Endeavor Wood Stove
Owner's Manual
Save these instructions
for future reference
SAFETY NOTICE:
Ifthisapplianceisnotproperlyinstalled,ahousefiremayresult.
Foryoursafety,followtheinstallationdirections. Contactlocal
buildingorfireofficialsaboutrestrictionsandinstallation
inspectionrequirementsinyourarea.
Dragon Wholesaling Pty. Ltd.
Unit 2, 16 Lexington Drive
Bella Vista NSW 2153
Australia
Copyright 2011, Travis
Industries, Inc.
$10.00
100-01275_000
4111122
Tested By:
AMDEL
8/26 Stirling St.
Thebarton, 5031, South Australia
TESTED TO: AS/NZS 4013:1999
REPORT NUMBER: L4507/94

2 Introduction
© Travis Industries 100-01275 4111122
Introduction
We welcome you as a new owner of an Endeavor wood-burning stove. In purchasing an Endeavor you
have joined the growing ranks of concerned individuals whose selection of an energy system reflects both
a concern for the environment and aesthetics. The Endeavor is one of the finest appliances the world
over. This manual will explain the installation, operation, and maintenance of this appliance. Please
familiarize yourself with the Owner's Manual before operating your appliance and save the manual for
future reference. Included are helpful hints and suggestions which will make the installation and
operation of your new appliance an easier and more enjoyable experience. We offer our continual
support and guidance to help you achieve the maximum benefit and enjoyment from your appliance.
Important Information
No other Endeavor appliance has the same serial
number as yours. The serial number is stamped onto
the label on the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: Endeavor
Serial Number:
Purchase Date:
Purchased From:
Mail your Warranty Card Today, and Save Your Bill
of Sale.
To receive full warranty coverage, you will need to
show evidence of the date you purchased your
appliance. Do not mail your Bill of Sale to us.
We suggest that you attach your Bill of Sale to this page
so that you will have all the information you need in one
place should the need for service or information occur.

Table of Contents 3
© Travis Industries 100-01275 4111122
Introduction ......................................................2
Important Information......................................2
Installation Options..........................................6
Features ............................................................6
Heating Specifications.....................................6
Dimensions.......................................................6
Emissions .........................................................6
Planning the Installation..................................7
Preparation for Installation....................................7
Additional Accessories Needed for Installation.....7
Floor Protection Requirements ......................8
Stove Placement Requirements .....................8
Clearances........................................................8
Chimney Connector Requirements................9
Chimney Requirements.................................10
Chimney Termination Requirements ...........11
Outside Air Requirements.............................11
Standard Ceiling with a Factory Built Chimney...12
Cathedral Ceiling with a Factory Built Chimney..12
Exterior Factory Built Chimney............................13
Hearth Stove Positive Connection ......................13
Interior or Exterior Masonry Chimney .................14
Safety Notice ..................................................15
Before Your First Fire....................................15
Verifying the Installation......................................15
Curing the Paint..................................................15
Over-Firing the Stove..........................................15
Opening the Door...........................................15
Starting a Fire.................................................16
Adjusting the Burn Rate................................17
Approximate Air Control Settings........................17
Ash Removal ..................................................17
Optional Blower Operation............................18
Re-Loading the Stove....................................18
Overnight Burn...............................................18
Normal Operating Sounds ............................18
Hints for Burning ...........................................19
Selecting Wood..............................................19
Why Dry Wood is Key.........................................19
Wood Cutting and Storage..................................19
Troubleshooting.............................................20
Daily Maintenance (while stove is in use)...21
Remove Ash (if necessary).................................21
Clean the Glass (if necessary)............................21
Monthly Maintenance (while appliance is in
use)..................................................................22
Door and Glass Inspection..................................22
Creosote - Formation and Need for Removal .....22
Yearly Maintenance ....................................... 23
Touch-Up Paint...................................................23
Cleaning the Air Duct and Blower (if applicable).23
Firebrick and Baffle Inspection............................23
Door Parts.......................................................24
Replacing the Glass............................................24
Replacing the Door Gasket.................................24
Replacing the Door Handle.................................24
Firebox Parts..................................................25
Floor and Side Firebrick Removal & Replacement25
Air Tube Removal & Replacement...............26
Baffle Removal & Replacement....................26
Warranty .........................................................27
Listing Label........................................................29
Outside Air Connector (Part number
99200139)........................................................29
Door Shell Installation...................................30
Stove Leg Installation....................................32
Pedestal (Part # 99200106)............................32
Using Outside Air with the Pedestal....................32
Outside Air Boot Installation (Part number
99200134)........................................................33

