LUCCI AIRFUSION CLIMATE II LD52WH User manual

CEILING FAN MANUAL
INSTALLATION
OPERATION
MAINTENANCE
WARRANTY INFORMATION
LUCCI
AIRFUSION CLIMATE II
DC
CEILING FAN
Version 1.1-Muti – Last updated on July 31, 2013 – © Copyright 2013 – LUCCI

2
CONTENTS
GB Installation Instruction Manual ............................................................................................. 3
D Installationsanleitung ............................................................................................................17
F Guide d’installation.................................................................................................................30
E Manual de instrucciones de instalación.................................................................................43
I Manuale delle istruzioni di installazione.................................................................................57
NL Installatiehandleiding.............................................................................................................70

3
CONGRATULATIONS ON YOUR PURCHASE
Congratulations on purchasing the latest in energy saving ceiling fans. This fan runs on DC (direct current)
power which gives it the benefit of being super energy efficient whilst still maintaining high volume
air-movement and silent operation.
Energy Saving - The DC motor is the latest technology in fan design. Its highly efficient motor saves up to 65%
energy than ceiling fans with traditional AC motors.
Silent operation – this DC fan motor is programmed with a stabilized current which efficiently reduces motor
noise.
Low operating temperature – The DC power is managed effectively which brings down the motor operating
temperature to less than 50degs. This results in a much cooler motor than a standard AC fan and increases
the longevity of the motor.
6 speed remote control, regular AC ceiling fans usually come with only 3 speeds, this DC fan comes complete
with a 6 speed remote, which give greater choice of comfort levels.
SAFETY PRECAUTIONS
1) This appliance is NOT intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
2) Children should be supervised to ensure that they do not play with the appliance.
3) The all-poles disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
4) Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the collection
systems available. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
5) The structure to which the fan is to be mounted must be capable of supporting a weight of 30kg.
6) The fan should be mounted so that the blades are at least 2.3 meters above the floor for Europe.
7) The fan should be mounted so that the blades are at least 2.1 meters above the floor for Australia.
8) The fan is designed for indoor use only. Mounting the fan in a situation where it is subject to water or
moisture is dangerous.
9) Only an authorized electrician should execute the installation.

4
BEFORE INSTALLATION
Unpack your fan and check contents. You should have the following:
1 mounting bracket x 1 7 Remote transmitter with holder x 1 set
2 Fan assembly with hanger cover, down rod,
canopy cover and canopy x 1
8 Extra Motor screws x 1 (not shown)
3 Blades x 3 9 Wooden screw x 2 (not Shown)
4 Blade fiber x 3 10 Balancing kits x 1 set (not shown)
5 Blade bracket kit x 3 11 Screw for remote holder x 2 (not shown)
6 Bottom cover x 1 12 12V Battery for remote x 1 (not shown)
Fig. 1

5
TOOLS REQUIRED
TOOLS REQUIRED：
- Phillips / Flat head screw driver
- Pair of pliers
- Adjustable Spanner
- Step ladder
- Wire cutter
- Wiring, supply cable as required by local provincial and national wiring codes and regulations.
INSTALLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are 300mm spacing from the tip of the blade to the
nearest objects or walls.
Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 30KG, with two
long screws provided. Ensure at least 30mm of the screw is threaded into the support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures other than wood,
the appropriate screw type MUST be used.
Angled Ceiling Installation
This fan hanging system supports a maximum 20 degree
angled ceiling installation.
Fig. 2
Fig. 3

6
HANGING THE FAN MOTOR ASSEMBLY
Installing Down rod
Lift fan assembly onto mounting bracket. Fig.4
Ensure the notch of ball joint is positioned on the stopper of mounting bracket to prevent fan from rotating when in
operation. Fig. 5
PREPARE AND COMPLETE THE ELECTRICAL WIRING --- WIRING DIAGRAM
(FIG. 6)
WARNING! FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A LICENSED
ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED WIRING.
NOTE: IF THERE IS TWO OR MORE DC CEILING FAN INSTALLED IN THE ONE LOCATION, AN ISOLATION
SWITCH IS REQUIRED FOR EACH CEILING FAN. THIS IS REQUIRED WHEN PROGRAMMING THE REMOTE
AND RECEIVER TO PAIR TOGETHER.
Fig. 4 Fig. 5
Fig. 6

