Lorex SG5550 User manual

FORMOREINFORMATION
Before operating thesystem,please readthismanual
thoroughly andretainit forfuture reference.
Thisproductbroadcastsoverpublicairwavesandits
video andaudio signalsmaybeinterceptedwithout
yourconsent.
2.4GHz1.8 ColorTFTLCD Monitor
With Wireless Camera
SG5550
PORTABLEHOMEVIDEO
SECURITYSYSTEM

ExplanationoftwoSymbols
Thelightningflashwitharrowheadsymbol,withinan
equilateraltriangle,isintendedtoalerttheusertothe
presence ofuninsulated"dangerousvoltage withinthe
product'senclosurethatmaybeofsufficientmagnitudeto
constituteariskof electricshocktopersons.
Theexclamationpointwithinanequilateraltriangleis
intendedtoalerttheusertothepresence of important
operatingandmaintenance(servicing)instructionsin
theliteratureaccompanyingtheappliance.
THEGRAPHIC SYMBOLSWITHSUPPLEMENTALMARKING AREON
THEBOTTOM OF THESYSTEM.
!
WARNING:Topreventfireorshockhazard, donotexposethisunitto
rain, water, orwetlocations.Donotinsertanymetallicobject
throughtheventilationgrills.
FCC CLASS BNOTICE
Note:
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsForaClass
Bdigitaldevice, pursuanttoPart15of theFCCRules.Theselimitsare
designedtoprovidereasonableprotectionagainstharmfulinterference ina
residential installation.Thisequipmentgenerates, usesandcanradiateradio
frequencyenergyand,ifnotinstalledand usedinaccordance withthe
instruction, maycauseharmfulinterference toradiocommunications.
However,thereisnoguarantee thatinterference will notoccur inaparticular
installation. Ifthisequipmentdoescauseharmfulinterference toradioor
televisionreception,(whichcanbedeterminedbyturningtheequipmentoff
and on),theuserisencouragedtotrytocorrecttheinterference byoneormore
ofthefollowingmeasures:
CAUTION
RISKOFELECTRICSHOCK.DO NOTOPEN.
CAUTION:TOREDUCETHERISKOFELECTRICSHOCK, DONOTREMOVE
COVER(ORBACK). NOUSER-SERVICEABLEPARTSINSIDE.REFER
SERVICINGTOQUALIFIEDSERVICEPERSONNEL.
!
•Reorientorrelocatethereceivingantenna
•Increasetheseparationbetweenthemonitorandthecamera.
•Connecttheequipmentintoanoutletonacircuit differentfromthat towhich
otherdevicesmaybeconnected.
•Consultthedealeroranexperiencedradioortelevisiontechnicianforhelp.
•Pleasereviewthetroubleshootingsectionof thismanual
i