4 Safety Precautions
© Travis Industries 100-01275 4111122
The viewing door must be
closed and latched during
operation.
Never block free airflow through
the air vents on this appliance.
Gasoline or other flammable
liquids must never be used to
start the fire or "Freshen Up" the
fire. Do not store or use
gasoline or other flammable
liquids in the vicinity of this
appliance. Do not burn garbage
or flammable fluids such as
gasoline, naphtha or engine oil.
This appliance is designed and
approved for the burning of cord
wood only. Do not attempt to
burn any other type of fuel other
than cord wood in this
appliance, it will void all
warranties and safety listings.
Ashes must be disposed in a
metal container with a tight lid
and placed on a non-
combustible surface well away
from the home or structure.
Do not touch the appliance while
it is hot and educate all children
of the danger of a high-
temperature appliance. Young
children should be supervised
when they are in the same room
as the appliance.
Keep furniture, drapes, curtains,
wood, paper, and other
combustibles a minimum of 36"
(914mm) away from the front of
the appliance. Do not store fuel
under or around the appliance.
This appliance must be properly
installed to prevent the
possibility of a house fire. The
instructions must be strictly
adhered to. Do not use
makeshift methods or
compromise in the installation.
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this appliance as well.
Inspect the chimney connector
and chimney at least twice
monthly and clean if necessary.
Creosote may build up and
cause a house fire.
Do not connect this appliance to
any chimney serving another
appliance.
This appliance must be
connected to a listed high
temperature (UL 103 HT)
residential type chimney or an
approved masonry chimney with
a standard clay tile, or stainless
steel liner.
Gas
ASHES
36"
Ok
Type
HT Clay
Liner

Safety Precautions 5
© Travis Industries 100-01275 4111122
Never try to repair or replace
any part of this appliance unless
instructions are given in this
manual. All other work must be
done by a trained technician.
Do not place clothing or other
flammable items on or near this
appliance.
Hot while in operation. Keep
children, clothing and furniture
away. Contact may cause skin
burns.
Allow the appliance to cool
before carrying out any
maintenance or cleaning.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney to
install this appliance.
Do not make any changes to the
appliance to increase
combustion air.
Maintain the door and glass seal
and keep them in good
condition.
Avoid placing wood against the
glass when loading. Do not
slam the door or strike the glass.
Overfiring the appliance may
cause a house fire. If a unit or
chimney connector glows, you
are overfiring.
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
Travis Industries, Inc. grants
no warranty, implied or
stated, for the installation or
maintenance of your
appliance,and assumes no
responsibility of any
consequential damage(s).



This
Manual

6 Features & Specifications
© Travis Industries 100-01275 4111122
Installation Options
Freestanding
Freestanding Hearth Stove
Features
EPA Phase II Approved
.06 Cubic Meter Firebox Volume
Single Operating Control
Accepts Logs Up to 495mm Long
Steel Plate Construction (9.5mm to 6mm)
Heavy Duty Refractory Firebrick
Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity* Up to 250 sq. meters
Maximum Burn Time Up to 10 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
Figure 1
Emissions
APPLIANCE EMISSION FACTOR BURNING HARDWOOD = 2.3 g/Kg
24” 610mm
23-1/2”
597mm 5-3/4” 146mm
Note:
Measure side, corner, and back
clearances from the stove top.
Measure front clearances from
the stove face.
Height:
Sculptured or Cast Legs....30-5/8" 778mm
Pedestal.............................34-5/8" 879mm
Weight: 448 Lbs.
203 Kilos
6” 152mm ø
1-3/4” 44mm

