2. BABY UNIT SETUP
2 .1 Setting up
1. Plug the remaining power cable into the socket on the back of the Baby unit.
2. Plug the other end of the cable into your mains wall socket and switch it on. ( g. 4)
2.2 Switching on and linking the Parent and Baby units
Before switching on, make sure the Parent and Baby unit are at least one metre from
each other. Any closer and you might get audio feedback sounds.
1. Press and hold the button on the Baby unit until the orange Link indicator
ashes.
2. Press and hold the button on the Parent unit until all the LEDs on the unit
brie y light up. The orange Link indicator will ash and then will remain steady
when the units have linked.
3. When the units are linked, the orange Link indicator lights on the Parent and Baby
units will stop ashing. When the lights stay steady, your monitor is ready to use.
2.3 Deciding where to put your units
The Baby unit should ideally be within 1 to 2 metres of your baby. Make sure both the
Baby unit and mains power cable are connected securely and they’re out of baby’s
reach. If the Parent and Baby units are too close together, you’ll hear a high-pitched
noise. That’s because the units are designed to be put at a distance from one another,
such as in separate rooms.
Important: The two units will need to be linked before you can start using them. If the link
between the units is broken, the Link indicator lights will ash while they try to look for each
other. After 30 seconds, if the link is still broken, the Link indicator lights will ash red. If the
link is broken, check that:
• the mains power is plugged in and switched on at the Baby unit
• both units are switched on
• the batteries are charged in the Parent unit
• the Parent and Baby units are within range of each other (in ideal conditions, that’s up
to 330 metres outdoors and 50 metres indoors).
3. USINGYOUR LUVION ICON CLEAR 70 AUDIO BABY MONITOR
3.1 Switching the Baby unit on
1. 1. Press and hold the button, the orange Link light ashes. When it’s nished
linking, it’ll stop ashing and remain steady.
2. To switch off , press and hold the button again.
3.2 Switching the Parent unit on
1. Press and hold the button on your Parent unit. The LED lights will ash. The
orange Link light will also icker on and off while the units are linking. When the
units have found each other, your Parent unit will go back to its idle screen.
2. To switch off , press and hold the button again. All the lights will switch off .
3.3 Changing the loudspeaker volume on your Parent unit
You can change the volume using the and buttons. If you’ve muted the sound,
the mute light will come on.
Note: The unit has ve volume levels plus O (Mute). If you try to set the volume higher or
