LS ELECTRIC XGT Series User manual

LS ELECTRIC strives to maximize your profits in gratitude for choosing us as your partner.
Programmable Logic Control
XGT Ethernet Module
XGL-EFMTB
XGL-EFMFB
XGL-EFMHB
XOL-ES4T
XOL-ES4H
XGL-EH5T
XGL-EFMT
XGL-EFMF
XGT Series

Safety Instruction
1
Before using the product …
Foryoursafetyandeffective operation,pleaseread the safetyinstructionsthoroughlybeforeusingtheproduct.
SafetyInstructionsshould always beobserved inorderto preventaccidentorrisk withthesafeandproperuse
theproduct.
Instructionsare dividedinto“Warning”and “Caution”, and the meaningof the terms is asfollows.
This symbol indicates the possibility of serious injury or death if some applicable
instruction is violated
This symbol indicates the possibility of severe or slight injury, and property
damagesifsomeapplicable instructionisviolated
Moreover, even classified events under its caution category may develop into serious accidents relying
on situations.Thereforewe strongly advise users to observe all precautions properly just like warnings.
The marks displayed on the product and in the user’s manual have the followingmeanings.
Be careful! Dangermaybe expected.
Be careful! Electricshockmayoccur.
The user’s manual even after read shallbe keptavailableand accessible to any user of the product.
Warning
Caution

Safety Instruction
2
Safety Instructions for design process
1. Please install a protection circuit on the exterior of PLC so that the whole system may
operate safely regardless of failures from external power or PLC. Any abnormal output or
operation from PLC maycauseserious problems to safety in whole system.
- Install protection units on the exterior of PLC like an interlock circuit that deals with opposite
operations such as emergency stop,protection circuit, and forward/reverse rotation or install an
interlockcircuit that dealswith high/lowlimitunder itspositioncontrols.
- If any system error (watch-dog timer error, module installation error, etc.) is detected during
CPU operation in PLC, all output signals are designed to be turned off and stopped for safety.
However, there are cases when outputsignals remain active dueto device failures in Relayand
TR which can’t be detected. Thus, you are recommended to install an addition circuit to monitor
theoutputstatusfor those critical outputswhich maycausesignificant problems.
2. Never overload more than rated current of output module nor allow to have a short circuit.
Overcurrentforalongperiodtimemaycause afire.
3. Never let the external power of the output circuit to be on earlier than PLC power, which may
cause accidentsfromabnormal output oroperation.
4. Please install interlock circuits in the sequence program for safe operations in the system
when exchange data with PLC or modify operation modes using a computer or other
external equipments Read specific instructions thoroughly when conducting control operations
with PLC.
Warning

Safety Instruction
3
Safety Instructions for design process
Safety Instructions on installation process
I/O signal or communication line shall be wired at least 100mm away from a high-voltage cable or
power line. Failtofollowthis instructionmaycausemalfunctionsfrom noise
Caution
1. Use PLC only in the environment specified in PLC manual or general standard of data
sheet. If not, electric shock, fire, abnormal operation of the product may be caused.
2. Before install or remove the module, be sure PLC power is off. If not, electric shock or
damageon the productmaybecaused.
3. Be sure that every module is securely attached after adding a module or an extension
connector. If the product is installed loosely or incorrectly, abnormal operation, error or dropping
may be caused. In addition, contact failures under poor cable installation will be causing
malfunctions aswell.
4. Be sure that screws get tighten securely under vibrating environments. Fail to do so will
put the product under direct vibrations which will cause electric shock, fire andabnormaloperation.
5. Do not come in contact with conducting parts in each module, which may cause electric
shock,malfunctionsorabnormal operation.
Caution

Safety Instruction
4
Safety Instructions for wiring process
1. Prior to wiring works, make sure that every power is turned off. If not, electric shock or
damageon theproductmaybecaused.
2. After wiring process is done, make sure that terminal covers are installed properly before
its use.Failtoinstallthecovermaycauseelectricshocks.
Warning
1. Check rated voltages and terminal arrangements in each product prior to its wiring
process. Applying incorrect voltages other than rated voltages and misarrangement among
terminalsmaycausefire ormalfunctions.
2. Secure terminal screws tightly applying with specified torque. If the screws get loose, short
circuit,fireor abnormal operation maybe caused. Securing screws too tightly will cause damages
to themoduleormalfunctions,short circuit, anddropping.
3. Be sure to earth to the ground using Class 3 wires for FG terminals which is exclusively
used for PLC. If the terminals not grounded correctly, abnormal operation or electric shock may
be caused.
4. Don’t let any foreign materials such as wiring waste inside the module while wiring,
which maycausefire,damageon theproductorabnormaloperation.
5. Make sure that pressed terminals get tighten following the specified torque. External
connector type shall be pressed or soldered using proper equipments.
Caution