Stove Installation (for qualified installers only) 7
© Travis Industries 100-01275 4111122
SAFETYNOTICE:
Please read this entire manual before you install and use your new room heater. Failure to
follow instructions may result in property damage, bodily injury, or even death. Contact
local building or fire officials about restrictions and installation inspection requirements in
your area.
Always use gloves when operating a hot stove. The door handle and other components become very
hot during normal use.
Planning the Installation
We suggest that you have an authorized Travis Industries dealer install your stove. If you install the
stove yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this stove and notify your
insurance company before proceeding with installation.
Preparation for Installation
The stove can be lightened by removing the firebricks and baffle (pg. 25) - replace before operation.
Check for damage to the exterior of the stove.
Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
Additional Accessories Needed for Installation
Door Shell (Black 99300195 Brass 99300196 or Pewter 99300197)
Legs or Pedestal

8 Stove Installation (for qualified installers only)
© Travis Industries 100-01275 4111122
Floor Protection Requirements
Stove must be placed on the Travis Industries legs or pedestal.
Floor protection must extend to the sides, rear, and front of the stove (see “Clearances” below for
minimum floor protection).
NOTE: When installed with reduced-clearance connector, the clearance to the backwall may be less
than the floor protection requirement. In this case the floor protection must extend to the wall.
Floor protection must be non-combustible and at least .018" thick (26 gauge).
Stove Placement Requirements
Clearances may be reduced by methods specified in NFPA 211, listed wall shields, pipe shields, or
other means approved by local building or fire officials.
Stove must be placed so that no combustibles are within, or can swing within (e.g., drapes, doors),
36" (914mm) of the front of the stove.
If the stove is placed in a location where the ceiling height is less than 7' (2,134mm), additional
requirements may apply (contact your local building official).
Must maintain the clearances to combustibles listed below (drywall, furniture, etc.):
Clearances
The following clearances must be met (see Figure 2)
Clearance Requirements: No Flue Shield With Flue Shield
A* Sidewall to stove N/A 350mm
B* Backwall to stove N/A 150mm
C* Cornerwall to stove 150mm 150mm
D Front Hearth 300mm 300mm
E Side Hearth 200mm 200mm
F Back Hearth 152mm 152mm
Figure 2
* Clearances to combustible material are according to heater test results using a standard flue kit,
(AS/NZS 2918:2001) fitted with 1 length 900mm deco mesh with a heat shield or 1 length 900mm x
120° stainless steel heat shield as a minimum. Any further enquiries please contact Dragon
Wholesaling Pty Ltd on 1800 064 234.

Stove Installation (for qualified installers only) 9
© Travis Industries 100-01275 4111122
Chimney Connector Requirements
The chimney connector must be 6” (150mm) diameter and stainless steel.
NOTE: Aluminum or galvanized steel is not allowed – these materials cannot withstand the flue
temperatures and may give off toxic fumes when heated.
Chimney connector is required from the flue collar of the stove to the factory-built chimney (see
Figure 4) or masonry chimney (see Figures 13, 14, and 15).
The chimney connector may not pass through a ceiling, attic, roof, closet, or any other concealed
space (use listed UL 103 HT chimney – see “Chimney Requirements for details). DO NOT USE
CONNECTOR PIPE AS CHIMNEY.
The chimney connector should be as short and direct as possible. No more than 180oof elbows (two
90oelbows, or two 45o& one 90oelbow, etc.) may be used for the entire system (connector and
chimney). Horizontal runs should slope upwards 1/4” (6mm) per foot (305mm) and be a maximum
36” long (914mm).
The chimney connector must be installed with the crimped end pointing downwards (see Figure 3).
This prevents creosote from leaking to the exterior of the pipe.
Figure 3
The chimney connector must be fastened to the stove and each adjoining section (and chimney).
On singlewall pipe
the crimped end
points downward.

