The CALLMASTER V Telephone Console 1
The CALLMASTER V Telephone Console
The CALLMASTER®V telephone has been specially designed for use with the
Automatic Call Distribution (ACD) system and the many features of the
DEFINITY®Enterprise Communications Server (ECS) and the DEFINITY®
Communications System Generic 1, Generic 2, and Generic 3. This
telephone is designed to be used with a headset in a 2-wire environment.
Note: Power for the CALLMASTER V telephone, including the headset,
comes from the DEFINITY switch through the 2-wire DCP line.
The CALLMASTER V also has a built-in Recorder Interface which allows you
to connect the telephone to a recording device so that you can record all voice
interactions. For more information about this interface, see “The
CALLMASTER V Recorder Interface” on page 3.
Note: The tape recorder used with the CALLMASTER V telephone must be
purchased by the user; it is
not provided with the telephone.
Figure 1 below shows a front view of the CALLMASTER V telephone. The
features of the telephone are explained after the figure.
Note: For a rear view of the telephone, see Figure 4 on page 9.
FIGURE 1 The CALLMASTER V Telephone Console, Front View
7
PQRS
3
DEF
Speaker
Mute Hold
Redial Transfer
Test Ring
2
ABC
1
4
GHI
*
56
89
MNOJKL
TUV WXYZ
O#
Volume
Tel #
CALLMASTER V
13
14
12
Menu Exit Prev Next
Conf
9
10
11
7
6
4
5
3
2
8
1

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
The CALLMASTER V Telephone Console 2
The following features correspond to the numbers in Figure 1.
Note: Two feature buttons must be administered in the following ways:
• One of the feature buttons must be designated as the
Headset On/Off button;
•The Release feature must be administered on a second feature
button.
Headset Connections with the CALLMASTER V
The headset connection for the CALLMASTER V consists of a headpiece
(shown as 1in Figure 2 below) which is plugged into an adapter cord (shown
as 2).
Note: Your system manager MUST administer a button on your
set. Use this button to turn your headset on and off. For instructions for
using this feature button, see “Headset On/Off” in the section titled
Call-Handling Features.
FIGURE 2 The Headset Connected to One of the Headset Jacks (shown
as 3) on the CALLMASTER V Telephone
1) Telephone Notepad 8) Volume control button
2) Mute (or ) button 9) Display
3) Speaker (or ) button 10) Softkeys
4) Transfer/Test (or ) button 11) Display control buttons
5) Redial (or ) button 12) Hold (or ) button
6) Conf/Ring (or ) button 13) Call appearance/feature buttons
(See Note immediately below)
7) Dial pad 14) Message light — labeled
Headset On/Off
1
3
2

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
The CALLMASTER V Telephone Console 3
Compatible Headpieces
The following Lucent Technologies headpieces can be used with these
telephones:
—Mirage®— Receiver fits over either ear. Not for noisy environments.
—StarSet®— Eartip fits in ear canal.
—Supra®— Adjustable headband and soft ear cushion.
—Encore® —Advanced sound technology with adjustable headband
and soft ear cushion.
—TriStar®— Advanced headpiece which fits over the ear.
The CALLMASTER V Recorder Interface
The CALLMASTER V’s Recorder Interface is designed for recording calls on a
standard tape recorder. (A recorder with AGC [Automatic Gain Control] is
recommended.) With this interface, a warning tone, a soft beep repeated every
13.5 seconds, notifies the agent and the calling party that the call is being
recorded.
Be aware that this tone may be a legal requirement.
The Softkeys
The softkeys are the four unlabeled round keys located directly below the
display. The four round display control buttons, labeled Menu, Exit, Prev, and
Next are located under the softkeys. See Figure 3.
FIGURE 3 The Display, Softkeys, and Display Control Buttons
IMPORTANT: The use of service observing features and call recording
features may be subject to federal, state, and local laws, rules, or regulations
and may be prohibited pursuant to the laws, rules, or regulations or require
the consent of one or both of the parties to the conversation. Customers
should familiarize themselves with and comply with all applicable laws, rules,
and regulations before using these features.
Softkeys
Display
Display
NextPrevMenu Exit
control buttons

