Lopi Answer User manual

Answer
Wood Stove
(EPA 2020 Compliant)
Manual
Freestanding Stove
Mobile-Home Approved
Alcove Approved
Hearth-Stove Approved
Masonry Fireplace Insert
Zero-Clearance (Metal) Fireplace Insert
Save these instructions for future reference
SAFETY NOTICE:
If this appliance is not properly installed, a house fire may result.
For your safety, follow the installation directions. Contact local
building or fire officials about restrictions and installation
inspection requirements in your area.
Copyright 2019, T.I.
$10.00 100-01510
4/20/2020
Tested to:
U.L. 1482, & ULC S267-00

2 Introduction
© Travis Industries 4/20/2020 - 1510 Answer
Introduction
We welcome you as a new owner of a Lopi Answer wood-burning stove. In purchasing a Lopi Answer
you have joined the growing ranks of concerned individuals whose selection of an energy system reflects
both a concern for the environment and aesthetics. The Lopi Answer is one of the finest appliances the
world over. This manual will explain the installation, operation, and maintenance of this appliance.
Please familiarize yourself with the Owner's Manual before operating your appliance and save the manual
for future reference. Included are helpful hints and suggestions which will make the installation and
operation of your new appliance an easier and more enjoyable experience. We offer our continual
support and guidance to help you achieve the maximum benefit and enjoyment from your appliance.
Important Information
No other Lopi Answer appliance has the same serial
number as yours. The serial number is stamped onto
the label on the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: Lopi Answer
Serial Number:
Purchase Date:
Purchased From:
Register your warranty online at:
traviswarranty.com
Save Your Bill of Sale.
To receive full warranty coverage, you will need to
show evidence of the date you purchased your heater.
We suggest that you attach your Bill of Sale to this
page so that you will have all the information you need
in one place should the need for service or information
occur.

Table of Contents 3
© Travis Industries 4/20/2020 - 1510 Answer
Introduction ............................................................2
Important Information............................................2
Installation Options................................................6
Features ..................................................................6
Heating Specifications...........................................6
Stove Dimensions ..................................................6
Emissions ...............................................................6
Planning The Installation.......................................7
Preparation for Installation ...................................7
Additional Accessories Needed for Installation..7
Stove Installation Considerations ........................7
Packing List ............................................................8
Floor Protection Requirements ............................8
Stove Placement Requirements ...........................8
Clearances – Singlewall Connector .....................9
Clearances – Reduced Clearance Connector......10
Chimney Connector Requirements ......................11
Chimney Requirements .........................................12
Chimney Termination Requirements ...................13
Outside Air Requirements.....................................13
Alcove Installation Requirements ........................14
Standard Ceiling with a Factory Built Chimney ............16
Cathedral Ceiling with a Factory Built Chimney ...........16
Exterior Factory Built Chimney .....................................17
Hearth Stove Positive Connection................................18
Hearth Stove Direct Connection ...................................18
Interior or Exterior Masonry Chimney...........................19
Planning The Installation.......................................20
Preparation for Installation............................................20
Installation Considerations............................................20
Packing List ............................................................20
Insert Dimensions ..................................................21
Fireplace Requirements ........................................22
Fireplace Altered Tag.............................................22
Insert Placement Requirements ...........................23
Hearth Requirements.............................................23
Masonry Fireplace Requirements.........................23
Zero-Clearance (Metal) Fireplace Requirements.24
Drafting Performance ............................................24
Leveling Bolt Installation.......................................24
Insert with Positive Connection............................25
Insert with Direct Connection (Masonry
Fireplace) ................................................................25
Safety Notice ..........................................................26
Before Your First Fire ............................................26
Verify the Installation ....................................................26
Curing the Paint ............................................................26
Carbon Monoxide (CO) Emissions .............................. 26
Over-Firing the Stove ................................................... 26
Opening the Door .................................................. 27
Before Starting a Fire ............................................ 27
Adjusting the Burn Rate........................................ 28
Approximate Air Control Settings................................. 28
Understanding Your Heater’s Combustion
System .................................................................... 29
Burning Your Heater.............................................. 29
Optional Blower Operation ................................... 30
Re-Loading the Stove............................................ 30
Overnight Burn ...................................................... 30
Normal Operating Sounds .................................... 30
Hints for Burning ................................................... 31
Selecting Wood...................................................... 31
Why Dry Wood is Key .................................................. 31
Wood Cutting and Storage........................................... 31
Do Not Burn List .................................................... 32
Troubleshooting .................................................... 33
Daily Maintenance (while stove is in use) ........... 34
Remove Ash (if necessary)......................................... 34
Clean the Glass (if necessary)..................................... 34
Monthly Maintenance (while appliance is in
use) ......................................................................... 35
Door and Glass Inspection........................................... 35
Door Adjustment .......................................................... 35
Creosote - Formation and Need for Removal.............. 35
Yearly Maintenance ............................................... 36
Touch-Up Paint ............................................................ 36
Cleaning the Air Duct and Blower (if applicable) ......... 36
Firebrick and Baffle Inspection..................................... 36
Door Parts .................................................................... 37
Replacing the Glass ..................................................... 37
Replacing the Door Gasket .......................................... 37
Replacing the Door Handle.......................................... 37
Firebox Parts.......................................................... 38
Floor and Side Firebrick Removal & Replacement...... 38
Air Tube Removal & Replacement ....................... 39
Air Tube Identification .................................................. 39
Baffle Removal & Replacement............................ 40
Listing Label........................................................... 42
Rear Blower Installation (Part # 99000138) ......... 43
Outside Air Boot Installation (Part number
99200134)................................................................ 44
Surround Panels .................................................... 45
Front Blower (part # 99000123) ............................ 46
To Switch The Power Cord To The Left Side: ............. 46
Installation Instructions................................................. 46

