Lumex LF1600 Installation and operating instructions

LF1600-INS-LAB-RevE15
© 2007 GF Health Products, Inc.
LF1600 Stand Assist user and attendant: Read this manual before
operating the Stand Assist. Save this manual for future reference.
LF1600 Stand Assist
Assembly and Operation Manual

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 2
CONTENTS
1 INTRODUCTION.........................................................................................................3
INTENDED USE ....................................................................................................3
2 SAFETY PRECAUTIONS........................................................................................... 4
SIGNIFICANCE OF SAFETY STATEMENTS ....................................................... 4
WARNINGS ...........................................................................................................4
3 HANDLING PROCEDURES....................................................................................... 5
SHIPPING AND TRANSPORTATION INSTRUCTIONS....................................... 5
4 FEATURES ................................................................................................................. 6
COMPONENTS.....................................................................................................6
FASTENERS AND TOOLS ...................................................................................6
5 ASSEMBLY INSTRUCTIONS.....................................................................................7
6 OPERATION ............................................................................................................. 10
7 MAINTENANCE........................................................................................................12
CLEANING THE STAND ASSIST....................................................................... 12
8 LIMITED WARRANTY..............................................................................................13
9 INDEX .......................................................................................................................15
WARNING: LF1600 Stand Assist attendant: Do not operate the LF1600
Stand Assist without rst reading and understanding this manual. If you
do not understand the warnings, cautions, and instructions provided
herein, contact your professional medical advisors, GF authorized
distributor, or technical representative before proceeding with the use of
this product; otherwise personal injury or damage to your Stand Assist
could result.
GF Health Products, Inc. is not responsible for typographical errors. For the
most updated and current information on packaging, warranties, products and
specications, including the most current version of these instructions, please
visit our website at www.grahameld.com. Graham-Field and Lumex are registered
trademarks of GF Health Products, Inc.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 3
1 INTRODUCTION
Important safety, operating, and maintenance instructions that warrant your
attention are included in this manual. Read the entire manual carefully before
operating your new LF1600 Stand Assist, keep it handy for future reference, and refer
to it as often as necessary to help maintain good performance standards.
The Lumex Stand Assist is a manual standing aid that requires patients to assist
themselves in preparation for transport. Patients qualied to use the Stand Assist
must have adequate arm strength to pull themselves upward and enough leg
strength to support their own weight. Patients who meet these criteria and have
difculty walking will nd the Stand Assist a useful transport device. Functionally,
the Stand Assist is positioned between a traditional walker and a battery powered
sit-to-stand lift. The Stand Assist is a convenient toileting alternative to a wheelchair.
Once the resident has positioned themself on board, the split seat can be positioned
to allow the resident to sit comfortably while a caregiver performs the transport.
For residents lacking the strength to assist themselves, we recommend a battery
powered sit-to-stand lift.
The Stand Assist is capable of the following transfers when used according to the
instructions:
• Bedtochair/wheelchair
• Bed/chair/wheelchairtocommode
• Roomtoroom
The safety precautions in this manual are general warnings intended to be used only
as basic guidelines. You may nd it necessary to develop your own methods for
safely solving frequently encountered challenges. Again, consult your professional
medical advisors for their recommendations about safety methods, and never
hesitate to ask for their assistance.
All information and specications in this manual are current at the time of printing.
INTENDED USE
The Lumex Stand Assist’s intended use is as a transport assistance unit.
Contraindication
The Lumex Stand Assist is intended for use by residents who have the strength
and stability to lift and support themselves. We recommend a battery powered
sit-to-stand lift for residents with limited strength and stability.
WARNING: Personal injury - this device is designed for transport
assistance of individuals between approximately 5'1" and 6'6"
(155 cm and 198 cm) in height. Ensure the LF1600 properly ts the
individual being transferred before use.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 4
2 SAFETY PRECAUTIONS
WARNING: Always follow these safety precautions when using your
LF1600 Stand Assist. Failure to do so could result in personal injury to you
or others or damage to the Stand Assist.