7
INSTALL CANOPY COVER
Loosen 2 screws from the bottom of the mounting bracket.
Slide the canopy up to the mounting bracket and place the key hole on the canopy over the screw on the mounting
bracket, turn canopy until it locks in place at the narrow section of the key holes, secure it by tightening the two set
screws. Avoid damaging the electrical wiring prepared previously.
Finally attach the canopy cover to canopy and secure it by pushing the lugs into the holes.
BLADE INSTALLATION
Insert the blade screws through blade assembly consist of the following order, bracket kit, blade, and fiber. Attach
the blade assembly to motor and secure it by tightening the 2 screws. Fig. 11
Repeat to install the other blades.
Finally install the bottom cover to shaft of motor by rotating it clockwise.
Fig. 7
Fig. 8

8
LIGHT KIT Installation (Light kit - optional)
Note: Light kit must be installed by a Licensed
Electrician.
NOTE: The light kit is available for selected ceiling fan
models and as an optional light kit.
1. Remove the bottom cover from shaft.
2. Remove the shinkable tube from light wires
connector.
3. For light kit installation, please refer to light kit
installation user guide.
USING YOUR CEILING FAN WITH REMOTE CONTROL
Pairing Transmitter and Receiver – when 2 or more DC ceiling are installed in one location
When two or more fans are located near each other, you may desire to have the receiver/transmitter for each fan set to
a different code, so that the operation of one fan does not affect the operation of the other fans.
The DIP switches for the transmitter (remote hand piece) are located in the battery compartment of the transmitter.
Configuring the DIP switches will allow a unique transmission code assigned to each fan ceiling.
NOTE: Ensure that you have installed an all - poles disconnection switch in the fixed wiring for each fan, when using DIP
code function.
NOTE: Ensure power to the Receiver is ON prior to pairing the transmitter with the receiver.
Transmitter/Receiver pairing for ceiling fan 1:
Turn off both ceiling fans 1 and 2 via the mains supply to the receiver.
Slide the cover of battery compartment of transmitter to access the DIP switches. This will be transmitter 1.
Change the position of the DIP switches in the remote transmitter 1, so that it will be different to transmitter 2. Fig.13
Install the 12VDC battery in the compartment. Please make sure the polarity of battery is correct.
Turn on the power to receiver 1. Keep the power OFF to receiver 2. (Each ceiling fan must have its own isolation
switch, so that only the Ceiling fan that needs to be paired with the transmitter will be ON).
Press and hold the SET button of transmitter 1 for 6 seconds within 60 seconds of switching the power to the
receiver of Ceiling Fan 1.
Now the transmitter should be paired with the receiver of ceiling fan 1. Turn ON/OFF or change the speed of ceiling
fan 1 by the transmitter to check the operation.
Fig. 9

