Lopi Endeavor User manual

Endeavor (Aust)
(EPA 2020 Compliant)
Wood Stove
Owner's Manual
 Freestanding Stove
 Hearth-Stove Approved
Save these instructions
for future reference
SAFETY NOTICE:
If this appliance is not properly installed, a house fire
may result. For your safety, follow the installation
directions. Contact local building or fire officials about
restrictions and installation inspection requirements
in your area.
Dragon Wholesaling Pty. Ltd.
Unit 4/16 Lexington Drive
Bella Vista NSW
Australia 2153
 Copyright 2019,
Travis Industries, Inc.
$10.00
100-01517
6/12/2019
Tested by:
Australian Solid Fuel Testing
3 Garden Street, Morwell Vic 3840
Tested to: AS/NZS 4012/4013: 2014
Report Number: ASFT19027

2 Introduction
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Introduction
We welcome you as a new owner of a Lopi Endeavor wood-burning stove. In purchasing a Lopi
Endeavor you have joined the growing ranks of concerned individuals whose selection of an energy
system reflects both a concern for the environment and aesthetics. The Lopi Endeavor is one of the
finest appliances the world over. This manual will explain the installation, operation, and maintenance of
this appliance. Please familiarize yourself with the Owner's Manual before operating your appliance and
save the manual for future reference. Included are helpful hints and suggestions which will make the
installation and operation of your new appliance an easier and more enjoyable experience. We offer our
continual support and guidance to help you achieve the maximum benefit and enjoyment from your
appliance.
Important Information
No other Lopi Endeavor appliance has the same serial
number as yours. The serial number is stamped onto
the label on the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: Lopi Endeavor
Serial Number:
Purchase Date:
Purchased From:

Safety Precautions 3
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Introduction ...................................................... 2
Important Information ...................................... 2
Listing Label ..................................................... 4
Installation Options .......................................... 7
Features ............................................................ 7
Heating Specifications ..................................... 7
Dimensions ....................................................... 7
Emissions, Efficiency and Heat Output ......... 7
Packing List ...................................................... 8
Planning the Installation .................................. 8
Preparation for Installation ............................. 8
Floor Protection Requirements ...................... 8
Stove Placement Requirements ..................... 8
Clearances ........................................................ 9
Chimney Connector Requirements .............. 10
Chimney Requirements ................................. 11
Chimney Termination Requirements ........... 12
Outside Air Requirements ............................. 12
Standard Ceiling with a Factory Built Chimney ... 13
Cathedral Ceiling with a Factory Built Chimney .. 13
Exterior Factory Built Chimney ............................ 14
Hearth Stove Positive Connection ...................... 14
Interior or Exterior Masonry Chimney ................. 15
Safety Notice .................................................. 16
Before Your First Fire .................................... 16
Verify the Installation ........................................... 16
Curing the Paint .................................................. 16
Carbon Monoxide (CO) Emissions ...................... 16
Over-Firing the Stove .......................................... 16
Opening the Door ........................................... 17
Bypass Operation .......................................... 17
Before Starting a Fire ..................................... 18
Adjusting the Burn Rate ................................ 19
Approximate Air Control Settings ........................ 19
Understanding Your Heater’s Combustion
System ............................................................ 20
Burning Your Heater ...................................... 20
Ash Removal .................................................. 21
Ash Pan Removal ............................................... 2 1 
Optional Blower Operation ........................... 22
Re-Loading the Stove .................................... 22
Overnight Burn ............................................... 22
Normal Operating Sounds ............................ 22
Hints for Burning ........................................... 23
Selecting Wood .............................................. 23
Why Dry Wood is Key ......................................... 23
Wood Cutting and Storage .................................. 23
Do Not Burn List .................................................. 24
Troubleshooting ............................................. 25
Daily Maintenance (while stove is in use) ... 26
Remove Ash (if necessary) ................................. 26
Clean the Glass (if necessary) ............................ 26
Monthly Maintenance (while appliance is in
use) .................................................................. 27
Door and Glass Inspection .................................. 27
Door Adjustment ................................................. 27
Creosote - Formation and Need for Removal ..... 28
Yearly Maintenance ....................................... 28
Touch-Up Paint ................................................... 28
Firebrick and Baffle Inspection ............................ 28
Door Parts ....................................................... 29
Replacing the Glass ............................................ 29
Replacing the Door Gasket ................................. 29
Replacing the Door Handle ................................. 29
Firebox Parts .................................................. 30
Floor and Side Firebrick Removal & Replacement30
Air Tube Removal & Replacement ............... 31
Baffle Removal & Replacement .................... 32
Removal ............................................................... 32
Replacement ........................................................ 35

