1. Attach (G) Front-Back Crosspieces to
(C) Glider Base's Using 14 - 2" Screws
per side, be sure to match all numbers &
or letters.
5' Adirondack Poly Glider Assembly Instructions
Hardware
2 - 5/16" x 3 1/2" Stainless Wafer Bolts
2 - 5/16" x 2 1/2" Stainless Wafer Bolts
8 - 5/16" x 2" Stainless Wafer Bolts
4 - Nuts
4 - Washers
56 - 1 1/2" Screws
8 - 2 1/2" Screws
44 - 2" Screws
1 - 5/32 Hex key
1 - (A) Seat Assembly
1 - (B) Back Assembly
2 - (C) Glider Base
2 - (D) Bearing Arm Supports
14 - (E) Back Slats
2 - (F) Armrest's
2 - (G) Front-Back Crosspieces
2 - (H) Crosspiece Supports
2 - (I) Lintels
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(I)
2.Attach (H) Crosspiece Supports to Front-
Back Crosspieces using 4 - 2" Screws per
side, be sure to match all numbers & or
letters.
3. Attach (D) Bearing Arm Supports to Glider
Base using 4 - 2 1/2" Screws per side, be
sure to match all numbers
& or letters.
4. Attach (F) Armrests to Glider Base using (2-Washers)&(2-Nuts) per side, be sure to
match all numbers & or letters. "Assembly order is Armrest Assembly-Washer-Nut"
Washer
Armrest Assembly
Nut
Inch
0
1
2
3
4
5
6
7

5. Attach (E) Back Slats to (B) Back Assembly
using 4 - 1 1/2" Screws per slat, be sure to match all
numbers & or letters.
6. Attach Back Assembly to (A) Seat Assembly using 6 - 2"
Wafer Bolts, be sure to Match all numbers & or letters, tighten Wafer
Bolts with included Hex Key.
7. Attach Back-Seat Assembly to Armrests using
1 - 3 1/2" Wafer Bolt
1 - 2 1/2" Wafer Bolt &
1 - 2" Wafer Bolt
per side,be sure to match all
numbers & or letters, tighten
Wafer Bolts with included Hex Key.
2" Wafer Bolt
3 1/2" Wafer Bolt
2 1/2" Wafer Bolt
8. Attach (I) Lintels to Armrest Assemblies
using 4 - 2" Screws per side, be sure
to match all numbers & or letters.
2" Wafer Bolt