4 Safety Precautions
© Travis Industries 4/20/2020 - 1510 Answer
The viewing door must be
closed and latched during
operation.
Smoke from this appliance may
active a smoke detector when
the door is open.
Never block free airflow through
the air vents on this appliance.
Gasoline or other flammable
liquids must never be used to
start the fire or "Freshen Up" the
fire. Do not store or use
gasoline or other flammable
liquids in the vicinity of this
appliance.
This appliance is designed and
approved for the burning of cord
wood only. Do not attempt to
burn any other type of fuel other
than cord wood in this
appliance, it will void all
warranties and safety listings.
Ashes must be disposed in a
metal container with a tight lid
and placed on a non-
combustible surface well away
from the home or structure.
Do not touch the appliance while
it is hot and educate all children
of the danger of a high-
temperature appliance. Young
children should be supervised
when they are in the same room
as the appliance.
Keep furniture, drapes, curtains,
wood, paper, and other
combustibles a minimum of 36"
away from the front of the
appliance.
This appliance must be properly
installed to prevent the
possibility of a house fire. The
instructions must be strictly
adhered to. Do not use
makeshift methods or
compromise in the installation.
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this appliance as well.
Inspect the chimney connector
and chimney at least twice
monthly and clean if necessary.
Creosote may build up and
cause a house fire.
Do not connect this appliance to
any chimney serving another
appliance.
This appliance must be
connected to a listed high
temperature (UL 103 HT)
residential type chimney or an
approved masonry chimney with
a standard clay tile, or stainless
steel liner.
Gas
ASHES
36"
Ok
Type
HT Clay
Liner

Safety Precautions 5
© Travis Industries 4/20/2020 - 1510 Answer
When installed in a mobile
home, this appliance must be
bolted to the floor, have outside
air, and not be installed in the
bedroom (Per H.U.D.
requirements). Check with local
building officials.
Do not place clothing or other
flammable items on or near this
appliance.
Never try to repair or replace
any part of this appliance unless
instructions are given in this
manual. All other work must be
done by a trained technician.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney to
install this appliance.
This wood heater has a
manufacturer-set minimum low
burn rate that must not be
altered. It is against federal
regulations to alter this setting or
otherwise operate this wood
heater in a manner inconsistent
with operating instructions in this
manual.
Allow the appliance to cool
before carrying out any
maintenance or cleaning.
Overfiring the appliance may
cause a house fire. If a unit or
chimney connector glows, you
are overfiring.
Maintain the door and glass seal
and keep them in good
condition.
Do not operate this heater with
broken or missing glass.
Avoid placing wood against the
glass when loading. Do not
slam the door or strike the glass.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Travis Industries, Inc. grants
no warranty, implied or
stated, for the installation or
maintenance of your
appliance,and assumes no
responsibility of any
consequential damage(s).
Smoke and CO Detectors: Make sure your home has a working smoke detector, especially near any bedrooms. We recommend
having a smoke and/or CO detector in the same room as the wood heater for additional safety.
Proposition 65 Warning: Fuels used in gas, woodburning or oil fired appliances, and the products of combustion of such fuels,
contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6
Travis Wood Burning Fireplaces, Stoves and Inserts are protected by one or more of the following patents; U.S. 9,170,025
4,665,889 as well as other U.S. and Foreign Patents pending.
This wood heater needs periodic inspection and repair for proper operation. It is against federal regulations to operate this
wood heater in a manner inconsistent with operating instructions in this manual.
Mobile
Home



