LuCell UP-040 User manual
UP-040
UP-060
Design revolution that empowers the safes users
Fire resistant safes
User manual
Contents
Safety Precautions
Before Use
Keypad Overview
Keypad Lock mode
Security mode
Connecting DC Adaptor (UP-060 only)
Using battery pack
Opening / Closing Door
How to use Alarm
Changing Password
Sound Eect On / O
Using ngerprint lock
Anchoring Instructions
3
3
4
4
4
5
6
7
7
8
8
9
10
Trouble shooting 11
2
The safe you purchased is a 'fire resistant safe' that protects valuables against fire.
Please record your password somewhere else not to forget.
The safe must be installed on a well ventilated, dry and flat surface at all times.
- Product may malfunction if any foreign metal substances or moisture enter keypad.
- Do not scratch keypad with any sharp material.
- Do not apply excessive force to keypad.
- Avoid exposure to any chemicals (gasoline, benzene, solvent, acetone, thinner, etc.)
- Avoid direct re or heat.
- Remove batteries when safe is not used for long time.
- Excessive force to safe handle may cause breakage.
- Safe can be broken into by using cutting or welding tools. Our company is not liable
for any stolen items.
Before Use
- Be carefull when opening and closing door. Finger or objects
may get stuck.
- Keep away from children.
- Do not hit edge of safe to avoid injury.
- Safe is heavy. be carefull when moving or installing safe to
avoid any injury.
- Firmly x safe to ground when installing. When moving safe,
inquire a professional if needed.
- Improper handling of safe can cause damage to oor or table.
- Avoid placing fragile objects, such as ceramic or glass, on safe.
They may fall and cause injury.
- Place safe on at surface. Otherwise, safe door may not close.
Safety precautions are to prevent any unexpected risk or damage.
Please read before use.
3
Safety Precautions
Keypad Overview
- Press START button twice for security mode to hide password.
Security Mode
- Press START for more than 3 seconds until “Act” appears. “Act” message signifies
activation of keypad lock mode. Any keypad input will only display “Act.”
- To deactivate keypad lock mode, press START for more than 3 seconds until “dEAct”
appears.
Keypad Lock Mode
LCD Display Touch START button
FingerprintTouch Keypad
Power supply (UP-060)
Touch Pannel
Main Body
Card/Key holder
Drawer (UP-060)
Tray (UP-040)
Shelf
Alarm
Memory button for password change
Battery compartment
4
Emergency battery port
Connecting DC adaptor
(UP-060 only)
Power input node
1. Check the location of power plug for adapter on the back of safe.
2. Connect DC 12V adapter jack to the power plug.
3. Connect the adapter power cord to the outlet socket.
4. Check if LCD lights on and off with notice sound.
If the safe is plugged in, auto-inspection starts.
Then, if notice sound goes off and all LCDs light on and off,
it is in normal condition.
5. Now you are ready to use the safe.
5
This safe uses DC 12V adaptor as main power supply.
Specication or design of adaptor is subject to change without pre-notice.
Unauthentic adaptor may cause troubles in the system
(This is not covered by our warranty)
6
Using Battery pack
Replace Batteries immediately when
- screen displays “Lo_bAt”
- safe door fails to open when “OPEn” message appears after password is entered.
- “good” appears on display along with “beep beep” sound after password is entered.
- screen fails to turn on after you press START button.
- Touch button is not clear enough.
- there is no response or malfuntion.
How to Replace Batteries
Replacing Batteries
When the door can be open
- Open the battery cover on the backside of the door,
then insert batteries with proper direction
When the door cannot be open
- Take Emergency battery pack on the side of safe.
- Insert batteries in the pack with proper direction.
- Insert the plug of the Emergency battery pack into the port on the right side of
door
Battery is auxiliary power supply.
Use the adaptor for the better use of safe
Battery pack is located on backside of door.
(Emergency battery pack on the side of safe’s door is only for urgent case)
After battery replacement, conrm safe is properly working before
closing door.
Use 1.5V alkaline batteries (AA x 6).
Proper insertion of the batteries is conrmed once screen displays “
SAFE” > _0... > “good” message appears and beep is heard.
7
1. Use the “On / Off” switch on the Alarm to control the Alarm.
2. Use 9V battery for Alarm
How to use Alarm
1. Press START button
“------“ will be displayed on screen.
2. Input 4~20 digit password.
Input factory password “1, 2, 3, 4, 5, 6” for User 1,
“5, 6, 7, 8, 9, 0” for User 2(Option).
“OPEn” will be displayed on screen along with beep sound.