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Call-Handling Features 4
Using the Softkey Feature Menus
There are three separate softkey feature menus. Each of these menus allows
you to select from four different features.
You can enter Softkey Mode (and view the softkey feature menu) by pressing
the display control button labeled Menu or . The following is an example
of a softkey feature menu.
The top line of each softkey feature menu screen shows you the status of
each of the four features. An arrow appears above the feature name or
abbreviation if that feature is active. In the above example, the arrow above
the Timer feature indicates that feature is active.
The second line on each softkey feature menu shows the features you can
access. To use any of these features, you must press the softkey below the
feature name or abbreviation.
Press the Next or Prev button until the feature you want to use appears on the
display.
Note: An error tone (one beep) sounds when you have made an
inappropriate softkey entry.
Press the Exit button at any time to exit the softkey feature menus and
return to normal call-handling operation.
Other Softkey Features That May Be On Your Display
There are 12 default features that can be accessed with the softkeys on a
CALLMASTER V telephone. However, the system manager may substitute
other softkey features in their place.
Call-Handling Features
HEADSET ON/OFF
The system administrator should have administered a button on
your CALLMASTER V telephone.
To turn on your headset
1. Press .
The green light next to the button goes on to remind you the headset is
active.
To turn off your headset
1. Press again.
Dir Drop HFAns Timer
Headset On/Off
Headset On/Off
Headset On/Off

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Call-Handling Features 5
The green light next to the button goes off.
CONFERENCE
The Conference feature allows you to conference up to six parties (including
yourself) on a call.
To add another party to a call (for a total of six parties)
1. Press (or ). [dial tone]
2. Dial the number of the new party and wait for an answer.
3. When you want to add the new person, press (or )
again.
4. Repeat Steps 1 through 3 for additional conference connections.
To add a call you have put on hold to another call you are connected to
1. Press (or ). [dial tone]
2. Press the call appearance button of the call on hold (first call).
3. Press (or )again.
To drop the last person added to the conference call
1. With a display: Press the Menu button and then press the softkey
below Drop.
Without a display: Press the button (if administered).
HOLD
The Hold feature puts a call on hold until you can return to it.
To put a call on hold while you answer another call or perform another
task
1. Press (or ).
To answer a new call while active on another
1. Press (or ).
2. Press the call appearance button of the incoming call.
To return to the held call
1. Press the call appearance button of the held call.
REDIAL
The Redial (or Last Number Dialed) feature automatically redials the last
extension or outside number (up to 24 digits) you dialed.
To redial the last number that you dialed
1. Press (or ).
Conf
Conf
Conf
Conf
Drop
Hold
Hold
Redial

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Call-Handling Features 6
RELEASE
An ACD agent can press to disconnect from a call.
To disconnect from a call
1. Press .
Note: Pressing is faster than waiting for a caller or trunk to
disconnect and enables you to perform other ACD or voice
terminal procedures sooner. You
do not hear dial tone after you
press .
If you want to disconnect from a call and then place another
call, you can press instead.
SPEAKER (LISTEN-ONLY) and GROUP LISTEN
The Speaker feature allows you to place calls or access other features without
using the headset. However, in order to speak to the other party, you must use
the headset. With the Group Listen feature, the headset and speaker are
active at the same time.
To use the listen-only speaker to place a call without using the headset
or for any listening-only feature (such as monitoring a call on which
you have been put on hold or for group listening)
1. Press (or ).
2. Place a call or access the selected feature.
3. Adjust speaker volume if necessary:
To raise the volume, press the right half of the Speaker Volume control
button labeled ; to lower the volume, press the left half of the
Speaker Volume control button labeled .
The display shows the volume level: (There are eight volume levels.)
To end a call (while the headset is off and only the speaker is active)
1. Press (or ).
To activate the speaker while using the headset so that both are active at
the same time (the Group Listen feature)
1. While you are using the headset, activate the speaker by pressing
(or ).
To turn off the speaker and return to headset use
1. Press (or ).
Release
Release
Release
Release
Drop
Spkr
->>>>>> +
Spkr
Spkr
Spkr