SAFETYINSTRUCTIONS
IMPORTANTSAFEGUARDS
Allthe safetyand operating instructionsshouldberead beforethe
applianceisoperated andretained forfuturereference.
1. HEEDWARNINGS -All warningson theapplianceand inthe operating
instructionsshouldbeadheredto.
2.FOLLOW INSTRUCTIONS -Alloperatinginstructionsshouldbe
followed.
3. WATERAND MOISTURE -Do not usethisvideoproductnearwater
forexample,abathtub, washbowl, kitchensink,laundry tubor
swimming pool, orin awet basement.
4.POWERSOURCES -Thisproduct shouldbe operated onlyfromthetype
of powersourceindicatedonthe markinglabel.
5.OVERLOADING -Donotoverloadoutletsand extension cords, which
canresult inariskoffireorelectricshock.
6.SERVICING -Do not attempttoservicethisproductyourself.Openingor
removingcoversmayexposeyoutodangerousvoltage orotherhazards.
Referallservicing orrepairstoqualifiedservicepersonnel.
7. DAMAGEREQUIRINGSERVICE -Unplugthisproductfromthewall
outletand referservicingorrepairstoqualified servicepersonnel under
thefollowing conditions:
a.Whenthepowersupplycordorplugisdamaged.
b.Ifliquidhasbeen spilled orobjectshavefallenintotheproduct.
c.Ifthe producthasbeenexposed torainorwater.
d.If the productdoesnotoperatenormallybyfollowing theoperating
instructions.Adjust onlythosecontrolsthatarecoveredbythe
operating instructions.
e.If the producthasbeen dropped orthe cabinethasbeen damaged.
f. Whenthe productexhibitsadistinctchangein performance.
8. REPLACEMENT PARTS -Whenreplacementpartsarerequired,be
suretheservicetechnicianhasused replacement partsthatare
specifiedbythemanufacturerorhavethesamecharacteristicsasthe
originalpart.Unauthorized substitutionsmayresultinfire,electric
shock, orotherhazards.
9.SAFETYCHECK -Uponcompletionof anyserviceorrepairstothis
videoproduct,asktheservicetechniciantoperformsafetychecksto
determine ifthe videoproductisinproperoperatingcondition.
10. An appliance andcartcombinationshouldbemovedwithcare.
Donotplacethisequipmenton an unstablecart, stand, ortable.The
equipment mayfall,causingseriousinjury toachildoradult, and
seriousdamage totheequipment. Wallorshelfmountingshould
followthe manufacturer'sinstructionsand shouldbedone with
amountingkitapprovedbythemanufacturer.
ii

TABLEOF CONTENTS
iii
INTRODUCTION&FEATURES………………………………………
SYSTEMINCLUDES…………………………………………………..
CONTROLSAND FUNCTIONS
MonitorControls FrontPanel...….……………………..……...
MonitorControls Side Panels.....................……….….....……
CameraControls …………………………………………………..
DockingStationControls ………………………………………….
INSTALLATION
Camera......................................................……………….…....
Monitor.....................................................................………......
SYSTEMOPERATION
Additional cameraconnection…………………………………….
AlarmAlert …………………………………………………………
Auto&ManualViewing Options………………………………….
AutoScanning………………………………………………………
SelectableDwell Settings…………………………………………
Connecting TheMonitorToAVCR ……...………………..…….
OPTIONALACCESSORIES..........................................................
TROUBLESHOOTING..............................................………..…...
TECHNICALSPECIFICATIONS....................................................
CARE&MAINTENANCE……………………………..……………….
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
14
15
16
PAGE

INTRODUCTION:
Thankyou forpurchasing the2.4GHzWireless 1.8”LCDColorVideo
System.Thisisan idealsolution formonitoring yourchild, business or
home.ThepackagecontainsaportableLCD monitor,a2.4GHz
wirelesscolorcamerawithNightVision capability, and apower
chargingdockingstation forthemonitor.
The systemisexpandableupto4cameras(additionalcamerassold
separately) withthe convenienceofauto-sequencing between camera
locations.Usethe Listen-inAudiofeaturetopickup sound withina
specificlocation.Avoidingthe hassleof runningwires, thissystemis
easytoinstalland operateforyourimmediatesecurityapplications.
The RCAaudio/videooutputsontheDocking Station allowyou toview
videoon alargerscreen,orconnecttoaVCR forrecording purposes.
Tolearnmoreaboutthis2.4GHzWireless 1.8”LCDColorVideo
Systemandourcompleterangeof accessory products,pleasevisitour
websiteat:
FEATURES:
•Portable2.4GHzColorwireless camera
•Portable2.4GHzreceiverhandsetwithabuiltin1.8”TFT fullcolordisplay
•IncludesChargingDockingStationwithA/VOut
•4channelselection
•BuiltinCDSsensortoturnonIRLEDatnighttime
•Upto300feet wireless transmission
•Flexible movecamera&monitorfromroomtoroom
•Listen-inaudio
•Autoscanning uptofourcameras
•Cameraand monitorwithACorbatteryoption
•CompatiblewithallLorex2.4GHzwireless devices
•Connect uptofourcameras(additionalcamerassoldseparately)
1

