Lucky Prospect Series Installation and maintenance manual
RIDERS
MANUAL
RIDERS
MANUAL
WELCOME TO THE LUCKY FAMILY
Pro Rider: Jackson Burklund
Welcome to the Lucky Family! We’re stoked
that you chose this Lucky scooter and we
promise that you’ve made a wise decision.
For this new lineup of complete scooters we
focused on going back to some of our original
designs while staying up to date with the
world’s best technology so we could bring you
the best possible scooter on the market today.
From our garage to the warehouse Lucky
has risen in ranks to become the dominating
brand you see today. We’ve designed all our
products with one general goal in mind - to
make premium scooters for every style of
rider so that they can express themselves
as individuals. With this being said it doesn’t
matter if you ride street, park, dirt, at or
whatever! We want you on the sickest, best
built line of scooters out there and we take
great pride in knowing that our wish came
true. Our pro rider’s have ridden & tested these
scooters again and again with trick after trick,
impact after impact, and they always come
away rolling smoother than ever.
We know that your scooter will be able to
perform and handle in every situation you
take it! I’m sure you already know everything
about your sick new ride but if you want a
quick refresher you can go over this manual.
It was written as a guide to help you through
basic scooter maintenance and mechanics. So
refresh your memory, learn how to dial your
whip, and then go out and ride!
RIDE IT. STOMP IT.
BARS
GRIPS
WHEEL
CLAMP
HEADSET
BRAKE
DECK
GRIPTAPE
FORK
WARNING:
Do not use
non-Lucky products
with your scooter.
Lucky scooters
have been built to
certain Lucky design
specications. The
original equipment
supplied at the time of
sale was selected on the
basis of its compatibility
with the deck, fork and
all other parts. Certain
aftermarket products
may or may not be
compatible.
Check out your scooter
when you unpack it.
Remove contents from box.
Inspect the contents of the
box for scratches in the paint
and/or dents that may have
occurred during shipping.
Because your scooter was
partially assembled and
packed at the factory, there
should not be any problems,
even if the box has a few
scars or dents.
PARTS ON YOUR NEW RIDE
Required Tool:
5mm Allen Wrench
(included)
SAFETY FIRST MY LUCKY FRIEND!
An Important Message To Parents
This manual contains important information. For your child’s safety, it is your responsibility to review this information with your child and make sure that
your child understands all warnings, cautions, instructions and safety topics. Lucky Scooters recommends that you periodically review and reinforce the
information in this manual with younger riders. You are required to inspect and maintain your child’s scooter to ensure their safety.
General Warning
Scooter riding can be a hazardous activity and is intended for ages 8 and above. The weight of a rider should not exceed 120 pounds(55kgs). Always wear
safety equipment such as helmet, knee pads, and elbow pads. Always wear a helmet while riding your scooter and keep the chinstrap securely buckled.
Always wear shoes. Scooters are intended to move and it is therefore possible to get into dangerous situations and/or lose control and/or fall. If such things
occur you can be seriously injured or die. Ride on smooth, paved surfaces away from motor vehicles. Avoid sharp bumps, drainage grates, and sudden
surface changes. Scooter may suddenly stop. Avoid streets and surfaces with water, sand, gravel, dirt, leaves, and other debris. Wet weather impairs traction,
braking, and visibility. Do not ride at night. Brake will get hot from continuous use. Do not touch after braking. Avoid excessive speed associated with
downhill rides. Adults must assist children in the initial assebly of the scooter to ensure that all parts are fastened and tight. Obey all trac and scooter riding
laws and regulations. Watch out for pedestrians. Check and secure all fasteners before every ride. Replace worn or broken parts immediately.
Like any other product, using a scooter can be a dangerous activity and may result in injury or death, even when used with
proper safety precautions. Use at your own risk and use common sense.
Proper Riding Attire
Always ensure that proper protective equipment is worn including an approved safety helmet. A helmet may be legally required by local law or regulation in
your area.
Acceptable Riding Practices and Conditions
Scooters are meant to be used only in controlled environments free of potential trac hazards and not on public streets. Do not allow your child to ride a
scooter in any areas where vehicle trac is present. The rider must maintain a hold on the handlebars at all times. Never allow more than one rider at a time
on a scooter. Never use near steps, sloped driveways, hills, roadways, alleys or swimming pool areas. Do not ride a scooter in wet weather. Scooters are
intended for use on solid, at, clean and dry surfaces such as pavement or level ground without loose debris such as rocks or gravel. Wet, slick, uneven or
rough surfaces may contribute to possible accidents. Do not ride a scooter in mud, ice, puddles or water. Avoid excessive speeds that can be associated
with downhill rides. Never risk damaging surfaces such as carpet or ooring by use of a scooter indoors. Do not ride at night or when visibility is impaired.
