MA grandMA2 Installation guide
english | deutsch
Quick MAnual
grandMA2
onPC Solutions
Die in diesem Booklet enthaltenen Angaben waren zum Zeitpunkt der Drucklegung korrekt. Durch die fortlaufenden Bemühungen unseres Unternehmens,
unsere Produkte ständig zu optimieren, kann es vorkommen, dass Angaben überholt sind, wenn Sie dieses Booklet lesen.
Vervielfältigung oder Veröentlichung dieses Booklets, auch teilweise, sind in jeglicher Form nur mit schriftlicher Genehmigung durch MA Lighting Technology
GmbH erlaubt.
Änderungen sind ohne vorherige Ankündigungen möglich.
Wie übernehmen keine Haftung bei Fehlern oder Ungenauigkeiten in diesem Booklet.
The information contained in this booklet were correct at time of printing. By continuing our company’s eorts to optimize our products, it may happen that
information is outdated, at the time you read this booklet.
Without having any written permission from MA Lighting Technology GmbH it is not allowed to copy, reproduce or publish any part of this booklet, neither in
printed form nor by photos or electronic media.
All technical specications are subject to change without notication.
We do not assume liability for any incorrect information in this booklet.
Art.Nr. 1212M 00169
MA Lighting International GmbH
An der Talle 24 – 28
33102 Paderborn · Germany
Phone: +49 52 51 68 88 65 10
www.malighting.com
© MA Lighting International
2019_v10
Quick-Manual-gMA2-Umschlag-onPC-Solutions_15032019.indd 1-3 15.03.19 16:35
1
2
1
The grandMA2 onPC solutions consist of the grandMA2 onPC command wing and the grandMA2 fader wing that control all kinds of
lighting genres such as conventional, moving lights, LEDs, video, and media via DMX signal or within a network environment.
All grandMA2 components, despite different hardware solutions, use the same software.
All components are fully integrable into the network environment.
Use all grandMA2 components and accessories within closed rooms and in the permissible environmental conditions only. Installation
and connection of the devices are explicitly to be carried out by trained personnel in compliance with all safety regulations.
4
Intended Use
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Symbols and Warning Labels
Warning – Danger area
Caution– Risk of electric shock
Risk of Electric Shock
The device is to be serviced by qualified personnel only as live parts may be exposed when opening and/or removing coverings.
Touching live parts may cause electric shock.
5
Safety
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Dispose of as hazardous waste. Follow the applicable regulations.
For more information see Disposal.
Declaration of conformity
For more information see Conformity.
Operating voltage ON/OFF
6
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Warning:
The device has to be grounded.
Do not ignore the safety purpose of the grounding-type plug. A grounding-type plug has two blades and a third grounding
connection. The third connection is provided for your safety.
Read all the instructions in this Quick Manual thoroughly, especially the General Safety Instructions further down and Limitations.
Follow the instructions and keep this Quick Manual for future use.
Follow all cautions and warnings stated in this Quick Manual and indicated on the device.
Important:
All repair and service work has to be exclusively performed by qualified service technicians.
This device is state-of-the-art technology;
However, residual risks cannot be ruled out;
To avoid risks, follow the safety instructions;
This class A device can cause radio frequency interference in a domestic environment;
This device is intended for professional use only and is not suitable for residential use.
MA Lighting Technology GmbH does not bear the damage which may occur due to inobservance of the safety instructions.
7
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Avoid Risks Caused by Electric Current
Defective device or defective power cable can cause severe or fatal injury due to electrical shock.
Follow the safety instructions to avoid the risks caused by electric current.
Do not use a defective power cable;
Do not open screwed down covers from the housing;
Use the device only if it is in a technically impeccable condition;
Do not repair the device on your own;
Do not reverse engineer the device, and make any changes to its components, and accessories;
Do not expose the device to rain or moisture;
Do not submerge the device in water.
