Ltech ArtNet-SPI-1 User manual

ArtNet-SPI-1
ArtNet-SPI Converter
1
1. Technical specs
3. Product dimension:
4. Interface instruction:
2
2. Performance features
warranty
5 years
73
120
45
ArtNet-SPI-1 ArtNet-SPI Converter ArtNet-SPI-1 ArtNet-SPI Converter
ArtNet-SPI converter is the Ethernet Control System based on the ArtNet protocol, used to convert the ArtNet
network data package into SPI(TTL) digital signal, adopting high-speed processor, stable and reliable working.
Following ArtNet standard protocol, it supports RJ45 network interface and green terminal output interface.
It is compatible with all the effects lighting control software which support ArtNet protocol, widely used in the
LED dot matrix and the stage lighting.
ArtNet-SPI-1 can control LED lighting with compatible driving IC, such as TM1804/1809, D705, LPD6803/1101,
UCS1903/1909/1912/2903/2909/2912/6909/6912, WS2811/2812/2801/2803, P9813, etc.
SPI(TTL) digital signal
12Vdc (with a power adaptor)
L120×W73×H45mm
L198×W78×H50mm
360g
-30 ~65℃ ℃
Working temp.:
ArtNet
ArtNet-SPI-1
Output signal:
Power input:
Dimension:
Package size:
Weight (G.W):
Input signal:
RJ45
Network connection:
Indoor use onlyIP:
Total isolationIsolation Ethernet port:
Total isolationIsolation power input:
30mA@12VdcCurrent:
2.1 Based on ArtNet protocol network data communication, accept network DMX data, output one set SPI data.
2.2 IP address is bound to SubNet, no need to reset, plug and play.
2.3 Manage ArtNet on broadcast mode or unicast mode.
2.4 Compatible with the light software based on ArtNet protocol, control LED lighting.
2.5 Connect up to 256 DMX universes to one network.
2.6 10/100Mb/s Ethernet port.
2.7 Firmware can be updated via the network.
ArtNet input
Power input
Universe Dip switch
Subnet Dip switch
Status lamp
12
OFF
ON
OFF
OFF
ON
ON ON
OFF
1 2
ON
1 2
ON
1 2
ON
1 2
ON
Diagrams
4
5
6
3
7
2
8
1
9
0
A
F
B
E
D
C
4
5
6
3
7
2
8
1
9
0
A
F
B
E
D
C
Universe
SubNet
1 2
Fun
ON
IC type switcher
(Operation as follows)
Power and LED lamp
connected socket
WS2811/WS2812/GS8206(BGR)/SM16703
TM1804/TM1809/UCS1903/UCS1909/UCS1912/UCS2903/UCS2909/UCS2912
LPD6803/1101, D705, UCS6909/6912
WS2801,WS2803
IC type
P9813
Switching IC type operation instruction:

5. Conjunction diagram:
Universe/SubNet Dip switch
1 2 345678 9 A B C D E F
0
Value 1 2 345678 9 10 11 12 13 14 150
Calculating method: Group address = Subnet×16 + Universe, IP Address = 2.xx.xx.group address,
MAC address=44-4d-58-2d-31-group address (xx is the random number generated by the factory)
For example: Subnet: 2, universe: B, group address=2×16 + 11 = 43, so the DMX output
group address is 43, corresponding IP address is 2.xx.xx.43, MAC address is 44-4d-58-2d-31-43.
3 4
7. Warranty agreement:
7.1 We provide lifelong technical assistance with this product:
★This manual only applies to this model. We reserve the right to make changes without prior notice.
7.4 Any amendment or adjustment to this warranty must be approved in writing by our company
only.
7.3 Repair or replacement as provided under this warranty is the exclusive remedy to the
customer. We shall not be liable for any incidental or consequential damages for breach
of any stipulation in this warranty.
7.2 Warranty exclusions below:
For faults beyond the 5-year warranty, we reserve the right to charge for time and parts.
A 5-year warranty is given from the date of purchase. The warranty is for free repair or
replacement if cover manufacturing faults only.
Any man-made damages caused from improper operation, or connecting to excess voltage
and overloading.
6. Attention:
6.1 The product shall be installed and serviced by the qualified person.
6.7 If a fault occurs, please return the product to your supplier. Do not attempt to fix this product
by yourself.
6.6 Ensure all wire connections and polarities are correct before applying power to avoid any
damages to the LED lights.
6.5 Please ensure that adequate sized cable is used from the controller to the LED lights to carry
the current. Please also ensure that the cable is secured tightly in the connector.
6.4 Please check if the output voltage of the LED power supply used comply with the working
voltage of the product.
6.3 Good heat dissipation will prolong the working life of the controller. Please ensure good
ventilation.
6.2 This product is non-waterproof. Please avoid the sun and rain. When installed outdoors, please
ensure it is mounted in a water proof enclosure.
Update time: 2018.09.25
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
www.ltech-led.com
ArtNet-SPI-1 ArtNet-SPI Converter ArtNet-SPI-1 ArtNet-SPI Converter
Address setting instruction:
Computer
ArtNet-SPI-1
Cable
ArtNet-SPI-1
ArtNet-SPI-1
Cable
Cable
CAT5
CAT5
CAT5
Switch
CAT5
ArtNet-SPI-1
Cable
CAT5
ArtNet-SPI-1
Cable
CAT5