10 Stove Installation (for qualified installers only)
© Travis Industries 100-01275 4111122
Chimney Requirements
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK
UNLESS SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS.
IN CANADA: This appliance must be connected to a factory-built chimney conforming to CAN/ULC-
S629, Standard for 650ºC Factory-Built Chimneys.
UL 103 HT Chimney must be used from the first ceiling or floor penetration to the chimney cap.
Use 6" diameter type UL 103 HT chimney from one manufacturer (do not mix brands) or code
approved masonry chimney with a flue liner.
Chimney must be fastened to each adjoining section.
Follow the chimney manufacturer's clearances and requirements.
Use the chimney manufacturer's fire stops, attic guards, roof supports, and flashings when passing
through a ceiling.
No more than 180oof elbows (two 90oelbows, or two 45oand one 90oelbow, etc.) may be used for
the entire system (connector and chimney).
NOTE: Additional elbows may be allowed if draft is sufficient. Whenever elbows are used the draft is
adversely affected. Additional chimney height may be required to boost draft.
Figure 4
Drafting
Performance This appliance relies upon natural draft to operate. External forces, such as wind,
barometric pressure, topography, or factors of the home (negative pressure from exhaust
fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries cannot be
responsible for external forces leading to less than optimal performance.




















Chimney Cap
(See the section "Chimney Termination
Requirements" for more details)










Factory Built Chimney Sections
Minimum Air Space to Combustibles
(See Chimney Manufacturer's
Instructions)
Floor Penetration Equipment
(Attic Radiation Shield with Chimney Support)
Reduced Clearance Chimney
Connector Sections
Roof Penetration Equipment (Roof
Radiation Shield, Flashing, Storm Collar)
}
}



Stove Clearance
(as outlined in this manual)


















}
Standard residential installations with reduced
clearance connector may use the clearance determined by
the manufacturer of the connector for the connector to wall
clearance or the clearance listed in this manual.
Mobile home installations must use the the reduced
clearance connector clearances listed in this manual under
“Additional Requirements for Mobile Home Installations”.
Minimum System 15' (4.57M)
Maximum System 33' (10.05M)

Floor
Protection

Stove Installation (for qualified installers only) 11
© Travis Industries 100-01275 4111122
Chimney Termination Requirements
Must have an approved cap (to prevent water from entering).
Must not be located where it will become plugged by snow or other material.
Must terminate at least 3' (914mm) above the roof and at least 2' (610mm) above any portion of the
roof within 10' (3.04M) - see Figure 5.
Figure 5
Outside Air Requirements
Required for mobile homes & in certain localities (check with building officials).
Must not be drawn from an enclosed space (garage, unventilated crawl space).
Requires the optional outside air connector or pedestal.
Air duct maximum length is 15’ (4.57M) with a minimum cross-section of 16 square inches
(10404mm) or 6’ (1.82M) with a minimum cross section of 7 square inches (4489mm).
Figure 6








Min. 3’ (914mm)
Min. 2’ (610mm)
10’ (3.04M)
Min. 3’ (914mm)
10’ (3.04M)
Min. 2’ (610mm)

Outside Air
Connector
Outside air entrance must be placed so
it does not become blocked by snow.



P
edestal or outside air boot may
b
e used to direct air from below
t
he stove. See the pedestal
i
nstructions for complete details.
Air may be drawn from a ventilated
crawl space or use an air duct.
The pedestal has an air
opening for use with the
outside air connections.
This allows air to be
drawn from behind the
pedestal.









12 Stove Installation (for qualified installers only)
© Travis Industries 100-01275 4111122
Standard Ceiling
with a Factory
Built Chimney
Figure 7
Cathedral Ceiling
with a Factory
Built Chimney
Figure 8
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)













Chimney Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions)
Chimney Connector Sections
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm collar
and flashing are required
(some require a radiation
shield).
}
}
Follow the chimney
manufacturer's instructions
and clearances for floor
penetrations. A ceiling
support is required, an attic
insulation shield is required
where insulation is present.
Insulation
Minimum 15'
(4.57M)
Maximum 33'
(10.05M)
Must Maintain Stove
and Connector
Clearances
Floor
Protection STOVE
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)





Chimney Sections
Minimum Air Space to
Combustibles (See Chimney
Manufacturer's Instructions)
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm
collar, flashing, and
cathedral-style chimney
support are required
(some require a radiation
shield).
}
Minimum 15'
(4.57M)
Maximum 33'
(10.05M)
Must Maintain Stove
and Connector
Clearances
STOVE
Chimney Connector
Floor
Protection