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Getting Messages 7
TEST
The Test feature allows you to test the lights and display on your telephone.
To test the lights and display on your telephone
1. With the headset off, press and hold down (or ).
Lights go on in columns, and all the display segments fill in.
2. To end test, release (or ).
Lights return to normal operation.
Note: If the lights or the display segments do not respond during the test,
see your system manager.
TRANSFER
The Transfer feature allows you to transfer a call from your telephone to
another extension or outside number.
To send the present call to another extension
1. While on a call, press (or ). [dial tone]
2. Dial the number to which the call is to be transferred. [ringing tone]
3. Remain on the line and announce the call.
(If the line is busy or if there is no answer, you can return to the held
call by pressing its call appearance button.)
4. Press (or )again to complete the transfer.
Note: To cancel an attempted transfer, press the original call appearance. If
your system has auto-hold activated, use to cancel a transfer so
that the potential transfer recipient is not left on hold.
Getting Messages
MESSAGE
Your Message light goes on when a caller has left a message for you.
Note: You may also be able to use the Message Retrieval display feature.
For directions on retrieving your messages, see your system manager.
Trnsfr
Trnsfr
Trnsfr
Trnsfr
Drop

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Selecting a Personalized Ring 8
Selecting a Personalized Ring
SELECT RING
The Select Ring feature allows you to choose your own personalized ringing
pattern for your telephone from among eight different patterns.
To select a personalized ringing pattern
1. With the headset off, press (or ).
Current ringing pattern plays and repeats every three seconds.
2. Continue to press (and then release) (or )to cycle
through all eight ringing patterns.
3. If you want to save the ringing pattern currently being played, do not
press (or ) anymore.You will hear the selected ringing
pattern two more times, and then it will be automatically saved.
You will hear a confirmation tone (two rising tones), and your new
ringing pattern is set.
Note: If you turn on the headset, receive a call, or lose power during
selection, the process is canceled and you must start again.
Voice and Display Features
For directions on using the voice features on your telephone such as
Abbreviated Dialing, Call Forwarding, and Send All Calls, see the section titled
Basic Voice Terminal Procedures in either of two user’s guides:
• DEFINITY® Enterprise Communications Server Generic 1, Generic 3,
and System 75 Automatic Call Distribution (ACD) Agent Instructions,
555-230-722
• DEFINITY® Enterprise Communications Server Generic 1, Generic 3,
and System 75 Automatic Call Distribution (ACD) Supervisor Instructions,
555-230-724
You can order both of these books from the Lucent Technologies BCS
Publications Center by calling 1 800 457-1235 (within the United States)
or 1 317 322-6791 (outside the United States).
Conf
Conf
Conf

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Operating Range Requirements 9
Operating Range Requirements
The total distance between the CALLMASTER V telephone (with Recorder
Interface active) and the recording device should not exceed
200 feet/ 60.96 meters.
The distance between the CALLMASTER V telephone and the PBX must NOT
exceed the following:
With 22-gauge wire, the distance between the CALMASTER V and the PBX
should not exceed 5,500 feet/ 1,676.4 meters; with 24-gauge wire, the
distance should not exceed 3,500 feet/ 1,066.8 meters; with 26-gauge wire,
the distance should not exceed 2,200 feet/ 670.56 meters.
The record output impedance is approximately 600 ohms and the output
channel is isolated from the telephone via a voice transformer that meets the
UL 1950 Dielectric Breakdown requirement of 1,000 URMS for one minute.
Telephone Installation
The CALLMASTER V telephone can be either desk-mounted or wall-mounted.
Read the following safety instructions and use the following directions and
refer to the following figure of the rear of the telephone for installing these
telephones.
FIGURE 4 The CALLMASTER V Telephone Console, Rear View
1
3
4
5
2
6
7