This
Manual

6 Features & Specifications
© Travis Industries 4/20/2020 - 1510 Answer
Installation Options
Freestanding
Freestanding in an Alcove
Freestanding in a Mobile Home
Masonry Fireplace Insert
Zero-Clearance (Metal) Fireplace Insert
Features
1.5 Cubic Foot Firebox Volume
Single Operating Control
Accepts Logs Up to 18" Long
Steel Plate Construction (1/4" & 3/16")
Heavy Duty Refractory Firebrick
Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* 750 to 1,400 (stove)
750 to 1,200 (insert)
EPA Tested Cord Wood BTUs per Hour** 12,129 to 59,527
Maximum Burn Time Up to 8 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature.
It is also affected by the quality and moisture level of the fuel.
** EPA tests to determine BTU output are achieved with a single load of wood at each burn rate. At home, you are
likely to add more wood to your stove to maintain your desired comfort level. By the simple process of loading your
stove with additional wood, you could achieve up to a 20% higher heat output than established during EPA testing.
This model was tested for efficiency using method B415.1-10 and was determined to have a weighted average
Higher Heating Value (HHV) Overall Heating Efficiency (OHE) of 72.4%. Overall efficiency of the heater may be
lower if the heater isoperated without a heat exchange blower or with the installed heat exchange blower turned off.
Stove Dimensions
Figure 1
NOTE: Measure all side, corner, and back clearances from the stove top.
Emissions
This heater meets the 2020 U.S. EPA’s cord wood emission limits for wood heaters. Tested to EPA Alt-125,
ASTM E3053-17, ASTM 2515-11, CSA B415.1-10 this heater has been shown to deliver heat at rates
ranging from 12,129 to 59,527 BTU/hr and an emission value of 2.00g/h. Report No. 0028WS047E
23-5/8”
(600mm)
6
” (152mm) Dia.
3/4” (19mm)
5-7/8
”
(149mm)
20”
(508mm)
16-1/4”
(413mm)
Height:
27-7/8” (708mm)
IDB1016

Stove Installation (for qualified installers only) 7
© Travis Industries 4/20/2020 - 1510 Answer
SAFETY NOTICE:
Please read this entire manual before you install and use your new room heater. Failure to
follow instructions may result in property damage, bodily injury, or even death. Contact local
building or fire officials about restrictions and installation inspection requirements in your area.
Planning The Installation
We suggest that you have an authorized Travis Industries dealer install your stove. If you install the
stove yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this stove and notify your
insurance company before proceeding with installation.
The location of your wood heater in your home will decide how affectively the heat produced will spread
throughout your house. Attention to the home design with consideration of natural convection and air
circulation should be taken into account when choosing the placement of your heater within the home.
Preparation for Installation
Check for damage to the exterior of the stove (dents should be reported, scratches can be fixed by
applying touch-up paint).
Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
The stove can be lightened by removing the firebricks and baffle (pg 38) - replace before operation.
Additional Accessories Needed for Installation
Legs (for stoves) or Panels (for inserts)
Stove Installation Considerations
The table below details the six most common types of installations and the considerations for each type.
Alternative methods of installation are available if they comply with local building codes.
Installation Type Considerations
Standard Ceiling with a Factory Built Chimney (Page 16) Requires ceiling and roof penetration
Provides best draft
Cathedral Ceiling with a Factory Built Chimney (Page 16) Cathedral style chimney support required
Provides best draft
Exterior Factory Built Chimney (Page 17) Uses two elbows to route chimney outside
Exterior chimney is hidden from the room
Elbows reduce draft
Optional exterior chase reduces cold air blockage
Hearth Stove Positive Connection (Page 18) Utilizes existing masonry or zero clearance (metal)
chimney
Provides good draft due to full reline
Easier to clean than direct or horizontal hearth stove
Hearth Stove Direct Connection (Page 18)
NOT APPROVED IN CANADA
Utilizes existing masonry or zero clearance (metal)
chimney
Requires construction of a "block-off plate"
Draft reduced due to elbows & chimney cross section
Interior Masonry Chimney (Page 19)
NOT APPROVED IN CANADA
Utilizes existing masonry chimney (not approved for
zero clearance (metal) fireplaces)