Safety Instruction
5
Safety Instructions for test-operation and maintenance
1. Don’t touch the terminal when powered.Electric shockorabnormaloperation mayoccur.
2. Prior to cleaning or tightening the terminal screws, let all the external power off including
PLC power. If not, electric shock or abnormal operation may occur.
3. Don’t let the battery recharged, disassembled, heated, short or soldered. Heat, explosion or
ignition maycauseinjuries orfire.
Warning
1. Do not make modifications or disassemble each module. Fire, electric shock or abnormal
operation mayoccur.
2. Prior to installing or disassembling the module, let all the external power off including PLC
power. If not, electric shock or abnormal operation may occur.
3. Keep any wireless equipment such as walkie-talkie or cell phones at least 30cm away from
PLC. If not,abnormaloperation maybe caused.
4. When making a modification on programs or using run to modify functions under PLC
operations, read and comprehend all contents in the manual fully. Mismanagement will cause
damages to products and accidents.
5. Avoid any physical impact to the battery and prevent it from dropping as well. Damages to
battery may cause leakage from its fluid. When battery was dropped or exposed under strong
impact, never reuse the battery again. Moreover skilled workers are needed when exchanging
batteries.
Caution

Safety Instruction
6
Safety Instructions for waste disposal
Product or battery waste shall be processed as industrial waste. The waste may discharge
toxic materials orexplode itself.
Caution

Revision History
7
Revision History
Version
Date
Remark
Page
V1.0
2005.03
FirstEdition
-
V1.1
2005.05
Addingthefunction description
-
V1.2
2005.09
AddingmoduledetachmentandhowtochangeSettingPLCtypeat
XG-PD
Addingappendix(CPUmemorydevice)
CH3.8
CH5.2
APPENDIX-
V1.3
2005.11
Fixingfigureandadding contents
-
V1.4
2005.11
Fixingfigureandcontents
-
V1.5
2008.07
1.Addingmodels
-addingXGI/XGRredundantsystem
-addingswitchmodule(XGL-EH5T)
2.Adding E-mailservice
3.Adding error code table
4.AddingCH11CompliancewithEMCSpecifications
5.Fixingheadquarter address
CH1.3.2
CH7.6
CH10.4
CH11
Back cover-
V1.6
2009.09
1. ModifyingOverview
2.AddingCPU
3.Addingcontents onstandardsetting(One IPSolution,DHCP)
CH1.2.1
CH1.3.2
CH5.3
V1.7
2011.05
1.Howtoenablelink throughflagadded
2.Write_NC,Send_NC”instructionadded
CH5.5.2
CH7.2.1
V1.8
2013.10
1.AddingCommunicationloadspecifications
2.ChangingModbusserver offsetarea
CH2.2.3
CH8.3.1
V1.9
2014.03
1.ChangingCommunicationloadspecifications
2.Addinginfo-U,iXP
3.AddingXGRHSLink
4.AddingXGTDedicatedCommunication’sHeader
5.AddingXGTDedicatedCommunication’s error Code
6.AddingHighPerformanceXGT
7.Changingerror code table
CH2.2.3
CH4
CH6.6~6.7
CH8.1.2
CH8
CH9.2.3
CH10.4
V2.0
2014.11
XG5000 V4.0UIUpdate
-
V2.1
2016.10
XGL-EFMTB,XGL-EFMFBcontentsadded
-
V2.2
2017.06
Adding RAPIEnetprotocolandCnetprotocol
-
V2.21
2017.09
Error code update
CH10.2.2
V2.30
2018.05
Adding OPCUAServerservice
CH12
V3.0
2020.02
AddingSmartextensionservice
-

Revision History
8
Version
Date
Remark
Page
V3.1
2020.06
1. Formatandcontentsmodificationaccordingtothechangeof
companyname(LSIS -> LSELECTRIC)
2.AddingRAPIEnet+autoscan
3.AddingSmartExtensionservicediagnosticvariables
ALL
CH3.6
CH4, CH9