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Telephone Installation 10
Important Safety Warnings for Installation
When this product is located in a separate building from the telephone
communications system, a line current protector MUST be installed at the
entry/exit points of ALL buildings through which the line passes. Only one
protector is needed at each installation point.
For 2-wire installations, the following is recommended:
•Lucent Technologies 4-type protectors
•ITW LINX LP-type protectors.
Lucent Technologies 3BIC (carbon block) or Lucent 3BEW (gas tube)
protectors are also acceptable in a 2-wire installation.
INSTALLATION WARNING
(for the CALLMASTER V)
12345678 MODULAR WALL JACK WIRING
Pin Pair Name Description
4
51
1BL-W W-BL 2-Wire (Tip)
2-Wire (Ring)
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN CAUSE DAMAGE
TO THE TELEPHONE OR CAUSE THE ASSOCIATED DEFINITY ECS
CIRCUIT PACK TO REMOVE POWER TO THE TELEPHONE. IN EITHER
CASE, THE TELEPHONE WILL NOT FUNCTION CORRECTLY.
For 2-wire operation, if you need to plug the telephone into a 4-pin or 6-pin
wall jack, instead of a standard 8-pin modular jack, see the Modular Wall
Jack Wiring table above to ensure that the wires from the 4-pin or 6-pin
wall jack are connected to the correct pins on the telephone LINE jack.
Two-wire installations must have only PBX connections on pair 1.
1
22
2W-O
O-W Record Output
Record Output

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Telephone Installation 11
Desktop Installation
Note: You can use the telephone without the desktop stand, if you so
choose.
If you do not use the telephone with attached desktop stand, it is
suggested that you place small round feet (included in a plastic bag in
the box in which the telephone was packed) on each corner of the
bottom of the telephone housing.
1. Turn the telephone face down on a flat surface.
2. Remove the desktop stand (the upper tabs on the stand are shown as
2in Figure 4; the lower tab slots are shown as 6in Figure 4). Also see
Figure 5 which shows removing the desktop stand.
3. Snap one end of the line cord into the “LINE” jack (4in Figure 4) on the
bottom of the telephone.
4. Connect the expansion module by snapping one end of the expansion
module cord into the “XM24” jack on the back of the telephone (3in
Figure 4).
5. Thread the line cord (and expansion module cord, if appropriate)
through the routing channel leading to the top of the desktop stand
(1in Figure 4). Make sure that the line cord is placed securely under
the square tab (7in Figure 4) to the left of the “LINE” jack and that the
line cord (andthe expansion module cord, if appropriate) is also placed
under the square tabs in the routing channel.
Note: If you are using an auxiliary power supply such as the 1151A1
or 1151A2 Power Unit, plug the line cord into the “PHONE” jack
on the auxiliary power supply.
6. Turn the telephone right side up, with the front facing you.
7. Plug the quick-disconnect (QD) connector on the headset into the
QD connector on the headset cord already plugged into one of the
Headset jacks (5in Figure 4) on the back of your telephone.
8. If appropriate, snap the free end of the expansion module cord into the
TEL SET jack on the expansion module.
9. Snap the free end of the line cord into the modular wall jack.
Note: If you are using an auxiliary power supply such as an 1151A1 or
1151A2 Power Unit, plug the power supply cord from the power
unit’s “LINE” jack into the modular wall jack.
10. Turn on the headset OR press (or )and listen for dial
tone. If there is no dial tone, check all wire connections to make sure
they are secure.
Spkr