Direct parental supervision is required for children.
Failure to use common sense and heed the above warnings further increases risk of serious injury. Use at your own risk
and with appropriate and serious attention to safe operation. Use caution.
PROSPECT & CREW COMPLETE > IHC COVENANT COMPLETE > HIC
HOW TO ASSEMBLE YOUR RIDE
1. Install the Bars:
Loosen the clamp on the Bars.
“Press” the bar down tube onto the
fork twisting if necessary. The tube will
slide nicely onto the IHC shim.
1. Install the Bars:
Loosen the clamp on the Bars.
“Press” the bar down tube onto the
fork twisting if necessary. The tube
will slide nicely onto the composite
aluminum HIC shim.
2. Align the wheel:
Align the front wheel to be straight
and aligned with the bars, lightly
tighten the clamp bolts alternating
between each of them until all are
tight. If you tighten one bolt too
much while the others are loose you
will damage the clamp not allowing
the clamp to tighten properly and will
void warranty.
2. Align the wheel:
Align the front wheel to be straight
and aligned with the bars, lightly
tighten the clamp bolts alternating
between each of them until all are
tight. If you tighten one bolt too
much while the others are loose you
will damage the clamp not allowing
the clamp to tighten properly and will
void warranty.
HOW TO ASSEMBLE YOUR RIDE
Lubricating your bearings
To keep your scooter fast and smooth you need to
lubricate your bearings. You will need to take o your
wheels to lubricate your wheel bearings, this is done by
taking 2 - 5mm allen wrenches and turning them counter-
clockwise. The wheels may need some encouragement
to slide out. Using a damp cloth wipe any dirt or grime on
your wheels and bearings. Using bicycle bearing oil, or
Bones Speed Cream, place 3 to 4 drops directly on the
bearing covers and allow the oil to sink in. If the wheels
do not spin freely after this you might need to replace your
bearings.
Adjusting or tightening your compression
If your bars start to shake or move side to side, this
means your clamp is loose or your compression needs
to be tightened. To tighten the compression; do so by
removing your handle bars and with your 5mm allen
wrench insert it in the allen bolt on top of the HIC SHIM or
SCS top cap, as demonstrated on previous page. Turning
it in a clock-wise direction, add light pressure and tighten
until some pressure is felt in the allen wrench. The forks
should still spin freely, however if over tightened you can
restrict the movement and damage your compression or
headset. To tighten the clamp lightly tighten each bolt on
the clamp or scs alternating bolts until all bolts are tight. If
you tighten one bolt too much while the others are loose
you will damage the clamp not allowing the clamp to
tighten properly and will void warranty. Adult supervision
recommended.
If you like a clean scooter
Never use any cleaning agents to clean your scooter,
doing so may damage paint or materials. Use a damp or
wet rag to wipe o any street dirt or park grime. Use a
dry plastic bristle brush or dry paint brush to brush away
dirt. Avoid putting water directly on grip tape and never
submerge your scooter in water, it is not a submarine!
Before each ride
Always make sure your scooter is in legit mechanical
shape before you head out to ride. Always check your
scooter for loose clamp bolts, loose axle bolts, loose
compression, loose headset, loose grips, loose brake,
or any other loose parts. Always check the deck, bars
and wheels for any signs of stress, cracks or heavy
damage. Scooters are tough but not invincible. Replace
any worn parts immediately!
RIDER GUIDE & maintenance
EVO COMPLETE > SCS
HOW TO ASSEMBLE YOUR RIDE
1. Install the Bars:
Loosen the top three SCS bolts
slightly and “press” the bar down tube
into the SCS, twisting if necessary.
The bar will slide nicely into the SCS.
The SCS clamp bolts should be
towards the rear of the scooter as
shown in the picture
2. Align the wheel:
Align the front wheel to be straight
and aligned with the bars, lightly
tighten the SCS clamp bolts
alternating between each bolt until
all bolts are tight. If you tighten one
bolt too much while the others are
loose you will damage the clamp
not allowing the clamp to tighten
properly and will void warranty.
WARRANTY
Pro Rider: JonMarco Gaydos
Lucky Scooters Limited Warranty
The manufacturer warranties this product to be free of
manufacturing defects for a period of 6 months from date
of purchase. This Limited Warranty does not cover normal
wear and tear, or any damage, failure, or loss caused by
improper assembly, maintenance, or aggressive use. This
Limited Warranty will be void if; the product is used in for
anything other than recreationally, modied in any way
including installing aftermarket parts.
Need Help?
Visit our web site for replacement parts, product support
and a list of authorized service centers at:
www.luckyscooters.com, call toll-free (866) 294-8669 or
Monday-Friday 9:00 AM - 5:00 PM Pacic Time.