About User’s Manual
9
Thank youforpurchasingPLC of LS ELECTRICCo.,Ltd.
Before use, make sure to carefully read and understand the User’s Manual about the functions, performances, installation and
programming of the product you purchased in order for correct use and importantly, let the end user and maintenance
administrator to be provided with the User’s Manual.
The User’s Manual describes the product. If necessary, you may refer to the following description and order accordingly. In
addition, youmayconnectourwebsite (http://www.lselectric.co.kr/)anddownloadtheinformationas aPDFfile.
RelevantUser’sManuals
Title
Description
XG5000User’s Manual
(forXGK,XGB)
XG5000softwareusermanualdescribingonlinefunctionsuchas
programming,print,monitoring,debuggingbyusing XGK, XGB
CPU
XG5000 User’s Manual
(forXGI,XGR)
XG5000softwareusermanualdescribingonlinefunctionsuch
asprogramming,print,monitoring,debuggingbyusingXGI,
XGRCPU
XGK/XGBInstructions&Programming
User’s Manual
User’smanualfor programming toexplain howto use
instructionsthatareused PLCsystem withXGK,XGBCPU.
XGI/XGR Instructions& Programming
User’s Manual
User’smanualfor programming toexplain howto use
instructionsthatareused PLCsystem withXGI,XGRCPU.
XGK CPU User’s Manual
XGK-CPUU/CPUH/CPUA/CPUS/CPUE/CPUSN/CPUHN/
CPUUNusermanualdescribingaboutXGKCPUmodule,
powermodule, base,IOmodule, specification of extension cable
andsystem configuration,EMCstandard
XGI CPU User’s Manual
XGI-CPUU/D,CPUU,CPUH,CPUS,CPUE,CPUUNusermanual
describingaboutXGICPUmodule,powermodule,base,IO
module, specificationofextensioncableandsystem
configuration,EMCstandard
XGR redundant series User’s
Manual
XGR-CPUH/F,CPUH/TusermanualdescribingaboutXGR
CPUmodule,powermodule,extensiondrive,base,IO module,
specificationofextensioncable andsystem configuration,EMC
standard
CommunicationdeviceUser’s Manual
User’s manual for programming to explain how to use Extension
driver, Smart I/O extention,SmartI/Oblock

Table of Content
10
◎Contents ◎
Chapter1 Overview------------------------------------------------------------------------------------------------------------------------------------------1-1
1.1 Guidetousethismanual--------------------------------------------------------------------------------------------------------------------------------1-1
1.2 Characteristics---------------------------------------------------------------------------------------------------------------------------------------------1-2
1.2.1 Ethernetmodule------------------------------------------------------------------------------------------------------------------------------------1-2
1.2.2 Switchmodule---------------------------------------------------------------------------------------------------------------------------------------1-3
1.2.3 Productname ---------------------------------------------------------------------------------------------------------------------------------------1-4
1.2.4 FunctionItemsbyVersion------------------------------------------------------------------------------------------------------------------------1-4
1.2.5 Numberofunits thatcanbeinstalledfor eachCPU---------------------------------------------------------------------------------------1-7
1.3 Softwareforusingtheproduct-------------------------------------------------------------------------------------------------------------------------1-8
1.3.1 Softwarechecklist----------------------------------------------------------------------------------------------------------------------------------1-8
1.3.2 Checkingtheproductinformation--------------------------------------------------------------------------------------------------------------1-9
Chapter2 Productspecifications--------------------------------------------------------------------------------------------------------------------------2-1
2.1 General specifications------------------------------------------------------------------------------------------------------------------------------------2-1
2.2 Performancespecifications-----------------------------------------------------------------------------------------------------------------------------2-2
2.2.1 Ethernetmodule------------------------------------------------------------------------------------------------------------------------------------2-3
2.2.2 Switchmodule---------------------------------------------------------------------------------------------------------------------------------------2-4
2.2.3 Powerspecification---------------------------------------------------------------------------------------------------------------------------------2-4
2.2.4 Loadspecifications---------------------------------------------------------------------------------------------------------------------------------2-5
2.3 StructureandCharacteristics---------------------------------------------------------------------------------------------------------------------------2-6
2.3.1 Namesof PartandFunction---------------------------------------------------------------------------------------------------------------------2-6
2.4 Specificationofcable-----------------------------------------------------------------------------------------------------------------------------------2-15
2.4.1 Twistedpaircable--------------------------------------------------------------------------------------------------------------------------------2-15
2.4.2 OpticalFiber Cable-------------------------------------------------------------------------------------------------------------------------------2-16
2.5 Howtoconnectcommunicationbetweenourproducts---------------------------------------------------------------------------------------2-17
2.5.1 Mastercommunication--------------------------------------------------------------------------------------------------------------------------2-17
2.5.2 Slavecommunication----------------------------------------------------------------------------------------------------------------------------2-18
Chapter3 ProductInstallationandtrialoperation-----------------------------------------------------------------------------------------------------3-1
3.1 Installation---------------------------------------------------------------------------------------------------------------------------------------------------3-1
3.1.1 Preparation foroperating -------------------------------------------------------------------------------------------------------------------------3-1
3.1.2 Settingsequenceforoperation------------------------------------------------------------------------------------------------------------------3-2
3.2 Installation---------------------------------------------------------------------------------------------------------------------------------------------------3-3
3.2.1 Ethernetmodule------------------------------------------------------------------------------------------------------------------------------------3-3
3.2.2 InstallingandRemovingthe SwitchModule-------------------------------------------------------------------------------------------------3-5

