Thank you very much for purchasing “LOBSTER” air riveter.
䞉These are the blind rivet tools which is only used for fixing blind rivets. These tools are not
designed for other purposes.
䞉This instruction manual shows how to use the tools safely, work properly, maintenance and
inspection which will make tools more effectively.
䞉Please check the blind rivets specification and durability on customers side before using it.䚷
䞉Read this manual carefully before using this tool. Follow instructions in this manual for
handling this tool, replacing accessories or replacing parts as needed.
䞉If you have any questions about this manual, contact the “LOBSTER” dealer where you
purchased the tool.
䞉It is impossible to foresee all potential dangers and describe them in this manual.
You must operate this tool paying attention to safety as well as observing the instructions
in this manual.
䞉This manual is translated from Japanese, its original language. It is your own responsibility
to achieve a full understanding of the contents of this manual before using the equipment
described.
䞉Lobtex Co., Ltd. has the copyright of this manual. It is prohibited to publish, copy or translate
to other language without prior consent.
䞉Our warranty does not apply to direct and indirect damages and lost income caused by the
misuse, abuse, and unauthorized modification of the tool.
We do not guarantee the strength or quality of blind rivet.
䞉We do not guarantee any damages and failures caused by any modifications without our
written approval.
䞉We do not guarantee any damages and failures caused by use of parts other than our
recommendation.

2
ᾀᵌᵲᶆᶃᴾᵿᶇᶐᴾᶎᶐᶃᶑᶑᶓᶐᶃᴾᶑᶆᶍᶓᶊᶂᴾᶀᶃᴾᶉᶃᶎᶒᴾᶕᶇᶒᶆᶇᶌᴾᶒᶆᶃᴾᶐᵿᶌᶅᶃᴾᶍᶄᴾᵎᵌᵓᴾᶒᶍᴾᵎᵌᵔᴾᵫᵮᵿᵌ
㻌㻌䞉 If an air pressure which is greater than this is used, the tool may become damaged, and
injury or damage to property may result.
ᾁᵌᵬᶃᶔᶃᶐᴾᶊᶍᶍᶉᴾᶇᶌᶒᶍᴾᶒᶆᶃᴾᶌᶍᶑᶃᶎᶇᶃᶁᶃᴾᶍᶄᴾᶒᶆᶃᴾᶒᶍᶍᶊᵊᴾᵿᶌᶂᴾᶌᶃᶔᶃᶐᴾᶎᶍᶇᶌᶒᴾᶒᶆᶃᴾᶌᶍᶑᶃᶎᶇᶃᶁᶃᴾᶒᶍᶕᵿᶐᶂᴾᶍᶒᶆᶃᶐᴾᶎᶃᶐᶑᶍᶌᶑᵌᴾᴾ
㻌㻌䞉 If the tool is used while the cut mandrels are still inside the tool not being ejected these mandrels
may be ejected from the tool’s nosepiece during use and cause serious injury.
ᾂᵌᵬᶃᶔᶃᶐᴾᶂᶇᶐᶃᶁᶒᴾᶒᶆᶃᴾᶃᶌᶂᴾᶍᶄᴾᶒᶆᶃᴾᶁᶆᶓᶒᶃᴾᶆᶍᶑᶃᴾᵆᶔᶃᶌᶒᴾᶍᶄᴾᶁᶓᶒᴾᶐᶇᶔᶃᶒᴾᶋᵿᶌᶂᶐᶃᶊᶑᵇᴾᶒᶍᶕᵿᶐᶂᴾᵿᶌᶗᴾᶎᶃᶐᶑᶍᶌᵌ
㻌㻌䞉 Cut rivet mandrels may be blasted off from the end of the chute hose and may cause injury.
ᾃᵌᵫᵿᶉᶃᴾᶑᶓᶐᶃᴾᶒᶍᴾᶎᶓᶒᴾᶒᶆᶃᴾᵡᶆᶓᶒᶃᴾᵦᶍᶑᶃᴾᶕᶆᶃᶌᴾᶓᶑᶇᶌᶅᵌ
ᴾᴾᴾᴾᵟᶊᶕᵿᶗᶑᴾᶕᶃᵿᶐᴾᶎᶐᶍᶒᶃᶁᶒᶇᶔᶃᴾᶅᶍᶅᶅᶊᶃᶑᴾᶕᶆᶇᶊᶃᴾᶗᶍᶓᴾᶓᶑᶃᴾᶒᶆᶃᴾᶒᶍᶍᶊᵌᴾᴾ
㻌㻌䞉 Spent mandrels may come out and cause the injuries.
㻌㻌䞉 Make sure to put the Chute Hose properly all the way (Nozzle Unit).
If the Chute Hose was not set properly, the hose may fall off and cause injuries.䚷
ᾄᵌᵫᵿᶉᶃᴾᶑᶓᶐᶃᴾᶒᶆᵿᶒᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᵿᶌᶂᴾᶒᶆᶃᴾᵿᶇᶐᴾᶑᶍᶓᶐᶁᶃᴾᵿᶐᶃᴾᶁᶍᶌᶌᶃᶁᶒᶃᶂᴾᶑᶃᶁᶓᶐᶃᶊᶗᵌ
㻌㻌䞉 If the threads of the joints do not match or if the screws are not inserted far enough, the air hose
may become disconnected during use and injury may result.
㻌㻌䞉 Use hose bands to securely connect the air hose joint and air hose. If they are not securely䚷㻌㻌
connected, the air hose may become disconnected during use and injury may result.
ᾅᵌᵲᶓᶐᶌᴾᶍᶄᶄᴾᶒᶆᶃᴾᵿᶇᶐᴾᶑᶓᶎᶎᶊᶗᴾᶀᶃᶄᶍᶐᶃᴾᶂᶇᶑᶁᶍᶌᶌᶃᶁᶒᶇᶌᶅᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶄᶐᶍᶋᴾᶒᶆᶃᴾᵿᶇᶐᴾᶑᶍᶓᶐᶁᶃᵌ
㻌㻌䞉 Compressed air may cause the air hose to whip around and injury may result.
ᾆᵌᵡᶆᶃᶁᶉᴾᶒᶆᵿᶒᴾᵿᶊᶊᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶎᵿᶐᶒᶑᴾᵿᶐᶃᴾᶄᶐᶃᶃᴾᶄᶐᶍᶋᴾᶂᵿᶋᵿᶅᶃᴾᶀᶃᶄᶍᶐᶃᴾᶓᶑᶃᵌᴾᵟᶌᶗᴾᶂᵿᶋᵿᶅᶃᶂᴾᶎᵿᶐᶒᶑᴾᶑᶆᶍᶓᶊᶂᴾᶀᶃ
ᴾᴾᴾᴾᶐᶃᶎᵿᶇᶐᶃᶂᴾᶀᶃᶄᶍᶐᶃᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶇᶑᴾᶓᶑᶃᶂᵌẅᴾẅᴾ
㻌㻌䞉 If the tool is used while any parts are damaged, injury may result.
㻌㻌䞉 If the tool is damaged by objects being dropped onto it, the damaged part may break and accident
or injury may result. 䚷㻌䚷䚷䚷
㻌㻌䞉 Don't pull and drag the tool by the air hose. It may trigger some damages on the tool body,
breakage of Rotary Joint or some other defects and lead serious troubles with injuries.
ᾇᵌᵧᶄᴾᶓᶑᶇᶌᶅᴾᶇᶌᴾᶃᶊᶃᶔᵿᶒᶃᶂᴾᶊᶍᶁᵿᶒᶇᶍᶌᶑᵊᴾᶓᶑᶃᴾᵿᴾᶑᵿᶄᶃᶒᶗᴾᶆᵿᶐᶌᶃᶑᶑᵊᴾᵿᶌᶂᴾᶒᵿᶉᶃᴾᶁᵿᶐᶃᴾᶒᶍᴾᵿᶔᶍᶇᶂᴾᶂᶐᶍᶎᶎᶇᶌᶅᴾᶐᶇᶔᶃᶒᶑ
ᴾᴾᴾᴾᶍᶐᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶇᶒᶑᶃᶊᶄᵌᴾ
㻌㻌䞉Accident or injury may result if this practice is not followed.
⅐ ※‿⁂⁁⁄⁆″⁀⁆‒⁅″‸‷⁆⁋‒※⁀⁅⁆⁄⁇‵⁆※⁁⁀⁅
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
䕺Be sure to read the following Important Safety Instructions carefully and make sure that you
understand them thoroughly before using this tool.
䕺Always wear protective goggles while using the tool.
The rivets may jump out by accident and cause injuries.
◆◆◆◆◆
英語／ENGLISH
英語／ENGLISH
䕺This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
䕺After reading this manual, keep it in a safe place where it is easily accessible to all users.
: Indicates a potentially hazardous situation which, if ignored, may result in death
or serious injury to the operator.
: Indicates a potentially hazardous situation which, if ignored, may result in moderate
injury to the operator or physical damage.
Moreover, failure to follow the instructions marked with the symbol or cautions without a
symbol which appear in the text of this manual may also have serious results in some
cases. Always be sure to observe the instructions given in the lmportant Safety Instructions.
䕺These Important Safety Instructions are divided into and .
The differences between these two levels are described below.
⚠ᵵᵟᵰᵬᵧᵬᵥ ⚠ᵵᵟᵰᵬᵧᵬᵥ
⚠ᵵᵟᵰᵬᵧᵬᵥ
⚠ᵡᵟᵳᵲᵧᵭᵬ ⚠ᵡᵟᵳᵲᵧᵭᵬ
⚠ᵡᵟᵳᵲᵧᵭᵬ
⚠ᵡᵟᵳᵲᵧᵭᵬ