4 Safety Precautions
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Listing Label

Safety Precautions 5
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
The viewing door must be
closed and latched during
operation.
Smoke from this appliance may
active a smoke detector when
the door is open.
Never block free airflow through
the air vents on this appliance.
Gasoline or other flammable
liquids must never be used to
start the fire or "Freshen Up" the
fire. Do not store or use
gasoline or other flammable
liquids in the vicinity of this
appliance.
This appliance is designed and
approved for the burning of cord
wood only. Do not attempt to
burn any other type of fuel other
than cord wood in this
appliance, it will void all
warranties and safety listings.
Ashes must be disposed in a
metal container with a tight lid
and placed on a non-
combustible surface well away
from the home or structure.
Do not touch the appliance while
it is hot and educate all children
of the danger of a high-
temperature appliance. Young
children should be supervised
when they are in the same room
as the appliance.
Keep furniture, drapes, curtains,
wood, paper, and other
combustibles a minimum of 36"
away from the front of the
appliance.
This appliance must be properly
installed to prevent the
possibility of a house fire. The
instructions must be strictly
adhered to. Do not use
makeshift methods or
compromise in the installation.
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this appliance as well.
Inspect the chimney connector
and chimney at least twice
monthly and clean if necessary.
Creosote may build up and
cause a house fire.
Do not connect this appliance to
any chimney serving another
appliance.
This appliance must be
connected to a listed high
temperature (UL 103 HT)
residential type chimney or an
approved masonry chimney with
a standard clay tile, or stainless
steel liner.
Gas
ASHES
36"
Ok
Type
HT Clay
Liner

6 Safety Precautions
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Do not place clothing or other
flammable items on or near this
appliance.
Never try to repair or replace
any part of this appliance unless
instructions are given in this
manual. All other work must be
done by a trained technician.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney to
install this appliance.
This wood heater has a
manufacturer-set minimum low
burn rate that must not be
altered. It is against federal
regulations to alter this setting or
otherwise operate this wood
heater in a manner inconsistent
with operating instructions in this
manual.
Allow the appliance to cool
before carrying out any
maintenance or cleaning.
Over-firing the appliance may
cause a house fire. If a unit or
chimney connector glows, you
are over-firing.
Maintain the door and glass seal
and keep them in good
condition.
Do not operate this heater with
broken or missing glass.
Avoid placing wood against the
glass when loading. Do not
slam the door or strike the glass.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Travis Industries, Inc. grants
no warranty, implied or
stated, for the installation or
maintenance of your
appliance, and assumes no
responsibility of any
consequential damage(s).
Smoke and CO Detectors: Make sure your home has a working smoke detector, especially near any bedrooms. We
recommend having a smoke and/or CO detector in the same room as the wood heater for additional safety.
Proposition 65 Warning: Fuels used in gas, woodburning or oil fired appliances, and the products of combustion of such
fuels, contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6
Travis Wood Burning Fireplaces, Stoves and Inserts are protected by one or more of the following patents; U.S. 9,170,025
4,665,889 as well as other U.S. and Foreign Patents pending.



This
Manual

7 Features and Specifications
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Installation Options
 Freestanding
 Freestanding Hearth Stove
Features
 2.5 Cubic Foot Firebox Volume (.071 cubic meters)
 Single Operating Control
 Accepts Logs Up to 18" Long (457mm)
 Steel Plate Construction (5/16" & 3/16") (8mm &
10mm)
 Heavy Duty Refractory Firebrick
 Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square meters)* Up to 250
Maximum Burn Time Up to 10 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
Figure 1
Emissions, Efficiency and Heat Output
 Appliance Emission Factor burning hardwood 1.1g/kg
 Overall Average Efficiency burning hardwood 66%
 Maximum Average Heat Output burning hardwood 11.1kw
23-1/2”
(597mm) 24”
(610mm)
6” (152mm) Dia. 1-3/4” (44mm)
5-3/4
”
(146mm)
Note:
Measure side, corner, and back
clearances from the stove top.
Measure front clearances from
the stove face
Height:
32” (813mm)
Weight:
448 lbs. (203 Kilos)