9
Setting DC Ceiling fan 2:
Turn off both ceiling fans 1 and 2 via the mains supply to the receiver.
Slide the cover of battery compartment of transmitter to access the DIP switches. This will be transmitter 2.
Change the position of the DIP switches in the remote transmitter 2, so that it will be different to transmitter 1. Fig.12
Install the 12VDC battery in the compartment. Please make sure the polarity of the battery is correct.
Turn on the power to receiver 2. Keep the power OFF to receiver 1. (Each ceiling fan must have its own isolation
switch, so that only the Ceiling fan that needs to be paired with the transmitter will be ON).
Press and hold the SET button of transmitter 2 for 6 seconds within 60 seconds of switching the power to the
receiver of Ceiling Fan 2.
Now the transmitter should be paired with the receiver of ceiling fan 2. Turn ON/OFF or change the speed of the
ceiling fan 2 by the transmitter to check operation.
Note: The pairing of Transmitter and Receiver is not required if only one Ceiling fan is installed. When more
than two ceiling fans are installed near each other, please refer to the instruction above.
Remote Control Buttons
○
1 - FAN SPEED CONTROL BUTTON:
There are 6 available speeds.
○
I button is for the lowest
speed, and ○
VI button is for the fastest speed.
NOTE: WHEN YOU TURN ON THE FAN THE FIRST TIME
OR SWITCH THE MAIN POWER TO THE CONTROLLER,
YOU NEED START THE FAN ON HIGH “○
VI ” SPEED
FIRST, AND THEN CHOOSE A LOWER SPEED.
A 5-10 SECONDS IS REQUIRED TO ALLOW THE DC FAN
TO RESPOND TO THE REMOTE EACH SPEED OR FAN
DIRECTION SELECTIONS, AS DC FAN INCORPORATE A
SENSOR CONTROL WHICH CONTROLS THE POWER
TO THE MOTOR. Fig. 11
Fig. 10

10
○
2 - FAN OFF BUTTON:
Press the button to turn the fan off
○
3 - REVERSE FUNCTION BUTTON:
Press the button to active reverse running function. The fan must be operating to activate the reverse function.
○
4 - LIGHT CONTROL BUTTON:
Press the button to turn on/off the light.
THE RECEIVER PROVIDES THE FOLLOWING LEVEL OF PROTECTIONS AGAINST.
Lock position: the receiver has a built in safety feature to protect against obstruction during operation. The motor will
be locked from operation and will disconnect from power after 30 seconds of interruption. Please remove obstacles
before re-starting. To reset, simply turn off the power supply to the fan motor and re-start.
Over 80W protection: when the receiver detects power consumption which is greater than 80W, the receiver power
will be stopped and operation will immediately discontinue. Turn the receiver power on after 5 seconds to restart the
fan.
REPAIRING THE FAN RECEIVER & REMOTE PAIRING
Should the remote and receiver lose control after installation or during use, the pairing of the remote and the
receiver must be repaired. Below are the operating symptoms and method to repair the pairing of the DC ceiling
fan remote and receiver
Issues:
Loss of control - Fan only running at high speed after installation
Loss of control - No reverse function after installation
Loss of control - remote cannot communicate with receiver
Solution:
If the fan runs at the highest speed continuously, it means the wiring of the installation is correct. When the fan operated
on high speed only, or fails to operate in reverse function or any other command/s, it is recommended to repair the
communication pairing of the remote and receiver. Please follow the steps below:
A. Remove the battery cover of remote, check the 434 MHz sticker area, make sure the battery is installed correctly
and the red LED light indicator will be flashing, it means the remote function is okay.

11
B. Turn off the main supply to receiver more than 30 seconds and turn on the main supply to receiver again. Press and
hold the SET button of remote for 6 seconds within 60 seconds of turning turn the power to the receiver.
C. Press the buttons on the remote to run the fan. In general, performing point A, B, and C should repair the remote
and receiver, and will allow full control of the fan. If not, please kindly do the next step.
D. The DIP switches of fans are set up at the factory in all up. And we can change DIP switch at any location in 16
options. (Ex. up-up-down-down).
E. Please repeat the (A)~(C) steps to check the function.
If the issues still persist after following point (A) to (D), and there is still no control, then please contact the local retailer for
a new remote or transmitter.