3
ᴾᴾᾀᵌᵠᶃᶄᶍᶐᶃᴾᶑᶒᵿᶐᶒᶇᶌᶅᴾᶋᵿᶇᶌᶒᶃᶌᵿᶌᶁᶃᴾᶍᶐᴾᶂᶇᶑᵿᶑᶑᶃᶋᶀᶊᶇᶌᶅᴾᶒᶆᶃᴾᶓᶌᶇᶒᴾᶒᶍᴾᶐᶃᶎᶊᵿᶁᶃᴾᶎᵿᶐᶒᶑᵊᴾᶀᶃᴾᶑᶓᶐᶃᴾᶒᶍᴾᶑᶒᶍᶎ
ᴾᴾᴾᴾᴾᴾᵿᶇᶐᴾᶑᶓᶎᶎᶊᶗᵌẅᴾ
㻌㻌㻌䞉 Performing maintenance or disassembly with air supplied may cause a part to jump out, oil to
squirt out, or the unit to perform unexpectedly, and may result in an accident or personal injury.
ᴾᴾᾁᵌᵲᶇᶅᶆᶒᶃᶌᴾᶒᶆᶃᴾᵠᶊᶃᶃᶂᴾᵮᶊᶓᶅᴾᶄᶇᶐᶋᶊᶗᴾᶀᶃᶄᶍᶐᶃᴾᶓᶑᶃᵌẅᴾ
㻌㻌㻌䞉 If the bleed Plug is loose or coming off during use, oil may squirt out resulting in an accident or
personal injury.
ᴾᴾᾂᵌᵢᶍᴾᶌᶍᶒᴾᶍᶎᶃᶐᵿᶒᶃᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶕᶇᶒᶆᶍᶓᶒᴾᶃᶏᶓᶇᶎᶎᶃᶂᴾᶒᶆᶃᴾᶄᶐᵿᶋᶃᴾᶆᶃᵿᶂᵌᴾẅᴾ
㻌㻌㻌䞉 Items such as fingers or a hand may become caught in the mechanism.
ᴾᴾᾃᵌᵢᶍᴾᶌᶍᶒᴾᶀᶐᶇᶌᶅᴾᶗᶍᶓᶐᴾᶄᵿᶁᶃᴾᶁᶊᶍᶑᶃᴾᶒᶍᴾᶒᶆᶃᴾᵿᶇᶐᴾᶍᶓᶒᶊᶃᶒᴾᶆᶍᶊᶃᶑᵌẅᴾ
㻌㻌㻌䞉 Pressurized air containing fine particles is discharged from the air outlet holes during use.
Keep eyes away from this area.
ᴾᴾᾄᵌᵟᶔᶍᶇᶂᴾᶑᶉᶇᶌᴾᶁᶍᶌᶒᵿᶁᶒᴾᶕᶇᶒᶆᴾᶑᶓᶀᶑᶒᵿᶌᶁᶃᶑᴾᶑᶓᶁᶆᴾᵿᶑᴾᶆᶗᶂᶐᵿᶓᶊᶇᶁᴾᶍᶇᶊᵊᴾᶊᶓᶀᶐᶇᶁᵿᶒᶇᶌᶅᴾᶍᶇᶊᴾᵿᶌᶂᴾᶅᶐᶃᵿᶑᶃᵌᴾẅᴾ
㻌㻌㻌䞉 Such substances may cause inflammation of the skin. If they come into contact with your skin,
㻌wash the affected area thoroughly.
ᴾᴾᾅᵌᵲᶆᶃᴾᶎᵿᶐᶒᶑᴾᶒᶍᴾᶀᶃᴾᶓᶑᶃᶂᴾᶋᶓᶑᶒᴾᶀᶃᴾᶒᶆᶍᶑᶃᴾᶑᶓᶎᶎᶊᶇᶃᶂᴾᶄᶐᶍᶋᴾᵪᶍᶀᶒᶃᶖᴾᶍᶐᴾᶐᶃᶁᶍᶋᶋᶃᶌᶂᶃᶂᴾᶀᶗᴾᵪᶍᶀᶒᶃᶖᵌ
ẅẅᴾᴾᵱᶃᶊᶃᶁᶒᴾᵿᶌᶂᴾᵿᶒᶒᵿᶁᶆᴾᶎᵿᶐᶒᶑᴾᵿᶎᶎᶊᶇᶁᵿᶀᶊᶃᴾᶒᶍᴾᶗᶍᶓᶐᴾᶐᶇᶔᶃᶒᵌẅᴾ
㻌㻌㻌䞉 Otherwise the unit may not produce maximum performance and may malfunction resulting in an
accident or personal injury.
ᴾᴾᾆᵌᵫᵿᶉᶃᴾᶑᶓᶐᶃᴾᶒᶆᵿᶒᴾᶒᶆᶃᴾᶕᶍᶐᶉᶎᶊᵿᶁᶃᴾᶇᶑᴾᶑᵿᶄᶃᵊᴾᶁᶊᶃᵿᶌᴾᵿᶌᶂᴾᶍᶐᶅᵿᶌᶇᶘᶃᶂᵌẅᴾ
㻌㻌㻌䞉 Accidents can easily occur in untidy workplaces.
㻌㻌㻌䞉 If the cut mandrels are allowed to fall onto the floor, you may slip on them, and injury may result.
ᴾᴾᾇᵌᵟᶔᶍᶇᶂᴾᶓᶌᶁᶍᶋᶄᶍᶐᶒᵿᶀᶊᶃᴾᶎᶍᶑᶒᶓᶐᶃᶑᴾᶕᶆᶇᶊᶃᴾᶕᶍᶐᶉᶇᶌᶅᵌẅẅᴾ
㻌㻌㻌䞉 You may fall down and injury may result.
ᴾᴾᾈᵌᵩᶃᶃᶎᴾᶎᶃᶍᶎᶊᶃᴾᶕᶆᶍᴾᵿᶐᶃᴾᶌᶍᶒᴾᶇᶌᶔᶍᶊᶔᶃᶂᴾᶇᶌᴾᶕᶍᶐᶉᴾᵿᶕᵿᶗᴾᶄᶐᶍᶋᴾᶒᶆᶃᴾᶕᶍᶐᶉᶎᶊᵿᶁᶃᵌẅẅᴾ
㻌㻌㻌䞉 Accidents or injury may result.
ᾀ὿ᵌᵫᵿᶇᶌᶒᵿᶇᶌᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶕᶇᶒᶆᴾᶁᵿᶐᶃᵌẅẅᴾ
㻌㻌㻌䞉 Refer to the Instruction Manual for details on replacing parts and attachments, otherwise injury㻌
㻌may occur.㻌
ᾀᾀᵌᵩᶃᶃᶎᴾᶒᶆᶃᴾᶆᵿᶌᶂᴾᶅᶐᶇᶎᴾᶂᶐᶗᴾᵿᶌᶂᴾᶁᶊᶃᵿᶌᵊᴾᵿᶌᶂᴾᵿᶔᶍᶇᶂᴾᵿᶂᶆᶃᶑᶇᶍᶌᴾᶍᶄᴾᶍᶇᶊᴾᵿᶌᶂᴾᶅᶐᶃᵿᶑᶃᵌẅẅᴾ
㻌㻌㻌䞉 Otherwise the grip may slip from your hand resulting in falling of the unit.
ᾀᾁᵌᵢᶍᴾᶌᶍᶒᴾᶊᶃᵿᶔᶃᴾᶒᶆᶃᴾᶄᶊᶍᶍᶐᴾᶊᶇᶒᶒᶃᶐᶃᶂᴾᶕᶇᶒᶆᴾᶁᶓᶒᴾᶋᵿᶌᶂᶐᶃᶊᶑᵌẅẅᴾ
㻌㻌㻌䞉 Cut mandrels are dangerous because their ends are sharp. Stepping on them is also dangerous
easily causing a slip and fall accident.
ᾀᾂᵌᵳᶑᶃᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶁᵿᶐᶃᶄᶓᶊᶊᶗᴾᵿᶌᶂᴾᶁᶍᶌᶁᶃᶌᶒᶐᵿᶒᶃᴾᶍᶌᴾᶁᶍᶐᶐᶃᶁᶒᴾᶍᶎᶃᶐᵿᶒᶇᶍᶌᴾᵿᶒᴾᵿᶊᶊᴾᶒᶇᶋᶃᶑᵌᴾᴾ
㻌㻌㻌䞉 Use the tool with proper care, paying full attention to methods of handing and operation and
surrounding conditions. Accidents and injury may result if this practice is not followed.
㻌㻌㻌䞉㻌Use common sense at all times, otherwise accidents or injury may result.
㻌㻌㻌䞉 When you are tired, do not use the tool, otherwise accidents or injury may result.
ᾀᾃᵌᵟᶑᶉᴾᵪᶍᶀᶒᶃᶖᴾᶒᶍᴾᶁᵿᶐᶐᶗᴾᶍᶓᶒᴾᵿᶌᶗᴾᶐᶃᶎᵿᶇᶐᴾᶕᶍᶐᶉᴾᶐᶃᶏᶓᶇᶐᶃᶂᵌẅᴾ
㻌㻌㻌䞉 Repair work should only be carried out by a qualified technician. Please contact your nearest
“LOBSTER”distributor, representative, or direct to Lobtex Co.,Ltd.,Osaka. If the tool is repaired
by someone without the necessary qualifications and experience, the tool may not perform to
optimum standards, and accidents or injury may result.
ᾀᾄᵌᵢᶍᴾᶌᶍᶒᴾᵿᶒᶒᶃᶋᶎᶒᴾᶒᶍᴾᶋᶍᶂᶇᶄᶗᴾᶒᶆᶃᴾᶒᶍᶍᶊᵌẅẅᴾ
㻌㻌㻌䞉 Unauthorized modifications may cause malfunctions which can lead to accidents or injury.
ᾀᾅᵌᵵᶆᶃᶌᴾᶂᶇᶑᶎᶍᶑᶇᶌᶅᴾᶍᶄᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶍᶐᴾᶎᵿᶁᶉᶇᶌᶅᴾᶋᵿᶒᶃᶐᶇᵿᶊᶑᵊᴾᶍᶀᶑᶃᶐᶔᶃᴾᶊᶍᶁᵿᶊᴾᶊᵿᶕᶑᴾᵿᶌᶂᴾᶁᶍᶂᶃᶑᴾᶍᶌᴾᶕᵿᶑᶒᶃ
ᴾᴾᴾᴾᴾᴾᶂᶇᶑᶎᶍᶑᵿᶊᵌẅẅᴾ
ᾀᾆᵌᵢᶍᴾᶌᶍᶒᴾᶐᶃᶋᶍᶔᶃᴾᶐᶓᶀᶀᶃᶐᴾᶀᶃᶊᶊᶍᶕᶑᴾᵿᶒᴾᶑᶕᶇᶔᶃᶊᴾᶈᶍᶇᶌᶒᴾᶇᶌᴾᶒᶆᶃᴾᶃᶌᶂᴾᶍᶄᴾᶍᶇᶊᴾᶎᶐᶃᶑᶑᶓᶐᶃᴾᶆᶍᶑᶃᵌẅᴾ
㻌㻌㻌䞉 Otherwise, your finger or a hand may be pinched.
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
⚠ᵡᵟᵳᵲᵧᵭᵬ