General Safety Instructions
To avoid injury or damage to the device:
Do not put your hands inside the device during operation;
Device and power cable must be kept away from children under the age of 8;
Children are not allowed to play with the device;
Disconnect the power supply from electric voltage during thunderstorms;
Disconnect the power supply from electric voltage if it is unattended for a longer period of time;
Disconnect the power supply before cleaning the device;
Do not use any liquid or spray cleanser. Use a dry cloth only;
Do not use device in the vicinity of water;
Do not expose it to a humid environment;
Do not pour any liquids over the device.
Do not block or cover any ventilation holes in the housing. These are essential for the airflow within the device and protect the
device from overheating;
8
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Do not insert any objects into the ventilation holes of the device as these could get in contact with live parts or could cause short
circuits, fire and/or an electric shock;
Do not place any objects on the power cable. Protect it from being walked on or pinched, particularly at the connector and where
the cables exit the device;
When using an extension cable, make sure the rated output of all devices connected in series does not exceed the maximum rated
output of the extension cable;
Do not support yourself on the device;
Do not place any heavy objects on top of the device;
Do not use excessive force on keys, buttons, faders, encoders, switch, connector;
If the power cable or the main power plug are defective, let a qualified technician replace it immediately;
Place the device on stable surfaces only. If it is placed on unstable surfaces, it may fall and break.
Only use power cables which are safety-marked;
Do not use any high-power walkie-talkies or cell phones near the device;
The device is provided with a safety plug. This plug can only be used with safety outlets.
As with all industrially manufactured goods, the use of substances that induce an allergic reaction such as aluminum cannot be
generally excluded. If you develop an allergic reaction (such as a skin rash, frequent sneezing, red eyes or respiratory difficulties),
consult a physician immediately to determine the cause.
If one of the following conditions occurs, disconnect the main power plug and call your local distributor or the technical support!
Power cable or main power plug is damaged or worn;
Ingress of liquids;
The device was exposed to rain or high ambient humidity;
The device does not function properly, even if you followed all the instructions of this Quick Manual. Only operate the controls as
stated in the Quick Manual. Incorrect control settings may damage the device;
The device fell damaging the housing.
9
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Contact us for any questions about your MA product.
MA Lighting and its extensive distributor network offer an unparalleled technical support. Call on our expertise for help with any
problem, no matter if it is about operation, software features, software installations or trouble shooting.
Online Manuals
All MA product related manuals are available as online versions. Just select your MA product and click on the according link. All further
documents can be found in our download area. Go to www.malighting.com.
Video Tutorials
Get tips and tricks from our MA experts on your MA product.
MA offers a whole range of videos on how to use your MA product in the best possible way. Just select your series and click on the
links to watch the videos on our YouTube channel. Go to www.malighting.com.
Community
Share your knowledge and get help from other MA users.
A community can be stronger and better than the individual. Be part of the MA community! Go to www.malighting.com.
Local Support
If you have a question regarding your MA Lighting product, please first of all contact your local MA product specialists.
Central Support
10
Support
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Central Support
If you are in need of further assistance or manufacturer support, please fill out an email request on www.malighting.com in Training
and Support. Your request will automatically be sent to support@malighting.com (in English or German). This email service is
monitored during MA Lighting's regular business hours in Germany from 8.30 am until 5 pm, Monday through Friday.
Emergency Hotline
In any case of a show critical emergency please contact the MA Lighting support hotline.
Phone +49 5251 68 88 65 99
Please note that this 24/7 hotline is strictly for emergency cases.
11
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Warning:
-Pay attention to temperature and humidity during transport. For more information see Limitations.
-After the transport check the device.
-If the device is damaged (dented, bent or broken), do not connect the grandMA2 onPC command wing or the grandMA2
fader wing to power!
Important:
Be careful when moving or lifting the grandMA2 onPC command wing or the grandMA2 fader wing, otherwise you may
injure your back or other parts of your body.
The grandMA2 onPC command wing and grandMA2 fader wing must be protected against environmental factors such as physical
shocks and vibration during transportation;
Remove all cables before transport;
The user is responsible for securely fastening the products for transport and for following the manufacturer´s safety instructions
when transporting the device;
Noncompliance of the safety instructions can result in personal injury or material damage;
Do not place the grandMA2 onPC command wing or the grandMA2 fader wing on unstable surfaces;
Do not place any objects on top of the grandMA2 onPC command wing or the grandMA2 fader wing.
