Logitech NuLOOQ navigator Operator's manual

Getting Familiar with your NuLOOQ navigator
Copyright © 2006 Logitech. All rights reserved. Logitech, the Logitech logo, and other
Logitech marks are owned by Logitech and its affiliates. All other trademarks are the
NuLOOQnavigator™: tips and tricks
Getting Familiar with your NuLOOQ navigator
tooltuner dial™
programmable
triggerpoints™
navring™ static value control
The NuLOOQ navigator input device is composed of the following components:
•The navring™ is the gray mobile ring encircling the body of the controller.
•The tooltuner dial™ (or tooltuner) is the flat circular disk on the top surface of the
controller.
•Three programmable triggerpoints™, numbered I, II, and III, across the center-line of the
tooltuner dial´s surface. (Note, button II doesn’t require to be pushed down. Just
resting your finger on button II activates the button.)
•The Static Value Control triggerpoint, located at the twelve o´clock position on the
tooltuner dial.
Using the nav ingr
The navring gives you two basic navigation functions: Scroll and Zoom. You can Scroll an image
or document by nudging the navring left, right, up or down. The navring moves only a small
amount, yet a small nudge can quickly move an image or document. The following default
Scroll and Zoom configurations are applicable to Adobe® Creative Suite® 2 applications.
property of their respective owners.

Getting Familiar with your NuLOOQ navigator
The navring also twists in a clockwise or counterclockwise direction. Twisting the navring will
zoom in or out of images in the host application.
Using the tooltuner dial
The tooltuner dial is a touch-sensitive circular disc located on the top of the NuLOOQ navigator.
The tooltuner dial is enabled anytime and also can be used for specific functions in CS2
applications.
If you are not in CS2 application, gently gliding your finger clockwise or counter clockwise
within the groove of the tooltuner dial will, by default increase or decrease system volume.
Within CS2 applications, the tooltuner dial becomes active after you click on the triggerpoint at
the 12 o’clock position. Once clicked on a simple feedback window appears, as seen below.
Copyright © 2006 Logitech. All rights reserved. Logitech, the Logitech logo, and other
Logitech marks are owned by Logitech and its affiliates. All other trademarks are the
property of their respective owners.

Getting Familiar with your NuLOOQ navigator
The feedback window gives you quick feedback on what option value is being controlled. Now
gently gliding your finger CW or CCW on the tooltuner dial will provide you a quick way to
increase or decrease those option values. Stay in this mode and switch tools and see that the
NuLOOQ navigator automatically detects the tool change and gives you the right options.
Using the triggerpoints
Triggerpoints are buttons embedded within the tooltuner dial. There are 3 programmable
triggerpoints, labeled I, II and III. These triggerpoints are user configurable via the NuLOOQ
navigator preference pane.
Triggerpoints I and III are push button triggerpoints, meaning, you push down on them till you
hear a click. Once you hear a click, the triggerpoint is activated.
Triggerpoint II is unique. Triggerpoint II does NOT require to be pressed. In fact just resting
your finger on triggerpoint II will activate the triggerpoint. This has some unique advantages.
You can map modifier keys such as OPTION, for example. Then just resting your finger on
triggerpoint II will emulate pressing the option key to bring up the color picker.
