LIVARNO LUX 74184 User manual

IAN 74184
ENERGY-SAVING FATHER & CHILD FLOOR LAMP
ENERGY-SAVING FATHER &
CHILD FLOOR LAMP
Operation and Safety Notes

GB / IE Operation and Safety Notes Page 5
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the
device.

1241/022L 1242/022L
11
9
8
7
6
5
3
4
2
1
10
13
12
16
17
18
19
20
21
11
9
8
7
6
5
3
4
2
1
10
13
12
16
17
18
19
20
21
1515 14 14

5GB/IE
Table of contents
Introduction
Proper use............................................................................................................................................Page 6
Included items .....................................................................................................................................Page 6
Description of parts and features.......................................................................................................Page 6
Technical data.....................................................................................................................................Page 6
Safety
Safety advice.......................................................................................................................................Page 7
Preparing the product for use
Assembling the lamp...........................................................................................................................Page 8
Switching the lamp on / off.................................................................................................................Page 8
Directing the lamp...............................................................................................................................Page 8
Replacing a bulb.................................................................................................................................Page 8
Care and cleaning....................................................................................................................Page 8
Disposal............................................................................................................................................Page 9
Warranty and Service
Warranty Declaration.........................................................................................................................Page 9
Service address...................................................................................................................................Page 9
Declaration of Conformity ..................................................................................................................Page 9
Manufacturer.......................................................................................................................................Page 9

6 GB/IE
Introduction
Energy-Saving Father &
Child Floor Lamp
Introduction
We congratulate you on the purchase of
your new device. You have chosen a high
quality product. Please read carefully
and completely through these operating instructions.
Fold out the page with the illustrations. These instruc-
tions form part of the product and contain important
information about bringing the product into use and
its handling. Always observe all the safety advice.
Check that the correct mains voltage is available and
that all the parts have been properly assembled
before bringing into use. Should you have any ques-
tions or be uncertain as to how to operate the de-
vice, please get in touch with your dealer or service
point. Please keep these instructions in a safe place
and hand them on to a third party if necessary.
Proper use
This light is suitable only for interior use, in dry and
enclosed spaces. This lamp is intended for use only
in a domestic environment.
Included items
Check that all the items and accessories are pre-
sent and that the lamp is in perfect condition
immediately after unpacking.
1 Floor lamp, Model 1241 / 022L or 1242 / 022L
2 Lamp glasses
1 Energy-saving bulb, 9 W, E 14
1 Energy-saving bulb, 22 W, E 27
2 Threaded rings
1 Tool
1 Support tube (reading lamp)
1 Support tube (uplight)
2 Threaded rods (support tube mount)
1 Support tube mount
2 Serrated lock washers
2 Nuts
1 Open spanner
1 Operating instructions
Description of parts
and features
1241 / 022L + 1242 / 022L
1Bulb (uplight)
2Threaded ring (uplight)
3Lamp glass (uplight)
4Fitting (socket) (uplight)
5Flexible arm
6Fitting (socket) (reading lamp)
7Lamp glass (reading lamp)
8Threaded ring (reading lamp)
9Tool
10 Support tube (reading lamp)
11 Bulb (reading lamp)
12 Mains lead with mains plug
13 Base
14 Serrated lock washers
15 Nuts
16 Support tube mount
17 Threaded rods (support tube mount)
18 Support tube (uplight)
19 ON / OFF switch (reading lamp)
20 ON / OFF switch (uplight)
21 Upper support tube
Technical data
Model No.: 1241 / 022L or 1242 / 022L
Operating voltage: 230–240 V ∼, 50 Hz
Bulbs: Energy-saving bulbs:
230–240 V ∼, E14, 9 W;
E27, 22 W (included)
or
230–240 V ∼, E14, 25 W;
E27, 60 W (not included)
Rated max. power: 1 x 25 W (reading lamp)
1 x 60 W (uplight)
Protection class:

7GB/IE
Safety
Safety
Safety advice
The right to claim under the guarantee shall be
rendered invalid in respect of damage caused by
the non-observance of these operating instructions!
No liability is accepted for consequent damage!
No liability is accepted for damage to property
or persons caused by improper handling or non-
observance of the safety advice!
To avoid danger to
life from electric shock
Every time before connecting the lamp the mains,
check it and the mains lead for damage. Never
use your light if you find it is damaged in any way.
CAUTION! A damaged light bulb means your
life is at risk from electric shock. If there is any
damage, repairs to be carried out or other
problems related to the light bulb, please contact
the service centre or a qualified electrician.
In order to prevent hazards, if the outer flexible
cable of this lamp becomes damaged it may
only be replaced by the manufacturer, a service
representative of the manufacturer or a similar
specialist!
Before assembly, ensure that the mains voltage
available corresponds to the operating voltage
necessary of the light (230–240V∼).
Never let the lamp come into contact with water
or other liquids.
Never open or insert anything into electrical
fittings or equipment. Doing this sort of thing can
lead to a serious danger to life from electric shock.
To avoid danger
of fire and injury
CAUTION! RISK OF INJURY! Check bulbs
for damage immediately after unpacking. Do
not fit defective bulbs into the light. If they are,
contact the service point for a replacement.
CAUTION! RISK OF INJURY FROM
BURNS! Ensure the lamp has been switched
off and allowed to cool before you touch it. In
this way you will avoid the danger of burns.
Bulbs give off a lot of heat around the top of
the lamp.
0.5 m
RISK OF FIRE! Install the light
so that it is at least 0.5 m from any
illuminated materials. Fire can result
from the development of too much heat.
Immediately replace the faulty light bulb with
a new one. Remove the lamp from the socket
before changing the light bulb.
Do not allow any objects to cover the lamp.
Fire can result from the development of too
much heat.
Never leave the lamp operating unattended.
Do not allow the lamp or the packaging materials
to lie around unattended. Plastic film or bags,
Styrofoam etc. can turn into dangerous toys for
children.
Working safely
Use only 230–240 volt ∼ energy-saving bulbs
with an E14 fitting and a maximum power
output of 9 watts for the reading lamp. Use only
230–240 volt ∼ energy-saving bulbs with an
E27 fitting and a maximum power output of
22 watts for the uplight.
or
Use only 230–240 volt ∼ bulbs with an E14
fitting and a maximum power output of 25 watts
for the reading lamp. Use only 230–240 volt ∼
bulbs with an E27 fitting and a maximum power
output of 60 watts for the uplight.
Install the light so that it is protected from
moisture and dirt.
Prepare carefully before assembly and allow
yourself enough time. Lay out all the individual
components and additional tools or materials
required so that you can see and reach them.
Remain alert at all times and always watch what
you are doing. Always proceed with caution
and do not assemble the lamp if you cannot
concentrate or feel unwell.