Safety requires the constant attention of the Stand Assist user and attendant. It is
extremely important to learn and always use safe methods of performing basic daily
activities. Always consult your professional medical advisors to determine those
methods most suitable for your individual abilities.
SIGNIFICANCE OF SAFETY STATEMENTS
Please note the following special statements, used throughout this manual, and their
signicance:
WARNING: Indicates a potential hazard situation or unsafe practice that,
if not avoided, could result in death or serious personal injury.
CAUTION: Indicates a potential hazard situation or unsafe practice that, if
not avoided, could result in minor or moderate personal injury.
sNOTICE: Indicates a potential hazard situation or unsafe practice that, if
not avoided, could result in product or property damage.
Info: Provides application recommendations or other useful information to
ensure that you get the most from your product.
WARNINGS
WARNING: Only qualied caregivers trained in the proper use of the
Stand Assist should use it to transport patients.
WARNING: Do not use the Stand Assist to transport patients who are
unable to pull themselves upright and support their own weight.
WARNING: The LF1600 Stand Assist maximum weight capacity is 400 lb
(180 kg), EVENLY DISTRIBUTED. Never use the Stand Assist to transport a
patient whose weight exceeds 400 lb (180 kg).
WARNING: Before using the Stand Assist for patient transport, check
the Stand Assist to ensure all components are properly and securely
assembled and in working order.
WARNING: Do not leave a patient unattended during any part of the transport.
WARNING: If components are damaged or missing, contact your GF
authorized distributor immediately. DO NOT use substitute parts. Use only
Lumex replacement parts. The use of non-Lumex replacement parts could
cause personal injury, property damage, and void the warranty.
WARNING: California Proposition 65 WARNING: This product contains
a chemical known to the State of California to cause cancer and
reproductive or developmental harm.
WARNING: GF Health Products, Inc. specically disclaims responsibility
for any bodily injury or property damage which may occur during any use
which does not comply with federal, state or local laws or ordinances.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 5
3 HANDLING PROCEDURES
SHIPPING AND TRANSPORTATION INSTRUCTIONS
If the Stand Assist is to be reshipped by common carrier, it should be packed in the
same carton in which it was received.
Unpacking
WARNING: The lift is heavy. To avoid personal injury, DO NOT attempt to
remove the lift from the box without assistance.
1. Check for any obvious damage to the carton or its contents. If damage is evident,
notify the carrier or your GF authorized distributor.
2. Remove all loose packing from the carton.
3. Carefully remove all the components from the carton.
Info: Unless the Stand Assist is to be used immediately, retain boxes, containers
and packing material for use in storing until use of Stand Assist is required.
Inspection
1. Examine the exterior of the Stand Assist for nicks, dents, scratches or other
damage.
2. Inspect all components.
Storage
1. Store the repackaged Stand Assist in a dry area.
2. DO NOT place other objects on top of the repackaged Stand Assist.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 6
4 FEATURES
COMPONENTS
Item Description Quantity
Base preassembled with footplate and casters 1
Side support arm unit 2
Kneepad assembly 1
Seat pad and handle bar support unit with cross
bar tube
2
FASTENERS AND TOOLS
No. Item Description Quantity
A1 Carriage bolt 8
A2 Hex bolt 2
A3 Button socket head cap screw 4
A4 Flat washer 10
A5 Lock washer 10
A6 Acorn nut 8
A7 Plastic cap 2
T1 Wrench 1
T2 Hex key 1

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 7
5 ASSEMBLY INSTRUCTIONS
Tools required: provided wrench, provided hex key
back casters
base assembly
1. Place the base assembly on the oor and lock the back casters for ease of
assembly, as shown above.
flat washer
lock washer hex bolt
plastic
cap
kneepad kneepad
support unit
kneepad
assembly
2. Insert the kneepads into the kneepad support unit. Install the two hex bolts
through lock washers, at washers, and kneepad support unit into nuts as shown
above. Tighten securely with the provided wrench. Install the two plastic caps on
the hex bolts. The nished assembly is shown at right above.