ᾀᾇᵌᵢᶍᴾᶌᶍᶒᴾᶐᶃᶋᶍᶔᶃᴾᶒᶆᶃᴾᶎᶐᶍᶒᶃᶁᶒᶇᶔᶃᴾᶒᶓᶀᶃᴾᶒᶆᵿᶒᴾᶃᶌᶄᶍᶊᶂᶑᴾᶍᶇᶊᴾᶎᶐᶃᶑᶑᶓᶐᶃᴾᶆᶍᶑᶃᵌᴾᵧᶄᴾᶎᶐᶍᶒᶃᶁᶒᶇᶔᶃᴾᶒᶓᶀᶃᴾᶇᶑᴾ
ᴾᴾᴾᴾᴾᶂᵿᶋᵿᶅᶃᶂᵊᴾᶑᶒᶍᶎᴾᶓᶑᶇᶌᶅᴾᶇᶒᴾᵿᶌᶂᴾᶐᶃᶎᵿᶇᶐᴾᶍᶐᴾᶐᶃᶎᶊᵿᶁᶃᴾᶇᶒᵌ
㻌㻌㻌䞉 Protective tube protects oil pressure and prevents danger in case that oil pressure hose is
broken. Dysfunction of protective tube may cause accident or injury.
ᾀᾈᵌᵫᵿᶌᶓᶄᵿᶁᶒᶓᶐᶇᶌᶅᴾᶂᵿᶒᶃᴾᶍᶄᴾᶒᶆᶇᶑᴾᶎᶐᶍᶂᶓᶁᶒᴾᶇᶑᴾᶑᶆᶍᶕᶌᴾᵿᴾᶒᶆᶃᴾᶀᶍᶒᶒᶍᶋᴾᶍᶄᴾᵟᶇᶐᴾᵡᶗᶊᶇᶌᶂᶃᶐᴾᵡᵿᶎᴾᶀᶗᴾᶀᶐᶃᶔᶇᶒᶗ
ᴾᴾᴾᴾᶁᶍᶂᶃᴾᵿᶌᶂᴾᵒᴾᶂᶇᶅᶇᶒᴾᶌᶓᶋᶀᶃᶐᶑᵌᵆᵰᶃᶄᶃᶐᴾᶒᶍᴾᵮᵌᵔᵇ
ᾁ὿ᵌᵵᵿᶐᶌᶇᶌᶅᴾᶊᵿᶀᶃᶊᶑᴾᶇᶌᶁᶊᶓᶂᶃᴾᶇᶋᶎᶍᶐᶒᵿᶌᶒᴾᶇᶌᶄᶍᶐᶋᵿᶒᶇᶍᶌᴾᵿᶌᶂᴾᶒᶇᶎᶑᴾᶍᶌᴾᶓᶑᶇᶌᶅᴾᶒᶆᶃᴾᶋᵿᶁᶆᶇᶌᶃᵌᴾᵧᶄᴾᶒᶆᶃᴾᶊᵿᶀᶃᶊᶑᴾ
ᴾᴾᴾᴾᴾᶀᶃᶁᶍᶋᶃᴾᶑᶍᴾᶂᶇᶐᶒᶗᴾᶍᶐᴾᶂᵿᶋᵿᶅᶃᶂᴾᶒᶆᵿᶒᴾᶒᶆᶃᶗᴾᶁᵿᶌᶌᶍᶒᴾᶀᶃᴾᶐᶃᵿᶂᵊᴾᶍᶐᶂᶃᶐᴾᵿᶌᶂᴾᶐᶃᶎᶊᵿᶁᶃᴾᶒᶆᶃᶋᴾᶕᶇᶒᶆᴾᶌᶃᶕᴾ
ᴾᴾᴾᴾᴾᶊᵿᶀᶃᶊᶑᵌᴾᵷᶍᶓᴾᶁᵿᶌᴾᶍᶐᶂᶃᶐᴾᶌᶃᶕᴾᶊᵿᶀᶃᶊᶑᴾᶄᶐᶍᶋᴾᵪᶍᶀᶒᶃᶖᴾᵡᶍᵌᵊᴾᵪᶒᶂᵌᴾᶒᶆᶐᶍᶓᶅᶆᴾᶍᶓᶐᴾᶂᶃᵿᶊᶃᶐᶑᵌẅᴾ
ᾁᾀᵌᵲᶆᶇᶑᴾᶎᶐᶍᶂᶓᶁᶒᴾᶇᶑᴾᵿᴾᶒᶍᶍᶊᴾᶄᶍᶐᴾᶃᶖᶁᶊᶓᶑᶇᶔᶃᴾᶓᶑᶃᴾᶍᶄᴾᶒᶆᶃᴾᶎᶐᶍᶄᶃᶑᶑᶇᶍᶌᵿᶊᴾᶀᶓᶑᶇᶌᶃᶑᶑᵌᴾᵵᶆᶃᶌᴾᶗᶍᶓᴾᵿᶐᶃᴾᶒᶆᶃᴾ
ᴾᴾᴾᴾᴾᶍᶌᶃᴾᶕᶆᶍᴾᶓᶑᶃᶑᴾᶒᶆᶇᶑᴾᶒᶍᶍᶊᴾᶄᶍᶐᴾᶒᶆᶃᴾᶄᶇᶐᶑᶒᴾᶒᶇᶋᶃᵊᴾᶎᶊᶃᵿᶑᶃᴾᶐᶃᶁᶃᶇᶔᶃᴾᵿᶌᴾᶇᶌᶑᶒᶐᶓᶁᶒᶇᶍᶌᴾᶄᶐᶍᶋᴾᶒᶆᶃᴾᶍᶌᶃᴾᶕᶆᶍ
ᴾᴾᴾᴾᴾᶆᵿᶑᴾᵿᶊᶐᶃᵿᶂᶗᴾᶓᶑᶃᶂᴾᶒᶆᶇᶑᴾᶒᶍᶍᶊᴾᶀᶃᶄᶍᶐᶃᵊᴾᵿᶊᶑᶍᴾᶎᶊᶃᵿᶑᶃᴾᶐᶃᵿᶂᴾᶒᶆᶃᴾᵧᶌᶑᶒᶐᶓᶁᶒᶇᶍᶌᴾᵫᵿᶌᶓᵿᶊᴾᶁᵿᶐᶃᶄᶓᶊᶊᶗᴾᵿᶌᶂ
ᴾᴾᴾᴾᴾᶓᶌᶂᶃᶐᶑᶒᵿᶌᶂᴾᶒᶆᶃᴾᶁᶍᶌᶒᶃᶌᶒᵌ㻌㻌ẅᴾ
㻌㻌㻌䞉 Wear protective goggles or safety glasses.
㻌㻌㻌䞉 If the tool is broken, do not operate.ᴾ
ᾁᾁᵌᵤᶍᶐᴾᶒᶆᶃᴾᶋᵿᶇᶌᶒᶃᶌᵿᶌᶁᶃᴾᶍᶄᴾᶒᶆᶃᴾᶋᵿᶇᶌᴾᶀᶍᶂᶗᵊᴾᶄᶍᶐᴾᶃᶔᶃᶐᶗᴾᵑᵎᵊᵎᵎᵎᴾᶇᶌᶑᶒᵿᶊᶊᵿᶒᶇᶍᶌᴾᶍᶄᴾᶒᶆᶃᴾᶄᵿᶑᶒᶃᶌᶃᶐᴾᶍᶐᴾᶇᶌᴾ
ᴾᴾᴾᴾᴾᶍᶌᶃᴾᶗᶃᵿᶐᵌẅẅᴾᴾ
ᾁᾂᵌᵭᶌᶊᶗᴾᶎᶃᶐᶑᶍᶌᶑᴾᶕᶆᶍᴾᵿᶐᶃᴾᶕᶃᶊᶊᴾᶒᶐᵿᶇᶌᶃᶂᴾᵿᶌᶂᴾᶏᶓᵿᶊᶇᶄᶇᶃᶂᴾᶑᶆᶍᶓᶊᶂᴾᶓᶑᶃᵊᴾᵿᶂᶈᶓᶑᶒᵊᴾᵿᶌᶂᴾᶋᵿᶇᶌᶒᵿᶇᶌᴾᶒᶆᶇᶑᴾᶎᶐᶍᶂᶓᶁᶒᵌẅᴾ
ᾁᾃᵌᵢᶍᴾᶌᶍᶒᴾᶋᶍᶂᶇᶄᶗᴾᶒᶆᶃᴾᶒᶍᶍᶊᵌᴾᵟᶌᶗᴾᶋᶍᶂᶇᶄᶇᶁᵿᶒᶇᶍᶌᴾᶒᶍᴾᶒᶆᶃᴾᶃᶏᶓᶇᶎᶋᶃᶌᶒᴾᶇᶋᶎᵿᶇᶐᶑᴾᶒᶆᶃᴾᶔᵿᶊᶇᶂᶇᶒᶗᴾᶍᶄᴾᶑᵿᶄᶃᶒᶗᴾ
ᴾᴾᴾᴾᴾᶂᶃᶔᶇᶁᶃᶑᵊᴾᶊᶃᵿᶂᶇᶌᶅᴾᶒᶍᴾᵿᴾᶆᶇᶅᶆᶃᶐᴾᶐᶇᶑᶉᴾᶒᶍᴾᶍᶎᶃᶐᵿᶒᶍᶐᶑᵌ
ᾁᾄᵌᵱᶊᶇᶎᵊᴾᶒᶐᶇᶎᶑᴾᵿᶌᶂᴾᶄᵿᶊᶊᶑᴾᵿᶐᶃᴾᶋᵿᶈᶍᶐᴾᶁᵿᶓᶑᶃᶑᴾᶍᶄᴾᶕᶍᶐᶉᶎᶊᵿᶁᶃᴾᶇᶌᶈᶓᶐᶗᵌᴾᵠᶃᴾᵿᶕᵿᶐᶃᴾᶍᶄᴾᶑᶊᶇᶎᶎᶃᶐᶗᴾᶑᶓᶐᶄᵿᶁᶃᶑ
ᴾᴾᴾᴾᴾᶁᵿᶓᶑᶃᶂᴾᶀᶗᴾᶓᶑᶃᴾᶍᶄᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᵿᶌᶂᴾᵿᶊᶑᶍᴾᶍᶄᴾᶒᶐᶇᶎᴾᶆᵿᶘᵿᶐᶂᶑᴾᶁᵿᶓᶑᶃᶂᴾᶀᶗᴾᶒᶆᶃᴾᵿᶇᶐᴾᶊᶇᶌᶃᴾᶍᶐᴾᶆᶗᶂᶐᵿᶓᶊᶇᶁᴾᶆᶍᶑᶃᵌẅẅᴾ
ᾁᾅᵌᵮᶐᶍᶁᶃᶃᶂᴾᶕᶇᶒᶆᴾᶁᵿᶐᶃᴾᶇᶌᴾᶓᶌᶄᵿᶋᶇᶊᶇᵿᶐᴾᶑᶓᶐᶐᶍᶓᶌᶂᶇᶌᶅᶑᵌᴾᵲᶆᶃᶐᶃᴾᶁᵿᶌᴾᶀᶃᴾᶆᶇᶂᶂᶃᶌᴾᶆᵿᶘᵿᶐᶂᶑᵊᴾᶑᶓᶁᶆᴾᵿᶑᴾᶃᶊᶃᶁᶒᶐᶇᶁᵿᶊ