Stove Installation (for qualified installers only) 13
© Travis Industries 100-01275 4111122
Exterior Factory
Built Chimney
NOTE:
Exterior chimneys are
subject to greater
moisture and creosote
accumulation due to the
lower temperatures. An
insulated chase will
reduce these
accumulations (the
proper clearances to the
chimney must be
maintained).
Figure 9
Hearth Stove
Positive
Connection
NOTE:
Most factory-built
chimney manufacturers
make stainless steel
chimney liners, either
flexible or rigid. This
provides a wide variety
of installation options.
Make sure to follow the
manufacturer's
instructions for
installation and support.
Figure 10






Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)


Chimney Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions)
Chimney Connector




Follow the chimney
manufacturer's
instructions and
clearances for roof
penetrations. A storm
collar and flashing are
required (some
require a radiation
shield).
}













Must Maintain Stove
and Connector
Clearances
}
Follow the chimney
manufacturer's
instructions and
clearances for wall
penetrations. A
wall radiation shield
(thimble) is
required.
Optional
insulated
chase
Wall Bands
and
Supports Insulated Tee
(with cleanout )
Must maintain
min.connector
clearance to
combustibles
Floor
Protection
Minimum 15' (4.57M)
Maximum 33' (10.05M)
STOVE
STOVE














Remove damper
or wire it open
Airtight Insulated
Clean-Out
Combustible
Mantle
NOTE: The entire fireplace and
chimney must be clean, undamaged,
and meet all local building codes
(UBC, etc.). Damage must be
repaired prior to installation. The
chimney must be 15' (4.57M) to 33'
(10.05M) tall.

The liner must be
stainless steel connector
or flexible vent. Follow
the liner manufacturer's
instructions for installation
and support.
Cap and flashing
prevents water from
entering
Must Maintain Stove
and Connector
Clearances
Floor
Protection
Must maintain
min.connector
clearance to
combustibles

14 Stove Installation (for qualified installers only)
© Travis Industries 100-01275 4111122
Interior or Exterior
Masonry Chimney
NOTE:
This type of installation is
not allowed in Canada.
NOTE:
This type of installation
requires a UBC approved
masonry connector, an
NFPA 211 approved
method, or a method
approved by local
jurisdictions.
Figure 11
Make sure the
clean-out seals in
place.
Clay Liner
This type of
installation requires
a UBC approved
masonry connector
or a factory built
(U.L. Listed) wall
thimble.
Chimney connector sections
NOTE: The chimney must have a
clay tile liner. If it does not, the
installation must use a positive
connection (full reline). The entire
fireplace and chimney must be
clean, undamaged, and meet all
local building codes (UBC, etc.).
Damage must be repaired prior to
installation. The chimney must be
15' (4.57M) to 33' (10.05M) tall.
Must Maintain Stove
and Connector
Clearances
Must maintain
min.connector
clearance to
combustibles
Floor
Protection STOVE

Operating Your Appliance 15
© Travis Industries 100-01275 4111122
Safety Notice
If this appliance is not properly installed, a house fire may result. For your safety, follow the installation
directions. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
Read and follow all of the warnings on pages 4 and 5 of this manual.
Before Your First Fire
Verifying the Installation
Before starting the stove, verify that the stove is properly installed and all of the requirements in this
manual have been followed.
Keep all flammable materials 910mm away from the front of the stove (drapes, furniture, clothing, etc.).
Curing the Paint
This heater uses a heat-activated paint that will emit some fumes while starting
the first fire. Open doors and windows to the room to vent these fumes. This
typically lasts two to four hours. You may also notice oil burning off of the interior
of the heater. This rust-stopping agent will soon dissipate.
Door Gasket - The door gasket might adhere to the paint on the front of the
heater. Leave the door slightly ajar for the first fire and be careful when opening
the door after the first fire.
Over-Firing the Stove
This stove was designed to operate at a high temperature. But due to differences in vent configuration,
fuel, and draft, this appliance can be operated at an excessive temperature. If the stovetop or other area
starts to glow red, you are over-firing the stove. Shut the air control down to low and allow the stove to
cool before proceeding.
Over-firing may lead to damage of plated surfaces. If you are uncertain of over-firing conditions, we
suggest placing a stove thermometer (e.g., Rutland® Model 710) directly over the door on the stovetop -
temperatures exceeding 800° are generally considered over-firing and will void the warranty.
Opening the Door
The door becomes hot during use. Use a glove to open the door if the handle is hot.
To prevent smoke from entering the room, open the air control before opening the door. You can also
open the door a small amount and let air enter the firebox.







