LORUS W136 User manual

■CHARACTERISTICS
1. Time/calendar display: Hour, minute,
seconds, date, day of the week and month.
2. Automatic calendar adjustment: Cal-
endar adjusts automatically for odd and
even months except February of leap years.
3. Time indication: Changeover between
12-hour and 24-hour indications is pos-
sible.
4. Stopwatch: 24-hour stopwatch with 1⁄100-
second readout up to 40 minutes and with
1-second readout after the first 40 min-
utes. Split time measurement is avail-
able.
5. Alarm: The alarm rings at the desig-
nated hour and minute with “beep, beep”
for 30 seconds.
6. Hourly time signal: Can be set to ring
every hour on the hour with a single “beep”.
7. Illuminating light (except Cal. W140):
The light evenly illuminates the display in
the dark.
■ DISPLAY AND BUTTON OPERATION
INSTRUCTION MANUAL
CAL. W136 (RE4 SERIES)
CAL. W190 (RB7 SERIES)
CAL. Y736 (RB9 SERIES)
NREY736C 11-2000
CAL. W140 (RCM SERIES)
CAL. Y735 (RVT SERIES)
A
B
C
Hour
Alarm mark
Time signal mark
Day indicator
Second
Minute
Time signal mark
Hour
AC
B
Day indicator*
Alarm mark
EL button
* The design of the day indication differs de-
pending on the calibre.
Second
Minute
[Cal. W140]
[Cal. W190 / Y735 / Y736]
[Cal. W136]
B
A
Minute
Second
Hour
C
Day indicator
EL button
Alarm mark
Button B : • Calendar (month, date and day)
display in the time/calendar display.
• Start/stop in the stopwatch func-
tion.
• Selection of the digits to be ad-
justed in the alarm setting func-
tion and the time/calendar set-
ting function.
Button C : • Alarm display in the time/cal-
endar display.
• Split/Split release/Reset in the
stopwatch function.
• Setting the digits in the alarm
setting function and the time/
calendar setting function.
• Stopping the alarm in any dis-
play.
Button B while keeping button C pressed:
Engagement and disengagement
of the alarm and the time signal.
Button C while keeping button B pressed:
Changeover of the calendar (month
and date) display.
Buttons B & C:
Alarm test in the time/calendar
display.
■HOW TO SET THE DUAL CALEN-
DAR DISPLAY
1 Press button “B” to show the calendar (month,
date, and day) display. The calendar dis-
play is shown while button “B” is kept
pressed.
2 The month and the date change places
with each other with each press of button
“C” while keeping button “B” pressed.
▼
▲
B
C
B
C
* In the 12-hour indication, “A” (AM)/“P” (PM)
mark is displayed. In the 24-hour indica-
tion, there is no indication.
Month Day Date Day
Date Month
■HOW TO USE THE STOPWATCH
A
B: Start/Stop
Stopwatch
indicator
Split indicator Stop indicator
1/100 second
indicator
C: Split/
Split release/
Reset
Minutes Seconds 1/100 second
Button A : • Selection of the display.
The selection is made in the following order:
▲
▼
▲
▲
A
----------------------------
------
------
----------------------------
Press
button “A”
for 2 sec.
A
Alarm setting
Time/calendar display
Stopwatch display
Time/calendar setting
▲
AA
Time
signal
mark

1 Press button “A” to show the stopwatch
display. (The stopwatch indicator starts
flashing.)
The stopwatch can measure up to 24 hours
and is displayed in minutes, seconds, and
1/100 seconds up to 40 minutes, and in
hours, minutes, and seconds after the first
40 minutes. (The 1/100 second indicator
flashes during the first 40 minutes.)
When the measurement is over 24 hours,
the stopwatch will be reset to “0:00oo”
and start counting again.
2 Reset the digits to “0:00oo” before using
the stopwatch. When the split and the
stopwatch indicators are flashing, press
button “B” to check that the stop indicator
starts flashing, and then press button “C”
twice to reset the digits to zero.
3 When measuring a long period of time,
return the stopwatch to the time/calendar
display after the stopwatch starts to pre-
vent any possible mistaken operation.