ᴾᴾᴾᴾᴾᶍᶐᴾᶍᶒᶆᶃᶐᴾᶓᶒᶇᶊᶇᶒᶗᴾᶁᵿᶀᶊᶃᶑᵌẅᴾ
ᾁᾆᵌᵲᶆᶇᶑᴾᶋᵿᶁᶆᶇᶌᶃᴾᶇᶑᴾᶌᶍᶒᴾᶇᶌᶒᶃᶌᶂᶃᶂᴾᶄᶍᶐᴾᶓᶑᶃᴾᶇᶌᴾᶎᶍᶒᶃᶌᶒᶇᵿᶊᶊᶗᴾᶃᶖᶎᶊᶍᶑᶇᶔᶃᴾᵿᶒᶋᶍᶑᶎᶆᶃᶐᶃᶑᴾᵿᶌᶂᴾᶇᶑᴾᶌᶍᶒᴾ
ᴾᴾᴾᴾᴾᶇᶌᶑᶓᶊᵿᶒᶃᶂᴾᵿᶅᵿᶇᶌᶑᶒᴾᶁᶍᶌᶒᵿᶁᶒᴾᶕᶇᶒᶆᴾᶃᶊᶃᶁᶒᶐᶇᶁᴾᶎᶍᶕᶃᶐᵌẅẅᴾ
ᾁᾇᵌᵣᶌᶑᶓᶐᶃᴾᶒᶆᵿᶒᴾᶒᶆᶃᶐᶃᴾᵿᶐᶃᴾᶌᶍᴾᶃᶊᶃᶁᶒᶐᶇᶁᵿᶊᴾᶁᵿᶀᶊᶃᶑᵊᴾᶅᵿᶑᴾᶎᶇᶎᶃᶑᵊᴾᶃᶒᶁᵌᵊᴾᶕᶆᶇᶁᶆᴾᶁᵿᶌᴾᶁᵿᶓᶑᶃᴾᵿᴾᶆᵿᶘᵿᶐᶂᴾᶇᶄᴾ
ᴾᴾᴾᴾᴾᶂᵿᶋᵿᶅᶃᶂᴾᶀᶗᴾᶓᶑᶃᴾᶍᶄᴾᶒᶆᶃᴾᶒᶍᶍᶊᵌ㻌㻌
ᾁᾈᵌᵧᶄᴾᶗᶍᶓᴾᶃᶖᶎᶃᶐᶇᶃᶌᶁᶃᴾᶌᶓᶋᶀᶌᶃᶑᶑᵊᴾᶒᶇᶌᶅᶊᶇᶌᶅᵊᴾᶎᵿᶇᶌᴾᶍᶐᴾᶕᶆᶇᶒᶃᶌᶇᶌᶅᴾᶍᶄᴾᶒᶆᶃᴾᶑᶉᶇᶌᴾᶇᶌᴾᶗᶍᶓᶐᴾᶄᶇᶌᶅᶃᶐᶑᴾᶍᶐᴾᶆᵿᶌᶂᶑᵊ
ᴾᴾᴾᴾᶑᶒᶍᶎᴾᶓᶑᶇᶌᶅᴾᶒᶆᶃᴾᶒᶍᶍᶊᵊᴾᶇᶌᶄᶍᶐᶋᴾᶗᶍᶓᶐᴾᶃᶋᶎᶊᶍᶗᶃᶐᴾᵿᶌᶂᴾᶁᶍᶌᶑᶓᶊᶒᴾᵿᴾᶎᶆᶗᶑᶇᶁᶇᵿᶌᵌẅẅᴾẅᴾ
ᾂ὿ᵌᵡᶍᶋᶎᶐᶃᶑᶑᶃᶂᴾᵿᶇᶐᴾᶁᵿᶌᴾᶁᵿᶓᶑᶃᴾᶑᶃᶔᶃᶐᶃᴾᶇᶌᶈᶓᶐᶗᵘ㻌㻌ẅẅᴾ
㻌㻌㻌䞉 Be sure to disconnect the tool from the air supply source when it is not in use or before replacing
or repairing it.
㻌㻌㻌䞉 Never direct air at yourself or anyone else.
ᾂᾀᵌᵵᶆᶇᶎᶎᶇᶌᶅᴾᶆᶍᶑᶃᶑᴾᶁᵿᶌᴾᶁᵿᶓᶑᶃᴾᶑᶃᶔᶃᶐᶃᴾᶇᶌᶈᶓᶐᶗᵌ
ẅẅᴾᵟᶊᶕᵿᶗᶑᴾᶋᵿᶉᶃᴾᶑᶓᶐᶃᴾᶒᶆᶃᶐᶃᴾᵿᶐᶃᴾᶌᶍᴾᶂᵿᶋᵿᶅᶃᶑᴾᶍᶌᴾᶆᶍᶑᶃᶑᴾᵿᶌᶂᴾᶌᶍᴾᶊᶍᶍᶑᶃᴾᶄᶇᶒᶒᶇᶌᶅᶑᵌ㻌㻌
ᾂᾁᵌᵢᶍᴾᶌᶍᶒᴾᶁᵿᶐᶐᶗᴾᶒᶆᶃᴾᶎᶌᶃᶓᶋᵿᶒᶇᶁᴾᶒᶍᶍᶊᴾᶀᶗᴾᶆᶍᶊᶂᶇᶌᶅᴾᶒᶆᶃᴾᶆᶍᶑᶃᵌ㻌㻌
ᾂᾂᵌᵮᶐᶃᶔᶃᶌᶒᵿᶒᶇᶔᶃᴾᶋᵿᶇᶌᶒᶃᶌᵿᶌᶁᶃᴾᶑᶆᶍᶓᶊᶂᴾᶀᶃᴾᶁᵿᶐᶐᶇᶃᶂᴾᶍᶓᶒᵊᴾᵿᶄᶒᶃᶐᴾᵿᴾᶑᶎᶃᶁᶇᶄᶇᶃᶂᴾᶒᶇᶋᶃᴾᶍᶄᴾᶍᶎᶃᶐᵿᶒᶇᶍᶌᵊᴾᵿᴾ
ᴾᴾᴾᴾᴾᶑᶎᶃᶁᶇᶄᶇᶃᶂᴾᶌᶓᶋᶀᶃᶐᴾᶍᶄᴾᶁᶗᶁᶊᶃᶑᵍᶍᶎᶃᶐᵿᶒᶇᶍᶌᶑᴾᶍᶐᴾᵿᴾᶑᶒᵿᶒᶃᶂᴾᶌᶓᶋᶀᶃᶐᴾᶍᶄᴾᶒᶇᶋᶃᶑᴾᶎᶃᶐᴾᶗᶃᵿᶐᵌẅẅᴾ
ᾂᾃᵌᵵᶆᶃᶌᴾᶗᶍᶓᴾᶆᵿᶌᶂᶊᶃᴾᶍᶇᶊᴾᶍᶐᴾᶅᶐᶃᵿᶑᶃᵊᴾᶍᶀᶒᵿᶇᶌᴾᶒᶆᶃᴾᶋᵿᶒᶃᶐᶇᵿᶊᴾᶑᵿᶄᶃᶒᶗᴾᶂᵿᶒᵿᴾᶑᶆᶃᶃᶒᴾᵆᵱᵢᵱᵇᴾᶄᶐᶍᶋᴾᶒᶆᶃᴾᶑᶓᶎᶎᶊᶇᶃᶐᵊ
ᴾᴾᴾᴾᴾᵿᶌᶂᴾᶄᶍᶊᶊᶍᶕᴾᶒᶆᶃᴾᶂᶃᶑᶁᶐᶇᶀᶃᶂᴾᶇᶌᶑᶒᶐᶓᶁᶒᶇᶍᶌᶑᵌᴾᴾᴾᴾẅẅᴾ
ᾂᾄᵌᵱᵿᶄᶃᶒᶗᴾᶔᵿᶊᶔᶃᴾᶋᶓᶑᶒᴾᶌᶍᶒᴾᶀᶃᴾᶐᶃᶋᶍᶔᶃᶂᴾᶍᶐᴾᶂᶇᶑᵿᶑᶑᶃᶋᶀᶊᶃᶂᵌ
ᴾᴾᴾᴾᴾᵱᵿᶄᶃᶒᶗᴾᶔᵿᶊᶔᶃᴾᶇᶑᴾᵿᶌᴾᶃᶑᶎᶃᶁᶇᵿᶊᶊᶗᴾᶇᶋᶎᶍᶐᶒᵿᶌᶒᴾᶑᵿᶄᶃᶒᶗᴾᶂᶃᶔᶇᶁᶃᵌᴾᵧᶄᴾᶇᶒᴾᶇᶑᴾᵿᶁᶁᶇᶂᶃᶌᶒᵿᶊᶊᶗᴾᶊᶍᶍᶑᶃᶌᶃᶂ
ᴾᴾᴾᴾᴾᶍᶐᴾᶂᵿᶋᵿᶅᶃᶂᵊᴾᶁᶍᶌᶑᶓᶊᶒᴾᶕᶇᶒᶆᴾᶒᶆᶃᴾᶑᶒᶍᶐᶃᴾᶗᶍᶓᴾᶎᶓᶐᶁᶆᵿᶑᶃᶂᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶍᶐᴾᵪᶍᶀᶒᶃᶖᴾᵡᶍᵊᴾᵪᶒᶂᵌ
ᾂᾅᵌᵢᶍᴾᶌᶍᶒᴾᶓᶑᶃᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᶕᶇᶒᶆᶍᶓᶒᴾᶐᶃᶑᶃᶒᶒᶇᶌᶅᴾᶑᵿᶄᶃᶒᶗᴾᶔᵿᶊᶔᶃᴾᵿᶄᶒᶃᶐᴾᶇᶒᴾᶀᶊᶍᶕᶑᴾᶍᶄᶄᵌ
ᾂᾆᵌᵧᶄᴾᶑᵿᶄᶃᶒᶗᴾᶔᵿᶊᶔᶃᴾᶑᶒᶇᶊᶊᴾᶀᶊᶍᶕᶑᴾᶍᶄᶄᴾᵿᶄᶒᶃᶐᴾᵿᶂᶈᶓᶑᶒᶇᶌᶅᴾᵿᶇᶐᴾᶎᶐᶃᶑᶑᶓᶐᶃᵊᴾᶑᶒᶍᶎᴾᶓᶑᶇᶌᶅᴾᶒᶆᶃᴾᶒᶍᶍᶊᴾᵿᶌᶂ
ᴾᴾᴾᴾᴾᶁᶍᶌᶑᶓᶊᶒᴾᶕᶇᶒᶆᴾᵿᴾᶑᵿᶊᶃᶑᴾᶍᶄᶄᶇᶁᶃᴾᶍᶄᴾᵪᶍᶀᶒᶃᶖᴾᵡᶍᵊᴾᵪᶒᶂᵌ
4
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
⚠ᵡᵟᵳᵲᵧᵭᵬ