12
Note: For your safety, new receiver must be installed by a licensed electrician.
Note: While repairing the DC ceiling fan remote and receiver is in process, the fan operates at highest speed
with REVERSE mode automatically for 90 seconds, and then operates with FORWARD mode for 90 seconds.
During the paring process, do not press any key on the remote.
BALANCING / WOBBLYING TROUBLE SHOOTING
Please note that all ceiling fans are not the same, even in the same model—some may move more or less than others.
Movement of a couple of centimetres is quite acceptable and does not suggest the fan will fall down.
Even though all blades are weighted and grouped by weight, it is impossible to eliminate wobble altogether. This should
not be considered a fault. Ceiling fans tend to move during operation due to the fact that they are not generally rigidly
mounted
You may do the following action to reduce the wobbling
1) Check all the blade mounting screws are tightened and securely.
2) Wobbling problems may result from inconsistent blade level. To check blade level, measure the distance from each
blade tip to the ceiling.
Note: If measurements are inconsistent:
- check blade mount screws are not over tightened or loose, which can cause the blade tip to not all sit level;
- An out of shape blade can cause wobbling, check by removing the blade and lay in on a flat surface. A good flat
blade will lay flat on the surface.
3) Blade tracking may be checked simply by use of a household ruler as shown in below Figure. Place the ruler
vertically against the ceiling and even with
the outside leading edge of a blade. Note
the distance of the edge of a blade same as
others. Turn the blade slowly by hand to
check the remaining blades. If a blade is
not in alignment, the blade is either out of
shape / warped or the blade screws are not
evenly tighten or either loose.
BALANCING KIT
1. A Balancing Kit is provided to balance the ceiling fan on initial installation. Please refer to the instruction on how to
use the Balancing Kit, that is included
2. The balancing kit can be used to assist re-balancing if the ceiling fan becomes un-balanced overtime. Do not discard
the balancing kit. Retain for possible future use.
FAN CARE AND WARRANTY INFORMATION
CARE & CLEANING
Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free cloth to avoid
scratching the paint/plated finish. Please make sure the fan is not operating when cleaning.
Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and create the possibility
of an electrical shock.
Fig. 12

13
WARRANTY SERVICE
The manufacturer warranty covers actual faults that may develop, but NOT minor complaints, e.g. noise from motor
run—ALL ELECTRIC MOTORS ARE AUDIBLE TO SOME EXTENT.
AUSTRALIAN/NEW ZEALAND CUSTOMER – Please refer to the separated WARRANTY STATEMENT.
EUROPEAN CUSTOMER – Please contact the retail outlet where the fan was purchase for warranty service.
WOBBLE
Ceiling fan tend to move during operation due to the fact that they are not generally rigidly mounted—if they were,
they could generate excessive ceiling vibration and stress on their Mountings.
Movement of a couple of centimetres is quite acceptable and does not suggest the fan will fall down.
Ceiling fans are mounted very securely on steel brackets with rubber cushioning or with ball-joints to allow free
movement.
Please note that all ceiling fans are not the same, even in the same model—some may move more or less than
others.
NORMAL WEAR AND TEAR
Threaded components working slighting loose or blade carriers even slightly bent due to vigorous cleaning or bumping
can cause extra wobble and noise. THIS IS NOT COVERED UNDER WARRANTY- but a little care and maintenance
can reduce or prevent this problem.
BUMP-IN-THE NIGHT
This is outside the manufacturer’s warranty. If a fan has a fault, it will be noticeable at all times. Naturally, when
everything is quiet at night, you will be more inclined to hear small noises, which may not be noticeable at other times.
Even slight power fluctuations and mains frequency signals superimposed in your electricity supply may cause a
change in fan motor noise, this is normal.
FAN LIGHT
Except for actual fault in manufacture, which are extremely rare. FAN LIGHTS AND GLOBES ARE NOT COVERED
UNDER YOUR FAN WARRANTY. Noises and vibration etc. are often more accentuated when a fan light is fitted.
For instance a fan light glass that has not been tightened or worked loose can cause a rattle. Again, care and
maintenance will reduce this.

