LSIS SV-iS7 series User manual

Profibus Option Board
SV-iS7 Series
User Manual
The best choice for your best interests!
LSIS works hard to ensure that all our clients receive the best possible benefits.
Safety Precautions
Please read all safety precautions before
using this product.
After reading this manual, please store it in
a location where it can be easily found.

INSTRUCTIONS TO USERS
iii
INSTRUCTIONS TO USERS
Thank you for your selecting our Profibus-DP option.
This instruction includes how to use the product and the instruction during
handling.
Your wrong handling of this product may cause damage and then it reduces the
duration of the product.
Therefore, please read this instruction carefully and then observes the instruction
without fail.

Safety Precautions
iv
Safety Precautions
Safety Precautions are for using the product safe and correct in order to prevent
the accidents and danger, so please go by them.
The precautions explained here only apply to the iS7 Profibus Option. For safety
precautions on the Inverter system, refer to the iS7 User’s manual.
The precautions are divided into 2 sections, ‘Warning’ and ‘Caution’. Each of the
meanings is represented as follows.
Precaution Definition
Warning If violated instructions, it can cause death, fatal injury or
considerable loss of property.
Caution If violated instructions, it can cause a slight injury or slight loss of
products
The symbols indicated in products and datasheet mean as follows
Symbol Definition
This symbol means pay attention because of danger of injury, fire or
malfunction.
This symbol means paying attention because of danger of electric
shock.
Store this datasheet in a safe place so that you can take it out and read it
whenever necessary. Always forward it to the end user.
Warning
Do not contact the terminals while the power is applied.
It can cause electric shock and malfunction.
Protect the product from being gone into by foreign metallic matter.
It can cause fire, electric shock and malfunction.

Safety Precautions
v
Caution
Be sure to check the rated voltage and terminal arrangement for the module and
observe them correctly.
It can cause fire, electric shock and malfunction.
Tighten up the terminal screw firmly to defined torque when wiring.
If the terminal screw looses, it can cause fire and electric shock.
Do not install around inflammable substances.
It can cause fire.
Use in an environment that meets the general specifications contained in this
datasheet.
It can cause electrical shock, fire, erroneous operation and deterioration.
Be sure that external load does not exceed the rating of output module.
It can cause fire and erroneous operation.
Do not use in the environment of direct vibration.
It can cause electrical shock, fire and erroneous operation.
Do not disassemble, repair or modify except A/S specialist.
It can cause electrical shock, fire and erroneous operation.
When disposing, treat it as industrial waste.
It can cause poisonous pollution or explosion.

Precautions for use
vi
Precautions for use
This option card is for SV-iS7 only. Don’t install it to any other device than
SV-iS7.
When using the product, use the inverter with grounded. For the method of
GND, please refer to the instruction manual of inverter body.
Be sure to connect inverter and option card exactly. For the method of
connection,
Please refer to “6. How to install option” in iS7 User’s Manual.
Do not separating or remodeling the PCB of Option card.
Turn off when install or uninstall the option.
Use Mobile or Radio telegraph at 30cm away from the product.
Input/output signal or communication wire should be 100mm away from high
voltage cable or power line.

Table of Contents
vii
Table of Contents
INSTRUCTIONS TO USERS .............................................................................................. III
SAFETY PRECAUTIONS ...................................................................................................IV
PRECAUTIONS FOR USE .................................................................................................VI
TABLE OF CONTENTS.....................................................................................................VII
1. SUMMARY ............................................................................................................. 1-1
1.1 Introduction.................................................................................................................1-1
1.2 Construction of Product .............................................................................................1-1
2. PRODUCT SPECIFICATION.................................................................................. 2-1
2.1 Basic Communication Specification of Profibus Option ............................................2-1
2.2 Dimension ..................................................................................................................2-2
3. APPEARANCE AND NAME OF EACH PART....................................................... 3-1
4. OPTION INSTALLATION METHOD....................................................................... 4-1
4.1 How to install option to inverter..................................................................................4-1
5. PROFIBUS PARAMETER...................................................................................... 5-1
5.1 Station Address Setting..............................................................................................5-1
5.2 Number of Status Data Setting ..................................................................................5-1
5.3 Number of Control Data Setting.................................................................................5-1
5.4 Address of Output Data Setting.................................................................................5-1
5.5 Address of Input Data Setting....................................................................................5-2
5.6 I/O Data Send/Receive ..............................................................................................5-2
6. BASIC FEATURE................................................................................................... 6-1
7. UNUSUAL OPERATION AND MEASURES .......................................................... 7-1
7.1 DATA_EX LED Operation and Measures against Error............................................7-1
7.2 CPU LED Operation and Measures against Error.....................................................7-2
7.3 Error LED Operation and Measures against Error....................................................7-2
8. CONSTRUCTION OF SYSTEM & TRANSMISSION SPECIFICATION................. 8-1
8.1 Installation of Terminating Resistance and its Specification......................................8-1