8 GB/IE
Preparing the product for use / Care and cleaning
Preparing the product for use
Assembling the lamp
Note: You will require a second person to help
with the assembly of the product.
Note: Assembly is identical for both models
(1241 / 022L or 1242 / 022L).
Before installation, remove the two black plastic
rings on the end of the support tube 18 to allow
the components to be screwed together properly.
First screw the support tube 18 clockwise into
the upper support tube 21 . Ensure that the
mains lead does not become trapped when it
is fed through the support tubes 18 , 21 .
Then screw the support tube 10 clockwise into
the flexible arm 5.
Screw the two threaded rods 17 clockwise into
the support tubes 10, 18 and push the support
tube mount 16 on to the threaded rods 17 .
Insert the floor lamp with the threaded rods 17
into the preformed holes in the base 13 .
Place the serrated lock washers 14 at the
underside of the support tube 13 on to the
threaded rods 17. Using the open spanner,
tighten the nuts 15 clockwise on to the threaded
rods 17 to fix the floor lamp to the base 13.
Note: Ensure that you hold the support tubes
10, 18 and threaded rods 17 firmly in place
when you are tightening the nuts 15.
Note: Ensure that the threaded rods 17 are
screwed in as far as possible so that the lamp
is stable when standing up.
Push the lamp glasses 3, 7over the fittings
4, 6. Fix the lamp glasses in place with the
threaded rings 2, 8using the tool 9.
Note: Use a dry, fluff-free cloth for inserting
the bulbs.
Screw the bulbs 1, 11 clockwise into the
fittings 4, 6.
Insert the mains plug 12 into a properly
installed socket.
Your lamp is now ready for operation.
Switching the lamp on / off
Use the ON / OFF switch 20 to switch the
uplight on or off.
Use the ON / OFF switch 19 to switch the
reading lamp on or off.
Directing the lamp
Bend the flexible arm 5to bring the reading
lamp into the desired position.
Replacing a bulb
RISK OF ELECTRIC SHOCK!
First pull the mains plug 12 out of the mains socket.
CAUTION! RISK OF BURNS! First allow the
lamp to cool completely.
Unscrew the defective bulb 1, 11 anticlockwise
out of the fitting 4, 6.
Then screw a new bulb clockwise into the fitting.
Note: Use only 230–240 volt ∼ energy-saving
bulbs with an E14 fitting and a maximum power
output of 9 watts for the reading lamp. Use
only 230–240 volt ∼ energy-saving bulbs with
an E27 fitting and a maximum power output of
22 watts for the uplight.
or
Use only 230–240 volt ∼ bulbs with an E14
fitting and a maximum power output of 25 watts
for the reading lamp. Use only 230–240 volt ∼
bulbs with an E27 fitting and a maximum power
output of 60 watts for the uplight.
Care and cleaning
RISK OF ELECTRIC SHOCK!
First pull the mains plug 12 out of the mains socket.
CAUTION! RISK OF BURNS! First allow the
lamp to cool completely.
RISK OF ELECTRIC SHOCK!
For electrical safety reasons, never clean the lamp
with water or other fluids nor immerse it in water.

9GB/IE
Care and cleaning / Disposal / Warranty and Service
Do not use any solvents, petrol or similar. This
would cause damage to the light.
Always use a dry, fluff-free cloth for cleaning.
Disposal
The packaging and ancillary packing
consist entirely of environmentally-friendly
materials. They can be disposed of at
your local recycling facility.
The symbol of the wheelie bin with the line
through it means that, in the European
Union, the product has to be disposed
of in a separate refuse collection. This applies to the
product and to all components bearing this symbol.
Products marked in this way may not be disposed
of along with normal domestic waste but have to
be handed in at a recycling collection point for
electrical and electronic appliances. Recycling helps
to reduce the consumption of raw materials and to
ease the burden on the environment.
Warranty and Service
Warranty Declaration
This product has a 3-year warranty from the date
of purchase; the warranty is only valid for the origi-
nal purchaser and is not transferable. Please keep
your receipt as proof of purchase. The warranty
applies to material or manufacturing defects only. It
does not cover wear parts or damage caused by
improper use. The guarantee lapses in cases of un-
authorized tampering. Your statutory rights are not
restricted in any way by this warranty. Please con-
tact the service centre by telephone. In the event of
any claims under the warranty. This is the only way
to ensure that your instrument can be returned free
of charge.
Service address
Briloner Leuchten GmbH
Im Kissen 2, 59929 Brilon, Germany
Tel.: [phone] / 97 12–0
Fax: [phone]
E-mail: [e-mail]
IAN 74184
Please have your receipt and the product number
(e.g. IAN 12345) available for all queries as proof
of purchase.
Declaration of Conformity
This product fulfils the requirements of the
applicable European and national directives
(Electromagnetic Compatibility 2004 / 108 / EC,
Low Voltage Directive 2006 / 95 / EC). Conformity
has been demonstrated. The relevant declarations
and documents are held by the manufacturer.
Manufacturer
Briloner Leuchten GmbH
Im Kissen 2
59929 Brilon
Germany

10

11

12

IAN 74184
Briloner Leuchten GmbH
Im Kissen 2
59929 Brilon (Germany)
© by ORFGEN Marketing
Last Information Update: 04 / 2012
Ident.-No.: 1241/022L + 1242/022L042012-6