* When button “B” or “C” is pressed in the
stopwatch display, a single “beep” sounds
to confirm the operation.
Start Stop Restart ResetStop
BBB BC
Start
BCBC
Split Split
release
Stop Reset
C
Finish (First runner)
BCBCC
Finish (Second runner)
Start
Finish time
of 2nd
competitor
Reset
Stop
Finish
time of 1st
competitor
Accumulated elapsed time measurement
Split time measurement
**
**Restart and stop can be repeated by pressing
button “B”.
**
**Measurement and release of split time can be
repeated by pressing button “C”.
Measurement between two competitors
1 Press button “A” for 2 seconds to activate
the alarm setting function. (The alarm set
indicator starts flashing.)
2 Press button “B” to activate the “Hour” or
“Minute” setting. The display changes in
the following order with each press of but-
ton “B”.
3 One digit (flashing) is advanced with each
press of button “C”. The digits are ad-
vanced quickly by keeping button “C” pressed.
4 After all the adjustments are completed,
press button “A” to return to the time/
calendar display.
(The display returns directly to the time/
calendar display and not to the time/cal-
endar setting.)
▲
▼
B
A
B
C
Hour Minutes
Alarm set indicator
■HOW TO SET THE ALARM
“A” (AM)
Hour setting
Minute setting
Note: When setting the hour digits, be sure
to check that the “A” (AM)/“P” (PM)
mark is correctly set.
■ HOW TO ENGAGE AND DISENGAGE
THE ALARM AND THE TIME SIGNAL
Alarm display
1 Press button “C” in the time/calendar dis-
play to show the alarm display. The alarm
display is shown while button “C” is kept
pressed.
B
C
Minutes
Hour
2 With each press of button “B” while keep-
ing button “C” pressed, the engagement
and disengagement of the alarm and the
time signal are made as follows:
“A” (AM)
▼
▼
▲
▲
Alarm is engaged.
Time signal is disengaged. Time signal is engaged. Alarm is disengaged.
Alarm and time
signal are engaged.
Alarm and time signal
are disengaged.
The alarm rings at the designated time for 30
seconds and stops. However, the alarm can
be stopped manually by pressing button “C”
in any display.
■HOW TO STOP THE ALARM
■ALARM TEST
The alarm can be tested with a beeping sound
by pressing buttons “B” and “C” at the same
time in the time/calendar display.
■ HOW TO SET THE TIME/CALENDAR
Time/calendar setting
indicator
1 Press button “A” to activate the time/calendar
setting function. (The time/calendar setting
indicator and the second digits start flashing.)
2 Selection of the digits to be adjusted (flash-
ing) is made in the following order by
pressing button “B”.
3 One digit (flashing) is advanced with each
press of button “C”. (The digits except
seconds are advanced quickly by keeping
button “C” pressed.)
•Second setting
Press button “C” in accordance with a
time signal. The seconds are reset to
“00” and start immediately.
When the seconds count any number
from “30” to “59” and button “C” is pressed,
one minute is added and the seconds
are immediately reset to “00”.
4 After all the adjustments are completed,
press button “A” to return to the time/
calendar display.
Seconds Minutes MonthHour
Day Date
→→→
A
←←
↑
C
B

Note: When setting the hour digits, be sure
to check that the “A” (AM)/“P” (PM)
mark is correctly set.
■ HOW TO CHANGEOVER THE 12-HOUR
AND THE 24-HOUR INDICATIONS
In the calendar or the alarm display, each
press of button “A” changes over the time
indication display from the 12-hour to the 24-
hour and vice versa.
• Changeover in the calendar display
24-hour
▼
A
▲
A
12-hour
[Keeping button “B” pressed]
• Changeover in the alarm display
24-hour
▼
A
▲
A
12-hour
[Keeping button “C” pressed]
* When the “A” (AM)/“P” (PM) mark disap-
pears, the calendar or the alarm display is
shown in the 24-hour indication.
■LUMIBRITE WATCH
(dial, hands, buttons, case, bezel,
strap, etc.)
✩If your watch is a LORUS LUMIBRITE watch,
it has following features.