5
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
⅐ ⁀⁁‿‷⁀‵‾″⁆⁇⁄‷
Booster
Air Cylinder Cap䚷Silencer
Where the
serial number
is shown
Branch Plug
Cylinder
L-type Quick Joint
Safety Valve
80
Hand Grip
Swivel Joint
Head Unit / Swivel Unit
Frame Head
Chute Hose
Nosepiece
Switch
Lever
Vacuum ON/OFF
Safety Cover
Rubber Bellow
Bleed Plug Frame Head Internal Parts
Hand Grip
Guide Pipe
Jaws
Jaw Case
Jaw Case
Head
Jaw Pusher
Spring Jaw
Pusher O-ring
P-10

6
Model No. ARV-025M
Weight 䚷䚷 Head (kg) 0.9
Total (kg) 4.6
Operating air pressure䚷㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌(MPa) 0.5 䡚0.6
Dimensions (Length x Height xThickness )䚷mm䚷(Head Unit) 310X80X39
Air consumption per minute at 0.5MPa 㻌㻌L/min 㻖㻌䐟 100
Tool stroke䚷㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌(mm) 19
Traction power at 0.5MPa (kN) 8.8
Applicable rivets (Rivet diameters)䚷㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌(Φmm) 2.4 䞉3.2 䞉4.0 䞉4.8
Operating environment Temperature 4䉝㻌to 35䉝
Relative humidity䚷80䠂㻌RH max (no condensation)
Sound㻌Pressure level 䠆䐠 (Lpa)㻌㻌 75.3 dB
Vibration at 0.6MPa (Emission value)
䚷㻌㻌㻌 Less than equal to 2.5m/sec2
Air intake Nipple screw size G1/4
⅐ ⁆‷‵›⁀※‵″‾‒‶″⁆″⅙
How to read the year and month of production
A year/month of manufacture 1 2 3 4 5 6 7 8 9 10 11 12
An English character A B M N K W T Y U O L Z
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
䠆Product specifications and design are subject to change for improvement without notice.
䠆Weight and dimensions given are standard values.
Actual products may differ slightly from the values given.
䠆Attaching position of rating plate (attention/caution label) is lateral side of air cylinder.
䠆Serial number is shown at the bottom of air cylinder cap by brevity code and 4 digit numbers.
䠆䐟㻌Under the condition of 30 pcs./min.
䠆䐠㻌Measured at equivalent noise measurement level.
year:㻌2014㻌㻌month:㻌8㻌䊻 NY 䕿䕿䕿䕿
N
䊼
Y
Example
䊼
(Serial No.)
䊼
Revision history of instruction manual
Item:Air Riveter
Model:ARV-025M
Date of sixth edition: February , 2020