carriage bolt
kneepad assembly
kneepad side
support assembly
side support arm
flat washer
lock washer
acorn nut
kneepad
assembly
side support arm
3. Attach the kneepad assembly to the two side support arms. Face the square holes
on the side support arms inward; t the square shoulder of each carriage bolt
in the square hole, installing each carriage bolt through the kneepad assembly
bracket and side support arm from the inside as shown above. Install the at
washer, lock washer, and acorn nut on the end of each carriage bolt as shown
above. Do not tighten the nuts; some play in this assembly will be needed to
assemble the entire unit. The nished assembly is shown at right above.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 8
buttonsockethead
capscrew
tubular
crossbar
seatpadandhandle
barsupportunit
seatand
crossbarassembly
4. Insert the two tubular cross bars into the holes on the seat pad and handle bar
support units as shown above. Align the small holes on the cross bar undersides
with the holes in the support units. Install the four button socket head cap screws
through the support units into the cross bars. Use the hex key to tighten. The
nished assembly is shown at right above.
basebracket
kneepadside
supportassembly
kneepads
lockablecasters
5. Insert the kneepad side support assembly into the base brackets as shown above.
The kneepads and arm curvature should be facing away from the lockable casters.
kneepad side
support assembly
seat and cross
bar assembly
6. Insert the seat and cross bar assembly into the tubes at the top of the kneepad
side support assembly as shown above.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 9
carriage bolt
base assembly
kneepad side
support assembly
seat and cross bar
assembly
flat washer
lock washer
acorn nut
a
a
b
c
c
b
7. Fasten the seat and cross bar assembly, kneepad side support assembly, and base
assembly together with carriage bolts:
a. Attach the kneepad side support assembly to the base assembly. Fit the square
shoulder of each carriage bolt in the square hole at inside of base bracket,
installing each carriage bolt through the base and kneepad side support
assembly as shown above. Install the at washer, lock washer, and acorn
nut on the end of each carriage bolt as shown above. Tighten the two nuts
securely using the provided wrench.
b. Attach the seat and cross bar assembly to the kneepad side support assembly.
Fit the square shoulder of each carriage bolt in the square hole at inside of
kneepad side support assembly, installing each carriage bolt through the
kneepad side support assembly and seat and cross bar assembly as shown
above. Install the at washer, lock washer, and acorn nut on the end of
each carriage bolt as shown above. Tighten the two nuts securely using the
provided wrench.
c. Securely tighten the four nuts that attach the kneepad assembly to the two
side support arms, installed in step 3, using the provided wrench.
WARNING: Before operating the Stand Assist, ensure that all components
are properly and securely assembled and that all fasteners are secure.
WARNING: Before operating the Stand Assist, read the operation
instructions.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 10
6 OPERATION
Info: Patients who desire additional security may wish to use the optional
DSLSA9 Sit-to-Stand Buttock Strap, available through your GF authorized
distributor.
The split seat units can be rotated upward to allow for patient loading then, once the
patient is in an upward standing position, lowered to form a complete two-sided seat.
WARNING: Ensure that both seat units are fully lowered and form a
complete seat before having the patient sit down on the Stand Assist.
WARNING: Do not leave a patient unattended during any part of the
transport.
1. Raise the two split seat units so
that they are parallel to the side
of the Stand Assist, as shown at
right.
2. Have the patient positioned at the edge of the surface
to be transferred from. Move the Stand Assist in front
of the patient. Position the patient so that her feet are
rmly on the platform and her knees and shins are in
contact with the two cupped kneepads, as shown at
right.
3. Lock the casters by stepping on the caster clip and
pushing down, as shown at right.
4. Have the patient grasp the cross bar closest to her and,
using her own strength, pull herself up into a standing
position securely on the base platform, as shown at
right.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 11
5. Lower both of the split seat units down into position to
form a complete seat, as shown at right.