8 Stove Installation (for qualified installers only)
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
SAFETY NOTICE:
Please read this entire manual before you install and use your new room heater. Failure to
follow instructions may result in property damage, bodily injury, or even death. Contact local
building or fire officials about restrictions and installation inspection requirements in your area.
Packing List
 Wood moisture meter
 Bypass tool
Planning the Installation
We suggest that you have an authorized Travis Industries dealer install your stove. If you install the
stove yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this stove and notify your
insurance company before proceeding with installation.
The location of your wood heater in your home will decide how affectively the heat produced will spread
throughout your house. Attention to the home design with consideration of natural convection and air
circulation should be taken into account when choosing the placement of your heater within the home.
Preparation for Installation
 Check for damage to the exterior of the stove (dents should be reported, scratches can be fixed by
applying touch up paint).
 Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
The stove can be lightened by removing the firebricks and baffle (page 30) - replace before operation.
Floor Protection Requirements
 Stove must be placed on the Travis Industries legs.
 Floor protection must extend to the sides, rear, and front of the stove (see “Clearances” below for
minimum floor protection).
 Floor protection must be min 12mm (compressed board). The Thermal resistivity of the floor
protector is 0.08m².K/W for 6mm thick sheets.
Stove Placement Requirements
Clearances may be reduced by methods specified in NFPA 211, listed wall shields, pipe shields, or
other means approved by local building or fire officials.
 Stove must be placed so that no combustibles are within, or can swing within (e.g. drapes, doors), 36"
(914mm) of the front of the stove
 If the stove is placed in a location where the ceiling height is less than 7' (2134mm), it must follow the
requirements in the section “Alcove Installation Requirements”
 Must maintain the clearances to combustibles listed below (drywall, furniture, etc.):

Stove Installation (for qualified installers only) 9
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Clearances
 The following clearances must be met.
Clearance Requirements: With 8” solid painted
casing heat shield
With 8” Decromesh
Casing heat shield
A Sidewall to stovetop 500mm 500mm
B Back wall to stovetop 225mm 200mm
C Corner wall to stovetop 150mm 225mm
D Floor protection front 350mm 350mm
E Floor protection side 108mm 108mm
F Floor protection back
*Minimum total hearth depth
163mm
1110mm
163mm
1110mm
AUSTRALIAN FLUE KIT REQUIREMENTS:
The above clearances are in accordance to the following:
The heater is to be installed with a 150mm/6” Stainless Steel triple skin (default) flue kit (fitted with heat
shields see below) which conforms to the requirements of the joint AS/NZS 2918:2018 3.3.2 Standard,
Appendix, with respect to the rear wall, side wall, floor and ceiling surface temperatures, when tested in
the positions shown.
Heat Shield Options:
1. 200mm/8” Decorative Mesh, up into the drop box, with the 1
st length (900mm) to have a solid
back.
2. 200mm/8" Solid painted casing.

10 Stove Installation (for qualified installers only)
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Chimney Connector Requirements
 Chimney connector is required from the flue collar of the stove to the factory-built chimney or
masonry chimney.
 The chimney connector must be 6” diameter and a minimum 24 gauge black steel, or one of the
reduced-clearance connectors listed on page 8.
NOTE: Aluminum or galvanized steel is not allowed – these materials cannot withstand the flue
temperatures and may give off toxic fumes when heated.
NOTE: Standard residential installations may use single-wall connector (Mobile-Homes may not).
 The chimney connector may not pass through a ceiling, attic, roof, closet, or any other concealed
space (use listed UL 103 HT chimney – see “Chimney Requirements for details). DO NOT USE
CONNECTOR PIPE AS CHIMNEY.
 IN CANADA: Where passage through a wall or partition of combustible construction is desired, the
installation shall conform to CAN/CSA-B365, Installation Code for Solid-Fuel-Burning Appliances and
Equipment.
 The chimney connector should be as short and direct as possible. No more than 180o of elbows may
be used for the entire system (connector and chimney).. Horizontal runs should slope upwards 1/4”
per foot and be a maximum 36” long.
 The chimney connector must be installed with the crimped end pointing downwards. This prevents
creosote from leaking to the exterior of the pipe.
 The chimney connector must be fastened to the stove and each adjoining section (and chimney).
 Standard residential installations may use single-wall connector.
 Standard residential installations with reduced clearance connector may use the clearance
determined by the manufacturer of the connector for the connector to wall clearance or the clearance
listed in this manual. Offsets must be used to maintain the stove to wall clearance. Mobile homes
must use the clearances listed in this manual under "Additional Requirements for Mobile Home
Installations".