12
Transport
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Temperature
Operation:
0 °C up to 40 °C / 32 °F up to 104 °F
Caution:
Higher temperatures can stress the cooling system of the device and destroy hardware components.
Storage / Transport:
-10 °C up to +50 °C / 14 °F up to 122 °F
Humidity
Operation:
20 % up to 90 % relative humidity (no condensation)
Storage / Transport:
10 % up to 90 % relative humidity (no condensation)
13
Limitations
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Environment
Follow all safety instructions;
Only use the device within its operating limits;
Only use the device indoors;
Air must be free of dust and any hazardous or explosive substances;
Avoid jolting;
This device is not protected against splash water. Do not use it near water;
Do not use the device in rain or moisture;
Do not place the device where it can come in contact with corrosive gases or saline air as this can cause maloperation.
14
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Connect and Power Up the Device
1. Unpack the device.
2. Remove the packaging and cushioning material.
3. Place the device indoors on a stable surface.
4. Download the grandMA2 onPC software on www.malighting.com
5. Install the software on your PC or laptop. For minimum requirements see System Requirements grandMA2 in the grandMA2
user manual.
6. Connect the grandMA2 onPC command wing or the grandMA2 onPC fader wing with your PC or laptop using a USB cable.
7. Start the grandMA2 console or grandMA2 onPC.
8. Switch on the grandMA2 onPC command wing or the grandMA2 onPC fader wing:
-Insert IEC connector into the corresponding jack.
-Connect the main power plug.
-Turn on the power switch:
-Set it to position I.
-The power switch lights up in red.
To turn off the grandMA2 onPC command wing set the power switch to position O.
Important:
Show data is only saved in the grandMA2 onPC software.
Important:
You can disconnect the grandMA2 onPC command wing using the grandMA2 onPC software. The DMX output will then
be immediately interrupted.
17
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Different Possibilities of Combination
Important:
Independent of the devices connected to the grandMA2 onPC command wing, the number of parameters can only reach
a maximum of 4,096.
grandMA2 onPC command wing Connected To Parameters
onPC command wing + PC/laptop 2,048
onPC command wing + PC/laptop + grandMA2 8Port Node 4,096
onPC command wing + PC/laptop + grandMA2 4Port Node 4,096
onPC command wing + PC/laptop + grandMA2 2Port Pro Node 3,072
onPC command wing +
PC/laptop + grandMA2 RPU
PC/laptop + grandMA NSP
PC/laptop + grandMA NPU
4,096
grandMA2 onPC fader wing Connected To Parameters
onPC fader wing + PC/laptop 2,048
onPC fader wing + PC/laptop + grandMA2 onPC command wing 3,072
18
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Hint:
The combination grandMA2 onPC fader wing and grandMA2 onPC command wing can be connected as follows:
-Connect the grandMA2 onPC fader wing to a grandMA onPC command wing and connect the grandMA2 onPC fader
wing to a PC or laptop;
-Connect the grandMA2 fader wing to a PC or laptop and connect a grandMA2 command wing to the same PC or laptop.
19
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
1
Hint:
The grandMA2 onPC command wing and the grandMA2 fader wing only require minor attention.
Warning:
All repair and service work has to be exclusively performed by qualified service technicians as live parts may be exposed
when opening and/or removing coverings. Touching live parts may cause electric shock.
Important:
The intervals between maintenance may differ depending on the frequency of transport and the operational environment.
Disconnect power supply before cleaning;
Clean the surface using dry cloth only;
Clean the wrist rest using a damp cloth only;
Do not use liquid cleanser or compressed air;
Do not use solvent when cleaning the housing;
Use a permanent marker for magnetic labels (Edding 140S ohp);
Remove the labeling from magnetic labels using ethanol;
Depending on the environment, we recommend to professionally clean the device once a year.
20
Maintenance
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Declaration of Conformity
English
Other manuals for grandMA2
3
Table of contents
Languages:
Other MA Lighting Equipment manuals
