LuxCraft 4x6 Rectangle Double Pedestal Table User manual

Parts List
1 - (A) Top
2 - (B) Pedestal Column
1 - (C) Pedestal Foot Long
2 - (D) Pedestal Feet
2 - (E) Pedestal Block
12 - (F) Brace
2 - (G) Top Long Crosspiece
2 - (H) Top Short Crosspiece
1 - (I) Stabilizer Block
Hardware
36 - 2 1/2" Screws
24 - 2" Screws
152 - 1 1/2" Screws
2 - 5/16" x 2-1/4" T Bolt
A
B
C
D
E
F
G
H
Oval or
Rectangle
1. Attach (C) & (D) Pedestal Feet to
(B) Pedestal Column using 8 - 2 1/2"
Screws per Pedestal Column in
predrilled holes.
2. Align (D) Block in center of
Pedestal Feet, Attach using 4
1 1/2" Screws per Block in
predrilled holes.
3. Attach 6 (F) Braces using 12-
1 1/2" Screws per Brace in
predrilled holes.
4. Attach remaining (F) Braces to Column using 6 - 1 1/2" Screws per
Brace in predrilled holes, Be sure to center brace on Column & keep
top side flush.
I
Page 1 of 2
4 x 6 Oval and Rectangle Double Pedestal Table
Assembly Instructions
12/11/ 2017
R.M.
Inch
0
1
2
3
4
5
6
7
Tools Required
#2 Square Drive Bit
(Not Included)

8. Align (I) Stabilizer
Block with Hole in
(A) Top, Attach
Stabilizer Block using
4 - 2-1/2" Screws.
Insert T Bolts.
5. Align (G) Top Long Crosspiece with Pedestal
Column & Braces, Install 8 - 2 1/2" Screws in each
Pedestal Column & 6 - 1 1/2" Screws in each
Top Long Crosspiece.
6. Attach (H) Top Short Crosspieces centered with Braces &
against Top Long Crosspiece. Install 6 - 1 1/2" Screws per
Top Short Crosspiece. ** Aluminum must be on top side**
**Aluminum must be on top side **
7. Lay (A) Top on a soft blanket to
prevent scratches, Position Base so all
Numbers & or Letters match. Attach Top
using 24 - 2" Screws in predrilled holes.
Page 2 of 2
4 x 6 Oval and Rectangle Double Pedestal Table
Assembly Instructions
12/11/ 2017
R.M.
