Louvolite SC Series Manual

SC Series™ Roller Blind
Fitting and Operating Instructions
for Systems 40® and 45®
Before attempting to fit your window blind,
please read the instructions carefully.
Louvolite, Ashton Road, Hyde, Cheshire SK14 4BG
Telephone: [phone] Fax: [phone] Email: [e-mail] www.louvolite.com
Side Control Roller Blinds - Child Safety
WARNING
Young children can strangle in the loop of pull cords, chains and tapes, and
cords that operate window coverings. They can also wrap cords around their
necks. To avoid strangulation and entanglement, keep cords out of the reach
of young children. Move beds, cots and furniture away from window
covering cords.
“Complete elimination of the strangulation risk can only be achieved by keeping cords, chains, and tapes and similar
out of the reach of children. Use of additional safety devices may reduce the risk of strangulation but cannot be
considered foolproof ... Persons in charge of children are ultimately responsible for following the safety instructions
provided by the manufacturer.” EN 13120
Cord Tidy
For the installer
Split cord tidy, put chain into the male section,
insert female section into this. Keep cords and
chain taught, fix to wall or window frame at
side of the blind. Always attach a Safety
Warning Tag
For the consumer
Always ensure that the chain
remains housed within the
cord tidy.
Easybreak™ Connector
For the installer
Join operating chain by last ball of each end
into the larger holes on each side of the
connector.
When blind is raised, connector should be at
top of the blind on the chain length nearest
the window. Always attach a Safety
Warning Tag
For the consumer
If any reasonable weight is placed within the
loop, the Easybreak™ connector will break
apart. To re connect, check connector is not
damaged, then insert the end of the ball chain
into larger hole in the connector. Push home
leaving the chain in the same position as
before. Connector should be at the top of the
blind, on the side of the chain nearest to the
window when blind is raised.
Bell Toggle
The chain loop can be split and
the bell toggles attached to
each end of the chain.
Cord Cleat
For the installer
Cord cleat should be fixed by two screws in a
safe position, not accessible to children.
Always attach a Safety Warning Tag
For the consumer
Always wrap the chain
or chains around the
cleat after use.
Part Code No. R9840

Fitting the Brackets
The bracket positions illustrated are for a blind with the control chain on the right hand side of
the blind. Brackets can be top, side or face fixed to any flat surface. They must be level to
ensure the smooth operation of the blind. Check that the rolled up fabric will not touch any
surface. To calculate the spacing between the brackets, add 35mm (13/8”) to the width of the
blind fabric. Fix the brackets so that the outsides of the brackets are this distance apart.
Blinds with Side Control Chain
Fitting the Blind
Hold the blind to the brackets with the fabric hanging from the back of the blind. Fit the spring
plunger into its bracket and push the blind into the bracket, depressing the plunger. When fitted
ensure that the plunger is depressed by at least 4mm. With the locating hook pointing
downwards, place the control end into the vertical part of the ‘+’ shaped hole in the bracket.
Allow the hook to drop downwards so that it locks into place in the bracket.
IMPORTANT
Please read the child safety information attached to your blind.
When fitted ensure plunger is
depressed by at least 4mm
Bracket Cover
Bracket (in face
fix position)
Plunger End
Bottom Bar
Bracket Cover
Bracket (in top
fix position)
Control End
Operating Chain
Aluminium Tube
Bracket Cover
Bracket (in top
fix position)
Locating Slots
Bracket Cover
Bracket (in face fix position)
Bottom Bar End Cap
Locating Spigot
Optional Easy Break
Chain Connector
Locating Hook
Fabric
Bottom Bar
Cord & Chain Tidy
Plunger End View
Control End View
