle through the music.
Answer/Reject Calls: When there's an incoming call, press the " □" button to answer the call or press and hold to
hang up.
Dial Back: Two quick presses of the " □" button on the handlebar remote control or helmet to redial
the last outgoing call.
Swith on the Bluetooth on your
phone and scan for the "Helmet
Headset" device.
Click to connect. The speakers
on both sides will make the
"Connected" sound when the
connection is completed.
"Connected"

7
Connect LIVALL Riding phone App
(for use the Walkie-Talkie function and take photos)
For Android: Start LIVALL Riding. The App
will automatically connect to the helmet;
For IOS: Follow LIVALL Riding guide to connect
to the helmet.
Only if the helmet is successfully connected to LIVALL APP, SOS alert feature and LED light indicators can work.
Power O
"POWER OFF"
"□" function button
Press and hold the " □" function
button for 3 seconds. You will hear "POWER OFF".(The
helmets without Bluetooth speakers
could not hear such voice prompts.)
The tail light will flash once in
orange indicating the helmet is
POWERED OFF.
Orange
light

8
Charging
To charge
Plug the USB charging cable into
the USB port on the helmet. The
tail charging light is illuminated in
red, indicating that the helmet is
being charged.
Charging time
It is recommended that the power
of the charger is no less than 0.5A.
Charging time takes about 3hours.
Charging complete
When the charging indicator light
turns o, it indicates that charging
is complete.
USB port Red light
0.5A 3 HRS

9
LIVALL Riding APP
LIVALL ON FACEBOOK
Bluetooth :
Bluetooth distance :
Charging port :
Electricity parameter :
Charging time :
Battery life :
Standby duration:
BT 4.1 + HFP/HSP/A2DP + BLE 4.0
Max. 10 meters
Magnet USB Charging cable
DC 5V/0.5A
3 hours
The max. battery life of the light is 10 hours. Listening time for music
is 3-to-6 hours.
Max. 180 days
Temperature : Temperature for use: 0°C~40°C.
Recommended temperature for storage : -20~45°C
VI. Technical Specications
V. Considerations
1. The helmet contains electronic parts inside. Please do not take a long ride in the rain although the helmet can
prevent the rain from splashing.
2. After the helmet gets wet in the rain, the water droplets might occur in the chimney of tail LED lights. The water
droplets will disappear when you put the helmet under the ventilation environment for 1-2 days.
3. The helmet contains the battery of 3.7V/450mAh. The battery capacity varies with temperature change. The
battery life can decay when the helmet is used at low temperatures or below Zero degrees Celsius.
4. Trying to clean the golden colour contacts of the charging plug sheet with metal or hard tools such as blades or
tweezers is strictly forbidden. Please use cotton swabs with clean water or alcohol in case of cleaning. Please make
sure the charging plug is clean and try while charging the helmet.
5. If the electronic functions do not work, please charge the helmet for 3 hours and then check if it works normally.
6. The helmet contains impact detection devices. Only if you connect your helmet with LIVALL APP, start ride mode
on the APP and your helmet suers from the heavy impact, SOS alert feature can be triggered. Your emergency
contacts set on LIVALL APP can accordingly receive your SOS messages.

10
• That the helmet can only protect if it ts well and that the buyer should try dierent sizes and choose the size
which feels secure and comfortable on the head.
• That the helmet should be adjusted to t the user e.g. the straps positioned so that they do not cover the ears,
the buckle positioned away from the jawbone and the straps and buckle adjusted to be both comfortable
and rm.
• How the helmet should be position on the head to ensure the intended protection is provided (e.g. that it
should be placed so as to protect the forehead and not be pushed too far over the back of the head.
• That a helmet cannot always protect against injury.
• That a helmet subjected to a severe impact should be discarded and destroyed.
• A statement of the danger of modifying or removing any of the original component parts of the helmet other
than as recommended by the manufacturer, and that helmets should not be adapted for the purpose of
tting accessories in a way not recommended by the manufacturer
LIVALL's website : www.livall.com
Performance standards:
• USA: CPSC1203:1998, FCC Part 15 Rules
• Europe: EN 62479:2010, EN 301 489-1 V1.9.2 (2011-09), EN 301 489-17 V2.2.1 (2012-09),
EN 300 328 V1.8.1 2012-06, EN 60950-1:2006+A11:2009+A1:2010+A12:2011
• Australia: AS/NZS 2063:2008+A1:2009, AS/NZS CISPR 22:2009+A1:2010, AS/NZS 4268:
2012+A1:2013, Radiation Protection Series Publication No. 3