14
TROUBLE-SHOOTING CHECKLIST
Always check the “Trouble Shooting Checklist” included in this booklet before calling for service. Unnecessary calls are
inconvenient for all and can attract a service charge.
For your safety, ensure the ceiling fan is OFF before carrying out any troubleshooting.
WARNING: THE CEILING FAN MUST BE SWITCHED OFF, BEFORE TROUBLE SHOOTING IS
PERFORMED.
NOTES TO INSTALLERS
All electric motors, including fans make some noise and may feel hot if touched—this is not a fault.
Some fan wobble more than other—even in the same model.
Fan lights can rattle, but are not covered under warranty
Fan wall controller make slight buzz and get warm especially on lower setting
These occurrences are not covered by the manufacturer’s warranty.
TROUBLE PROBABLE CAUSES SUGGESTED REMEDY
1. Fan will not start
(Warning: THE ceiling
must be switched OFF,
and the assistance of a
licensed electrician
maybe required.)
A. Fuse or circuit breaker blown.
Check main and branch circuit fuses or circuit breakers.
B. Loose power connections to
the fan. (normally occur during
installation.
Check power connections to fan. Must be
performed be a Licensed Electrician.
C. No response from the remote
transmitter
- Battery is low. Replace batteries.
- Check if correct remote transmitter is paired
with the receiver.
D. Switch the Fan ON via the
mains switch. Check if there is power to the fan.
2. Fan Wobbles
(Refer to Wobble
section of the manual
for further information.)
A. Fan blades are not horizontal
to ceiling.
Refer to “wobbling fixing” section of manual.
- The blade may require adjustment at the
blade mounting screws;
- The blade is out of shape, thus causing
wobbling. New blades set will require to
be replaced. Contact retailer for further
details.
B. Blade screws are loose. Make sure all screws are securely fastened.
C. Blade/s are out of shape
Remove blade and lay on a flat surface to check
if blades are out-of-shape. Contact retailer for
further details.
3. Fan sound noisy
A. Top canopy touching ceiling.
Lower Canopy from ceiling to ensure minimum 3 mm clearance.
B. Loose fan blade screws.
Re-tighten all screws on fan blades but never over-tighten.
C. Ceiling fan not secured
against ceiling. Re-tighten all screws in the hanging bracket or plate.
D. Incorrect speed controller.
Change the controller to the one supplied. (Must be performed by a Licensed Electrician.)
4. Mechanical Noise A. Allow at least for 8 hours
settling-in period.
5. Light will not turn
ON (Optional light kit
ONLY) The globe/lamp has failed. Replace globe/lamp

15
TECHNICAL INFORMATION
AIRFUSION CLIMATE
SERIES DC FAN
models Rated Voltage Rated power (motor) Battery for remote
LD52BN,LD52WH
LD52CC,LD52AB 220-240VAC 35W 1 x 12V 23AE
WARRANTY CONDITIONS
IN AUSTRALIA / NEW ZEALAND CUSTOMER – Please refer to the separated WARRANTY STATEMENT.
IN EUROPE – If you are a European Customer Please contact the retail outlet where the fan was purchase for warranty
service.
This product is guaranteed against electrical defects in material or manufacturing workmanship for faults when
under normal domestic/residential conditions for a certain period of time from the date of purchase. This
warranty covers parts and labour costs for the motor subject to the following conditions:
1. Installation being performed by a qualified licensed Electrician.
This warranty will not apply if the ceiling fan is installed by anyone other than a licensed electrician.
Problems arising from incorrect installation are not covered by warranty. The cost of repairs and/or service
call where the defect is due to the installation and not due to faulty material or workmanship, in accordance
with wholesaler and their authorized agent, will be payable at time of repair.
2. The correct controller being fitted to the fan.
Only use the controller supplied with the fan or a genuine replacement. Using solid-state dimmer type or
non-genuine controllers will void the warranty. Use of non-genuine controllers may cause the fan to
operate with a loud hum and at altered speeds. Where controllers are supplied complete with light switch
– do not use this switch to operate the fan. Fans connected using this switch to turn the fan on/off, will not
be covered by warranty.
3. Repair work being carried out by licensed electrician only after authorization by wholesaler or their
authorized agent to complete the repair and is subject to the supply of dated proof of purchase and
installing electricians details.
4. The exclusion from warranty of any changes to ceiling fan blade or motor, plated and/or painted finishes
due to climatic conditions (moisture, salt air etc) or after 6 months from the date of purchase or other
circumstances deemed to be beyond the control of wholesaler or their authorized agents.
5. The warranty service does not cover:
a. Transportation and in-transit insurance costs, if the product or parts thereof have to be returned for
repair or replacement to the retailer or their authorized agent.
b. Repair of defects caused by accident, fire, misuse, alterations modification, negligence, incorrect or
incomplete installation/operation, any unauthorized person attempting to repair the ceiling fan, or
acts of God.
c. Claims or damage to furniture, carpet, wall, ceilings or any other consequential loss either direct or
indirectly resulting from a faulty ceiling fan.
6. Except in the case of pre-packed integrated light models, light fittings attached to the fan are not covered
by this warranty. Where the fan is pre-packed complete with a light, the light fitting will be covered by
warranty to electrical defect. Tarnishing caused by climatic conditions and breakage of glass is not covered
by warranty. Globes/lamps are also not covered by warranty. All light fittings attached to the fan must be