WARNING: Ensure that both seat units are lowered
and form a complete seat before having the patient
sit down on the Stand Assist.
6. Have the patient lower herself down onto the seat while
keeping her knees and shins in the kneepads, and while
continuing to hold the cross bar with both hands, as
shown at right.
7. Unlock the casters. Place both hands on the cross bar
furthest from the patient, as shown at right, and move
the Stand Assist to the new surface. Ensure that the
patient is secure and in proper position as described in
Step 6 before and during transfer, as shown at right.
8. Position the Stand Assist against the new surface,
ensuring that the patient will be in a position to sit down
rmly and safely on the transfer surface.
9. Lock the casters.
10. Have the patient pull herself back up to a full standing
position.
11. Raise the two split seat units so that they are parallel to
the side of the Stand Assist, as shown at right, to allow
the patient to lower herself.
12. Stand beside the patient as she lowers herself down
onto the new surface.
13. Ensure that the patient is safely positioned. Unlock the
casters and move the Stand Assist to storage.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 12
7 MAINTENANCE
To ensure safety and proper use, perform the following steps monthly:
• Checkallfastenerstoensurethattheyaresecurelyfastenedandnowearandtear
is evident. Replace and tighten any worn fasteners before using the Stand Assist.
• Checkthetwoseatassembliestomakesuretheyarenotwornordamaged,and
that the bolts are tight. Replace any worn or damaged seat components before
using the Stand Assist.
• Checkthecasterstomakesuretheyareinworkingorderandaresecuredrmly
to the Stand Assist. Replace any worn or damaged casters before using the
Stand Assist.
If any maintenance procedure is not clear to you, ask your GF authorized distributor
for assistance.
sNOTICE: Improper maintenance can cause operating problems and may
affect your warranty.
WARNING: Unauthorized modication or the use of non-Lumex
replacement parts could change the structure of the Stand Assist, void
the warranty, and create a hazardous condition resulting in serious
personal injury.
CLEANING THE STAND ASSIST
• Wipeofftheframeatleastonceaweekwithasoftcloth.DrytheStandAssist
immediately if exposed to moisture.
• Cleantheframeeverythreemonthswithamildsoapandwatersolution.The
frame does not need to be waxed.
• Cleanupholsteryandplasticcomponentsatleastonceamonthwithamildsoap
and water solution.
sNOTICE: Do not use solvents, abrasive waxes, caustic chemicals or spray
silicone to clean the Stand Assist.
sNOTICE: Do not use abrasive cleansers to clean the Stand Assist; they
could scratch the nish.
sNOTICE: Do not use steam or high pressure cleaners to clean the
Stand Assist.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 13
8 LIMITED WARRANTY
SCOPE OF WARRANTY
GF Health Products, Inc. (“GF”) warrants to the original purchaser only that it will
replace or repair components, at GF’s sole discretion, that are defective in material or
workmanship under normal use and service. All warranties are conditioned upon the
proper use of the products strictly in accordance with good commercial practice and
applicable GF instructions and manuals, including proper use and maintenance. To
the extent that a component is warranted by a third party, GF conveys all of its rights
under that warranty to the original purchaser, to the extent permitted. This limited
warranty shall only apply to defects that are reported to GF’s customer service team
within the applicable warranty period and which, upon examination by GF or its
authorized representative, prove to be a warranty item. This limited warranty is not
transferable.
The warranted components and time period are set forth below:
Frame: three years
Parts, including casters: one year
The applicable warranty period shall commence from date of shipment to the original
customer, unless there is an expiration date on the component in which case the
warranty shall expire on the earlier of warranty period or the expiration date.
OBTAINING WARRANTY SERVICE
This limited warranty shall only apply to defects that are reported to the Distributor
from whom the Customer purchased the product within the applicable warranty
period. If there is not a Distributor, you must contact GF directly by calling
770-368-4700, sending a fax request to 770-368-2386, or by e-mailing a request to
cs@grahameld.com. Specic directions will be provided by the Customer Service
Representative. Failure to abide by the specic directions will result in denial of the
warranty claim.