Table of Content
11
3.3 Testoperation----------------------------------------------------------------------------------------------------------------------------------------------3-7
3.3.1 PrecautionsforSystemConfiguration---------------------------------------------------------------------------------------------------------3-7
3.3.2 Checkitemsbeforetrialoperation--------------------------------------------------------------------------------------------------------------3-7
3.3.3 Themethodtoremoveandreplacethemodule.-------------------------------------------------------------------------------------------3-9
3.4 PrecautionswhenConnectingtoaNetwork-----------------------------------------------------------------------------------------------------3-10
3.4.1 Useringnetwork----------------------------------------------------------------------------------------------------------------------------------3-10
3.4.2 Useline network----------------------------------------------------------------------------------------------------------------------------------3-11
3.5 XG5000 Program---------------------------------------------------------------------------------------------------------------------------------------3-12
3.5.1 CPUtypesetting----------------------------------------------------------------------------------------------------------------------------------3-12
3.5.2 Communicationmoduleregistration---------------------------------------------------------------------------------------------------------3-13
3.5.3 Standardsettings---------------------------------------------------------------------------------------------------------------------------------3-17
3.5.4 Hosttablesetting---------------------------------------------------------------------------------------------------------------------------------3-22
3.5.5 SNTPSetting--------------------------------------------------------------------------------------------------------------------------------------3-22
3.5.6 SetsEIPServer-----------------------------------------------------------------------------------------------------------------------------------3-23
3.5.7 AdvancedSettings-------------------------------------------------------------------------------------------------------------------------------3-24
3.5.8 Download/Upload--------------------------------------------------------------------------------------------------------------------------------3-25
3.5.9 Linkenable-----------------------------------------------------------------------------------------------------------------------------------------3-28
3.6 System diagnosis ---------------------------------------------------------------------------------------------------------------------------------------3-32
3.6.1 Diagnostics-----------------------------------------------------------------------------------------------------------------------------------------3-32
3.6.2 Typesofdiagnosticfunctions------------------------------------------------------------------------------------------------------------------3-33
Chapter4 SmartExtensionservice-----------------------------------------------------------------------------------------------------------------------4-1
4.1 Overview ----------------------------------------------------------------------------------------------------------------------------------------------------4-1
4.2 Smart extensionservicesetting -----------------------------------------------------------------------------------------------------------------------4-2
4.2.1 Standardsettings-----------------------------------------------------------------------------------------------------------------------------------4-2
4.2.2 SmartExtensionservice--------------------------------------------------------------------------------------------------------------------------4-3
4.2.3 SmartExtensionmastersetting-----------------------------------------------------------------------------------------------------------------4-8
4.2.4 SettingCommunicationdevice----------------------------------------------------------------------------------------------------------------4-20
4.2.5 SmartExtensionservicesettingDownload------------------------------------------------------------------------------------------------4-23
4.2.6 SmartExtensionEnableServices------------------------------------------------------------------------------------------------------------4-24
4.3 HotSwappingfunction---------------------------------------------------------------------------------------------------------------------------------4-25
4.3.1 HotSwap Operation-----------------------------------------------------------------------------------------------------------------------------4-25
4.3.2 HotSwap Operationsetting--------------------------------------------------------------------------------------------------------------------4-26
4.3.3 DiagnosticVariableOperationAccordingto ExchangeEBormoduleswhilerunning(hotswap)Option-----------------4-27
4.3.4 OperationbyHotSwapSetting---------------------------------------------------------------------------------------------------------------4-29
4.3.5 OperationandReturnConditionof CommunicationDeviceAccordingtoHotSwapSetting---------------------------------4-34
4.4 SmartExtension serviceoperation-----------------------------------------------------------------------------------------------------------------4-36
4.5 Smartextension diagnosisfunction-----------------------------------------------------------------------------------------------------------------4-42
4.5.1 Statusbyservice(Smartextension)---------------------------------------------------------------------------------------------------------4-42

