Lumex LUMEX 700175C-2 User manual

INSTRUCTIONS
& WARRANTY
INFORMATION
UpRise nyx Folding Walker
700175C-2
IMPORTANT: READ BEFORE USE
All illustrations and specifications in this manual are based on the latest product information available
at the time of publication. Graham-Field reserves the right to make changes at anytime, without notice.
© 2006, Graham-Field Health Products, 2935 Northeast Parkway, Atlanta, Georgia 30360.
Printed in China. GF0700085RevA07
LIFETIME LIMITED WARRANTY
Quality is the hallmark of all Lumex®products.
Trusted by healthcare professionals and end-users
for over 50 years, Lumex features a full line of
patient aids and specialty healthcare seating.
Lumex products are designed and built to precise
standards and are carefully inspected prior to shipment.
We are dedicated to providing products that will give
our customers years of dependable service.
This Lumex product is warranted to be free of defects
in materials and workmanship for the lifetime of the product.
This warranty does not cover product failures due to
normal wear and tear or device misuse. The warranty
does not extend to non-durable components, such as
rubber accessories, which are subject to normal wear
and require periodic replacement.
Should a product defect that is covered by this warranty
arise, we will, at our option, repair or replace the product.
For additional information on this Lumex product or this warranty,
please contact an authorized Graham-Field Health Products Dealer.
700175C-2 - HangTag (v7):Hang Tag 5/14/2007 11:07 AM Page 1

INSTRUCTIONS FOR USE –
PLEASE READ ALL INSTRUCTIONS BEFORE USE.
The Lumex 700175C-2 is designed as a dual purpose mobility aid. It is recommended
for use by users with heights ranging from 5’4 to 6’2. Please consult a healthcare
professional for the proper adjustment.
SINGLE RELEASE FOLDING WALKER
SIZE SELECTION CHART
HEIGHT ADJUSTMENT
NOTE: For ea e of hipping, the walker i hipped in it lowe t height po ition.
The walker hould be adju ted to the de ired height before operation.
Refer To Illu tration Below:
The legs of each walker are equipped with an adjustment button and
an adjustable leg attachment with several adjustment positions.
1. Adjust the height of the walker by aligning all four leg attachments
to the same position height.
2. To adjust the height of a leg attachment, depress the adjustment
button and twist the leg attachment to the desired height.
TO OPEN UNIT
1. Grasp one handgrip and pull away from center of walker.
2. Repeat with other handgrip.
3. Push handgrips away from each other until the release
mechanisms click into place.
4. Walker is safely opened when push button in release mechanism is up.
TO CLOSE UNIT
1. Push downward on release mechanism and hold. NOTE: Side of walker
will collap e inward when relea e mechani m i depre ed.
2. Grab one handgrip and push toward center of walker.
3. Repeat for other handgrip.
MAINTENANCE
• Wipe walker weekly with a damp cloth.
• Grips may be cleaned with mild soap or detergent.
D N T use organic solvents, such as acetone, which may damage grip.
• Never use abrasive cleaners or scouring pads on any part of the walker.
• Check all hardware weekly to ensure that it is securely attached.
• Replace walker tips as needed.
• To guarantee the best service from your walker, always specify
Lumex replacement parts, available from your Lumex dealer.
Reducer Cap
H-Frame
Handgrip
Release
Mechanism
Walker Tip
Adjustable Leg
Extension
Leg Attachment
Adjustment Button
(on inside of each
leg attachment)
Leg extensions are available for users over 6' 2".
Please consult your Lumex dealer.
SAFETY GUIDELINES –
PLEASE READ BEFORE USE
1. This product should not be used without proper instruction
from a healthcare professional.
2. This product has a maximum user weight limitation of 400 lb.
3. Before using, be sure that walker is locked in the open position.
4. Graham Field assumes no responsibility for any damage or injury
caused by improper installation, assembly or use of this product.
5. If components are damaged or missing, contact your
dealer immediately. D N T use substitute parts.
6. Inspect walker weekly for proper function and wear. If any
component is not in proper working order or appears worn,
contact your dealer for repair and/or appropriate
replacement parts.
7. Before use, ensure that push button protrudes fully through
height adjustment hole and the release mechanism is locked
in the “open” position.
8. Always use caution when using this product on wet or
slippery surfaces.
Mod l
Numb r
Us r
H ight
Adjustm nt Rang /
Handgrip To Floor
700175C-2 5'4" - 6'2" 32" - 39"
Secondary
Handgrip
