Longshine COBRA15 User manual

Version: 1.0
Date: February 16, 2016
Fanless True Flat High Performance
COBRA15 System Series
USER MANUAL
Windows POS systems
Intel Celeron Processor J1900 technology

COBRA15
2016/02/15 Version: 1.0
ii
About this Manual
Thank you for purchasing COBRA15 All-in-One system. This terminal offers all the enhanced
features and is easy to connect to various optional devices for optimal performance. This user
manual describes how you can setup and connect your terminal.
Copyright
The information in this guide is subject to change without prior notice.© Copyright 2015
All rights reserved. This product and related documentation are protected by copyright and are
distributed under licenses restricting their use, copying, and distribution. No part of this
documentation may be reproduced in any form by any means without prior written
authorization of the manufacturer and its licensors, if any.

COBRA15
2016/02/15 Version: 1.0
iii
Federal Communications Commission (FCC)
Declaration of Conformity
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesirable operation.
This equipment has been tested and found to comply within the limit of a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the interference receiving antenna.
Increase the distance of separation between the equipment and interference receiver.
Connect the equipment to a power outlet on a circuit different from that to which the
interference receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING:
Use the included AC power cord so as not to interfere with radio and television reception.
If you use other cables, it may cause interference with radio and television reception.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING:
This is a equipment of Class A. This device could cause interferences in residential areas; in the case of interferences
it can be demand from the user to provide appropriate solutions for it.
WARNING:
The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with
FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for

COBRA15
2016/02/15 Version: 1.0
iv
compliance could void the user’s authority to operate this equipment.
RoHS

COBRA15
2016/02/15 Version: 1.0
v
BEFORE YOU PROCEED
Read the safety notices and the User Manual carefully before using the product.
Keep the box and packaging in case the product needs to be shipped in the future.
Follow the product and warning label instructions.
For safety reasons, only qualified service personnel should open the terminal.
Any changes or modifications that do not follow the instructions in this manual will void
this product/s warranty.
! SAFETY PRECAUTIONS
In the interest of safety, please observe the following precautions:
Power Requirement:
This product is designed to 12V, 60W DC adapter.
Never connect to any outlet or power supply having a different voltage or frequency.
! POWER SUPPLY SAFETY NOTICE
Disconnect this terminal from the AC outlet before cleaning. Use only a moistened cloth for
cleaning.
Check the voltage of the power source when connecting the equipment to the power
outlet. Make sure the voltage of the power outlet conforms within voltage range of the
terminal. Failure to comply may cause the electric shock or damage to the terminal. If you
are not sure of the electricity voltage that you are using, contact your local electricity
company.
To avoid electric shocks, disconnect the power cord from the electrical outlet before
relocating the system.
Do not overload electric power outlets to avoid fire or electric shocks.
Protect the power cord from being walked on or pinched particularly at plug.
If the equipment is not used for a long time, disconnect the equipment from the mains to
avoid damage.
Never allow liquid into ventilation openings. This could cause fire or electrical shock.

COBRA15
2016/02/15 Version: 1.0
vi
! OPERATING INSTRUCTIONS
Keep the User Manual for future reference.
Follow the product label instructions.
Lay this terminal Upside down on a stable safe surface when installing. Heavy objects
placed on the product can cause damage or obstruct proper ventilation.
If one of the following situations arises, notify a qualified service technician immediately:
a. The power cord or plug is damaged.
b. The terminal has been dropped and damaged.
c. The terminal does not function according to the user manual.
d. The terminal has obvious signs of damage.
Do not place the unit where with high humidity and dust. They can cause extensive
damage. Avoid places where unit is likely to be exposed to oily fumes and vapors.
Places exposed to direct sunlight, or near heating appliances can attain extremely high
temperatures, which may deform the cabinet, or can become a prime cause of damage.
The operating ambient temperature range is 0°C ~ 40°C (32°F ~ 104°F), and humidity of 10%
- 90%. When using the unit on the system rack, be sure to keep this ambient temperature
inside the range.
Avoid shaky places or hot-springs areas where hydrogen sulfide and acidic ions are likely to
be generated.
When transporting this unit, make sure it is not likely to be subjected to impacts. They can
be a prime cause for damage.

COBRA15
2016/02/15 Version: 1.0
vii
CONTENTS
1. Introduction .....................................................................................................................................8
1.1 How to use this manual .................................................................................................8
1.2 A Visual tour of COBRA15 ..............................................................................................9
1.2a What comes with COBRA15 ...............................................................................13
1.2b Dimensions of COBRA15 and its optional peripherals.......................................15
1.3 Features of COBRA15 ...................................................................................................17
1.4 IO Interface...................................................................................................................18
2. Hardware assembly........................................................................................................................19
2.1.1 HDD + SSD .........................................................................................................19
2.1.2 Memory.............................................................................................................20
2.1.3 Mini-PCI-E m-SATA SSD......................................................................................22
2.2 Optional peripherals installation..................................................................................25
2.2.1 MSR ...................................................................................................................25
2.2.2 Line VFD customer display ................................................................................27
2.2.3 Second 7” LCD display .......................................................................................30
3. Touch panel calibration ..................................................................................................................32
4. Specification ...................................................................................................................................39

COBRA15
8 Version: 1.0
1. Introduction
Thank you for purchasing POS COBRA15 Series Terminal. Read this chapter to know about your POS
COBRA15 Series Terminal package contents, outlook and dimensions.
1.1 How to use this manual
This manual contains all the information needed for setting up a COBRA15. In addition, you can
also consult the manual for the instructions to assemble / to service the terminal and to install the
optional peripherals.
Introduction to COBRA15 and this user manual.
All necessary information for hardware setup.
Specifications of COBRA15 and configuration of the motherboard.
Information for troubleshooting COBRA15.