Table of Content
12
4.5.2 ViewCommunication ModuleLog-----------------------------------------------------------------------------------------------------------4-44
4.6 Smartextensionsystem configuration-------------------------------------------------------------------------------------------------------------4-47
4.6.1 TypicalConfiguration----------------------------------------------------------------------------------------------------------------------------4-47
4.6.2 Ring /Lineconfiguration. -----------------------------------------------------------------------------------------------------------------------4-48
4.6.3 Auto Speed SyncOperation-------------------------------------------------------------------------------------------------------------------4-49
Chapter5 Highspeed linkservice------------------------------------------------------------------------------------------------------------------------5-1
5.1 Overview ----------------------------------------------------------------------------------------------------------------------------------------------------5-1
5.2 HSlinksend/receive dataprocessing--------------------------------------------------------------------------------------------------------------5-2
5.3 HSlinksetting----------------------------------------------------------------------------------------------------------------------------------------------5-3
5.3.1 Standardsettings-----------------------------------------------------------------------------------------------------------------------------------5-3
5.3.2 HSLinkService-------------------------------------------------------------------------------------------------------------------------------------5-4
5.3.3 Communicationdeviceconfiguration(SmartI/Oblockv1 version)-----------------------------------------------------------------5-10
5.4 HSLinkoperation---------------------------------------------------------------------------------------------------------------------------------------5-18
5.5 HSLinkInformation-------------------------------------------------------------------------------------------------------------------------------------5-24
5.5.1 Highspeed linkflag------------------------------------------------------------------------------------------------------------------------------5-24
5.5.2 HSLinkInformationMonitor-------------------------------------------------------------------------------------------------------------------5-26
5.6 XGRRedundancyProgramMethod---------------------------------------------------------------------------------------------------------------5-28
5.6.1 WhenconfiguringanXGR redundantnetwork -------------------------------------------------------------------------------------------5-28
5.6.2 WhenconfiguringanXGR Singlenetwork-------------------------------------------------------------------------------------------------5-30
5.7 XGRRedundantHighSpeedLink SettingProgram-------------------------------------------------------------------------------------------5-31
5.7.1 WhenconfiguringanXGR redundantnetwork -------------------------------------------------------------------------------------------5-31
5.7.2 WhenconfiguringanXGR Singlenetwork-------------------------------------------------------------------------------------------------5-38
5.8 EthernetSystem Configuration----------------------------------------------------------------------------------------------------------------------5-41
5.8.1 ConfigurationofEthernetSystem UsingDedicatedNetwork-------------------------------------------------------------------------5-42
5.8.2 Mixof DedicatedNetworksandThird-PartyEthernetSystems ----------------------------------------------------------------------5-42
5.8.3 Mixof public,dedicatedandthirdpartyEthernetsystems-----------------------------------------------------------------------------5-43
5.8.4 System configurationusingInfoU,PLC-to-PLCDedicatedEthernetinXGRsystem-------------------------------------------5-43
5.8.5 System configurationusingsinglenetworkEthernetinXGRsystem---------------------------------------------------------------5-44
Chapter6 P2Pservice---------------------------------------------------------------------------------------------------------------------------------------6-1
6.1 Overview ----------------------------------------------------------------------------------------------------------------------------------------------------6-1
6.1.1 OverviewofP2Pservice--------------------------------------------------------------------------------------------------------------------------6-1
6.1.2 P2Pparameter configuration--------------------------------------------------------------------------------------------------------------------6-1
6.2 TypeofP2Pservice--------------------------------------------------------------------------------------------------------------------------------------6-2
6.2.1 TypeofP2Pcommand---------------------------------------------------------------------------------------------------------------------------6-2
6.2.2 TypeofP2Pservice -------------------------------------------------------------------------------------------------------------------------------6-2
6.3 P2P service setting ---------------------------------------------------------------------------------------------------------------------------------------6-4
6.3.1 Ethernet(server)driver----------------------------------------------------------------------------------------------------------------------------6-4