䣃䣔䣘䢯䢲䢴䢷䣏儼儧儭㒊እほᅗ

7
Set up a correct nosepiece and a correct guide pipe according to the size of㻌rivet㻌
to㻌the used.㻌(Refer to page 10.)
㻖Default setup is 3.2 mm-diameter nosepiece and yellow guide pipe.
Fix the end of chute hose to the mandrel
containing case.
Fix the either end of the chute hose to the
containing case or else, so that it does not
loose during operation. There must be
enough space in the end of the chute hose.
Lack of space or obstacles in the end of the
chute hose may prevent a mandrel of cut rivet
from being discharged or cause degradation
in discharge power.
㻖Be sure to prepare a containing case, to prevent the mandrel from being blasted off.
Cut rivet mandrels may be blasted off from the end of the chute hose and may cause injury.
Prepare an air compressor. Be sure to place an air filter and an air regulator
between the compressor and the air riveter.
Mandrel
Body
Rivet diameter
Classify by color
㻌㻌A㻦Yellow
䚷B㻦White
Guide Pipe
Need Enough
Space
Fix
Rivet Size
(Rivet Diameter) Nosepiece Guide Pipe
Φ2.4 2.4 A(Yellow)
Φ3.2 3.2
Φ4.0 4.0 B(White)
Φ4.8 4.8
Complete Air Supply System
䠍
ᾀ
䠍
ᾁ
䠍
ᾂ
Die Stamp for Size
Nosepiece
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
⅐ ⁂⁄‷⁂″⁄″⁆※⁁⁀‒‴‷‸⁁⁄‷‒⁇⁅‷
Mandrel
Storage Case
of Mandrel
Rivet
Air Compressor
Air Filter
ARV-025Mヘッド部外観図
Pressure
Regulator
⚠ᵵᵟᵰᵬᵧᵬᵥ ᾂᵆᵮᵌᵐᵇ

Set up 0.5 to 0.6 MPa as air pressure.
㻖Too much pressure may cause damage to the tool. Too low pressure may cause incomplete
rivetting or incomplete cutting.
Make sure that the tool works properly.
After connection with air, make sure that the tool works smoothly without oil leak
by idle run (operating 2 or 3 times without rivets.)
8
䠍
ᾃ
䠍
ᾄ
䠍
ᾅSAFETY VALVE
This tool incorporates a “safety valve”that blows off air to indicate the abnormality when too
much air is supplied to the riveter.
Pressure:0.5㻌to㻌0.6 MPa
Blow off air pressure: 0.64MPa㻌
(1) Stop using the tool immediately, and stop the air supply.
Safety valve cannot be reset without stopping air supply.
(2) Setup the air pressure to the range between 0.5 and 0.6 MPa.
(3) Supply air again and confirm that the safety valve does not blow off.
Safety valve must not be removed or disassembled.
Safety valve is an especially important safety device. If it is accidentally
loosened or damaged, consult with the store you purchased the tool
or Lobtex Co, Ltd.
䞉Do not use the tool without resetting safety valve after it blows off.
It may cause damage of the tool.
䞉If safety valve still blows off after adjusting air pressure, stop using the
tool and consult with a sales office of Lobtex Co, Ltd.
Appropriate air
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
The tool needs careful cleaning and maintenance if it is not used for a long time.
(Ref: “P10. Cleaning the Frame head and jaw case”) After cleaning and maintenance,
vacuum mechanism must be operated before use.
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
⚠ᵵᵟᵰᵬᵧᵬᵥ ᾀᵆᵮᵌᵐᵇ
⚠ᵡᵟᵳᵲᵧᵭᵬᴾᵑᵓᵆᵮᵌᵒᵇ
⚠ᵡᵟᵳᵲᵧᵭᵬᴾᵑᵔᵆᵮᵌᵒᵇ
⚠ᵡᵟᵳᵲᵧᵭᵬᴾᵑᵕᵆᵮᵌᵒᵇ

9
䚷䚷䚷䚷 Replace the nosepiece with one which matches the size of the rivet to be used.
(Refer to item in “Preparation Before Use” on page 7.)
䚷䚷䚷䚷 Select a suitable size of rivet for the workpiece to be riveted.
䠍
ᾀ
䠍
ᾁ
䚷䚷䚷䚷 Drill a hole of appropriate size (0.1 to 0.2mm larger than the diameter
䚷䚷䚷䚷䚷 of the rivet) into the workpiece.
䚷䚷䚷䚷 Insert a rivet mandrel into the Nosepiece of the riveter.
䚷䚷䚷䚷䚷䚷㻌㻌㻌Rivet is not dropped because it is vacuumed up.
䚷䚷䚷䚷 Insert the rivet body into the work piece hole.
䚷䚷䚷䚷 Press the body collar onto the material and grip the
㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌 switch lever.
㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌䞉 The body is crimped.
䚷䚷䚷㻌㻌 When the switch lever is released, the mandrel is
䚷䚷䚷䚷䚷 automatically evacuated in the chute hose.
㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌The Next crimping operation must be done
㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌only after the cut mandrel is evacuated.㻌䚷
䠍
ᾂ
䚷䚷䚷㻌㻌 Turn the vacuum air cock to counter clockwise
to㻌ctivate the vacuum device.
The vacuum device is activated. You can
hear the vacuum noise.
䚷䚷䚷㻌䚷䚷㻌㻌㻌㻌㻌Do not use the air cock at halfway position,
䚷㻌䚷䚷䚷䚷㻌㻌㻌㻌㻌but turn to the end position it stops.䚷㻌䚷䚷䚷䚷
㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌(Use vacuum system after doing P.7㻌
㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌㻌“PREPARATION BEFORE USE”.)
䠍
ᾃ
䠍
ᾄ
䠍
ᾅ
䠍
ᾆ
䠍
ᾇ
Condition of
Vacuum Activated
(Air sound comes out)
Air Cock
Condition of
Vacuum Inactivated
(Air stops)
Air Cock
సᴗᡭ㡰ࣜ࣋ࢵࢸ࢕ࣥࢢࡍࡿẕᮦࡢཌࡉ࡟࠶ࡗࡓࢧ࢖ࢬࡢࣜ࣋ࢵࢺࢆ㑅ᢥࡍࡿࠋࣜ࣋ࢵࢺࢧ࢖ࢬ࡟ྜࢃࡏ࡚ࣀ࣮ࢬࣆ࣮ࢫࢆ஺᥮ࡍࡿࠋ㸦3ࠕࡈ౑⏝๓ࡢ‽ഛࠉࠉࠖཧ↷㸧ࣜ࣋ࢵࢸ࢕ࣥࢢࡍࡿẕᮦ࡟ṇࡋ࠸ୗ✰㸦ࣜ࣋ࢵࢺᚄࡼࡾ㹼PP኱ࡁࡃ㸧ࢆ㛤ࡅࡿࠋࣜ࣋ࢵࢺᮏయࢆ⿦╔ࡋࡓ≧ែ࡛ࠊୗ✰࡟ᤄධࡍࡿࠋ࢚࢔࣮ࢥࣥࢺ࣮࣮ࣟࣛࢆ21᪉ྥ࡟ᅇ㌿ࡉࡏࠊࣂ࣮࣒࢟ࣗࢆసືࡉࡏࡿࠋᅇ㌿㸦⣙ᗘ㸧࡛༑ศ࡛ࡍࠋ21᪉ྥ࡟ᅇ㌿ࡉࡏ㐣ࡂࡿ࡜◚ᦆࡢཎᅉ࡟࡞ࡾࡲࡍࠋࣜ࣋ࢵࢱ࣮ࡢඛ➃࡟ࠊࣜ࣋ࢵࢺࡢࢩࣕࣇࢺ㒊ࢆᤄධࡍࡿࠋࣜ࣋ࢵࢱ࣮ࡢඛ➃ࢆẕᮦ࡟㍍ࡃᢲࡋᙜ࡚ࠊẕᮦ➼࡟ࡍࡁ㛫ࡀ࡞࠸ࡇ࡜ࢆ☜ㄆᚋࢫ࢖ࢵࢳࢆᘬࡃࠋࢫ࢖ࢵࢳࢆᘬ࠸ࡓ󰪍ཬࡧᘬ࠸࡚࠸ࡿ㛫ࡣࠊࢫ࢖ࢵࢳ㒊ศ࠿ࡽⱝᖸࡢ࢚࢔࣮ࡀ₃ࢀࡲࡍࡀࠊࡇࢀࡣᨾ㞀࡛ࡣ࠶ࡾࡲࡏࢇࠋẕᮦ࡟ࣜ࣋ࢵࢺᮏయࡀࣜ࣋ࢵࢸ࢕ࣥࢢࡉࢀࡿࠋ
ࢫ࢖ࢵࢳࢆᨺࡍ࡜ࠊษ᩿ࡉࢀࡓࢩࣕࣇࢺࡀࢱࣥࢡࣘࢽࢵࢺ࡟཰⣡ࡉࢀࡿࠋ
࠙せⅬࠚࢩࣕࣇࢺࡀ☜ᐇ࡟᤼ฟࡉࢀࡓᚋࠊḟࡢࣜ࣋ࢵࢸ࢕ࣥࢢ࡟⛣ࡗ࡚ࡃࡔࡉ࠸ࠋ㸺౑⏝ ᗘ㸼࿘ᅖ ᗘࡀΥ㹼Υࡢ⠊ᅖ࡛ࡈ౑⏝ࡃࡔࡉ࠸ࠋࢱࣥࢡ࡟⣙༙ศ⛬ᗘࡓࡲࡾࡲࡋࡓࡽࠊࢱࣥࢡࡢᮎ➃࡟ࡘ࠸࡚࠸ࡿࢱࣥࢡ࢟ࣕࢵࣉࢆ23(1᪉ྥ࡟ᅇ㌿ࡉࡏࠊྲྀࡾࡣࡎࡋࠊ୰ࡢࢩࣕࣇࢺࢆᤞ࡚࡚ࡃࡔࡉ࠸ࠋࢱࣥࢡෆ࡟ࢩࣕࣇࢺࢆ༙ศ௨ୖࡓࡵࡿ࡜ࠊ᤼ฟࡉࢀࡿࢩࣕࣇࢺࡀࢱࣥࢡෆ࡟ࡓࡲࡗࡓࢩࣕࣇࢺ࡟㑧㨱ࡉࢀ࡚࢞࢖ࢻࣃ࢖ࣉෆ࡟ṧࡗ࡚ࡋࡲ࠸ࠊࡘࡲࡾࡀⓎ⏕ࡋࡓࡾࠊࣀ࣮ࢬࣆ࣮ࢫ࠿ࡽ࢚࢔࣮ࡀ྿ࡁฟࡍཎᅉ࡟࡞ࡾࡲࡍࠋࡈὀពࡃࡔࡉ࠸ࣜ࣋ࢵࢺࡢࢩࣕࣇࢺࡢඛࡀ࡜ࡀࡗ࡚࠸ࡿࡶࡢࡶ࠶ࡾࡲࡍࠋᣦࢆയࡘࡅ࡞࠸ࡼ࠺࡟ὀពࡋ࡚ࡃࡔࡉ࠸ࠋ㆙࿌㸦3㸧
᪥ᮏㄒ㸭-$3$1(6(
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
⅐⁁⁂‷⁄″⁆※⁀‹‒⁆›‷‒″※⁄‒⁄※⁈‷⁆‷⁄‒‒
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
ḵ
ḵ
ḵ
Mandrel
Storage Case
of Mandrel