COBRA15
9 Version: 1.0
1.2 A Visual tour of COBRA15
Before you start, please take a few moments to become familiar with COBRA15 Terminal.
Item No
Description
1
Touch screen
2
Removable Hard drive Extraction slot
3
POWER LED
4
Base / Stand
5
Optional devices
Elegant, Solid, Fashionable and Compact Design
1
2
3
4
5

COBRA15
10 Version: 1.0
Item No
Description
6
Function cover
7
Optional for VFD ,7”Secondary Display cover
8
MSR cover
9
Speaker holes (speaker Optional)
10
HDD Cover
11
Switch cover
12
Cable cover
6
7
8
9
9
11
12
10

COBRA15
11 Version: 1.0
“Very Easy Maintenance”
Please follow the instructions to reach all inner components:
Step 1: Please position the terminal as shown below
on a working table with “soft protective pad”.
Step 2: Please remove cable cover by
sliding it downwards.
Push
Push
Step 3: Please remove the circled six
screws.
Step 4: Please disconnect and remove all the
connected cables from IO interface and unscrew
the HDD screw.

COBRA15
12 Version: 1.0
Step 6: The back cover can now be removed.
Step 5: Please unplug and remove the hard
disk.
Only authorized system engineers are advised to disassemble the device.
Please be aware that unauthorized modifications will void your warranty.
You are advised to contact your authorized supplier for technical support.

COBRA15
13 Version: 1.0
1.2a What comes with COBRA15
Please check if your packaging contains below listed items before setting up your COBRA15. If any
of the items is missing or damaged, please contact your supplier immediately.
Main system with hidden power adapter in the stand.
CD for product User Manual, Touch Kits and Peripherals Drivers & Utilities.
M/B CD for user manual, drivers and utilities.
2 x 15cm RJ-45 to RS-232 converter cables and 2 x 40 cm RJ-45 to RS-232 converter cables.
AC power cord.
Optional Items:
MSR
Fingerprint reader
2D Image scanner
VFD customer display
ADDIMAT reader
i-Button reader
Second 7” LCD display
COBRA15 with MSR
COBRA15 with Fingerprint reader

COBRA15
14 Version: 1.0
COBRA15 with second 7” LCD
display
COBRA15 with i-Button
reader
COBRA15 with ADDIMAT reader
COBRA15 with 2D Image scanner
COBRA15 with VFD customer display

COBRA15
15 Version: 1.0
1.2b Dimensions of COBRA15 and its optional peripherals
15” COBRA15 dimensions:
15” COBRA15 with MSR+RFID integrated:
15” COBRA15 with VFD customer display
integrated:
15” COBRA15 with 7”second display
integrated:

COBRA15
16 Version: 1.0

COBRA15
17 Version: 1.0
1.3 Features of COBRA15
Low power consumption
LV (Low Voltage) design of the device is embedded
with a unique chipset and CPU renders power saving
function.
Saving cost of ownership
Modular design provides the owner with the
following benefits:
(a) cost effectiveness,
(b) customization flexibility, and
(c) Easy maintenance.
Dust/water proof
COBRA15 features a highly durable, rigorously tested
design that is reliable and dependable in rugged
environments.
Environment protection
Environmental friendly, RoHS compliant product.
High Stability
COBRA15 has a longer overall system MTBF to
provide a higher stability during operation.

COBRA15
18 Version: 1.0
1.4 IO Interface
IO interface is located at the bottom of the display. To clearly see IO interface you must remove
the cable cover.
Chart of the connector panel:
Item No
Description
A
Power DC-IN 12V
B
2 USB 2.0
C
LAN 10/100/1000Mbps Ethernet
D
VGA Connector
E
2 USB 2.0
F
Line out
G
Mic in
H
COM1 –COM4 Serial Ports (the serial ports for BIOS Setup 0/ +5V/ +12V-1A MAX
power output ,RJ-45 on PIN5 and D-SUB9 on PIN9)
A
C
B
D
E
F
H
G

COBRA15
19 Version: 1.0
2. Hardware assembly
Please make sure that the system power is turned off and the power supply is disconnected when
making any hardware changes to COBRA15.
2.1.1 HDD + SSD
Step 4: Then remove HDD or SSD
from the tray.
Step 2: Please pull out and retrieve
HDD or SSD.
Step 6: Please tighten left and right
screws indicated below to fix HDD or SSD
in place.
Step 1: Please remove the HDD
screw.
Step 3: Dismounting HDD from the tray
requires two screws to be removed.
Step 5: Please insert new HDD or SSD
into the tray.

COBRA15
20 Version: 1.0
Step 7: Please push in HDD or SSD into the terminal
where indicated below.
Step 8: Please tighten the circled
screw to complete the installation.