2 to 4 hours
R
otate
t
he door
h
andle.
Swing
the door
open.

16 Operating Your Appliance
© Travis Industries 100-01275 4111122
Starting a Fire
Since the dawn of time man has debated the best way to start a fire. Some use the boy-scout "tee-pee",
some prefer the "tic-tac-toe" stack. Either way, review the hints and warnings below to ensure proper fire
starting.
Make sure the air control and is pushed in. If additional air is needed, open the doors 1/4" during the
first five minutes of start-up.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start
or "freshen up" a fire in this stove. Keep all such liquids well away from the stove while it is in use.
If using a firestarter, use only products specifically designed for stoves - follow the manufacturer's
instructions carefully.
If the smoke does not pass up the chimney, ball up one sheet of newspaper, place it in the center of the
firebox and light it. This should start the chimney drafting (this eliminates "cold air blockage").
Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning
rapidly, place a few larger pieces of wood onto the fire.
Starting a “Top-Down Fire”
One particularly successful method for starting a fire is to
stack several large pieces of wood in the center of the stove
(see the illustration to the right). Then place a several wads
of newspaper in the center with kindling on top. When you
light the newspaper this “top-down” fire will burn its way to
the center, igniting the larger pieces. With some practice,
this method should work for you.
Bypass Pushed In
Used for normal operation
Bypass Pulled Out
Used for starting and re-loading









Use the included pull tool
to operate the bypass rod

Operating Your Appliance 17
© Travis Industries 100-01275 4111122
Adjusting the Burn Rate
Use the air control slider to control the burn rate of the stove. See the illustration below for details.
Approximate Air Control Settings
Overnight Burn Fully in to 3mm open
Medium Burn 3mm to 16mm open
Medium High Burn 16mm to fully open
High Burn Fully open (pulled out)
The air control becomes hot during operation - use gloves or a tool to prevent burns.
The air control may take several minutes to influence the burn rate. When making adjustments, you
may wish to let the stove burn for 10 minutes to gauge performance.
Ash Removal
Ashes should be placed in a metal container with a tight fitting lid. Other waste is not placed in
this container. The closed container of ashes should be placed on a non-combustible floor or on
the ground, away from all combustible materials, pending final disposal. If the ashes are
disposed of by burial in soil or otherwise locally dispersed, they should be retained in the closed
container until all cinders have thoroughly cooled.




Low Burn
(air control closed) High Burn (air control open)
Use the air control to
change the burn rate.





ASHES

18 Operating Your Appliance
© Travis Industries 100-01275 4111122
Optional Blower Operation
The blower is available to assist the convection chamber in distributing heat to your home. The directions
below detail the options you have with the blower and the best method for operation.
The blower may be used to affect heat output (i.e., to reduce heat output, turn the blower down).
Route the power cord in a location where it will not come in contact with the appliance or become hot.
Re-Loading the Stove
Follow the directions below to minimize smoke spillage while re-loading the stove.
1 Open the air control all the way (push it in). Open the bypass (if applicable).
2 Open the door slightly. Let the airflow inside the firebox to stabilize before opening the doors fully.
3 Load wood onto the fire.
Overnight Burn
This stove is large enough to accommodate burn times up to eight hours. Follow the steps below to
achieve an overnight burn.
1 Move the air control to high burn and let the stove become hot (burn for approximately 15 minutes).
2 Load as much wood as possible. Use large pieces if possible.
3 Let the stove burn on high for 15 minutes to keep the stove hot, then turn the air control to low.
4 In the morning the stove should still be hot, with embers in the coal bed. Stir the coals and load
small pieces of wood to re-ignite the fire, if desired.
Differences if chimney height and draft may lower overall burn times.
Normal Operating Sounds
Creaks and Clicks:
The thick steel may creak or click when the stove heats up and cools down – this is
normal.
Blower Sounds:
The blower will make a slight “hum” as it pushes air through the stove.
Hint:
Make sure the leveling bolts on the legs are extended, preventing the hearth from
amplifying any vibrations.
OFF
Turn the dial all the way counter-
clockwise until it clicks off.
BLOWER
CONTROL