Stove Installation (for qualified installers only) 11
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Chimney Requirements
 DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
 DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK
UNLESS SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS
 UL 103 HT Chimney must be used from the first ceiling or floor penetration to the chimney cap.
 Use 152mm (6") diameter type UL 103 HT chimney from one manufacturer (do not mix brands) or
code approved masonry chimney with a flue liner.
 Chimney must be fastened to each adjoining section.
 Follow the chimney manufacturer's clearances and requirements.
 Use the chimney manufacturer's fire stops, attic guards, roof supports, and flashings when passing
through a ceiling.
 No more than 180o of elbows may be used for the entire system (connector and chimney).
NOTE: Additional elbows may be allowed if draft is sufficient. Whenever elbows are used the draft is
adversely affected. Additional chimney height may be required to boost draft.
(a) Min. System Height 4.5 meters (15’)
Max. System Height 10.058 meters (33’)
(b) Roof Penetration and Termination (see
chimney manufacturer’s requirements)
(c) Chimney Sections
(d) Ceiling Penetration (see chimney
manufacturer’s requirements)
(e) Minimum air space to combustibles (see
chimney manufacturer’s requirements –
typically 51mm (2”)
(f) Connector – see “Chimney Connector” on the
previous page.
Figure 2
Drafting
Performance
Draft is the force which moves air from the appliance up through the chimney. The amount of
draft in your chimney depends on the length of the chimney, local geography, nearby
obstructions and other factors. Too much draft may cause excessive temperatures in the
appliance and may damage the heater. Inadequate draft may cause backpuffing into the
room and `plugging' of the chimney. Inadequate draft will cause the appliance to leak smoke
into the room through appliance and chimney connector joints. An uncontrollable burn or
excessive temperature indicates excessive draft.
a
b
c
de
f
f
b

12 Stove Installation (for qualified installers only)
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Chimney Termination Requirements
 Must have an approved cap (to prevent water from entering)
 Must not be located where it will become plugged by snow or other material
 Must terminate at least 3.28' (1000mm) above the roof and at least 2' (610mm) above any portion of
the roof within 10' (3.04M) (see Figure 3).
Figure 3
Outside Air Requirements
 Required for mobile homes & in certain localities (check with building officials).
 Must not be drawn from an enclosed space (garage, unventilated crawl space). May be drawn from
ventilated crawl space (a) or exterior of home (d). Must have suitable rodent/debris screen and rain
protection (hood).
 Requires the optional outside air kit (sku# 99200139) – see below.
 Air duct maximum length is 15’ (4.57M) with a minimum cross section of 16 square inches
(10323mm) or 6’ (1.83M) with a minimum cross section of 7 square inches (4517mm).
Figure 4








Min. 3’ (914mm)
Min. 2’ (610mm)
10’ (3.04M)
Min. 3’ (914mm)
10’ (3.04M)
Min. 2’ (610mm)
Outside Air
Connector
O
utside air entrance must be placed so
i
t does not become blocked by snow.
Min. 3.28’ (1000mm)
Min. 3.28’ (1000mm)
Min. 2’ (610mm)
Min. 2’ (610mm)
10’ (3.04M)
10’ (3.04M)