16
installed by a qualified licensed Electrician ensuring such attachments are complete and do not affect the
fan’s performance. Light fittings will often accentuate noises and vibrations, which can be traced to loose
glass or fittings and are not covered by warranty. Broken glass as supplied in the pre-packed light complete
models is not considered an item requiring a warranty service call. Notification within 48 hours of
installation is required where glasses have found to be broken on unpacking.
7. The warranty applies to actual faults which may develop. Minor running noises are not covered. All
electrical motors have some audible noise. Allow at least eight hours of operation to allow the bearings to
properly seat. The fan, especially when set on low, may feel warm to touch – this is not a fault. If excessive
heat is generated a service call may be required. Fan noises can vary due to slight power fluctuations and
mains frequency signals for off – peak-controlled appliances. These changes are most noticeable in the
quiet of night, mains frequency signals which come across as an intermittent hum (mostly at night) are out
of control of the manufacturer in these cases your electricity provider should be contacted, or an
electrician to fit a suitable noise filter.
8. Threaded components such as blade nuts can work slightly loose during normal operation. These should
be tightened regularly to ensure the fan doesn’t develop operation noises. If noises do develop, check this
aspect before requesting service. This is not covered by warranty.
9. Minor variation of speed may be evident between different fans, even in the same model and is not a
product fault and not covered by warranty.
10. Blades are not covered by warranty against defect in material. The replacement of the blades is not covered
by the in home warranty service call, Notification within 48 hours of installation is required where blades
have found to be broken on unpacking, contact the retailer or their authorized agent who will send you a
new set of blades. Each blade set is balanced so it is important to replace all blades. Blades affected by
climatic conditions and by maintenance are not covered by this warranty.
This warranty applies only to Australian states and its mainland territories and New Zealand. The benefits of
this warranty are in addition to any rights offered under state or territory law.
For a warranty service, contact the warranty hotline number in this booklet and advise: the model number and
style, the nature of the fault, date and place of purchase. Service cannot be arranged without this information.
Please also not the following, prior to requesting service, please consult the Trouble-shooting checklist that is
printed in the manual
All electric motors, including fans, make some noise and may feel hot to touch – this is not a fault.
Some fans wobble more than others – even the same model.
Blades are weighed to be within tolerance to minimize wobbling. In multiple installations do not mix
blades from fans.
Fanlights can rattle and are not covered by warranty.
Finish to the fan, including blades and light complete models, are covered by 2 Years warranty.
Blade and glass replacements are not covered by in home servicing.