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Telephone Installation 12
Wall Installation
Note: For wall-mounting, you will need a 1-foot line cord. (This cord is not
supplied with the telephone, but can be ordered by using this
comcode: 103786760.)
1. Make sure the 8-conductor wall mount plate is in place.
2. Place the telephone face down on a flat surface.
3. Remove the desktop stand which is attached to the base of the
telephone by tabs on the top and back of the stand, shown as 2and 6
in Figure 4.
— Press inward on the top of the stand until you can lift the upper tab(s)
of the stand (shown as 1in Figure 5 below) out of the tab slot(s)
(shown as 2in Figure 5 below) on the telephone.
— Lift the bottom of the stand out of the lower tab slot(s).
FIGURE 5 Removing the Desktop Stand
4. Snap the line cord into the “LINE” jack in the bottom of the telephone.
5. Reverse the desktop stand so that the larger end is facing down and
coil the excess line cord in the back of the deskstand.
6. Engage the upper tabs (1in Figure 5) of the deskstand into the slots
(4in Figure 5). Slowly lower the reversed deskstand onto the bottom of
the telephone until the lower tabs (shown as 3in Figure 5) snap into
the appropriate slots on the bottom of the telephone (2in Figure 5).
7. Install two screws (part of Kit #108170366 that is packaged with the
telephone) to fasten the base to the bottom of the telephone. See
Figure 6 for the location of the two areas in which these screws must
be installed.
8. Place the free end of the line cord through the opening in the middle of
the deskstand and then snap the free end of the line cord into the wall
jack.
9. Place the base of the telephone on the wall-jack mounting studs, and
2
1
2
4
3
RRe

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Telephone Installation 13
pull downward until it is secure. (See Figure 6.)
FIGURE 6 Placing the Telephone on the Wall Jack Mounting Studs
10. Plug the quick-disconnect (QD) connector on the headset into the
QD connector on the headset cord already plugged into one of the
Headset jacks on the back of your telephone.
11. Turn on the headset OR press (or )and listen for dial
tone. If there is no dial tone, check all wire connections to make sure
they are secure.
Installing the Designation Card
Use the button designation card, already installed on your CALLMASTER V
when it is shipped from the factory to write the telephone number, extension,
name, or feature that each call appearance/feature button can access. On the
left side of the phone is a Notepad on which you can write frequently-dialed
numbers or extensions.
To label and install the designation card and telephone Notepad
1. The transparent designation card and Notepad covers are attached to
the frame of the telephone by tabs on the top and bottom of the cover.
Remove either or both of these covers by pulling the top tab forward
and then lifting the bottom of the transparent cover from the telephone.
2. Print the numbers/features on the button designation card that
corresponds with the telephone you are using. On the Notepad write
frequently-called numbers or extensions or any other information that
will help you use your telephone in your daily work.
3. Place the button designation card and/or the Notepad under the plastic
card cover on the telephone by inserting the tabs at the bottom and
then pressing the top down until it clicks.
Spkr

CALLMASTER® V Telephone Console User’s Guide 555-233-735 Issue 1
Telephone Installation 14
Orderable Cards and Equipment
The following cards and equipment are orderable.
• You can order additional designation cards in quantities of 25 cards
per package. Notepads can also be ordered in quantities of 25 per
package. Use the following comcodes when you place your order.
— 25 sheets of designation cards (8-1/2” x 11”)
Comcode 847991650
— 25 sheets of designation cards (A4-size)
Comcode 848020749
— 25 sheets of Notepads with 9 Notepads per sheet (8-1/2” x 11”)
Comcode 108562570
— 25 sheets of Notepads with 9 Notepads per sheet ((A4-size)
Comcode 108562588
— Designation card covers can be ordered in quantities of 25 per
package
Comcode 108272402
— Notepad covers can be ordered in quantities of 25 per package
Comcode 108573304
• You may also order an optional handset D-Kit, so that you can
connect a K-type handset to the telephone. This kit includes the
handset and a handset cord, and can be ordered with one of the
following numbers: (PEC 31293 & 31293A,
Comcode 407904309).
Note: This handset is the only handset that can be used with the
CALLMASTER V telephone.
• A tray with five quick reference cards can be inserted in the grooves
located under the base of the CALLMASTER V telephone. The tray
and the cards are ordered separately with the following numbers:
the tray = PEC 33111, Comcode 108272584;
the cards = Comcode 108032178).
• An XM24 Expansion Module can be connected to the
CALLMASTER V to extend the number of available call appearance
and/or feature buttons. The XM24 module can be ordered with the
following numbers:
A gray XM24 = PEC 33071/A, Comcode 108544511