8 Stove Installation (for qualified installers only)
© Travis Industries 4/30/2020 - 1510 Answer
Packing List
Wood Moisture Meter
Touch up paint
Gloves
Floor Protection Requirements
Stove must be placed on the Travis Industries legs.
Floor protection must extend to the sides, rear, and front of the stove (see “Clearances” for minimum
floor protection).
Floor protection must be non-combustible and at least .018" thick (26 guage).
No R value is required for floor protection - (R = 0).
Stove Placement Requirements
Clearances may be reduced by methods specified in NFPA 211, listed wall shields, pipe shields, or
other means approved by local building or fire officials.
Stove must be placed so that no combustibles are within, or can swing within (e.g. drapes, doors), 36"
(914mm) of the front of the stove
If the stove is placed in a location where the ceiling height is less than 7' (2134mm), it must follow the
requirements in the section “Alcove Installation Requirements”
Must maintain the clearances to combustibles (drywall, furniture, etc.) shown in following illustrations:

Stove Installation (for qualified installers only) 9
© Travis Industries 4/20/2020 - 1510 Answer
Clearances – Singlewall Connector
NOTE: Measure rear and side
stove clearances from the
nearest edge of the stove top.
NOTE: Measure front floor
protection from the face of the
stove (unibody).
23-5/8" (600mm)
16-1/4" (413mm)
5-7/8" (149mm)
19-1/2" (496mm) 16-1/2" (420mm)
US 6" (153mm)
Can. 8" (204mm)
27" (686mm)
US 16" (407mm)
Can. 18" (458mm)
FLOOR PROTECTION
18" (458mm)
US 6" (153mm)
Can. 8" (204mm)
19-1/2" (496mm)
23-5/8" (600mm)
16-1/4" (413mm)
5-7/8" (149mm)
US 6" (153mm)
Can. 8" (204mm)
US 16" (407mm)
Can. 18" (458mm)
FLOOR PROTECTION
10" (254mm)
ST
R
A
I
G
H
T
INST
A
LL
A
T
IONS
(singlewall connector)
CORNER INSTALLATIONS
(singlewall connector)
TOP OF STOVE
Connector
App. 6" (153mm) dia.
Approx. 42-1/4" (1074mm)
from Corner to Front
of Stove
US 6" (153mm)
Can. 8" (204mm)
TOP OF STOVE
Connector
App. 6" (153mm) dia.
IDB1164

10 Stove Installation (for qualified installers only)
© Travis Industries 4/20/2020 - 1510 Answer
Clearances – Reduced Clearance Connector
NOTE: Measure rear and side stove
clearances from the nearest edge of
the stove top.
NOTE: Measure front floor
protection from the face of the stove
(unibody).
NOTE: Reduced clearance
connectors may require an
appliance adapter to connect to the
flue collar.
NOTE: Standard residential
installations with reduced clearance
connector may use the clearance
determined by the manufacturer of
the connector for the connector to
wall clearance or the clearance
listed in this manual. Offsets must
be used to maintain the stove to wall
clearance.
NOTE: Vent diameter varies
depending upon brand and model.
NOTE: Reduced clearance
installations require one of the
chimneys and connectors listed
below:
AMERI-TEC model DCC with model HS
chimney
DURAVENT model DVL with DURATEC
or DURA-PLUS chimney
GSW Super Chimney Twenty-One
connected directly to appliance
I.C.C. Excel (2100-2 Can.) (103-HT USA)
chimney with ULTRABlack connector
METALFAB model DW connector with TG
chimney
OLIVER MACLEOD PROVENT model PV
connector with model 3103 chimney
SECURITY model DP connector with
SECURITY model ASHT or S2100
chimney
SELKIRK METALBESTOS model DS
connector with model SSII chimney
Standard Masonry Chimney with any one
of the above listed connectors
23-5/8" (600mm)
16-1/4" (413mm)
5-7/8" (149mm)
11-1/2" (293mm) 9" (229mm)
US 6" (153mm)
Can. 8" (204mm)
21-1/2" (547mm)
US 16" (407mm)
Can. 18" (458mm)
FLOOR PROTECTION
13" (331mm)
US 6" (153mm)
Can. 8" (204mm)
16-1/2" (420mm)
23-5/8" (600mm)
16-1/4" (413mm)
5-7/8" (149mm)
US 6" (153mm)
Can. 8" (204mm)
US 16" (407mm)
Can. 18" (458mm)
FLOOR PROTECTION
7-1/2" (191mm)
ST
R
A
I
G
H
T
INST
A
LL
A
T
IONS
(reduced clearance connector)
CORNER INSTALLATIONS
(reduced clearance connector)
TOP OF STOVE
Approx. 38-3/4" (985mm) from
Corner to Front of Stove
US 6" (153mm)
Can. 8" (204mm)
Connector
App. 7" (178mm) dia.
IDB1165
TOP OF STOVE
Connector
App. 7" (178mm) dia.