17
WIR GRATULIEREN ZUM KAUF DIESES GERÄTES
Herzlichen Glückwunsch zum Kauf dieses mit der neuesten Stromspartechnologie ausgerüsteten Ventilators. Dieser
Ventilator wird mit DC Gleichstrom (Direct Current) betrieben, wodurch das Gerät extrem viel Strom spart, aber dennoch
eine hohe Ventilator-Effizienz und ein leiser Betrieb des Gerätes erzielt werden.
Energiesparend – Der DC Gleichstrommotor repräsentiert die neueste Technologie im Ventilatordesign. Der Motor ist
hoch-effizient und spart bis zu 65% Energie im Vergleich mit Ventilatoren, die mit traditionellen AC-Motoren ausgestattet
sind.
Geräuscharmer Betrieb – Der DC Gleichstrommotor dieses Ventilators arbeitet mit stabilisiertem Gleichstrom, wodurch
der Geräuschpegel des Motors sehr effektiv reduziert wird.
Niedrige Betriebstemperatur – DC-Strom kann sehr effizient reguliert werden, wodurch sich die Betriebstemperatur des
Motors auf unter 50 Grad reduziert. Da durch den Gleichstrombetrieb eine niedrigere Betriebstemperatur erzielt wird,
verlängert sich die Lebensdauer des Motors im Vergleich zu standardmäßigen AC Wechselstrommotoren.
Herkömmliche AC Deckenventilatoren mit 6-stufigen Steuerungen bieten dennoch nur 3 Geschwindigkeitsstufen an;
dieser DC-Deckenventilator kann effektiv 6 Geschwindigkeitsstufen regulieren und bietet somit eine größere Auswahl an
Geschwindigkeitseinstellungen an.
SICHERHEITSHINWEISE
1) Dieses Gerät ist NICHT für den Gebrauch durch Personen (einschließlich Kindern) mit körperlichen,
sensorischen oder geistigen Behinderungen geschaffen, oder durch Personen, die keine Erfahrung im
Umgang mit dem Gerät haben, oder mit dem Gerät nicht vertraut sind, vorausgesetzt diese wurden zuvor
ausreichend über den Betrieb des Gerätes durch die, für deren Sicherheit zuständige Personen
unterwiesen.
2) Kinder müssen beim Betrieb dieses Gerätes beaufsichtigt werden, so dass diese nicht mit dem Gerät
spielen.
3) Eine allpolige Stromtrennung für alle Anschlussleitungen muss in der Kabelinstallation gemäß den
Installationsanweisungen integriert werden.
4) Entsorgen Sie elektrische Geräte niemals im Hausmüll, sondern geben Sie diese an den
dafür vorgesehenen Sammelstellen ab. Treten Sie mit Ihrer örtlichen Verwaltung für
Hinweise zur ordnungsgemäßen Entsorgung dieses Gerätes in Kontakt. Wenn elektrische
Geräte in Aufschüttungen oder Müllhalden entsorgt werden, können gefährliche
Substanzen in das Grundwasser ausgespült werden und so in die Nahrungskette
gelangen, wodurch Gesundheitsschäden und andere Störungen des Wohlbefindens
verursacht werden können.
5) Die Halterung, an der dieser Ventilator befestigt werden soll, muss für eine Mindestlast von 30kg
ausgelegt sein.
6) In Europa sollte der Ventilator so an der Decke befestigt werden, dass sich die Ventilatorflügel
mindestens 2,3m über dem Boden befinden.
7) In Australien sollte der Ventilator so an der Decke befestigt werden, dass sich die Ventilatorflügel
mindestens 2,1m über dem Boden befinden.
8) Dieser Ventilator ist nur für den Einsatz in geschlossenen Räumen geschaffen. Durch die Installation an
Orten, wo der Ventilator Wasser oder Feuchtigkeit ausgesetzt würde, setzen Sie sich möglichen
Personenverletzungen oder anderen Gefahren aus.
9) Die Installation des Gerätes sollte nur von einem qualifizierten Elektriker ausgeführt werden.