Stove Installation (for qualified installers only) 13
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Standard Ceiling
with a Factory
Built Chimney
Figure 5
Cathedral Ceiling
with a Factory
Built Chimney
Figure 6
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)
Chimney Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions - usually
2" (51mm))
Chimney Connector Sections
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm collar
and flashing are required
(some require a radiation
shield).
}
}
Minimum 15'
Maximum 33'
(10.06M)
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Follow the chimney
manufacturer's instructions
and clearances for floor
penetrations. A ceiling
support is required, an attic
insulation shield is required
where insulation is present
.
Insulation
(4.57M)
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)
Chimney Sections
Minimum Air Space to
Combustibles (See Chimney
Manufacturer's Instructions -
usually 2" (51mm))
Follow the chimney
manufacturer's instructions
and clearances for roof
penetrations. A storm
collar, flashing, and
cathedral-style chimney
support are required
(some require a radiation
shield).
}
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Floor Protection
(See the section "Floor
Protection Requirements"
for more details)
Chimney
Connector
Sections
Minimum 15'
Maximum 33'
(10.06M)
(4.57M)

14 Stove Installation (for qualified installers only)
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Exterior Factory
Built Chimney
NOTE:
Exterior chimneys are
subject to greater
moisture and creosote
accumulation due to the
lower temperatures. An
insulated chase will
reduce these
accumulations (the
proper clearances to the
chimney must be
maintained).
Figure 7
Hearth Stove
Positive
Connection
NOTE:
Most factory-built
chimney manufacturers
make stainless steel
chimney liners, either
flexible or rigid. This
provides a wide variety
of installation options.
Make sure to follow the
manufacturer's
instructions for
installation and support.
Figure 8
Chimney Cap
(See the section "Chimney
Termination Requirements"
for more details)
Chimney Sections
Minimum Air Space to
Combustibles (See
Chimney Manufacturer's
Instructions)
Chimney Connector
Sections
Follow the chimney
manufacturer's
instructions and
clearances for roof
penetrations. A sto rm
collar and flashing are
required (some
require a radiation
shield).
}
Stove Clearances
(See the section "Stove
Placement Requirements"
for more details)
Follow the chimney
manufacturer's
instructions and
clearances for wall
penetrations. A
wall radiation shield
(thimble) is
required.
Optional
insulated
chase
Wall Bands
and
Supports
Insulated Tee
(with cleanout )
Min. 18"
(457mm)
clearance to
ceiling
Floor Protection
(See "Floor
Protection
Requirements"
for details)
Minimum 15' (4.57M)
Maximum 33' (10.05M)
Remove damper
or wire it open
Airtight Insulated
Clean-Out
Min. 36"
(915mm)
Combustible
Mantle
NOTE: The entire fireplace and
chimney must be clean, undamaged,
and meet all local building codes
(UBC, etc.). Damage must be
repaired prior to installation. The
chimney must be 15' (4.57M)
Floor Protection
(See the section
"Floor Protection
Requirements"
for more details)
See the section
"Stove Placement
Requirements" for
minimum clearances
required.
The liner must be
stainless steel connector
or flexible vent. Follow
the liner manufacturer's
instructions for installation
and support.
Cap and flashing
prevents water from
entering
to 33' (10.06M) tall.

Stove Installation (for qualified installers only) 15
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Interior or Exterior
Masonry Chimney
NOTE:
This type of installation is
not allowed in Canada.
NOTE:
This type of installation
requires a UBC approved
masonry connector or a
factory built (U.L. Listed)
wall thimble.
Figure 9
Make sure the
clean-out seals in
place.
Clay Liner
See the section "Stove
Placement Requirements" for
minimum clearances required.
Min. 18" (458mm)
clearance
to ceiling This type of
installation requires
a UBC approved
masonry connector
or other method
approved by the
NFPA 211 standard.
Chimney connector sections
NOTE: The chimney must have a
clay tile liner. If it does not, the
installation must use a positive
connection (full reline). The
entire fireplace and chimney must
be clean, undamaged, and meet
all local building codes (UBC,
etc.). Damage must be repaired
prior to installation. The chimney
must be 15' (4.57M) to 33' (10.06M) tall.
See the section
"Floor Protection
Requirements"