Table of Content
13
6.3.2 P2Pchannel-----------------------------------------------------------------------------------------------------------------------------------------6-4
6.3.3 P2Pblock---------------------------------------------------------------------------------------------------------------------------------------------6-7
6.4 P2Pserviceoperation------------------------------------------------------------------------------------------------------------------------------------6-9
6.5 Userframedefinition -----------------------------------------------------------------------------------------------------------------------------------6-19
6.5.1 Overviewofauserframedefinition----------------------------------------------------------------------------------------------------------6-19
6.5.2 Userframedefinitionsetting-------------------------------------------------------------------------------------------------------------------6-19
6.5.3 Operationofauserframedefinition----------------------------------------------------------------------------------------------------------6-24
6.6 E-mail Service--------------------------------------------------------------------------------------------------------------------------------------------6-32
6.6.1 Emailsetting---------------------------------------------------------------------------------------------------------------------------------------6-32
6.6.2 Writingaddress -----------------------------------------------------------------------------------------------------------------------------------6-33
6.6.3 Createblock ---------------------------------------------------------------------------------------------------------------------------------------6-37
6.7 DownloadinganddiagnosisofP2Pparameter--------------------------------------------------------------------------------------------------6-38
6.7.1 DownloadingaP2Pparameter---------------------------------------------------------------------------------------------------------------6-38
6.7.2 P2Pserviceoperation---------------------------------------------------------------------------------------------------------------------------6-39
6.7.3 P2Pservicediagnosis---------------------------------------------------------------------------------------------------------------------------6-40
6.8 XGRRedundancyProgramMethod---------------------------------------------------------------------------------------------------------------6-41
Chapter7 Serverservice------------------------------------------------------------------------------------------------------------------------------------7-1
7.1 XGTserver--------------------------------------------------------------------------------------------------------------------------------------------------7-1
7.1.1 Overview----------------------------------------------------------------------------------------------------------------------------------------------7-1
7.1.2 Requesttoreadinformationandstatus(PC/HMI->PLC)--------------------------------------------------------------------------------7-7
7.1.3 Serveroperation----------------------------------------------------------------------------------------------------------------------------------7-11
7.2 Modbus Server ------------------------------------------------------------------------------------------------------------------------------------------7-14
7.2.1 Overview--------------------------------------------------------------------------------------------------------------------------------------------7-14
7.2.2 Serveroperation----------------------------------------------------------------------------------------------------------------------------------7-16
7.3 EtherNet/IPserver-------------------------------------------------------------------------------------------------------------------------------------7-18
7.3.1 Overview--------------------------------------------------------------------------------------------------------------------------------------------7-18
7.3.2 OperationSequence-----------------------------------------------------------------------------------------------------------------------------7-20
7.3.3 Parameter setting---------------------------------------------------------------------------------------------------------------------------------7-21
7.3.4 Clientsetting---------------------------------------------------------------------------------------------------------------------------------------7-22
7.3.5 Serversetting--------------------------------------------------------------------------------------------------------------------------------------7-28
7.3.6 Tagregister ----------------------------------------------------------------------------------------------------------------------------------------7-30
7.3.7 SettingDownload---------------------------------------------------------------------------------------------------------------------------------7-33
7.3.8 EtherNet/IPperiodiccommunicationoperationexample-------------------------------------------------------------------------------7-34
7.3.9 Diagnosis-------------------------------------------------------------------------------------------------------------------------------------------7-49
7.3.10 Systemconfiguration----------------------------------------------------------------------------------------------------------------------------7-50
7.4 OPCUAfunction----------------------------------------------------------------------------------------------------------------------------------------7-51
7.4.1 Overview--------------------------------------------------------------------------------------------------------------------------------------------7-52
7.4.2 Parameter setting---------------------------------------------------------------------------------------------------------------------------------7-56

Table of Content
14
7.4.3 OPCUA settings ---------------------------------------------------------------------------------------------------------------------------------7-57
7.4.4 Variableregistration------------------------------------------------------------------------------------------------------------------------------7-60
7.4.5 SettingDownload---------------------------------------------------------------------------------------------------------------------------------7-61
Chapter8 Additionalfunctions-----------------------------------------------------------------------------------------------------------------------------8-1
8.1 Remotecommunication---------------------------------------------------------------------------------------------------------------------------------8-1
8.2 XG5000settingandconnection-----------------------------------------------------------------------------------------------------------------------8-2
8.2.1 Remote1-stageconnection(whenusingUSB)--------------------------------------------------------------------------------------------8-2
8.2.2 Remote2-stageconnection(whenusingUSB) -------------------------------------------------------------------------------------------8-4
8.2.3 CPU accessdirectlyfrom PC connectedto Ethernet -------------------------------------------------------------------------------------8-6
8.3 System configurationusingswitchmodule---------------------------------------------------------------------------------------------------------8-9
8.3.1 Ethernet, RAPIEnetmixedsystem configuration(supportedbyEthernetV6.0orhigher,switchV1.1orhigher)----------8-9
Chapter9 Troubleshooting ---------------------------------------------------------------------------------------------------------------------------------9-1
9.1 LEDErrorCheck------------------------------------------------------------------------------------------------------------------------------------------9-2
9.1.1 Abnormaloperationindicationof XGL-EFMT/EFMF------------------------------------------------------------------------------------9-2
9.1.2 Abnormaloperationindicationof XGL-EFMTB/EFMF----------------------------------------------------------------------------------9-3
9.1.3 AbnormaloperationdisplayofXGL-EH5T---------------------------------------------------------------------------------------------------9-5
9.1.4 AbnormaloperationdisplayofXOL-ES4T/ES4H------------------------------------------------------------------------------------------9-6
9.2 ErrorcheckingmethodbyXG5000connection---------------------------------------------------------------------------------------------------9-7
9.2.1 Error/WarningcheckduringPLC operation------------------------------------------------------------------------------------------------9-7
9.2.2 Error/Warningcheckduringcommunicationmoduleoperation---------------------------------------------------------------------9-14
9.2.3 ViewCommunication ModuleLog-----------------------------------------------------------------------------------------------------------9-27
9.3 XGTdedicatedcommunicationerrorcode-------------------------------------------------------------------------------------------------------9-28
9.3.1 STATUSvaluethatcanbecheckedincommunicationframe------------------------------------------------------------------------9-28
9.4 Troubleshooting by error ------------------------------------------------------------------------------------------------------------------------------9-29
9.4.1 Troubleshooting-----------------------------------------------------------------------------------------------------------------------------------9-29
Chapter10 EMCStandard------------------------------------------------------------------------------------------------------------------------------10-1
10.1 Therequirementsforcompliance withEMCstandards---------------------------------------------------------------------------------------10-1
10.1.1 EMCStandard------------------------------------------------------------------------------------------------------------------------------------10-1
10.1.2 Panel-------------------------------------------------------------------------------------------------------------------------------------------------10-2
10.1.3 Cable ------------------------------------------------------------------------------------------------------------------------------------------------10-3
10.2 Requirementtoconform totheLow-voltageDirective-----------------------------------------------------------------------------------------10-4
10.2.1 StandardsapplicabletoXGTseries---------------------------------------------------------------------------------------------------------10-4
10.2.2 SelectionofXGTSeriesPLC------------------------------------------------------------------------------------------------------------------10-4
Appendix----------------------------------------------------------------------------------------------------------------------------------------------------------------- A-1
A.1XGTCPUmemorydevicelist ----------------------------------------------------------------------------------------------------------------------------- A-1
A.1.1XGKCPUdevices-------------------------------------------------------------------------------------------------------------------------------------- A-1