LORUS LUMIBRITE watches absorb and store
light energy from natural and artificial light
sources and emit light in the dark. They are
made of environmentally friendly material,
and therefore, are harmless to human beings
and the environment.
• With a full charge, LORUS LUMIBRITE
watches glow in the dark hours longer than
conventional luminous watches of this type.
If exposed to a light of more than 500 lux
(i.e., the brightness of a typical office) for
approximately 10 minutes, or direct sunlight
for 2 minutes, they will glow for hours.
• Since LORUS LUMIBRITE watches emit
the light they store, the brightness will
decrease gradually over time. The length
of time they will glow may also differ slightly
depending on such factors as the brightness
of and distance from the light source used
to charge the watch.
■ILLUMINATING LIGHT
(except Cal. W140)
When EL button is pressed and released in
the time/calendar or stopwatch display, or
in the alarm setting or time/calendar setting
function, the electroluminescent light evenly
illuminates the display for 4 seconds for
easy viewing in the dark.
EL button
Notes:
1. The watch works with one battery. When
the light begins to lose its luminance,
this is an indication that the battery is
depleted. We recommend that you change
the battery before the watch itself stops.
2. If the light is used continuously for a
long time, the battery life may be less
than the specified period.
■BATTERY CHANGE
The miniature battery which powers your watch
should last as individually specified below.
However, because it is inserted at the factory,
the actual life of the battery once in your
possession may be less than the specified
period.
Be sure to replace the battery to prevent any
possible malfunction as soon as it runs down.
To replace the battery, we recommend taking
the watch to a local watch repair shop.
CAL. NO. BATTERY BATTERY LIFE
(Approx.)
■CARE OF YOUR LORUS WATCH
• BATTERY
• WATER RESISTANT
No
indication
WATER
RESISTANT
WATER
RESISTANT
(50 M/5 BAR)*
WATER
RESISTANT
100 M/
10 BAR or
above
Condition
of use
Accidental
contact with
water, such
as splashes
and rain
Swimm-
ing and
taking a
shower
Skin
diving Scuba diving
Indica-
tion on
the dial/
case back
NO NO NO NO
YES YES NO NO
YES NO NO NO
YES YES YES NO
()
*
CAUTION
Do not expose the old battery to
fire or recharge it. Keep it at a
place beyond the reach of chil-
dren. If a child swallows it, consult
a doctor immediately.
* If your watch is 200 M/20 BAR, 100 M/10
BAR or 50 M/5 BAR water resistant, it is so
indicated on the dial/case back.
•Do not operate the buttons when the watch
is wet.
•If the watch is exposed to salt water, rinse
it in fresh water and then wipe it thoroughly
dry.
Caution:
Leather straps are not water resistant except
so indicated, even if the watch head is water
resistant.
W136 8 years
W140 7 years
Y735 5 yearsSEIKO CR2016
Y736 5 years
W190 3 yearsPANASONIC CR1620
SEIKO CR2025
Note: If the alarm is used for more than 30
seconds a day (and/or the illuminating
light for more than 4 seconds a day
for Cal. W136, W190, Y735 and Y736),
the battery life may be less than the
specified period.
■ViViDiGi
ViViDiGi is a new type of liquid crystal panel
that makes possible various colors and high
contrast.
• Excellent light reflection and transmission
make the display bright and clear.
• Various color options are available.
• Either the whole panel or the displayed
data only can be illuminated. (Except Cal.
W140)
* Features vary in different models.

• ALLERGIC REACTION
Because the case and band touch the skin
directly, it is important to clean them
regularly. If not, shirt sleeves may be
stained and those with delicate skin may
develop a rash. Please wear the watch
with some play to avoid any possible allergic
reaction. If you develop a rash on your
wrist, stop wearing and consult a physician.
• MAGNETISM
Your watch will not be affected by mag-
netism generated by household electric
appliances.
• SHOCKS AND VIBRATIONS
Your watch may be worn for normal sports
activities, but be careful not to drop it or
hit it on hard surfaces.
• TEMPERATURE
Your watch is preadjusted so that constant
accuracy may be insured at normal tem-
perature.
■SERVICE
When your LORUS watch requires repair
or servicing, please see the enclosed
WARRANTY/GUARANTEE.
Printed in China