18
VOR DER INSTALLATION
Packen Sie Ihren Ventilator aus, und überprüfen Sie den Packungsinhalt. In der Verkaufspackung sollten sich die
folgenden Komponenten befinden:
1Halterung x 1 7Fernbedienung mit Wandhalterung x 1 set
2Ventilator-Einheit mit Abdeckung für
Aufhängung, Haltestange, Schirmabdeckung
und Schirm x 1
8Zusätzliche Motorschrauben x 1 (nicht
dargestellt)
3Ventilatorflügel x 3 9Holzschrauben x 2 (nicht dargestellt)
4Ventilatorflügel-Einlagen x 3 10 Balanciergewichte x 1 set (nicht dargestellt)
5Ventilatorflügel-Halterungssatz x 3 11 Schrauben für Halterung der Fernbedienung x
2 (nicht dargestellt)
6Untere Abdeckung x 1
12 12V Batterie für Fernbedienung x 1 (nicht
dargestellt)
Abb. 1

19
BENÖTIGTE WERKZEUGE
BENÖTIGTE WERKZEUGE:
- Phillips-/Schlitzschraubenzieher
- Zange
- Verstellbarer Schraubenschlüssel
- Stehleiter
- Kabelzange
- Kabel, Zuleitungskabel gemäß den örtlichen, nationalen und regionalen Vorschriften mit entsprechender
Kodierung.
INSTALLATION DER HALTERUNG
Der Deckenventilator muss an einem Ort installiert werden, wo die Flügelspitzen mindestens einen Abstand von 30cm
zum nächsten Gegenstand oder der Wand haben.
Befestigen Sie die Halterung an einem sicheren Deckenträger oder einer strukturell äquivalenten Stelle, die ein Gewicht
von mindestens 30KG tragen kann, und verwenden Sie dazu die zwei mitgelieferten Schrauben. Stellen Sie sicher, dass
die Schraubengewinde mindestens 30mm in den Untergrund eingedreht werden.
HINWEIS: Die für die Halterung mitgelieferten Schrauben sind nur für den Einsatz mit Holzstrukturen geeignet.
Für andere Materialien MÜSSEN entsprechend geeignete Schraubentypen verwendet werden.
Installation an geneigten Decken
Dieses Ventilatorhalterungssystem ist nur für die Installation an
Decken mit einer Neigung von maximal 20 Grad geeignet.
Abb. 2
Abb. 3

20
ANHÄNGEN DES VENTILATOR-MOTORGEHÄUSES
Installation der Hängestange
Heben Sie das Ventilatorgehäuse mit Hängestange an und hängen Sie diese in die Halterung ein. Abb.4
Stellen Sie sicher, dass die Nut der Kugelgelenkverbindung mit dem Anschlag der Halterung in Kontakt ist, um den
Ventilator daran zu hindern sich zu verdrehen. Abb. 5
VORBEREITUNG UND DURCHFÜRUNG DER VOLLSTÄNDIGEN
ELEKTRISCHEN INSTALLATIONSARBEITEN VERSCHALTUNGSDIAGRAMM
(ABB. 6)
WARUNG! UM IHRE PERSÖNLICHE SICHERHEIT ZU GEWÄHRLEISTEN, MÜSSEN ALLE ELEKTRISCHEN
ANSCHLÜSSE VON EINEM QUALIFIZIERTEN UND ZUGELASSENEN ELEKTRIKER AUSGEFÜHRT WERDEN.
HINWEIS: EIN ZUSÄTZLICHER TRENNSCHALTER, DER ALLE ANSCHLUSSPOLE TRENNT, MUSS IN DIE
STATIONIONÄRE VERKABELUNG INTEGRIERT WERDEN.
HINWEIS: FALLS ZWEI ODER MEHR DC DECKENVENTILATORN AN EINEM ORT INSTALLIERT SIND; MUSS
EIN ALLPOLIGER TRENNSCHALTER FÜR JEDEN DC-VENTILATOR INSTALLIERT WERDEN. DIESE SIND
NÖTIG, SO DASS DIE BEIDEN FERNBEDIENUNGEN UND EMPFÄNGER SO PROGRAMMIERT WERDEN
KÖNNEN, DASS DIESE KORREKT ZUSAMMENARBEITEN.
Abb. 4 Abb. 5
Abb. 6
Halterung
Anschlag der
Halterung
Nut der
Kugelgelenkverbindung