Stove Installation (for qualified installers only) 11
© Travis Industries 4/20/2020 - 1510 Answer
Chimney Connector Requirements
Chimney connector is required from the flue collar of the stove to the factory-built chimney or
masonry chimney.
The chimney connector must be 6” diameter and a minimum 24 gauge black steel, or one of the
reduced-clearance connectors listed on page 10.
NOTE: Aluminum or galvanized steel is not allowed – these materials can not withstand the flue
temperatures and may give off toxic fumes when heated.
NOTE: Standard residential installations may use single-wall connector (Mobile-Homes may not).
The chimney connector may not pass through a ceiling, attic, roof, closet, or any other concealed
space (use listed UL 103 HT chimney – see “Chimney Requirements for details). DO NOT USE
CONNECTOR PIPE AS CHIMNEY.
IN CANADA: Where passage through a wall, or partition of combustible construction is desired, the
installation shall conform to CAN/CSA-B365, Installation Code for Solid-Fuel-Burning Appliances and
Equipment.
The chimney connector should be as short and direct as possible. No more than 180oof elbows (two
90oelbows, or two 45o& one 90oelbow, etc.) may be used for the entire system (connector and
chimney).. Horizontal runs should slope upwards 1/4” per foot and be a maximum 36” long.
The chimney connector must be installed with the crimped end pointing downwards. This prevents
creosote from leaking to the exterior of the pipe.
The chimney connector must be fastened to the stove and each adjoining section (and chimney).
Standard residential installations may use single-wall connector (Mobile-Homes may not)
Standard residential installations with reduced clearance connector may use the clearance
determined by the manufacturer of the connector for the connector to wall clearance or the clearance
listed in this manual. Offsets must be used to maintain the stove to wall clearance. Mobile homes
must use the clearances listed in this manual under "Additional Requirements for Mobile Home
Installations".
IDB1117

12 Stove Installation (for qualified installers only)
© Travis Industries 4/20/2020 - 1510 Answer
Chimney Requirements
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK
UNLESS SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS.
IN CANADA: This appliance must be connected to a factory-built chimney conforming to CAN/ULC-
S629, Standard for 650°C Factory-Built Chimneys.
UL 103 HT Chimney must be used from the first ceiling or floor penetration to the chimney cap.
Use 6" diameter type UL 103 HT chimney from one manufacturer (do not mix brands) or code
approved masonry chimney with a flue liner.
Chimney must be fastened to each adjoining section.
Follow the chimney manufacturer's clearances and requirements.
Use the chimney manufacturer's fire stops, attic guards, roof supports, and flashings when passing
through a ceiling (see “b” below).
No more than 180oof elbows (two 90oelbows, or two 45o& one 90oelbow, etc.) may be used for the
entire system (connector and chimney).
NOTE: Additional elbows may be allowed if draft is sufficient. Whenever elbows are used the draft is
adversely affected. Additional chimney height may be required to boost draft.
Figure 2
Drafting
Performance
Draft is the force which moves air from the appliance up through the chimney. The amount of
draft in your chimney depends on the length of the chimney, local geography, nearby
obstructions and other factors. Too much draft may cause excessive temperatures in the
appliance and may damage the heater. Inadequate draft may cause backpuffing into the
room and `plugging' of the chimney. Inadequate draft will cause the appliance to leak smoke
into the room through appliance and chimney connector joints. An uncontrollable burn or
excessive temperature indicates excessive draft.
a
b
b
d
c
f
e
(a) M in. System Height 15’
(c) Chimney Sections
(b) Roof Penetration and Term ination
(d) Ceiling Penetration
(e) M in. air space to com bustibles
(f) Connector - see “Chimney Connector” on the
M ax. System Height 33’
(See Chim ney M anufacturer’s Req.)
(See Chim ney M anufacturer’s Req.)
(See Chim ney M anufacturer’s Req. - Typ 2”)
previous page
f
ID B111 8