www.lselectric.co.kr
■ Overseas Subsidiaries
• LS ELECTRIC Japan Co., Ltd. (Tokyo, Japan)
Tel: [phone] E-Mail: [e-mail]
• LS ELECTRIC (Dalian) Co., Ltd. (Dalian, China)
Tel: [phone] E-Mail: [e-mail]
• LS ELECTRIC (Wuxi) Co., Ltd. (Wuxi, China)
Tel: [phone] E-Mail: [e-mail]
• LS ELECTRIC Shanghai Office (China)
Tel: [phone] E-Mail: [e-mail]
• LS ELECTRIC Vietnam Co., Ltd.
Tel: [phone] E-Mail: [e-mail] (Hanoi)
Tel: [phone] E-Mail: [e-mail] (Hochiminh)
• LS ELECTRIC Middle East FZE (Dubai, U.A.E.)
Tel: [phone] E-Mail: [e-mail]
• LS ELECTRIC Europe B.V. (Hoofddorf, Netherlands)
Tel: [phone] E-Mail: [e-mail]
• LS ELECTRIC America Inc. (Chicago, USA)
Tel: [phone] E-Mail: [e-mail]
■ Headquarter
LS-ro 127(Hogye-dong) Dongan-gu, Anyang-si, Gyeonggi-Do, 14119,
Korea
■ Seoul Office
LS Yongsan Tower, 92, Hangang-daero, Yongsan-gu, Seoul, 04386,
Korea
Tel: 82-2-2034-4033, 4888, 4703 Fax: 82-2-2034-4588
E-mail: [e-mail]
■ Factory
56, Samseong 4-gil, Mokcheon-eup, Dongnam-gu, Cheonan-si,
Chungcheongnam-do, 31226, Korea
©2005. LS ELECTRIC Co., Ltd. All Rights Reserved.
2020.06

Table of Content
16

Chapter 1 Overview
1-1
Chapter 1 Overview
1.1Guide to use this manual
This user's manual provides information on the performance specifications and operation methods of each product required
to use the Ethernet (FEnet) module and switch module.
Category
Item
Contents
Chapter 1
Overview
This chapter describes the structure of this manual, product features, and features
provided by version.
Chapter 2
Product
specifications
It describes the general specifications, performance specifications and cable
specifications for PLC. Also, it describes part names and functions.
Chapter 3
Installation and trial
operation
Installation method, setting sequence for operation, cable wiring precautions, trial
operation (module registration, basic setting, download upload, link enable, system
diagnosis). This section explains how to remove and replace the module.
Chapter 4
Smart extension
service
Function overview, Smart extension service operation, Smart extension setting,
Smart extension diagnosis function, Smart extension system.
Chapter 5
HS Link Service
Describes the function overview, high speed link service operation, high speed link
setting, high speed link information, XGR redundancy program method and
Ethernet system configuration.
Chapter 6
P2P service
Function overview, P2P service operation, P2P service setting, user frame
definition overview, operation, setting, E-mail service, P2P parameter download
and diagnosis, XGR redundancy program method are described.
Please refer to Chapter 5 for system configuration.
Chapter 7
Server service
Function overview, XGT server operation, Modbus server overview, Modbus server
operation, EtherNet / IP service operation, EtherNet / IP service setting, EtherNet /
IP service diagnosis, EtherNet / IP system configuration.
Please refer to Chapter 5 for system configuration.
Chapter 8
Additional service
This chapter describes remote communication control, OPC UA function, OPC UA
server setting, and system configuration using switch module.
Chapter 9
Troubleshooting
LED error check, module error check using XG5000, problem-specific
troubleshooting, and communication error code.
Chapter
10
EMC Standard
Describes the requirements for compliance with EMC standards and the
requirements for compliance with the Low Voltage Directive.
Appendix
-
This section describes theXGT CPU memory device list, term descriptions, flag list,
communication relay (L) list, ASCII code table, and dimensions.

