Lumex WALKABOUT LT RJ4302 Series Installation guide

INSTRUCTIONS
& WARRANTY
INFORMATION
Walkabout LT™Rollator
RJ4300 Series & RJ4302 Series
IMPORTANT: READ BEFORE USE
All illustrations and specifications in this manual are based on the latest product information available
at the time of publication. Graham-Field reserves the right to make changes at anytime, without notice.
© 2004, Graham-Field Health Products, 2935 Northeast Parkway, Atlanta, Georgia 30360.
Printed in China. Doc Number: GF0600057RevA06
LIFETIME LIMITED WARRANTY
Quality is the hallmark of all Lumex®products.
Trusted by healthcare professionals and end-users
for over 50 years, Lumex features a full line of
patient aids and specialty healthcare seating.
Lumex products are designed and built to precise
standards and are carefully inspected prior to shipment.
We are dedicated to providing products that will give
our customers years of dependable service.
This Lumex product is warranted to be free of defects in
materials and workmanship for the lifetime of the original
consumer purchaser.
This warranty does not cover product failures due to
normal wear and tear or device misuse. The warranty
does not extend to non-durable components, such as
rubber accessories, which are subject to normal wear
and require periodic replacement.
Should a product defect that is covered by this warranty
arise, we will, at our option, repair or replace the product.
For additional information on this Lumex product or
this warranty, please contact an authorized Graham-Field
Health Products Dealer.
RJ4300A-HangTag2:Hang Tag 9/6/2006 12:51 PM Page 1
All manuals and user guides at all-guides.com
all-guides.com

Detachable
Wire Basket
Handgrip
Locking
Hand Brake
Rest Seat
Adjustment
Bolt & nob
Rear Leg
Locking
Mechanism
INSTRUCTIONS FOR USE –
PLEASE READ ALL INSTRUCTIONS BEFORE USE.
Please consult a healthcare professional for the proper adjustment.
HEIGHT ADJUSTMENT
1. Remove Rollator from case.
2. Cut plastic ties to remove basket.
3. Unfold frame; spread front and back legs apart.
4. Push down locking mechanism to secure legs in place.
5. Insert tube sections of left and right handle bars into their
respective vertical frame sections.
6. Adjust handle bars to user’s height. DO NOT extend the handle bars beyond
the knurled (crosshatched) portion of the handle bars. Ensuring that the
hole on the frame is aligned with the holes on the handle bar at the desired
arm height, insert the bolt so that the threads are pointing outside the rolla-
tor frame. Tighten the knob-nut onto the bolt. Repeat for the opposite side
of the frame.
OPERATION
HAND BRAKE: Squeeze hand brakes to stop; release hand brakes to walk.
Ensure that both hand brakes are squeezed at the same time to ensure proper
braking. If only one hand brake is squeezed, only one wheel will brake.
TO LOCK: Push hand brakes down to lock. Ensure that both left and right hand
brakes are locked. Always lock hand brakes when user is immobile; never sit on
rest seat if hand brakes are not locked.
TO UNLOCK: Lift hand brakes up to unlock.
FOLDING ROLLATOR: Remove any attached accessories, such as the
wire shopping basket. Flip up locking mechanisms. Press legs together.
ATTACH ACCESSORIES
SHOPPING BASKET:
Attach wire shopping basket hooks beneath walker rest seat.
MAINTENANCE
•For dust and dirt, wipe Rollator gently with damp, soft cloth.
• Use a mild soap and water solution to clean, rinse with clear water,
then dry with a soft cloth.
• Never use organic solvents, abrasive cleaners or scouring pads on
any part of Rollator.
• Check fit and tightness of all nuts, bolts and knobs weekly to ensure
that Rollator is safe to use.
• To guarantee the best service from your Rollator, always specify
Lumex replacement parts, available from your Lumex dealer.
SAFETY GUIDELINES –
PLEASE READ BEFORE USE
1. This product should not be used without proper
instruction from a healthcare professional.
2. This product has a maximum user weight limitation of 300 lbs.
3. Graham-Field Health Products assumes no responsibility
for any damage or injury caused by improper installation,
assembly or use of this product.
4. If components are damaged or missing, contact your
dealer immediately. DO NOT use substitute parts.
5. Before use, ensure that all assembled parts are secure
and all hardware is tightened.
6. Always use caution when using this product on wet
or slippery surfaces. Do not use Rollator on stairs or
steep inclines.
7. Inspect Rollator weekly for proper function and wear.
If any component is not in proper working order or
appears worn, contact your Lumex dealer for repair
and/or appropriate replacement parts.
8. Assemble Rollator as instructed to ensure safe use.
9. If the hand brakes fail to stop the Rollator, contact
your Graham-Field Health Products dealer immediately
for adjustment.