16 Operating Your Appliance
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Safety Notice
If this appliance is not properly installed, a house fire may result. For your safety, follow the installation
directions. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
Read and follow all of the warnings on pages 4 and 5 of this manual.
Do not operate this strove with the ash pan open. A fire will result.
Before Your First Fire
Verify the Installation
Before starting the stove, verify that the stove is properly installed and all of the requirements in this
manual have been followed.
Keep all flammable materials 36" away from the front of the stove (drapes, furniture, clothing, etc.).
Curing the Paint
Follow the steps below to cure the paint (first fire):
a) Open doors and windows in the room to ventilate the heater during the
curing process.
b) Vacate the room. The fumes from the initial heating process are non-toxic
but may be unpleasant.
c) Slowly bring the heater to a medium burn (400°F/204°C) for 45 minutes.
Then increase the burn temperature to a hot burn (600°F/315°C) for an
additional 45 minutes. This will cure the paint.
Door Gasket - The door gasket might adhere to the paint on the front of the
heater. Leave the door slightly ajar for the first fire and be careful when
opening the door after the first fire.
Carbon Monoxide (CO) Emissions
Smoke from wood heaters contain CO. This gas is an indication of incomplete combustion and is
detrimental to the environment and to your health. The more visible the smoke, the higher the CO levels.
Burning dry wood is the most significant step you can take to reduce CO emissions. It is also important to
understand the combustion process so you can burn your heater efficiently. Read the manual thoroughly
so that you can operate your heater in the most efficient and clean manner possible.
Over-Firing the Stove
DO NOT OVERFIRE THIS HEATER: Attempts to achieve heat output rates that exceed heater design
specifications can result in permanent damage to the heater.
This stove was designed to operate at a high temperature. But due to differences in vent configuration,
fuel, and draft, this appliance can be operated at an excessive temperature. If the stove top or other area
starts to glow red, you are over-firing the stove. Shut the air control down to low and allow the stove to
cool before proceeding.
Over-firing may lead to damage of plated surfaces. If you are uncertain of over-firing conditions, we
suggest placing a stove thermometer (e.g. Rutland® Model 710) directly over the door on the stove top -
temperatures exceeding 800° are generally considered over-firing and will void the warranty.








2 to 4 hours

Operating Your Appliance 17
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Opening the Door
The door becomes hot during use. Use a glove to open the door if the handle is hot.
To prevent smoke from entering the room, open the air control before opening the door. You can also
open the door a small amount and let air enter the firebox.
Bypass Operation
The bypass controls the flow of smoke inside the heater. When pulled out, smoke goes directly up the
flue, creating more draft. When pushed in, the smoke goes around the baffle, utilizing the secondary
combustion and making the heater more efficient.
 When starting or re-loading, pull the bypass out.
 During normal operation, push the bypass in.
Lift the door
h
andle.
Swing
the door
open.
U
se t
h
e
i
nc
l
u
d
e
d
pu
ll
too
l
to operate the bypass rod
Bypass Pushed In
Used for normal operation
Bypass Pulled Out
Used for starting and re-loading

18 Operating Your Appliance
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Before Starting a Fire
 Make sure the air control is pulled out. If additional air is needed, open the door 1/4" during the first
five minutes of start-up.
Do not open the ash pan when the stove is lit. Fire will result.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start
or "freshen up" a fire in this stove. Keep all such liquids well away from the stove while it is in use.
DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. Do not place such fuel
within space heater installation clearances or within the space required for charging and ash removal.
If using a firestarter, use only products specifically designed for stoves - follow the manufacturer's
instructions carefully.
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT
MAY CAUSE SKIN BURNS.
If the smoke does not pass up the chimney, ball up one sheet of newspaper, place it in the center of the
firebox and light it. This should start the chimney drafting (this eliminates "cold air blockage").
Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning
rapidly, place a few larger pieces of wood onto the fire.