Riveting for a long time generates chips and dust at several parts, which causes troubles.
The tool needs periodical cleaning and maintenance according to this manual.
Before cleaning and maintenance of each part, make sure that the power of air
compressor is turned off to stop air supply and eliminate the residual pressure.
Otherwise, you may be injured.
䞉When assembling each part, apply lubricant agent such as grease at each sliding
area without fail. Otherwise, malfunction may occur.
䞉All parts must be completely assembled and all fastening areas must be fastened.
ᾀ
If chips are clogged, jaw cannot work smoothly. Cleaning must be performed in every 3000 times
of crimping.
䞉Jaw is a consumable supply. It must be replaced periodically. This tool uses high-endurance hard
tool material jaw (optional parts). When you order the part, order“hard tool material jaw, medium”.
䞉Do not loosen or remove an oil retaining screw. The oil retaining screw is used for air vent during
assembly.
䞉Do not loosen or remove a jaw case or lock nut of jaw case. If it is loosened or removed, oil is
leaked from head area, which cause malfunction. Jaw case and lock nut of jaw case are mounted
at screw unit of oil piston so that they are not loosened. If they are accidentally loosened during
operation or during maintenance, ask repair.
Stop air supply.
Remove the frame head with auxiliary
spanner A.
Frame Head
Oil Retaining Screw
Pull Collar to the direction shown in the figure to
loosen jaw case head and remove it.
Whirl-stop Ring
Jaw Case Head
Remove jaw pusher spring, guide pipe,
jaw pusher, O-ring and jaw.
Clean up each part with a brush.
10
䠍
ᾄ
䠍
ᾃ
䠍
ᾂ
䠍
ᾁ
䠍
ᾀ
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
⅐ ‿″※⁀⁆‷⁀″⁀‵‷
Cleaning the Frame head and Jaw case head section
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
&+5#55'/$.;
%.'#0+0)
➡
⚠ᵵᵟᵰᵬᵧᵬᵥ
⚠ᵡᵟᵳᵲᵧᵭᵬ
Jaw Case
Guide Pipe
Hand Grip Jaw Pusher
Spring
Jaws
Jaw Case Head
Jaw Pusher
O-ring
P-10

䚓 䚓
䚓䚓
Assemble parts in reverse procedure of disassembly.
Wind and tighten jaw case head to the end and return
it to the position where convex and notch are aligned,
then set up Collar. At assembly, apply lubricant oil
JO-50on㻌the㻌backside㻌of㻌jaw.
ᵐCleaning the Spool section
Use stick such like plastic which does not
create damage and take off the Spool from
Spool Cap A side.
If dust is accumulated at spool area, spool cannot move smoothly. Spool must be
cleaned when spool moves slowly or improperly.
Stop air supply.
Remove spool cap A and B with a spanner.
Spool
Cap A
Spool
Cap B
SpoolPlastic Stick
Be careful of
hole plugging
Clean up each part with a brush. In this case, make
sure that the small hole of the spool is not plugged.
Assemble parts in the reverse procedure of disassembly.
At assembly, apply lubricant oil on the O-ring of the spool.䚷䚷䚷㻌㻌㻌
11
䠍
ᾅ
䠍
ᾀ
䠍
ᾁ
䠍
ᾂ
䠍
ᾃ
䠍
ᾄ
Align convex
and notch
Get down whirl-stop ring
Apply lubricant oil
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
4'#55'/$.;4'#55'/$.; %.'#0+0) &+5#55'/$.;
ḵ
ḵ

䚓
ᾂChecking Hydraulic Oil
Stand the booster, wind the oil tank cap
counterclockwise, and remove it.㻌㻌㻌
Remove the cap.
Make sure to use Lobtex's hydraulic oil. Other
manufacturer's oil may affect the tool's performance
negatively.
Generally, riveting is completed by only one switch lever operation. However, if hydraulic
oil is decreased, multiple switch lever operations are needed. In this case, hydraulic oil
must be checked.
Stop air supply. Oil Tank Cap
Cap
Fuel proper amount of oil. Fill up the oil by
supporting the tank carefully to see if the oil
does not overflow.
Press the tank lightly not to allow air to go into the
tank and replace the cap and the oil tank cap.
12
䠍
ᾀ
䠍
ᾁ
䠍
ᾂ
䠍
ᾃ
䠍
ᾄ
䠍
ᾅ
(+..+0)1+.
䚓
䚓 䚓
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
Normal condition has a little
dent like A
If it is like B,
C, D, there is
not enough oil,
or air might be
inside.
D
Normal
Oil shortage or air might got inside.
A
B C
If the switch lever operation got required few times
after performing jaw maintenance and supplying
hydraulic oil, there are possibility that some air got
inside.Please contact your nearest distributor how
to take out the air.
Check the condition of the internal tank
by visual contact. If the internal tank are
dented or inflated, the hydraulic oil might
be insufficient or the air might got inside.
Please contact your nearest distributor
how to take out the air.
⚠ᵡᵟᵳᵲᵧᵭᵬ
%*'%-+0)

ᾃDISCONNECTING HYDRAULIC COUPLER
In some cases, disconnecting head area from booster area makes it easier to do
maintenance work or refueling. In that case, disconnect hydraulic coupler as following
procedure:
Remove the coupler bag by a spanner.
Stop air supply.
Pull out the male coupler.
Stand the booster and pour the oil to the
B-ring line of the male coupler.
Fasten the coupler bag with a spanner.
Male CouplerFemale Coupler
White B
Ring Line
Oil
Press-in the male coupler and wipe out the
leaked oil.
13
䠍
ᾀ
䠍
ᾁ
䠍
ᾂ
䠍
ᾃ
䠍
ᾄ
䠍
ᾅ
&+5#55'/$.;4'#55'/$.;
ḵ
ḵ
Coupler Bag
Coupler Bag
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ

ᾄCleaning the Nozzle Unit section
Remove the safety cover and the
chute hose.
Remove the nozzle unit from the main unit
by a spanner.
They are connected a little tight. Therefore,
disconnect them by pliers. Be careful not to
hurt the O-ring attached with the nozzle A.
Clean carefully inside of the tube of the nozzle A and the nozzle B,
and the small hole of the nozzle B.
Assemble parts in reverse procedure of disassembly.
If dust is accumulated at nozzle unit, power of vacuuming rivet's mandrel weakens.
If power of vacuuming mandrel is getting weak, check as following procedure:
Stop air supply.
Disconnect the nozzle unit A from the nozzle
unit B. Nozzle Unit
Nozzle A Nozzle B
O-ring Hole
ᵧᶋᶎᶍᶐᶒᵿᶌᶒ
14
䠍
ᾀ
䠍
ᾁ
䠍
ᾂ
䠍
ᾃ
䠍
ᾄ
䠍
ᾅ
Nozzle Unit
Protective Cover
Chute Hose
&+5#55'/$.;
4'#55'/$.; %.'#0+0)
䚓
䚓
䚓
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ

䖃This to in less dust, less humid and drafty place on solid floor.
䖃When not using the tool for a while please do the maintenance shown on “P.10 - P.14 CLEANING
AND MAINTENANCE” and stow.
䖃To use the tool longer, we recommend you to request us overhaul service periodically.
䚷㻌㻌(Overhaul is not a free-of-charge service) Consult the store you purchased this tool or
Lobtex local sales office about overhaul service and other maintenance service.
Model Part name Code No. Qty.
ARV-025M Hard tool material Jaw, Medium 10281 1 set
ARV-025M Frame Head 10105 1 set
15
⅐ ⁅⁆⁁⁄″‹‷
⅐ ⁁⁄‶‷⁄※⁀‹‒⁂″⁄⁆⁅
㻖㻌When parts are modified for improvement, the older parts are kept in stock for a period of five years.
Specify the model, part name, code number and the quantities of parts as shown below and place an
order with the “LOBSTER” dealer where you purchased the tool.
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ

Head Unit is consisted of the following parts:
HEAD AREA
16
⅐ ⁂″⁄⁆⁅‒⁆″‴‾‷
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
㻟㻢 㻟㻣 㻠㻝 㻠㻞 㻠㻟 㻠㻠 㻠㻢
㻠㻜
㻟㻥
㻟㻤
㻠㻡
㻝㻢
㻝㻟 㻝㻠 㻝㻡 㻞㻢
㻞㻡
㻞㻣
㻞㻤 㻟㻝 㻟㻞 㻟㻟 㻟㻠 㻟㻡
㻭
㻝㻞
㻝㻝
㻣㻝㻜
㻥
㻤
㻢
㻡
㻠
㻟
㻞
㻝䇳㻮
㻝㻣 㻝㻤 㻝㻣
㻝㻥
㻞㻜
㻞㻞
㻞㻠 㻟㻜㻞㻥
㻞㻟
㻞㻝
㻟㻢

ᵧᶌᶂᶃᶖ
ᵬᵭᵌ ᵮᵿᶐᶒᴾᶌᵿᶋᶃ ᵡᶍᶂᶃ ᵬᵭᵌ ᵫᵿᶒᶃᶐᶇᵿᶊ
1-A Nosepiece 2.4 10027 Steel
1-C Nosepiece 4.0 10029 Steel
1-D Nosepiece 4.8 10030 Steel
201 Spanner A 10141 Steel
202 Spanner B 10142 Steel
203 Hydraulic Oil 10012 ---
204 Guide Pipe B (U) 24367 䐣
ACCESSORIES
17
202
204
203
201
1-D
1-C
1-A
ᵧᶌᶂᶃᶖ
ᾝιώ ᵮᵿᶐᶒᴾᶌᵿᶋᶃ ᵡᶍᶂᶃ ᾝιώ ᵫᵿᶒᶃᶐᶇᵿᶊ ᵧᶌᶂᶃᶖ ᾝιώ ᵮᵿᶐᶒᴾᶌᵿᶋᶃ ᵡᶍᶂᶃ ᾝιώ ᵫᵿᶒᶃᶐᶇᵿᶊ
1-B Nosepiece 3.2 10028 Steel 24 Spring 22031 Steel
2 Frame head 10105 Steel 25 O-ring P-5 12120 Rubber
3 Jaw case head 10280 Steel 26 Oil retaining screw 12135 Steel
4Jaw (hard tool material,
med) 10281 Steel 27 㻖Frame (U) 23733 䐟
5 Jaw pusher 10132 Steel 28 Spring pin 3×18 10145 Steel
6 Jaw pusher spring 10133 Steel 29 Straight joint 14848 䐠
7 Guide Pipe A 㻔U㻕24366 Brass 30 Air tube 䃥4×2.6 m 23672 Plastic
8 Jaw case 10279 Steel 31 Oil piston 23731 Steel
9 Collar 10286 Steel 32 Urethane O-ring P-22 25443 Rubber
10 Collar spring 10287 Steel 33 B-ring P-22 10181 Plastic
11 Jaw case spacer B 23750 Aluminum 34 O-ring S-28 10221 Rubber
12 Jaw case spacer A 23752 Steel 35 Hanger 10106 Steel
13 Hand grip 23744 Aluminum 36 O-ring P-10 10274 Rubber
14 Jaw case lock nut 23748 Steel 37 Frame cap 24364 Aluminum
15 Returning spring 23747 Steel 38 Hexagon socket set Screw
M3x4 17101 Steel
16 Stop ring 23745 Steel 39 Air Cock (Ball Valve) 24365 䐡
17 O-ring P-12 10128 Rubber 40 Air Tube 䃥6×2.6 m 24368 Plastic
18 B-ring P-12 10129 Plastic 41 O-ring S-5 10276 Rubber
19 Switch lever 23742 Steel 42 O-ring S-6 10220 Rubber
20 Switch lock nut 23741 Brass 43 㻖Nozzle Unit 14324 䐢
21 O-ring S-10 10151 Rubber 44 Safety Cover 25463 Aluminum
22 O-ring P-4 10454 Rubber 45 +(Plus)Pan-head Screw M3×8 20860 Steel
23 Switch 23740 Plastic 46 Chute Hose 10381 Plastic
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
㻖No.27 includes No.17X2 and No.18X1.
㻖No.43 includes No.41X1 piece and No.42X1.㻌
䐟Aluminum 䞉Rubber 䞉Plastic䚷
䐡Brass 䞉Rubber 䞉Stainless 䞉Plastic䚷
䐣Brass 䞉Stainless
䐠Brass 䞉Rubber 䞉Plastic
䐢Brass 䞉Rubber

Swivel unit and booster unit are consisted of the following parts:
SWIVEL UNIT AND BOOSTER UNIT
18
A
C
133134
133
132
131
118
117
140141142143144
145
135 136
137
138
128
127
120
125
124
123
122
121
113115
130129
139
126
114
D
112
110
109 111
108
119
116
107 102 103 105 106
101
104
113 114
113 114
132
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ

ᵧᶌᶂᶃᶖ
ᾝιώ ᵮᵿᶐᶒᴾᶌᵿᶋᶃ ᵡᶍᶂᶃ ᾝιώ ᵫᵿᶒᶃᶐᶇᵿᶊ ᵧᶌᶂᶃᶖ ᾝιώ ᵮᵿᶐᶒᴾᶌᵿᶋᶃ ᵡᶍᶂᶃ ᾝιώ ᵫᵿᶒᶃᶐᶇᵿᶊ
101 Swivel Joint (U) 23656 䐤126 O-ring P-5 12120 Rubber
102 Rubber Bellow 28490 Rubber 127 㻖Safety Valve (U) 25467 䐢
103 Hydraulic Hose 23644 䐟128 O-ring S-11 25590 Rubber
104 Protection Tube 23668 Plastic 129 O-ring S-12 23709 Rubber
105 Coupler Bag 23652 Steel 130 Spool Cap A 23688 Brass
106 Coupler Male Joint (U) 23645 䐤131 㻖Air Piston (U) 67919 䐠
107 Coupler Female Joint (U) 23710 䐤132 O-ring P-85 10452 Rubber
108 㻖Oil Cylinder (U) 23682 䐠㻌 133 Hex socket bolt M6x15 23690 Steel
109 O-ring S-30 23685 Rubber 134 Air Cylinder Cap 23678 Aluminum
110 O-ring P-24 10207 Rubber 135 Fixing Screw 22030 Stainless
111 O-ring P-14 10434 Rubber 136 Branch Plug 22029 Steel
112 B-ring P-14 10435 Plastic 137 Nipple 14484 Brass
113 Hex socket bolt M5x10 25593 Steel 138 O-ring P-9 10219 Rubber
114 Plain Washer (M6) 24426 Steel 139 L-type Joint 22034 䐣
115 Oil Cylinder Joint 23700 Aluminum 140 O-ring P-12 10128 Rubber
116 Booster Spring Collar 67916 Plastic 141 Oil Tank Base 23693 Aluminum
117 Returning Spring 23691 Steel 142 O-ring G-30 12445 Rubber
118 Air Cylinder 23706 Aluminum 143 Oil Tank 15644 Rubber
119 Warning Label 61075 䐥144 Cap 15819 Plastic
120 Silencer 23689 Plastic 145 Oil Tank Cap 15606 Aluminum
121 Straight Joint 10273 䐡--- --- --- ---
122 Spool Cap B 23708 Brass --- --- --- ---
123 O-ring S-12 23709 Rubber --- --- --- ---
124 O-ring P-8 10336 Rubber --- --- --- ---
125 Spool 23707 Brass --- --- --- ---
19
ᒍᛖ὾ᾔᾝᾖᾛᾘᾢᾗ
䐟Steel 䞉Plastic䚷
䐢Brass 䞉Rubber 䞉Stainless䚷
䐥㻌Paper 䞉Plastic
䐠Aluminum 䞉Rubber 䞉Plastic
䐣Brass 䞉Rubber 䞉Plastic
䐡Brass 䞉Rubber 䞉Stainless 䞉Plastic㻌
䐤Rubber 䞉Steel 䞉Plastic
㻖No.108 includes No.109X1, No.110X1, No.111X3, and No.112X2.
㻖No.127 includes No.128X1.
㻖No.131 includes No.132X1.