Stove Installation (for qualified installers only) 13
© Travis Industries 4/20/2020 - 1510 Answer
Chimney Termination Requirements
Must have an approved cap (to prevent water from entering).
Must not be located where it will become plugged by snow or other material.
Must terminate at least 3' (914mm) above the roof and at least 2' (610mm) above any portion of the
roof within 10' (3.04M) - see Figure 3.
Figure 3
Outside Air Requirements
Required for mobile homes & in certain localities (check with building officials).
Must not be drawn from an enclosed space (garage, unventilated crawl space). May be drawn from
ventilated crawl space (a) or exterior of home (d). Must have suitable rodent/debris screen and rain
protection (hood).
Requires the optional outside air kit (sku# 99200139) or air boot (sku# 99200134 ).
Air duct maximum length is 15’ (4.57M) with a minimum cross section of 16 square inches
(10323mm) or 6’ (1.83M) with a minimum cross section of 7 square inches (4517mm).
Figure 4
Min. 3’ (914mm)
Min. 2’ (610mm)
Min. 3’ (914mm)
Min. 2’ (610mm)
 10’ (3.04M)
 10’ (3.04M)
IDB1119
Outside Air
Connector
Outside air entrance must be placed so
it does not become blocked b
y
snow
.
a
b
c
IDB1020

14 Stove Installation (for qualified installers only)
© Travis Industries 4/20/2020 - 1510 Answer
Alcove Installation Requirements
Whenever the stove is placed in a location where the ceiling height is less than 7' (2134mm) tall, it is
considered an alcove installation. Because of the reduced height, the special installation requirements
listed below must be met.
Chimney connector and chimney must be one of the following types:
AMERI-TEC model DCC with model HS chimney
DURAVENT model DVL with DURATEC or DURA-PLUS chimney
GSW Super Chimney Twenty-One connected directly to appliance
I.C.C. Excel (2100-2 Can.) (103-HT USA) chimney with ULTRABlack connector
METALFAB model DW connector with TG chimney
OLIVER MACLEOD PROVENT model PV connector with model 3103 chimney
SECURITY model DP connector with SECURITY model ASHT or S2100 chimney
SELKIRK METALBESTOS model DS connector with model SSII chimney
Standard Masonry Chimney with any one of the above listed connectors
NOTE: Reduced clearance connectors may not connect to the flue collar – an appliance adapter may be required.
Alcoves are classified as combustible or non-combustible. Non-combustible alcoves must have walls
and a ceiling that are 3 1/2" (89mm) thick of a non-combustible material (brick, stone, or concrete).
This non-combustible material must be spaced and ventilated at least 1" (25mm) off of all combustible
materials (walls, ceiling, etc.) to allow air to move around the non-combustible walls and ceiling. All
other alcoves are considered combustible. The clearances below must be met:
a
b
d
f
g
e
c
IDB1015
Miniumum Clearance Combustible
Alcove
Non-Combustible
Alcove
(a) Sidewall to stove 13”
(331mm)
6”
(153mm)
(b) Backwall to stove 9”
(229mm)
2”
(51mm)
(c) Connector to
sidewall
21-1/2”
(547mm)
14-1/2”
(369mm)
(d) Connector to
backwall
11-1/2”
(293mm)
4-1/2”
(115mm)
(e) Maximum depth of
alcove
48”
(1220mm)
48”
(1220mm)
(f) Minimum width of
alcove
49-5/8”
(1261mm)
35-5/8”
(905mm)
(g) Minimum height of
alcove
84”
(2134mm)
6”
(153mm)
above stove top
Non-combustible alcove
construction (on walls
and ceiling) - see the
explanation above.
Min. 3 1/2"
(89mm) non-
combustible
material
Combustible
materials
1" (25mm)
Min.
Ventilated
air space
Non-combustible
reinforcer
IDB1121