Operating Your Appliance 19
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Adjusting the Burn Rate
Use the air control slider to control the burn rate of the stove. See the illustration below for details.
Approximate Air Control Settings
Overnight Burn Fully in to 6.35mm open
Medium Burn 6.35mm to fully open
High Burn Fully open (pulled out)
The air control becomes hot during operation - use gloves or a tool to prevent burns.
The air control may take several minutes to influence the burn rate. When making adjustments, you
may wish to let the stove burn for 10 minutes to gauge performance.
Use the air control to
change the burn rate
High Burn
(air control open)
Low Burn
(air control closed)

20 Operating Your Appliance
© Travis Industries 6/12/2019 - 1517 Endeavor (AUST)
Understanding Your Heater’s Combustion System
This heater uses a dual combustion system detailed below:
Primary Combustion: This is the combustion (fire) that takes place directly on the wood. Primary combustion
determines how fast the fire burns. Air for primary combustion is supplied through the air control. When you
adjust the air control you control the amount of air that reaches the fire and creates primary combustion. The air
control supplies air to the air wash (the air holes above the door opening – used to help clean the glass) and
through the pilot orifice (center bottom of the door opening). By using the air control, and supplying air through
these two openings, you control primary combustion.
Secondary Combustion: This is the combustion (fire) that does not contact the wood. Secondary combustion
burns the visible emissions or smoke that is not consumed during primary combustion. During some phases of
combustion you will see secondary combustion. It appears as a glowing flame at the top of the firebox. Air for
secondary combustion is supplied by the air tubes at the top of the firebox.
Items to Consider:
 During medium and high burn rates the stove will manage secondary and primary combustion on its own.
When the heater is set to a low burn rate more care is needed to ensure the secondary combustion system
works properly. Make sure the stove is hot and a good coal bed is established before adjusting your heater to
low burn.
 Understanding the combustion system in this heater will help minimize the visible emissions this heater
releases into the environment. The primary pilot orifice at the center bottom of the door opening is designed to
help the secondary combustion at low burn settings. The pilot provides a small amount of air that burns up
through the fuel load providing the heat and flame needed for the secondary system to ignite. The air tubes
under the baffle need to remain ignited for low burns to be effective.
 As you load your heater for a low burn, take care in placing the wood. This will affect how well your
secondary system works as the wood is consumed. Do not block the pilot orifice. Stack wood so the pilot air
can burn its way up between the pieces, helping your heater burn effectively throughout the low fire. This will
reduce the visible emissions your heater produces and increase the amount of heat you get from the wood. If
you are unsure how well your heater is burning look at the chimney cap to monitor visible emissions.
Burning Your Heater
Starting a Fire: There are many ways to start a fire and you will become adept as you become familiar with the
way your heater burns. Before you start, make sure your burn rate setting (air control) is all the way open and the
by-pass (if equipped) is open. Starting a wood appliance can produce a lot of smoke. To reduce the smoke when
starting your fire the top down method described here was found to have the cleanest starts. Stack four or five
layers of medium sized kindling 1 to 2” in diameter in a tic tac toe pattern, three to four pieces per layer with about
½” (12.7mm) to 1” (25.4mm) spacing. On top of your kindling stack place crumpled newspaper and a nest of
pencil sized kindling. Light the paper and small kindling on top and let it burn down through your layers of kindling.
With this method you should be able to close the door about two to three minutes after lighting, if the fire starts to
die out reopen the door and leave it cracked until the fire takes off. Never leave your heater unattended if the door
is not latched shut. Three to five minutes after closing the door you should be able to shut the by-pass, again if
the fire starts to die out open the bypass until the fire is established and stays lit. Reload the unit with regular cord
wood when the kindling pile has burned about three quarters of the way through. Put enough wood in to establish
a good coal bed, five to seven pieces. The presence of a hot coal bed is critical to good combustion. We cannot
overstate the importance of a hot coal bed before slowing your burn rate down. We recommend burning this first
full load of cord wood completely through at the high burn rate to get your heater up to temperature and to
establish a coal bed before reloading and slowing the burn rate.
Reloading: When reloading a hot heater set the burn rate on high for at least 15 min before slowing it down.
Low Burn: If preparing for an overnight or low burn a longer heat up period may be necessary. Reload the
heater full of wood making sure there are air gaps between the wood pieces so the pilot air can burn up through
the middle load keeping the secondary combustion system hot and active throughout the burn. After loading, burn
the heater on high for at least 15 minutes before setting the air control to low. Excessive creosote buildup (or
sooting) in the heater at the end of a low burn signifies that the heater was not hot enough and the wood load was
not burned long enough on high after loading before shutting down the air control.