SYSTEMINCLUDES:
1.8 LCD screen –
2.4GHzColorMonitor
2.4GHzColorWireless Camera
with 8Infra-redemitters
Owner’sManual
Also includes:
1 6VDC 300mAAdapter(Camera)
withbatteryoption(4 “AA”, notincluded)
1 6VDC 800mAAdapter(Monitor)
withbatteryoption(4 “AA”, notincluded)
1 RCAAudio/Video Cables
Mounting hardwareforCamera
Windowdecals
2
DockingStation/Charger
forMonitor

MONITORCONTROLS –FRONTPANEL
.
.
1.2.4GHzAntenna -Highgaindipoleantenna receivesaudioandvideo
signalfromthecamera.
2.LCD -1.8”ColorScreen.
3. ChannelIndicator -ShowswhichChannel themonitorissetto(1-4).
Channel1isrepresented onthe left side-Channel 4on the right side.
4. ChannelSelector- Manuallyswitchesbetween channels1-4.
5. Display On/Off -Turnsthe LCD ScreenDisplayOn/Off onthe monitor.
Note:pressing thisbutton turnsthemonitortoStandbymode.Videowill
automaticallyreappearintheeventof an Alarm,and AudioremainsON.
6. Auto Button -Initiatesautomaticrotationbetween channels1-4.
Press thisbutton againtoterminateAutomode.
7. AutoIndicator -Illuminateswhen thesystemisinAutomode.
8. Alarm On/Off -Press for2sectosettheAlarmmodeOn/Off.Formore
information on the Alarmfeature,pleaserefertopage10.
9. Alarm /Low BatteryIndicator -Illuminateswhen Alarm modeisset,and
blinksslowlywhen the Batterypowerislow.
10.Speaker -Emitssound fromthe cameralocation.
3
1
3
4
5
6
7
2
9
8
10

MONITORCONTROLS –SIDEPANELS
1. AudioSensitivity -Setsthe sensitivitylevelforthealarmAudio
triggering(refertopage10 formoreinformation).
2.ON/OFFSwitch -Switchesthe poweron themonitorONorOFF.
3. DC InputJack -Connecttothesupplied 6VDC 800 mAACadapter.
Note:IfPowerisconnected viatheDockingStation,thisinputisnot
requiredasthemonitorwilldrawPowerfromtheDocking Station.
4. BeltClip/Stand -intheuprightposition,thisclipservesasabelt clip
forconvenientportability.You can alsolowerthispiecetoserveasa
Standforthe monitor(withouttheDocking Station).
5.Battery Compartment –Requires4 “AA”Batteries(notincluded).
6. BrightnessControl -Allowsyou toadjustthebrightnessofthe picture.
7.VolumeControl Turnthisdialtoadjust thevolumeon the monitor.
4
4
1
2
3
6
7
5

CAMERACONTROLS
1. CDSSensor -Turnson the IRemittersin lowlightconditions.
2.InfraredLED’s-Enhancethepicturequalityinlowlight conditions.
3.Lens -ColorCMOSImage Sensor.
4. Microphone -Built-incondensermicrophoneprovideslisten-in audio
capabilityfromcameratomonitor.
5.ON/OFFPower Button -Controlspowertothe camera.
6. ChannelSelectorSwitch -Slide switchsetthecamera’schannel(1-4)
7. DC INJack -Connectstothe 6VDC(300mA)adapter.
8.Battery Compartment(notshown) -Requires4 “AA”Batteries
(notincluded).
5
1
2
3
4
5
6
7
8

DOCKING STATIONCONTROLS
1. Cradle -Carefullyslidethemonitordownwardintothedocking cradle.
Themonitornowhastheadded featureofAudio/Video Out for
connection toalargermonitor(suchasaTV) oraVCR.
2. ChargeIndicator -Illuminateswhen bothPowerandtheMonitorare
connected.The DockingStationwillrechargethe batteriesinthe
monitorprovided that youhaveinserted Rechargeablebatteries.
(PleaserefertoPage 8forrechargingtime.)
3.Videoand AudioOutputJacks -RCAjacksforA/VOutput
connection toanothervideo source(using the supplied A/Vcable).
4. DC INJack -Connectstothe 6VDC800mAadapter,the sameone
used forthe monitor.
6
1
3
2
4