Chapter 1 Overview
1-2
1.2Characteristics
Ethernet is a 'technical standard' established by the IEEE, which enables easy network construction and high-speed, high-
capacity data collection through CSMA / CD communication. Ethernet module is a module for data transmission between
upper system such as PC device or PLC using electric / optical media. The Ethernet module supports TCP / IP and UDP / IP
protocols and has the following characteristics.
1.2.1 Ethernet module
Easy module change using module change switch of CPU and module change wizard of XG5000.
Up to 24 Ethernet modules can be installed regardless of the main base and the extension base.(XGR CPU only
supports main base)
Media support based on the IEEE802.3 standard.
Check parameter and service setting,module and network status usingcommunication configuration tool (XG5000).
Dynamic Host Configuration Protocol (DHCP) support for dynamically setting IP addresses.
Provide access table to secure communication with host PC (HMI).
Smart extension service for easy configuration and high speed data communication between our products.
High speed link support for high speed data communication between our products.
Possible to set high speed link block to transfer data between modules(Maximum transmission 32 blocks x 200
words, maximum reception 32 blocks x 200 words, maximum transmission and reception 128 blocks x 200 words).
Communication with up to 16 modules is available in addition to the high speed link.(Dedicated communication
server + P2P communication) (up to 32 modules in Ethernet V6.0 or higher).
The loader service through the Ethernet (XG5000) is supported: (Dedicated TCP/IP PORT: 2002 assignment)
Easy connection with 3rd party modules (system) using P2P communication and XG5000.
Support for dedicated protocols (XGT) and open protocols (EtherNet / IP, Modbus / TCP).
Simple client function for communication between our communication module and other company's modules
(Dedicated Communication, EtherNet / IP, Modbus / TCP, User frame definition client functions).
Provides various diagnostic functions and module and network status information.
- Status of communication module
- Communication service(Smart extension, high speed link,P2P,Dedicated protocol server) status
- The Auto Scan function that provides our module information connected to the network is provided.
- The PING function that allows you to check the existence of a other module is provided.
- The type of packet and data average received by module are provided (Forecast the network load).
- The function to diagnose the communication module through the network is provided.
Provide email service(ASCII)
Provide One IP Solution function
Notes
Supported OS versions of each function are as follows.
1) FEnetOS V 6.0 or higher: Support XGT Cnet dedicated protocol, MODBUS RTU protocol, MODBUS ASCII
protocol ,RAPIEnet protocol.
2) FEnet OS V 8.0 or higher: Supported Smart extension service and EtherNet / IP protocol.
3) XGR CPU OS V2.4 or higher: : Supported One IP Solution function

Chapter 1 Overview
1-3
1.2.2 Switch module
Aswitchmoduleis ahubmodulethathasa switchingfunctionforinterfacingbetweenXGT series Ethernetmodules.Mounting
XGT base module to connect PLC-to-PLC or system-to-system by Ethernet communication.
(1) Can be mounted on XGK / I / R base module (XGL-EH5T)
It can be mounted on XGT base without external power, and its compactsize makes it easy to install insmall spaces.
(2) Supported 1Gbps communication (XOL-ES4T, XOL-ES4H)
100M / 1Gbps communication can be selected. It also supports electric and optical mixing modules.
(3) Supported Ring configuration (XOL-ES4T, XOL-ES4H)
Ring 1 is available between Port1 and Port2, Ring2 is available between Port3 and Port4.
(4) Reliability of Industrial Device Standards
Compared to commercial switches, it guarantees environmental and noise reliability.
(5) Built-in crossover function (provides convenience in cable work)
Direct cables between routers and switch or between PC and switches, cross cables between routers and routers or
switch and switches. Auto Crossover is a device that providesauto-detecting function andcan be connected between
same devices by direct cable.
(6) High speed link operation guarantee
Broadcast Storm, that is, the switch keeps broadcasting traffic and releases the function that causes network down,
so the high speed link packet operates normally.
(7) Provide CHS(chassis) GROUND on RJ-45 connectors.
Transmission error rate is improved when using shielded cables (STP) on RJ-45 connectors.