Table of Contents
viii
8.2 Max. Transmitting Distance Specification ................................................................. 8-1
9. ENVIRONMENT CONFIGURATION & OTHER FUNCTIONS................................9-1
9.1 GSD Files (Electronic Data Sheets).......................................................................... 9-1
9.2 User Parameter Setting............................................................................................. 9-2
9.3 Extended Diagnostic.................................................................................................. 9-2
10. COMMUNICATION PARAMETER........................................................................10-1
10.1 Map Structure of Whole Communication Parameter in European Style................. 10-1
10.2 Parameter Group for Periodical Transmission........................................................ 10-2
10.3 Parameter Group for User & Macro Grp Transmission .......................................... 10-3
10.4 0h240 ~ 0h27F: Macro Grp Parameter Currently Configured................................ 10-4
11. PARAMETER DESCRIPTION ..............................................................................11-1
11.1 List of iS7 Profibus Communication Related Parameters........................................11-1
11.2 Description of iS7 Profibus Communication Related Parameters...........................11-3
12. EXISTING IS5/IG5/ IG5A COMPATIBLE COMMON AREA PARAMETER..........12-7
13. IS7 EXTENDED COMMON AREA PARAMETER ..............................................13-14
WARRANTY........................................................................................................................ A
MANUAL REVISION HISTORY........................................................................................... B

1. Summary
1-1
1. Summary
1.1 Introduction
You can connect SV-iS7 inverter to Profibus network using Profibus option.
With Profibus option board built in, inverter control and monitoring by PLC
sequence program or optional master module is available.
As a number of inverters in connection operate through one communication line
only, It reduces the installation cost compared with communication being unused.
Furthermore, its simple wiring enables the reduction of installation time and easy
maintenance and repair.
1.2 Construction of Product
Profibus option, (1) 9-Pin Connector, Fixing Screw (M3), Manual

1. Summary
1-2

2. Product Specification
2-1
2. Product Specification
2.1 Basic Communication Specification of Profibus
Option
Device Type : Profibus DP Slave
Auto Baud Rate Detect : Support
Sync Mode : Support
Freeze Mode : Support
Max Input Length : 8 words
Max Output Length : 8 words
Max Data Length : 16 words
Baud Rate Support : 9.6K, 19.2K, 93.75K, 187.5K, 500K, 1.5M,
3M, 6M, 12M
Modular Station : Support
Max Module : 2

2. Product Specification
2-2
2.2 Dimension
93mm
22.5mm
69mm

3. Appearance and Name of Each Part
3-1
3. Appearance and Name of Each Part
Figure 1. Exterior Appearance
LED Display
No. Name Application
①DATA_EX LED Always “On” when Profibus is Online status.
②ERROR LED “On” when error occurs in the option
③CPU LED “On” when the option board is built in the
inverter and power is supplied to the inverter
④Communication connecting Terminal Terminal that connects it with Profibus
communication
⑤Inverter connecting Connector Terminal that connects it with inverter body
※For further operation, please refer to ‘7. Troubleshooting’.
① ②
④
③
⑤

3. Appearance and Name of Each Part
3-2
Communication Line Connecting Terminal
Pin No. Signal Description
1 Shield Protective Ground Line
2 M24 24V Output GND
3 RxD/TxD-P Send/Receive Data Plus
4 CTRL-P Control Signal for Repeater
5 DGND Signal GND
6 VP 5V for Terminating Resistance
7 P24 24V Output Plus
8 RxD/TxD-N Send/Receive Data Negative
9 CTRL-N Control Signal for Repeater
NOTE
This product supports the signal Nos. 3,5,6,8 only.

4. Option Installation Method
4-1
4. Option Installation Method
4.1 How to install option to inverter
1. Power off.
2. Connect connector after isolating front cover from iS7 as shown in Figure
below.
3. Fix by enclosed volt.
4. Power On and Check “Profibus” at parameter, “CNF 31: Option-1 Type”.
CAUTION
Cut off the power when remove the option, it may cause electric shock or break down.
NOTE
1. iS7 has 3 option connectors, they are located in front upper, lower and left side:
Option    at the Figure.
2. Profibus must be connected with Option




4. Option Installation Method
4-2

5. Profibus Parameter
5-1
5. Profibus Parameter
5.1 Station Address Setting
Minimum Value Max. Value Position on Keypad
Field Bus ID 0 125 No. 7 of COM Group
※Station address is a peculiar value distinguishing each node in the Profibus
Network, and therefore each different device cannot jointly possess the same
value. Station address can be changed through Keypad manipulation. Default
value set from the factory is 1.
5.2 Number of Status Data Setting
Determines the number of output data (Variable to be monitored out of the
inverter variables)
Minimum Value Max. Value Position on Keypad
Para Status Num 0 8 No. 30 of COM Group
5.3 Number of Control Data Setting
Determines the number of input data (Variable to be commanded from outside
among the inverter variables)
Minimum Value Max. Value Position on Keypad
Para Ctrl Num 0 8 No. 50 of COM Group
5.4 Address of Output Data Setting
Determines the address setting in the number of data to be output.
Minimum Value Max. Value Position on Keypad
Para Status 1~8 0h0000 0hFFFF Nos. 31~38 of COM
Group

5. Profibus Parameter
5-2
5.5 Address of Input Data Setting
Determines the address setting in the number of data to be input.
Minimum Value Max. Value Position on Keypad
Para Ctrl 1~8 0h0000 0hFFFF Nos. 51~58 of COM Group
5.6 I/O Data Send/Receive
Output data set in the keypad of the inverter is transmitted to Profibus Master
Module (Control Program of PLC or PC) through Profibus Option Module. On the
contrary, the control data is transmitted from Profibus Master Module (Control
Program of PLC or PC) to Profibus Option Module, which is sent from Profibus
Option Module to the inverter.

6. Basic Feature
6-1
6. Basic Feature
When turning on the inverter power or when reset occurs;
CPU LED flashes if power supply is in normal state.
ERR LED is On if power supply is in abnormal state.
Conduct configuration using the keypad.
If the communication with the Master Station as configured, Profibus
communication status DATA_EX LED is Off.

6. Basic Feature
6-2