CAMERAINSTALLATION
Option 1:You can placethe cameraonadeskoranyleveledsurface.
Selectalocationthatisnearan ACoutletand withinreachofthe AC
adaptercord.Youcanadjust the cameraheadverticallytothebest viewing
angle.
Option 2:Forwallmounting,usethesupplied mountingbracket and
screws.First, attachthestand tothe wallwhereyou wanttoinstall the
cameraanddrivethe 2supplied screwsintothe wall.Attachthecamerato
the standandfirmlytightentheswivel.Adjust the cameratothebest
viewing angle.
Power-Up theCamera:Oncethe cameraismountedin place,connectthe
supplied 6VDC300 mAtotheDC INjack attheside ofthecamera, and
plug itintoanelectricaloutlet.
You alsohavetheoptionof using4 “AA”alkaline batteriesinyourcamera.
Toutilizethebatteryoption,followthesesteps:
1.Ensurethepowerbutton onthe cameraisdepressedtoOFF.
2. Loosen thescrewat thebackof thecameraandremovethecover.
3.Insert 4 “AA”batteries(notincluded)intothe battery compartment while
noting the polarity(+/ -symbols).
Warning:topreventdamageto theunit,ensure thebatteriesare
alignedproperlyandbattery typesare notmixed
4. Closethecompartment byre-screwing it, and turnthecamera “ON”.
7
WALL
DESK
Ensurethepowerswitchonthemonitorandcameraaresetto
theOFFpositionbeforeproceedingwiththefollowing steps.
NOTE
OPTION#1 OPTION#2

BATTERYCASE&COMPARTMENT
Removethebatterycasecoverbyunscrewing thebolt atthe back of the
monitor.Thissystemrequires4 “AA”sizebatteries(notincluded).
Yourwireless monitorhasACorbattery option. Whenusing theACoption
withrechargeablebatteries,yourmonitorwillautomaticallyswitch
tobackupbatteryfeatureduring apoweroutage, providing you with
uninterruptedpowertothemonitor.
Torechargethe batteries,simplyplacethemonitorintheDocking Station
withtheACAdapterconnected.Thebatteryoptionalsoprovidesyou the
flexibilitytomovethemonitorfromroomtoroom. Batterylifeis
approximately2 3hours.Ittakes10~15hourstofullyrecharge the
batteries.When themonitor’ssound weakensorthe picturebecomes
unsteady, replacethe batteries.
8
If using the DockingStation,connectthe supplied6VDC800 mAadapter
tothe DCINPUT JACKattherearoftheDocking Stationand plugitinto
an electricaloutlet.
Alternatively,youcanbypass the DockingStationandplug theadapter
directlyintotheDC INPUTJACKontheside ofthemonitor.
MONITORINSTALLATION
6VDC800 mA
ACAdapter
Note: ConnectionoftheMonitorto
the DockingStationisoptional.
The benefitsofthe Docking
Station are: A/VOutandBattery
Charging.
Battery TypeSwitch: Inorderforthe
monitortodetect Rechargeable Batteries,
the switchinside thebatterycompartment
mustbe setatRechargeable ratherthan
Alkaline.
Note: Donotsettheselectorswitchto
Rechargeable ifnon-rechargeable
batteriesarebeingused.
Warning:Topreventdamagetotheunit,
ensurethatthebatteriesarealigned
properlyand battery typesarenotmixed.

