Lumex 816070A User manual

INSTRUCTIONS
& WARRANTY
INFORMATION
Dual Paddle Folding Walker &
Dual Paddle Folding Walker With Wheels
816070A, 816080A, 816170A, 816180A,
816270A, 816280A, 816370A, 816380A
IMPOR AN : READ BEFORE USE
LIFETIME LIMITED WARRANTY
Quality is the hallmark of all Lumex®products.
Trusted by healthcare professionals and end-users
for over 50 years, Lumex features a full line of
patient aids and specialty healthcare seating.
Lumex products are designed and built to precise
standards and are carefully inspected prior to shipment.
We are dedicated to providing products that will give
our customers years of dependable service.
This Lumex product is warranted to be free of defects in
materials and workmanship for the lifetime of the original
consumer purchaser.
This warranty does not cover product failures due to
normal wear and tear or device misuse. The warranty
does not extend to non-durable components, such as
rubber accessories, which are subject to normal wear
and require periodic replacement.
Should a product defect that is covered by this warranty
arise, we will, at our option, repair or replace the product.
For additional information on this Lumex product or
this warranty, please contact an authorized Lumex Dealer.
All illustrations and specifications in this manual are based on the latest product information available
at the time of publication. Graham-Field reserves the right to make changes at anytime, without notice.
© 2006, Graham-Field Health Products, 2935 ortheast Parkway, Atlanta, Georgia 30360.
Printed in China. GF0600051 RevB06
Dual Paddle Folding Walker:Hang Tag 9/6/2006 1:09 PM Page 1

INS RUC IONS FOR USE –
PLEASE READ ALL INS RUC IONS BEFORE USE.
The chart below can be used as a guide to select a height-
appropriate walker. Please consult a healthcare professional
for the proper adjustment.
DUAL PADDLE FOLDING WALKER
HEIGH ADJUS MEN
NOTE: For ease of shipping, the alker is shipped in its lo est height position.
The alker should be adjusted to the desired height before operation.
Refer To Illustration Belo :
The legs of each walker are equipped with an adjustment button and an
adjustable leg attachment with eight adjustment positions.
1. Adjust the height of the walker by aligning all four leg
attachments to the same position height.
2. To adjust the height of a leg attachment, depress the adjustment button
and twist the leg attachment to the desired height.
O OPEN UNI
When removed from box, walker is in a closed position.
1. Grasp one handgrip and pull away from center of walker.
2. Repeat with other handgrip.
3. Push handgrips away from each other until the paddle release
mechanisms click into place.
O CLOSE UNI
1. Grab hold of release paddles with fingers and pull up.
2. Pull one hand grip towards the center of the unit until it stops
at the crossbrace.
3. Repeat for the other hand grip.
Reducer Cap
Side Frame
Handgrip
Paddle
Release
Mechanism Cross bar
Walker Tip
Adjustable Leg
Extension
Leg Attachment
Adjustment Button
(on inside of each
leg attachment)
Leg extensions are available for users over 6' 2".
Please consult your Lumex dealer.
MAIN ENANCE
• Wipe walker weekly with a damp cloth.
• Grips may be cleaned with mild soap or detergent.
DO OT use organic solvents, such as acetone, which may damage grip.
• ever use abrasive cleaners or scouring pads on any part of the walker.
• Check all hardware weekly to ensure that it is securely attached.
• Replace walker tips as needed.
• To guarantee the best service from your walker, always specify
Lumex replacement parts, available from your Lumex dealer.
SAFE Y GUIDELINES –
PLEASE READ BEFORE USE
1. This product should not be used without proper instruction
from a healthcare professional.
2. This product has a maximum user weight limitation of 300 lb.
3. Before using, be sure that walker is locked in the open position.
4. Graham-Field Health Products assumes no responsibility for
any damage or injury caused by improper installation, assembly
or use of this product.
5. If components are damaged or missing, contact your
dealer immediately. DO OT use substitute parts.
6. Inspect walker weekly for proper function and wear. If any
component is not in proper working order or appears worn,
contact your Graham-Field Health Products dealer for repair
and/or appropriate replacement parts.
7. Before use, ensure that push button protrudes fully through
height adjustment hole and the release mechanisms are locked
in the “open” position.
8. Always use caution when using this product on wet or
slippery surfaces.
Model Number Size User Weight Adjustment Range/
Handgrip to Floor
816070A, 816080A Adult 5'4"- 6'2" 32" - 39"
816170A, 816180A Junior 4'7"- 5'3" 27" - 32"
816270A, 816280A Adult 5'4"- 6'2" 32 1/2" - 39 1/2"
816370A, 816380A Junior 4'7"- 5'3" 27" - 32"
Front Fixed Wheel
