LUCCI AIRFUSION BREEZE User manual

V1.0- E N ( 0 8 / 2 0 1 8 )
LUCCI
AIRFUSION BREEZE
PEDESTAL FAN
⚫INSTALLATION
⚫OPERATION
⚫MAINTENANCE
⚫WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Breeze Pedestal Fan Installation Instructions
1 | Page
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and
save all instructions before using the product.
SAFETY PRECAUTIONS
1. In Europe: This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning the use of the appliance in a safe way and understand the hazards
involved. Cleaning and maintenance shall not be undertaken by children without supervision.
2. In Australia: The appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance by a person responsible for their safety.
3. Children should be supervised to ensure that they do not play with the appliance.
4. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available. If electrical
appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and well-being.
5. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the
manufacturer or its service agent.
6. Ensure that fan is switched off and unplug from the mains socket outlet before removing the guard for
cleaning.
7. Do not operate any product with a damaged cord or plug, after the product malfunctions, is dropped or
appears damaged in any way. Return the complete product to the place of purchase for inspection, repair
or replacement.
8. Switch off and unplug from the mains socket outlet when not in use, before assembling or disassembling
parts and before cleaning. Fully assemble the fan before switching on.
9. Avoid contact with moving parts. Do not insert any object through the grill when the fan is operating.
10. Do not cover the grill, or operate in close proximity to curtains, etc.
11. This fan is suitable for indoor use only.

Breeze Pedestal Fan Installation Instructions
2 | Page
PARTS LIST
Unpack your fan carefully. Examine all parts. You should have the following:
1
Fan head assembly x 1
7
Heavy base x1
2
Height adjustment pipe x 1
8
Flat washer x 1
3
Power cord clip x 1
9
Spring washer x1
4
Height adjustment ring x 1
10
Base locking screw x 1
5
Standing pipe x1
11
Tilt adjustment knob x 1
6
Standing base x1
12
Fixed knob X 1
Fig. 1

Breeze Pedestal Fan Installation Instructions
3 | Page
ASSEMBLING THE FAN
1. Loosen the base locking screw (10), spring washer (9) and flat washer (8) from the standing pipe. Fig. 1
2. Attach the standing pipe (5) onto the standing base (6). Install the base locking screw (10) through the spring washer
(9), flat washer (8), heavy base (7) and then tighten the base locking screw (10) to secure the standing pipe (5). Fig.1
3. Loosen the height adjustment ring (4) and pull out the height adjustment pipe (2) to the desired height.
Tighten the height adjustment ring (4) firmly. Fig. 1
4. Place the fan head assembly (1) onto the top of the height adjustment pipe (2). Secure it by tigntening the fixed knob
(12). Fig. 1
5. Loosen the tilt adjustment knob (11) and adjust the fan head upwards or downwards to your desired tilt angle.
Secure the fan head tilt angle by tightening the tilt adjustment knob (11) firmly. Fig. 1
6. Insert the plug into the mains socket outlet and ensure it is fully plugged in.
USING YOUR FAN
FAN SPEED CONTROL (Fig.2)
The fan has 3 different speeds which are controlled by the speed control switch.
III - High speed
II - Medium speed
I - Low speed
0- OFF
FAN SWING CONTROL (Fig.3)
The oscillation of the fan is controlled by the Oscillation knob.
1. Push down the oscillation knob, the fan will oscillate from left to right.
2. Pull up the oscillation knob, the fan will stop oscillating.
Fig. 2
Fig. 3

Breeze Pedestal Fan Installation Instructions
4 | Page
CARE AND CLEANING
CARE AND CLEANING:
•Periodic cleaning of your fan is the only maintenance required. Use a soft brush or lint free cloth to avoid scratching
the paint finish. Please turn off the power switch and un-plug when you do so.
•Do not immerse your fan in the water. It could damage the motor or the blades and create the possibility of an
electrical shock.
•Ensure that the fitting does not come in contact with any organic solvents or cleaners.
•To clean the fan blade, wipe with only a damp clean cloth with NO organic solvents or cleaners.
•The motor has a permanently lubricated ball bearing so there is no need to oil.
NOTE: Always turn OFF the power and unplug from the mains socket outlet before attempting to clean your fan.
TECHNICAL INFORMATION
FAN models
Rated Voltage
Rated power (motor)
Speed control
16” fan
220-240VAC
50W
3 speeds