OPERATION
Camera
(1)Connectthepoweradaptertothe camerapowerinput andturnon
the camerabypressing Power.Ensurethecameraissettochannel1.
Monitor
(1)Connectthesupplied poweradaptortothepowerinput ofthemonitor
ortheDocking Station.TurnonthemonitorbyswitchingPower
ON/OFFtoON. TheLCD willdisplayChannel 3bydefault.
(2)Usethe channelselectorswitchbutton toensurethemonitorissetto
the samechannel asthecameratoviewthepicture. Note:If you
experiencereception problems(eg. poorpicture), you mayneedto
select anotherchannelonboththecameraand monitor.
(3)Adjust the volumetothe desiredlevel.Youmayalsomutethe audio
optionbyreducingtheVolumedialtotheminimumlevel.
(4)Adjust the brightness level asrequired.
TrytopositionboththeCameraand Monitorashighoffthegroundas
possibleforbetterpicturereception.
NOTE
ADDITIONALCAMERACONNECTION
9
Thisvideo securitysystemallowsyou toviewup tofourdifferentcamera
locations.Additionalcamerasaresoldseparately,pleasereferto
www.lorexcctv.com formoreinformation.
When connectingmorethanonecameratothemonitor/camerasystem,
you willneedtoseteachcameratoadifferent channel (Channels1-4).
CH 1

ALARMALERT
10
Thisvideo securitysystemisequippedwithanAudio-based Alarm
system, whichalertsyou of sound atthecamera.
Toactivatethe Alarmfeature, holdtheAlarmbuttonon the monitorfor2
seconds. Ared lightwillilluminatetoindicatethatAlarmmodeisactive,
and themonitorwillgotoStandbymode(videowillnot appearontheLCD
screen, and thespeakersound willcease).
AnAlarmisactivatedwhen sound atthecamerasiteisdetected.Inthe
eventof an Alarm,themonitorwillemitabuzzersound for10seconds,
and theLCD screen will turnONfor60seconds. Duringthe60 second
duration,asubsequentAlarmcannotbe triggered.Ifthere’sno further
noiseatthecameraafter60 seconds,themonitorwillreturntothe
Standbymode.Tostop the Alarm’sbuzzersound, pressthe Alarmbutton.
Alarmmodecan be deactivated byholding the Alarmbuttonfor2
seconds. The systemwillthen returntoitsprevioussettings.
SETTING ALARMSENSITIVITY
You canadjustthe levelof theAlarmfeature’ssensitivityvia the Audio
Sensitivitydialon the sideofthe monitor.AtlowerAudio Sensitivity
settings,loudersoundswill berequired totriggeranAlarm.When the
AudioSensitivityisatahighsetting, softsoundswill triggertheAlarm.
AUTO &MANUAL VIEWINGOPTIONS
ThissystemispresettoManualmode.Tomanuallyview aspecific
cameralocation, press theChannel Selectorbutton tonavigatebetween
Channels1-4.
Alternatively,youcansetthe systemtoAutomodebypressing theAuto
button.InAutomode,theAutoLEDlightwillturnON,and thecamera
channelswillrotateautomatically.ToexitAutomode,presstheAuto
buttonagain.

AUTOSCANNING
Thisvideo securitysystemprovidesyou withtheoptiontoautomatically
switchbetween the fourcameralocations.Ifyou havefewerthan four
cameras,youcan alsosetthesystemtoscanbetween three ortwo
locations.
SettingAutoScanto2or3cameralocations:
1.Press and holdtheAutobutton formorethan2seconds. AllfourLED
lightson thefront ofthemonitorwillturnON.
2.Continuetopress and holdtheAutobutton.TheChannel4LEDwill
turnoff. The systemisnowset toscan between threecamera
locations(Channel1-3).
3.Continuetopress and holdtheAutobutton.TheChannel3LEDwill
nowbe turnedoff.Thesystemisnowset toscan between twocamera
locations(Channel1-2).
4.Continuetopress and holdtheAutobuttontoreturntothe fourcamera
viewing option(allfourLEDlightswillbe illuminated).
SELECTABLEDWELLSETTINGS
Dwell Setting isthetimeduration between eachcameraview in the auto
sequencemode.
Thissystemprovidesyou withthe option ofthreeselectabledwelltimes(2,
5and 10seconds)when set toAutoMode.Thissystemispresettoatwo
second interval.
Changing DwellTime:
1.Press and holdtheChannelSelectbutton.The LEDlight willturnon to
indicatethatit isset to2seconds.
2.Continuetopress and holdthe ChannelSelectbutton.The LEDlightwill
flashonesecond intervaltoindicatethatit isnowset tothe5second
interval.
3.Continuetopress and holdthe ChannelSelectbutton.
4.TheLEDlight willflashthreesecond intervaltoindicateit isset tothe10
second interval.
11