Stove Installation (for qualified installers only) 15
© Travis Industries 4/20/2020 - 1510 Answer
Mobile Home Requirements
Outside air must be installed - see "Outside Air Requirements" on page 13
Chimney connector and chimney must be one of the following types:
AMERI-TEC model DCC with model HS chimney
DURAVENT model DVL with DURATEC or DURA-PLUS chimney
GSW Super Chimney Twenty-One connected directly to appliance
I.C.C. Excel (2100-2 Can.) (103-HT USA) chimney with ULTRABlack connector
METALFAB model DW connector with TG chimney
OLIVER MACLEOD PROVENT model PV connector with model 3103 chimney
SECURITY model DP connector with SECURITY model ASHT or S2100 chimney
SELKIRK METALBESTOS model DS connector with model SSII chimney
Standard Masonry Chimney with any one of the above listed connectors
NOTE: Reduced clearance connectors may not connect to the flue collar – an appliance adapter may be required.
Stove placement must maintain the following clearances to combustibles (drywall, furniture, etc.)
If using offsets, use the connector clearance listed in Figure 5, not the
connector manufacturer's clearance.
The appliance must be secured to the floor (consult your building official).
Secure the outside air boot to the floor and stove to insure the stove does
not dislocate.
Mobile home installations require a spark arrester at the chimney
termination.
The appliance must be grounded to the chassis of the mobile home
(consult your building official).
WARNING:DO NOT INSTALL IN SLEEPING ROOM.
CAUTION:THE STRUCTURAL INTEGRITY OF THE MOBILE HOME
FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED.
Figure 5
Straight Installations Corner Installations
45°
13”
(331mm)
11-1 / 2 ”
(293mm) 16-1/2”
(293mm)
7-1/2”
(191mm)
21-1/2”
(547mm)
9”
(229mm)
IDB1108
12” Min.
Connector Clearance
(as outlined above)
Stove Clearance
(as outlined above)
IDB1166

16 Stove Installation (for qualified installers only)
© Travis Industries 4/20/2020 - 1510 Answer
Standard Ceiling
with a Factory
Built Chimney
Figure 6
Cathedral Ceiling
with a Factory
Built Chimney
Figure 7
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)
Chimney Pipe Sections
Connector Pipe Sections
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm collar
and flashing are required
(some require a radiation
shield).
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Follow the chimney
manufacturer's instructions
and clearances for floor
penetrations. A ceiling
support is required, an attic
insulation shield is required
where insulation is present
.
Insulation
Chimney Manufacturer's
Minimum Air Space to
Combustibles (See
Instructions - usually 2" (51mm))
Minimum 15'
(4.57M)
Maximum 33'
(10.06M)
IDB1122
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)
Chimney Pipe Sections
Connector Pipe Sections
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm collar
and flashing are required
(some require a radiation
shield).
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Chimney Manufacturer's
Minimum Air Space to
Combustibles (See
Instructions - usually 2" (51mm))
Minimum 15'
(4.57M)
Maximum 33'
(10.06M)
IDB1123

Stove Installation (for qualified installers only) 17
© Travis Industries 4/20/2020 - 1510 Answer
Exterior Factory
Built Chimney
NOTE:
Exterior chimneys are
subject to greater
moisture and creosote
accumulation due to the
lower temperatures. An
insulated chase will
reduce these
accumulations (the
proper clearances to the
chimney must be
maintained).
Figure 8
F
o
ll
ow t
h
e c
hi
mney
manufacturer's
instructions and
clearances for roof
penetrations. A stor
m
collar and flashing are
required (some
require a radiation
shield).
(See the section "Stove
Placement Requirements"
for more details)
Follow the chimney
manufacturer's
instructions and
clearances for wall
penetrations. A
wall radiation shield
(thimble) is
required.
Optional
insulated
chase
Wall Bands
and
Supports
Insulated Tee
(with cleanout )
Connector must maintain
Proper Clearance to Ceiling
Min 18” (457mm) for
single-wall pipe
Stove Clearances
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)
Chimney Pipe Sections
Connector Pipe Sections
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Chimney Manufacturer's
Minimum Air Space to
Combustibles (See
Instructions - usually 2" (51mm))
Minimum 15' (4.57M)
Maximum 33' (10.05M)
IDB1124