Opening / Closing Door
3. Pull door open when display shows “OPEn”.
4. Door locks automatically when door is closed.
Press START button to cancel password entry.
Safe must be opened within 3~4 seconds.
“Err-03” indicates incorrect password.
5 consecutive incorrect password will sound alarm for 3 minutes.
Press START button and enter correct password to stop alarm.
Note that the alarm sound is 120dB which can damage your hearing
8
- Open door and press white memory button for 3 seconds.
After "beep' message appears, "On-OFF" will be displayed.
- Press 0 then START for sound ON. Press 1 then START for sound OFF.
Sound Eect On/O
Changing Password
1. Enter current password and open door.
2. Press white memory button located inside door.
“-CodE-“ will be displayed, then “USEr_” will be displayed.
3. Press 1 then START button.
“------“ will be displayed.
4. Enter new 4~20 digit password.
“AgAin”, then “------“ will be displayed.
5. Enter new password again.
“USEr_1” will be displayed.
6. New password is set.
Confirm new password works with door open.
*To add second password, press 2 (in step 3) and repeat steps.
Safe can be programmed with either 1 or 2 passwords.
After having changed the password, please conrm safe is properly
working before closing the door.
Memory button for password change
9
Using ngerprint lock
1. Push white memory button for 3 seconds until display shows “Set”.
2. Push white memory button once shortly again.
3. Press “0” to register fingerprint.
4. Put finger on screen when display shows “1-Scan” and light on screen and wait for
seconds.
5. Put finger off screen when display shows “1-donE”.
6. Scan same fingerprint two times more.
7. Finished.
1. Push START button.
2. Scan registered fingerprint on the screen
3. Door mechanism will release if fingerprint is correct.
4. Pull door open when display shows “OPEn”.
1. Push white memory button for 3 seconds until display shows “Set”.
2. Push white memory button once shortly again.
3. Press “1” to delete fingerprint.
4. Input Id No. to delete and press START button.
*To delete all fingerprints at once, press white memory button.
5. Finish.
Registration of ngerprints
Opening with ngerprints
Deletion of ngerprints
Maximum 10 ngerprints can be registered.
“Err-04” will be shown on display when ngerprint is not correct or an
unauthorized ngerprint attempts access.
10
1. Bolt may need to be cut.
2. Place cover over hole for re resistance.
Anchoring Instructions
1. Anchor bolts vary according to model. After checking anchor bolt size, drill a hole
to a depth of 2 inches (50mm). Refer to chart for appropriate hole size.
2. Insert anchor bolt and pipe into hole.
3. Place flat washer and nut on anchor bolt. Tighten with 14mm wrench to allow
anchor bolt to expand and secure into floor.
4. Remove nut and washer from anchor bolt.
5. Place safe on top of anchoring bolt through center hole on bottom of safe.
6. Place washer, lock washer, and nut on anchor bolt, Tighten.
Anchor bolt must be inserted into oor BEFORE safe is bolted down.
A (Anchor size) B (Diameter of hole)
1/4” (M6 x 50mm) 0 10mm (5/16”)
3/8” (M10 x 101mm) 0 14mm (9/16”)
3/8” (M10 x 152mm) 0 14mm (9/16”)
Cover
Lock washer
Flat washer
14mm Nut
Anchor bolt
Anchor pipe
Trouble shooting
No response when
START button
pressed
·Main power error
·Dead battery
·Incorrect insertion of
batteries
·Keypad lock mode ON
·Circuit error
·Check the adaptor
·Replace new batteries
·Remove batteries and insert
in the correct polarity
·Press START for 3 seconds to
deactivate keypad lock mode
·Contact Service Centre
Alarm continues
ringing and safe
does not work
·5 times wrong password
input
·Enter correct password or wait
3 minutes until automatic alarm
stops
“Err-03” message
appears
Incorrect password ·Enter correct password
Green light ON, does
not open when “
OPEn” is displayed
·Low battery
·Incorrect turning of handle
/ key
·Lock equipment error
·Replace new batteries
·Turn handle clockwise
·Contact Service centre
Cannot change
password
·Exceeded time limit
during password change
·Keypad malfuntion
·Button error
·Enter password in under 5
seconds
·Contact Service Centre
·Contact Service Centre
“Lo_bAt” message
apears ·Low battery ·Replace new batteries
“Act” message
appears
·Keypad lock mode ON ·Press START for 3 seconds to
deactivate keypad lock mode
Forgot password ·Contact Service Centre
MeasuresSituation Possible Cause
11