CONNECTINGTHEMONITORTOATV
Inordertoviewvideofromthe cameraonalargerscreen thanthe
1.8”LCD,youcanusetheVideo/AudiooutputfromtheDocking
Stationasshowninthediagrambelowand viewthevideo on TV.
Pleasenote:Toview thepictureontheTV,youmust select anA/V
orAUXchannel.
Connectionsforrecording
Similarly,themonitorcan alsobeconnectedtoaVCR.
Connectthesuppliedaudio/videocablefromthebackofthe monitortothe
Audio/VideoInputsof aVCR.
PleaseNote:Torecord,youmustselecttheA/VorAUXchannel on your
VCR.
12
RCAcable

13

TECHNICALSPECIFICATIONS
MONITOR
Display 1.8”ColorLCD
Resolution 280 x220 pixels
Viewing Angle 90º(L/R)
CameraCapable Up to4
Wireless transmission Up to300 feet (openspace)
PowerSource 6V800mAAdapter(included)
Battery Option 4 “AA”Batteries(not included)
CAMERA
Image Device Color1/4”CMOS
PictureElement 510 x492 pixels
Lens 3.6mm
Viewing angle 60º
MinimumIllumination 3LUX@F2.0, 0LUXwithLED’s
at 3ftorless
PowerSource6V300mAAdapter(included)
Battery Option 4 “AA”Batteries(not included)
15
Becauseour productsare subject tocontinuous improvement, SVIIand its subsidiaries reservethe right tomodify
product design and specificationswithout noticeand without incurring anyobligation. E&OE

CAREAND MAINTENANCE:
Pleasefollowtheseinstructionstoensureproper
careandmaintenanceofthissystem.
Keep yourmonitorandcameradry.If it getswet,
wipe itdryimmediately.
Useand storeyourunitinnormaltemperature
environment.Extremetemperaturescanshorten
the lifeof theelectronicdevices.
Handlethemonitorcarefully.Dropping itcancause
seriousdamagetothe unit.
Occasionallycleantheunitwithadampclothtokeep
itlookingnew. Do notuseharshchemicals,cleaning
solventsorstrong detergentstoclean theunit.
Keep the unit awayfromexcessivedirt anddust.It
can causeprematurewearof parts.
16
FCC Information
Thisdevicecomplieswithpart15 oftheFCC Rules,Operationissubjecttothefollowingtwo
conditions:(1)Thisdevicemaynot causeharmfulinterference, and(2)Thisdevicemust acceptany
interferencereceived,includinginterferencethat maycauseundesiredoperation.
CAUTION: Changesormodificationsnotexpresslyapprovedby Summerinfantmayvoidthe
usersauthoritytooperatethisequipment.
NOTE: ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass Bdigital
device,pursuant topart15 oftheFCC Rules.
Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceina
residentialinstallation.Thisequipmentgenerates,usesand canradiateradiofrequencyenergyand,
ifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterference toradio
communications,However,thereisnoguarantee thatinterferencewill notoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,
whichcanbedeterminedbyturningtheequipmentoff andon,theuserisencouragedtotryto
correct theinterferencebyoneormoreofthefollowingmeasures:
l Reorientorrelocatethereceivingantenna
lIncreasetheseparationbetweentheequipment andthereceiver
lConsult thedealeroranexperiencedradio/ TVtechnicianforhelp.