18 Stove Installation (for qualified installers only)
© Travis Industries 4/20/2020 - 1510 Answer
Hearth Stove
Positive
Connection
NOTE:
Most factory-built
chimney manufacturers
make stainless steel
chimney liners, either
flexible or rigid. This
provides a wide variety
of installation options.
Make sure to follow the
manufacturer's
instructions for
installation and support.
Figure 9
Hearth Stove Direct
Connection
NOTE:
This type of installation is
not allowed in Canada.
NOTE:
Direct connections require
installation of an airtight,
non-combustible block-off
plate or damper adapter.
Figure 10
Remove damper
or wire it open
Min. 36"
(915mm)
Combustible
Mantle
NOTE: The entire fireplace and
c
himney must be clean, undamaged,
a
nd meet all local building codes
(UBC, etc.). Damage must be
repaired prior to installation. The
c
himney must be 15' (4.57M) to
3
3' (10.05M) tall
.
Floor Protection
(See the section
"Floor Protection
Requirements"
for more details)
See the section
"Stove Placement
Requirements" for
minimum clearances
required.
The liner must be
stainless steel connector
or flexible vent. Follow
the liner manufacturer's
instructions for installation
and support.
Cap and flashing
prevents water from
entering
IDB112
5
Remove damper
Block-off plate or
NOTE: All cleanouts must be
be sealed
or wire it open
damper adapter
Min. 36"
(915mm)
Combustible
Mantle
NOTE: The entire fireplace and
c
himney must be clean, undamaged,
a
nd meet all local building codes
(UBC, etc.). Damage must be
repaired prior to installation. The
c
himney must be 15' (4.57M) to
3
3' (10.05M) tall
.
Floor Protection
(See the section
"Floor Protection
Requirements"
for more details)
See the section
"Stove Placement
Requirements" for
minimum clearances
required.
The liner must be
stainless steel connector
or flexible vent. Follow
the liner manufacturer's
instructions for installation
and support.
Cap prevents water
from entering
IDB1126

Stove Installation (for qualified installers only) 19
© Travis Industries 4/20/2020 - 1510 Answer
Interior or Exterior
Masonry Chimney
NOTE:
This type of installation is
not allowed in Canada.
NOTE:
This type of installation
requires a UBC approved
masonry connector or a
factory built (U.L. Listed)
wall thimble.
Figure 11
Cap prevents water
from entering
IDB1127
(See the section "Stove
Placement Requirements"
for more details)
Stove Clearances
Connector Pipe Sections
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Make sure the
clean-out seals in
place.
Clay Liner
This type of
installation require
s
a UBC approved
masonry connector
or other method
approved by the
NFPA 211 standard
NOTE: The chimney must have a
c
lay tile liner. If it does not, the
installation must use a positive
c
onnection (full reline). The
e
ntire fireplace and chimney must
be clean, undamaged, and meet
a
ll local building codes (UBC,
e
tc.). Damage must be repaired
prior to installation. The chimney
must be 15' (4.57M) to 33' (10.05M) tall
.
Connector must maintain
Proper Clearance to Ceiling
Min 18” (457mm) for
single-wall pipe

20 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 4/20/2020 - 1510 Answer
SAFETY NOTICE:
Please read this entire manual before you install and use your new room heater. Failure to follow instructions
may result in property damage, bodily injury, or even death. Contact local building or fire officials about
restrictions and installation inspection requirements in your area.
Planning The Installation
We suggest that you have an authorized Travis Industries dealer install your fireplace insert. If you
install the fireplace insert yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this fireplace insert and
notify your insurance company before proceeding with installation.
Preparation for Installation
Check for damage to the exterior of the fireplace insert (dents should be reported, scratches can be
fixed by applying touch up paint).
Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
The fireplace insert can be lightened by removing the firebricks and baffle (pg 38) - replace before
operation.
Installation Considerations
Installation Type Considerations
Insert with Positive Flue (Full Reline)
(Page 25)
• Utilizes existing masonry or zero clearance fireplace
• Provides best draft
• Easiest to clean
Insert with Direct Connect Flue
(Page 25)
• Masonry fireplace only
• Provides good draft
• Requires fireplace block-off plate
Packing List
Wood Moisture Meter
Touch up paint