RUN
OFFSTART
HIGH
The high position is all the way counter-
clockwise, without clicking off.
BLOWER
CONTROL













LOW
Turn the dial all the
way clockwise.
BLOWER
CONTROL













RUN
OFFSTART
RUN
OFFSTART

Operating Your Appliance 19
© Travis Industries 100-01275 4111122
Hints for Burning
Get the appliance hot before adjusting to low burn
Use smaller pieces of wood during start-up and high burns to increase temperature
Use larger pieces of wood for overnight or sustained burns
Stack the wood tightly together to establish a longer burn
Leave a bed of ashes (13mm deep) to allow for longer burns
Be considerate of neighbors & the environment: burn dry wood only
Burn small, intense fires instead of large, slow burning fires when possible
Learn your appliance's operating characteristics to obtain optimum performance
Selecting Wood
Dry Wood is Key
Dry wood burns hot, emits less
smoke and creates less creosote.
Testing Wood Moisture
Split wood stored in a dry area will
be fully dry within a year. This
insures dry wood. If purchasing
wood for immediate use, test the
wood with a moisture meter. Some
experienced wood burners can
measure wood moisture by
knocking pieces together and
listening for a clear "knock" and not
a "thud".
Why Dry Wood is Key
Wet wood, when burned, must release water stored within the wood. This cools the fire, creates
creosote, and hampers a complete burn. Ask any experienced wood burner and he or she will agree: dry
wood is crucial to good performance.
Wood Cutting and Storage
Wet
Wood
Leads
To Leads
To
Dry
Wood
Leads
To Leads
To
Less
Heat More Heat
More Smoke
and Creostoe Less Smoke and Creostoe
Cut wood to length and
chop into quarters. Store the wood off the ground in a
covered area. Allow for airflow
around the wood to dry the wood.
Air Flow
Air Flow
Air Flow

20 Operating Your Appliance
© Travis Industries 100-01275 4111122
Troubleshooting
Problem Possible Cause
Smoke Enters Room During
Start-Up
Open the air control (pg. 17).
Cold Air Blockage - burn a piece of newspaper to
establish a draft.
If the flame is not getting enough air, a small crack in
the door is all that is needed.
Kindling Does Not Start - Fire
Smolders
Open the air control (pg. 17).
Not enough starter paper - use additional newspaper if
necessary.
If the flame is not getting enough air, a small crack in
the door is all that is needed.
Smoke Enters Room While Re-
Loading
Open the air control before opening the door (pg. 17).
Let the air stabilize before fully opening the door.
Then open the door approximately 1 inch. Let air go
into the firebox for a few seconds. Once the smoke
appears to be flowing up the chimney consistently,
open the door.
Insufficient Draft - Chimney height and outside
conditions can negatively affect draft. In these cases a
small amount of smoke may enter the home. Adding
more pipe or a draft-inducing cap may help.
Stove Does Not Burn Hot Enough Wood is Wet - see the section "Selecting Wood" on
page 19 for details on wood.
Make sure the air control is all the way open. Slide the
control back and forth to insure the control is not stuck.
Insufficient Draft - Chimney height and outside
conditions can negatively affect draft. In these cases
the fire may burn slowly. Adding more pipe or a draft-
inducing cap may help.
Blower Does Not Run Stove is Not Up to Temperature - This is normal. The
blower will come on when the stove is hot - usually 15
to 30 minutes.
Electricity is Cut to the Blower - Check the household
breaker or fuse to make sure it is operable.
Stove Does Not Burn Long
Enough
Depending upon wood, draft, and other factors, the
burn time may be shorter then stated. Make sure the
doors are sealing and not allowing air into the firebox -
See the section "Door and Glass Inspection" on page
22 for details.
Check the ash bed for coals. Often, coals are still
glowing under a slight bed of flyash. By raking these
into a pile you can re-start your stove quickly.