The warranty does not cover and GF shall not be liable for the following:
1) Defects, damage, or other conditions caused, in whole or in part, by misuse,
abuse, negligence, alteration, accident, freight damage, tampering or failure to
seek and obtain repair or replacement in a timely manner;
2) Products which are not installed, used, or properly cleaned and maintained as
required in the ofcial manual for the applicable product;
3) Products considered to be of a non-durable nature including, but not limited to:
lters, fuses, gaskets, lubricants, and charts;
4) Accessories or parts not provided by GF;
5) Charges by anyone for adjustments, repairs, replacement parts, installation or
other work performed upon or in connection with such products which are not
expressly authorized in writing, in advance, by GF;

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 14
6) Any labor or shipping charges incurred in the replacement part installation or
repair;
7) Costs and expenses of regular maintenance and cleaning; and
8) Representations and warranties made by any person or entity other than GF.
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL
DAMAGES DISCLAIMER
THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. GF MAKES NO IMPLIED WARRANTIES OF ANY
KINDINCLUDINGANYIMPLIEDWARRANTIESOFMERCHANTABILITYORFITNESS
FOR A PARTICULAR PURPOSE. IF ANY MODEL OR SAMPLE WAS SHOWN TO THE
CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY TO ILLUSTRATE THE
GENERAL TYPE AND QUALITY OF THE PRODUCT AND NOT TO REPRESENT THAT
THE PRODUCT WOULD NECESSARILY CONFORM TO THE MODEL OR SAMPLE IN
ALL RESPECTS. THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF
THEDEFECTIVEPARTS.GFSHALLNOTBELIABLEFORANDHEREBYDISCLAIMS
ANY DIRECT, SPECIAL, INDIRECT, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL
DAMAGES,INCLUDING,BUTNOTLIMITEDTO:DAMAGESFORLOSSOFPROFITS
OR INCOME, LOSS OF USE, DOWNTIME, COVER, OR EMPLOYEE OR INDEPENDENT
CONTRACTORWAGES,PAYMENTSANDBENEFITS.
The warranties contained herein contain all the representations and warranties with
respect to the subject matter of this document, and supersede all prior negotiations,
agreements and understandings with respect thereto. The recipient of this document
hereby acknowledges and represents that it has not relied on any representation,
assertion, guarantee, warranty, collateral contract or other assurance, except those
set out in this document.
For additional information on this product or this warranty, please contact a GF
Customer Service Representative.
NOTES:
1) Additional terms and conditions may apply.
2) Freight claims must be notated on the appropriate shipping documents and must
be made with immediacy. International, federal and state regulations govern
specic requirements for freight claims. Failure to abide by those regulations may
result in a denial of the freight claim. GF will assist you in ling the freight claim.
3) Claims for any short shipment must be made within thirty (30) days of the invoice
date.

LF1600-INS-LAB-RevE15 • LF1600 Stand Assist 15
9 INDEX
A
Assembly instructions 7
C
CAUTION statement, signicance 4
Cleaning the Stand Assist 12
Components, identication 6
F
Fasteners and tools, identication 6
Features 6
H
Handling Procedures 5
I
Info statement, signicance 4
Inspection 5
Intended use 3
Introduction 3
M
Maintenance 12
N
NOTICE statement, signicance 4
O
Operation 10
S
Safety precautions 4
Safety statements, signicance of 4
Shipping and transportation instructions 5
Signicance of safety statements 4
Sit-to-Stand Buttock Strap, optional 10
Storage 5
T
Tools required for assembly, list 7
Transport, perform 10
U
Unpacking 5
W
Warnings 4
WARNING statement, signicance 4
Warranty 13
Weight capacity 4
Weight capacity, maximum 4

Made in Taiwan
